Roger Technology BH30 Series Operating instructions

ISTRUZIONI E AVVERTENZE PER L’INSTALLATORE
INSTRUCTIONS AND RECOMMENDATIONS FOR THE INSTALLER
ANWEISUNGEN UND HINWEISE FÜR DEN INSTALLATEUR
INSTRUCTIONS ET AVERTISSEMENTS POUR L’INSTALLATEUR
INSTRUCCIONES Y ADVERTENCIAS PARA EL INSTALADOR
INSTRUÇÕES E AVISOS PARA O INSTALADOR
Serie BH30
Automazione per cancelli scorrevoli
Sliding gates automations
Automatisierung für Schiebetore
Automatisme pour portails coulissants
Automatismos para cancelas correderas
Automações para portões deslizantes
Istruzioni originali
IS118 Rev.08 09/04/2020

EN
01
1 General safety precautions
WARNING: IMPORTANT SAFETY INSTRUCTIONS
THESE INSTRUCTIONS MUST BE FOLLOWED TO GUARANTEE THE SAFETY OF THE PERSONS
PRESERVE THESE INSTRUCTIONS
This installation manual is intended for qualied personnel only.
Failure to observe the information included in this manual may result in personal injury or damage to the
equipment.
ROGER TECHNOLOGY cannot be held responsible for any damage or injury due to improper use or any use other
than the intended usage indicated in this manual.
The installation, electrical connections and adjustments must be performed by qualied personnel, in accordance
with best practices and in compliance with applicable regulations.
Read the instructions carefully before installing the product.
Incorrect installation may pose risks.
Before installing the product, make sure it is in perfect condition: In case of doubts, do not use the product and refer
exclusively to professionally qualied personnel.
Do not install the product in explosive environment and atmosphere: inammable gas or vapours constitute serious
danger for safety.
Before installing the motor, make all structural modications related to the safety precautions and to the protection or
segregation of areas involving crushing, shearing, dragging risks or any other risks.
WARNING: check that the existing structure fulls the required resistance and stability specications.
ROGER TECHNOLOGY is not liable for failure to observe the good practices in the construction of xtures to be moto-
rised or for deformations that may occur during use.
The safety devices (photocells, sensing edges, emergency stops, etc.) must be installed taking into consideration the
following: the regulations and directives in force, the good practices criteria, the installation environment, the opera-
ting logic of the system and the forces generated by the motorised door or gate.
The safety devices must protect any areas where there is crushing, shearing, dragging or any other danger in general
generated by the motorised door or gate; the installer is advised to check that the moving wings do not have sharp
edges or anything that may pose shearing and/or dragging risks.
If it is deemed necessary based on the risk analysis, install sensing edges on the mobile part.
It should be noted that, as provided by the UNI EN 12635 standard, all requirements of the EN 12604 and EN 12453
standards must be fullled and, if necessary, also checked.
The European standards EN 12453 and EN 12445 dene the minimum safety requirements for the operation of au-
tomatic doors and gates. In particular, these standards require the use of force limiting and safety devices (sensing
ground plates, photocell barriers, hold-to-run operation, etc.) intended to detect persons or objects in the operating
area and prevent collisions in all circumstances.
The installer is required to measure impact forces and select on the control unit the appropriate speed and torque
values to ensure that the door or gate remains within the limits dened by the standards EN 12453 and EN 12445.
ROGER TECHNOLOGY cannot be held responsible for any damage or injury caused by the installation of incompatible
components which compromise the safety and correct operation of the device.
If the hold-to-run function is active, the installer will have the obligation to check the maximum stop distance or the
alternative use of the rubber deformable edge, the closing speed or the gate and in general all aspects indicated by
the applicable regulations. Moreover, please not that if the command means is xed, it must be located in a position
guaranteeing the automation system control and operation and the command type and the use type must comply with
the UNI EN 12453 standard, prospectus 1 (with the following restrictions: type A or B command or type 1 or 2 use).
In case of hold-to-run operation, remove any potential persons away from the range of action of the automation sy-
stem’s moving parts; the direct commands must be installed at a minimum height of 1.5 m and must not be accessi-
ble to the public; moreover, unless the device is key operated, they must be located with a direct view to the motorised
part and far from the moving parts.
Apply the signs indicated by the regulations in force for the identication of the dangerous areas.
Each installed device must have a visible indication of the motorised door or gate identication data, in accordance
with the EN 13241-1:2001 standard or subsequent revisions
A switch or an omnipolar cut-off switch with a contact opening of at least 3 mm must be installed on the mains po-
wer line; put the cut-off switch in OFF position and disconnect any buffer batteries before performing any cleaning or
maintenance operations.
Ensure that an adequate residual current circuit breaker with a 0.03 A threshold and a suitable overcurrent cut-out
are installed upstream the electrical installation in accordance with best practices and in compliance with applicable
legislation.
When requested, connect the automation to an effective earthing system that complies with current safety standards.
The electronic parts must be handled using anti-static conductive wrist straps with grounding wire.
Only use original spare parts when repairing or replacing products.
The installer must provide the user with complete instruction for using the motorised door or gate in automatic, ma-
nual and emergency modes, and must hand the operating instructions to the user of the installation upon completion.
Keep away from hinges and moving parts.

02
EN
Keep out of the area of action of the motorised door or gate while it is moving.
Never try to stop the motorised door or gate while it is moving as this may be dangerous.
The motorised door or gate may be used by children aged 8 and above, by persons with diminished physical, sensory
or mental capacity and by persons without the necessary experience and knowledge provided that they are supervi-
sed or have received adequate instruction on using the device safely and to ensure that they understand the dangers
involved in its operation.
Children must be supervised at all times to ensure that they do not play with the device and that they keep out of the
area of action of the motorised door or gate.
Keep remote controls and any other control devices out of the reach of children to prevent the risk of the motorised
door or gate being operated unintentionally.
Failure to observe these instructions may lead to danger.
Any repair or technical interventions must be performed by qualied personnel.
The cleaning and maintenance operations must be performed exclusively by qualied personnel.
Check the system frequently and check if there are any mechanical imbalances and wear signs, any damage to the
cables, springs and support pieces.
In the event of a fault or malfunction of the product, turn the main power switch off and have the installation serviced
by qualied personnel and refrain from attempting to repair or perform any direct intervention yourself.
Lubricare e tener puliti i punti di snodo (cerniere) e di attrito (guide di scorrimento).
Pedestrian openings on the gate leaves to be automated are forbidden and if they already exist, ensure an ecient
locking system during movement.
Perform the gate leaves locking and unlocking operations with the engine stopped.
The packaging materials (plastic, polystyrene, etc.) should not be discarded in the environment or left within reach of
children, as they are a potential source of danger.
Dispose of and recycle the packaging items according to the provisions of the laws in force.
These instructions must be kept and must be made available to any other persons authorised to use the installation.

03
EN
2 Symbols
The symbols and their meaning in the manual or on the product label are indicated below.
Generic danger.
Important safety information. Indicates operations and situations in which the personnel involved must
pay close attention.
Dangerous voltage risk.
Indicates operations and situations in which the personnel involved must pay close attention to dangerous
voltages.
Hot surfaces risk.
Indicates danger due to hot surfaces or which anyway have high temperatures (risk of burns)
Useful information
Indicates useful information for the installation.
Refer to the Installation and use instructions.
Indicates the obligation to refer to the manual or original document, which must be available for future
use and must not be damaged in any way.
Protective earth connection point.
Indicates the admissible temperature range.
Alternating current (AC)
Direct current (DC)
Symbol for the product disposal according to the WEEE directive.
3 Product description
ROGER TECHNOLOGY cannot be held responsible for any damage or injury due to improper use or any use other than the intended usage
indicated in this manual.
We recommend using only ROGER TECHNOLOGY accessories and control and safety devices.
For further information, refer to the installation manual of the B70/1DC control unit.
Code Motor
type Description Power supply
230 V 115 V
BH30/603/HS Electromechanical HIGH SPEED BRUSHLESS motor, low voltage, super intensive use, with native
encoder onboard, irreversible ideal for sliding gates up to 600 kg with built-in digital controller B70
series, mechanical limit switch √
BH30/603/HS/115 Electromechanical HIGH SPEED BRUSHLESS motor, low voltage, super intensive use, with native
encoder onboard, irreversible ideal for sliding gates up to 600 kg with built-in digital controller B70
series, mechanical limit switch √
BH30/604/HS Electromechanical HIGH SPEED BRUSHLESS motor, low voltage, super intensive use, with native
encoder onboard, irreversible ideal for sliding gates up to 600 kg with built-in digital controller B70
series, magnetic limit switch √
BH30/604/HS/115 Electromechanical HIGH SPEED BRUSHLESS motor, low voltage, super intensive use, with native
encoder onboard, irreversible ideal for sliding gates up to 600 kg with built-in digital controller B70
series, magnetic limit switch √
BH30/803 Electromechanical BRUSHLESS motor, low voltage, super intensive use, with native encoder onboard,
irreversible ideal for sliding gates from 800 to 1000 kg. with built-in digital controller B70 series,
mechanical limit switch.
√
BH30/803/115 √
BH30/804 Electromechanical BRUSHLESS motor, low voltage, super intensive use, with native encoder onboard,
irreversible ideal for sliding gates from 800 to 1000 kg. with built-in digital controller B70 series,
magnetic limit switch.
√
BH30/804/115 √
BH30/804/R Electromechanical BRUSHLESS - REVERSIBLE - motor, low voltage, super intensive use, with native
encoder onboard, irreversible ideal for sliding gates up to 800 kg with built-in digital controller B70
series, magnetic limit switch.
√
BH30/804/R/115 √
KEY:
HIGH SPEED MOTOR
REVERSIBLE MOTOR

04
EN
4 Technical Data
BH30/603/HS
BH30/604/HS
BH30/603/HS/115
BH30/604/HS/115
BH30/803
BH30/804 BH30/803/115 BH30/804/115 BH30/804/R
BH30/804/R/115
MAINS POWER SUPPLY 230V 50 Hz 115V 60 Hz 230V 50 Hz 115V 60 Hz 230V 50Hz 115V 60 Hz
BRUSHLESS MOTOR POWER SUPPLY 24V 24V 24V 24V 24V 24V
DRIVE TYPE IRREVERSIBLE IRREVERSIBLE IRREVERSIBLE IRREVERSIBLE REVERSIBLE REVERSIBLE
MAXIMUM POWER ABSORPTION 140W 140W 140W 140W 140W 140W
START-UP POWER ABSORPTION 350W 350W 450W 450W 400W 400W
MAX. START-UP FORCE 500N 500N 800N 800N 600N 600N
RATED FORCE SERVICE 50%
(-20°C - +50°C) 150N 150N 300N 300N 180N 180N
RATED FORCE SERVICE 50%
(+50°C - +55°C) 50N 50N 100N 100N 60N 60N
RATED FORCE SERVICE 100%
(-20°C - +50°C) 50N 50N 100N 100N 60N 60N
RATED FORCE SERVICE 35%
(+50°C - +55°C) 150N 150N 300N 300N 150N 150N
MAXIMUM SPEED 24 m/min 24 m/min 12 m/min 12 m/min 20 m/min 20 m/min
RATED SPEED 20 m/min 20 m/min 12 m/min 12 m/min 18 m/min 18 m/min
MAXIMUM LEAF WEIGHT 600 kg 600 kg 1000 kg 1000 kg 800 kg 800 kg
MAXIMUM LEAF LENGHT 12 m 12 m 12 m 12 m 12 m 12 m
DOOR MAXIMUM FRICTION AT START (*) 50N 50N 150N 150N 60N 60N
OPERATING CYCLES PER DAY (IN TEST) (**) 250.000 250.000 250.000 250.000 250.000 250.000
USE INTENSIVE INTENSIVE INTENSIVE INTENSIVE INTENSIVE INTENSIVE
DEGREE OF PROTECTION IP44 IP44 IP44 IP44 IP44 IP44
WORKING TEMPERATURE -20°C
+55°C -20°C +55°C -20°C +55°C -20°C +55°C -20°C +55°C -20°C +55°C
SOUND PRESSURE DURING USE <70 dB(A) <70 dB(A) <70 dB(A) <70 dB(A) <70 dB(A) <70 dB(A)
MAXIMUM ADMISSIONED GRADIENT 0,5% 0,5% 0,5% 0,5% 0,5% 0,5%
EXIT GEAR Z15/module 4 Z15/module 4 Z15/module 4 Z15/module 4 Z15/module 4 Z15/module 4
CONTROL UNIT B70/1DC B70/1DC B70/1DC B70/1DC B70/1DC B70/1DC
FORCE TO BE APPLIED ON THE MECHANI-
CAL RELEASE 130N 130N 130N 130N 130N 130N
(*) To measure with dedicated instrument.
(**) Internal test veried at the nominal values with a 6 m gate at environmental temperature of 20° C. The value shown is not the maximum value.
4.1 Product label (example)
The technical data shown in this manual do not replace those shown on the product label.
The product label is applied to the motor, by opening the release handle (see gure).
Labels must not be removed, damaged, dirty or concealed.
MADE IN ITALY
AUTOMAZIONE PER ANTE SCORREVOLI
ROGER TECHNOLOGY S.R.L.
Via S. Botticelli 8 - 31021
Bonisiolo di Mogliano
Veneto (TV) - ITALIA
P.CODE:
BH30/603/HS
V ~230
W 140
N 150
S3 35%
IP 44
LOTTO/BC TL40
IN 0001
PM OCT 2018
+55°C
-20° C

05
EN
5 Typical installation
3
3x1.5/230 V 3x0.5-TX
5x0.5-RX
RG58
2x1
5x0.5-RX
3x0.5-TX
3x0.5
37 12647 52
DESCRIPTION RECOMMENDED CABLE
1BH30 Automation Power supply H07RN-F 3x1,5 mm2 double insulated cable
2External photocell F4ES/F4S - Transmitter Power supply 24Vac 50Hz, 24Vdc Cable 3x0,5 mm2(max 20 m)
External photocell F4ES/F4S - Receiver Cable 5x0,5 mm2(max 20 m)
3Internal photocell F4ES/F4S - Transmitter Power supply 24Vac 50Hz, 24Vdc Cable 3x0,5 mm2(max 20 m)
Internal photocell F4ES/F4S - Receiver Cable 5x0,5 mm2(max 20 m)
4Flashing light Power supply 24Vdc a LED
(25 W max, power consumption 50%) Cable 2x1 mm2(max 10 m)
Antenna Cable 50 Ohm RG58 (max 10 m)
5
Key selector R85/60 Cable 3x0,5 mm2(max 20 m)
Keypad H85/TTD - H85/TDS board DECODER H85/DEC: Power supply 12-24Vdc
H85/DEC/2: Power supply 24Vdc Cable 2x0,5 mm2(max 30 m)
6Rack /
7Limit switch bracket /
6 Dimensions
165,8
83
315
329

06
EN
7 Preliminary checks and installation of the foundation plate
PRELIMINARY CHECKS BEFORE INSTALLATION
• Before proceeding with the installation, move the gate manually to check the mechanical conditions and if the movement is regular and friction-free.
• Check that the gate is structurally sound and check that the gate leaf is stable. The gate may cause injury or damage to property in the event of derailing
or falling to one side.
• The guide rail must be securely xed to the ground and must be perfectly straight, with no kinks or other irregularities which may obstruct the movement
of the gate leaf, and must not have a gradient greater than 0.5%.
• Check that the guide rails are in good condition and adequately greased.
• Always install mechanical stops in the gate open and gate closed positions, anchored securely to the ground and with elastic damper elements (e.g. rubber
buffer) to attenuate the impact of the gate leaf against the stop.
• Check that, when the motor is unlocked, the door doesn’t move if left in any position.
INSTALLING FOUNDATION PLATE
• The automation system may be installed on the right or left hand side.
• Fit the four 10MA nuts onto the anchor bolts included, tightening along the full length of the thread.
• Fit the anchor bolts into the 4 holes in the foundation plate and fasten with the 4 nuts as shown in gure 1.
• Referring to the measurements given in the gure, cast a slab of cement with the base plate sunk into the cement. The plate must be perfectly level and
clean.
• The distances between the foundation plate [B] and the rack [A] must be as indicated.
• The exible conduits of the electrical system must exit from the hole on the right hand side of the foundation plate (seen from the inner side).
Fig. 1 Fig. 2
B
B
A
A
14
75-77
14 5
25
8 Installation drive unit
• Undo the screws of the cover and remove the lid by lifting up as shown in g. 1. Check that the six adjuster feet do not protrude from the base of the
gearmotor.
• Put the O-ring (B) onto each screws M10x40 (A). Insert the screws in the gearmotor corners (C) and secure them with the nuts M10 (D).
• Fit the BH30 on the 4 anchor bolt, as shown in g. 2. If necessary, undo the nuts on the foundation plate.
• Adjust the horizontal position of the gearmotor by sliding along the slots on the foundation plate.
• When adjusting the vertical position, also consider the correct fastener measurements for the rack. See paragraph 9.
• Fit the spacer M10 (E).
• Fit the cover.
A
B
C
D
E
Fig. 1 Fig. 2

07
EN
9 Fixing The Rack
N.B.: The BH30 gearmotor may be used with racks with a teething module of 4.
• Unlock the gearmotor (see User Guide) and move the gate into the open position.
• Place the rack on the pinion, then fasten the entire length of the rack, sliding the gate to allow access to the fasteners.
• To ensure that subsequent sections of rack are aligned correctly and maintain the correct tooth pitch, we recommend installing the rack sections with
connector pieces.
• Ensure that there is a clearance of at least 1 - 2 mm between the pinion and the rack. If necessary, adjust the height of the gearmotor or, if possible, of the rack.
• Manually check that the gate slides smoothly and without impediment.
• Fasten the gear motor denitively.
1-2 mm
CREMAGLIERA
RACK
10 Fastening the micro-switch mechanical limit switch or magnetic limit switch
• Move the gate into the fully open position and then into the fully closed position, and fasten the limit switch
brackets onto the rack, ensuring that they are turned the right way around.
• With mechanical limit switches: R = RIGHT; L = LEFT (g. 1).
• With magnetic limit switches, the arrows must point towards the middle of the rack (g. 2).
ATTENTION: the magnet can be adjusted by a maximum of 8 mm by loosening the two screws.
ATTENTION: between magnet and limit switch bracket there must be a distance of 10 mm at most.
• Perform a few open/close manoeuvres then adjust the positions of the limit switch brackets so that the gate
stops 40 to 80 mm before the mechanical stop. The stopping distance depends on the weight of the gate,
friction, the control unit used and weather conditions.
• The gate must not come into contact with the mechanical stops when opening and closing.
MICROSWITCH MECHANICAL LIMIT SWITCH
MAGNETIC LIMIT SWITCH
max.10 mm
8 mm
8 mm
Fig. 2
Fig. 1
N.B.: between magnet
and limit switch bracket
there must be a distance
of 10 mm at most
N.B.: the magnet can be adjusted to a
maximum of 8 mm in relation to the rack
mounting bracket.
The screws must be parallel to each other.
~40÷80

08
EN
11 Electrical connections
A switch or an omnipolar cut-off switch with a contact opening of at least 3 mm must be installed on the mains power line; put the
cut-off switch in OFF position and disconnect any buffer batteries before performing any cleaning or maintenance operations.
Ensure that an adequate residual current circuit breaker with a 0.03 A threshold and a suitable overcurrent cut-out are installed upstream
the electrical installation in accordance with best practices and in compliance with applicable legislation.
For power supply, use a H07RN-F 3G1.5 type electric cable and connect it to the terminals L (brown), N (blue), (yellow/green), located
inside the automation system.
Strip the insulation from the ends of the power cable wires which will be connected to the terminal (see ref. A), and secure the cable with the
cable retainer.
Measure the voltage on the primary mains power connection with a tester.
For the Brushless automation system to function correctly, the mains power voltage must be 230Vac (115 Vac) ±10%.
If the detected value does not comply with the above specied values or is not stable, the automation system may NOT operate eciently.
Connections to the electrical distribution network and to any other low-voltage conductors in the external section to the electrical panel
must be on an independent path and separate from the connections to the command and safety devices (SELV = Safety Extra Low
Voltage).
Make sure that the mains power conductors and the accessory wires (24 V) are separated.
The cables must be double insulated, strip them near the relevant connection terminals and lock them with clamps (not supplied).
The electrical connections and the gear motor BH30 testing operations are described in the installation manual of the control unit
B70/1DC.
+SC
8910 11 12 13 14 15 16 17 18
COM
FT2 FT1
COS2 COS1 COM
ST
+LAM
COM COM
ANT
COR
+24V
PED
PP
CH
AP
ORO
COM LNA LNB
ENC
POWER IN
MOTOR
YXZ
F2
F3
F1
PROG TEST
+
-
FC SB
M
LN
3x2,5 mm²
230 Vac
115 Vac
ALIMENTAZIONE
POWER SUPPLY
A
CAVO MOTORE
MOTOR CABLE

09
EN
12 Magnetic limit switches connections
The gate open and gate closed limit switch outputs are OPEN COLLECTOR signals.
FCA (OPEN COLLECTOR)
FCC (OPEN COLLECTOR)
COM
FCC
FCA
24V AC/DC
COM
ROSSO / RED
BLU / BLUE
NERO / BLACK
MARRONE / BROWN
24V AC/DC
13 Start-up
• Check that the manual release device functions correctly.
• The installer is required to draw up and preserve the technical le of the system for at least 10 years, which must contain the wiring
diagram, the drawing and the photo of the system, the risk analysis and the solutions adopted, the manufacturer’s declaration of conformity
for all connected devices, the instructions manual of each device and / or accessory and the system’s maintenance plan.
• Apply a plate indicating the automation system data on the motorised door or gate, the name of the person in charge of the start-up, the
serial number and the year of construction, as well as the CE mark.
• Apply a plate and / or label with the indications for the operations required to manually unlock the system.
• Draw up and provide the end user with the declaration of conformity, instructions and warnings for use and the maintenance plan.
• Make sure that the end user has understood the correct automatic, manual or emergency operation of the system.
• Inform the end user about the dangers and risks that may be present.
14 Ordinary maintenance schedule
Perform the following operations and checks every 6 months, depending on the intensity of use of the automated system.
Disconnect the mains power and the batteries (if any) and unlock the gear motor (SEE THE USER MANUAL):
• Perform a visual check to determine if the gate, the fastening brackets and the existing structure have the required mechanical robustness and that they
are in good state.
• Check the gate-gear motor alignment and the distance (1-2 mm) between the pinion neck and the ridge of the rack.
• Clean the guide rails of the wheels, the rack and the pinion of the gear motor and lightly lubricate the rack and the pinion of the gear motor.
• Manually check that the gate slides smoothly and without impediment.
Reconnect the mains power and the batteries (if any) and lock the gear motor (SEE THE USER MANUAL):
• Check if the limit switches operate correctly.
• Check the force adjustments.
• Check that the safety devices and all control functions operate correctly.
15 Additional information and contact details
ROGER TECHNOLOGY is the exclusive proprietor holder of all rights regarding this publication.
ROGER TECHNOLOGY reserves the right to implement any modications without prior notication. Copying, scanning or any alterations to this document are
prohibited without express prior authorised from by ROGER TECHNOLOGY.
This instruction manual and the warnings for the installer are given in printed form and included in the box containing the product.
The digital version of this documentation (in PDF format) and all future revisions are available from the reserved area of our website www.rogertechnology.
com/B2B, in the section ‘Self Service’.
ROGER TECHNOLOGY CUSTOMER SERVICE:
business hours: Monday to Friday
08:00 to 12:00 - 13:30 to 17:30
Telephone no: [phone]
E-mail: [e-mail]
Skype: service_rogertechnology

10
DECLARATION OF INCORPORATION
(Directive 2006/42/CE - Annex II B)
The manufacturer: Roger Technology - Via Botticelli 8, 31021 Bonisiolo di Mogliano V.to (TV)
Declares that the partly-completed machinery designed to be incorporated according to the corresponding instructions manual:
Description of the device: 24 V DC automated system for sliding gates BH30 Series powered by the built-in control unit.
Built-in control unit model: B70/1DC
Product code
Serial Number
See the P.CODE eld on the label applied to the product
See eld IN on the label attached to the product.
is compliant with the provisions of the following Community directives:
• 2006/42/EC directive (Machinery Directive) and the related technical documentation has been compiled according to annex VII B of the same directive;
• 2014/30/EU directive (Electromagnetic Compatibility);
• 2014/35/EU directive (Low Voltage);
• The Radio Equipment Directive 2014/53/EU (RED).
• 2011/65/UE directive (RoHS)
and that the following regulations and/or technical specications have been applied:
EN 301 489-1 V2.2.0; EN 62233: 2008;
EN 301 489-3 V2.2.1; EN 60335-1: 2012 + A11:2014+A1 (IEC):2013
EN 55014-1: 2006 + A1:2009 + A2:2011; EN 60335-2-103: 2015;
EN 55014-2: 2015; EN ISO 13849-1:2015;
EN 61000-3-2: 2014; EN ISO 13849-2:2012;
EN 61000-3-3: 2013;
EN 61000-6-2: 2005;
EN 61000-6-3: 2007; + A1:2011;
Declares to undertake to provide information related to the partly-completed machinery, following a duly justied request from the national authorities. The
commitment includes the transmission methods and does not affect the intellectual property rights of the manufacturer of the partly-completed machinery.
Declares that the partly-completed machinery must not be commissioned until the nal machinery in which it will be incorporated is declared compliant with
the provisions of the 2006/42/EC directive.
Place and date of declaration Personauthorisedto compilethetechnicaldocumentation Company name and full address of the manufacturer:
ROGER TECHNOLOGY S.R.L. Via S.Botticelli, 8
31021 Bonisiolo di Mogliano Veneto Treviso ITALY
Bonisiolo di Mogliano Veneto
10/11/2016
Research and Development Ocer
(Ing. Dino Cinti)
Legal Representative of the company
(Dino Florian)
Rev001
