Rohde & Schwarz EVSG1000 User manual

R&S®EVSG1000
VHF/UHF Airnav/Com Analyzer
User Manual
User Manual
Version 06
1178622702
(;ÜÌK2)

This document describes the following R&S®EVSG1000 models with firmware version 1.40 and later:
●R&S®EVSG1000 (1329.8009.02)
Furthermore, it covers the following options:
●R&S®EVSG-B1 Second Signal Proc. Unit (1329.8809.02)
●R&S®EVSG-B2 Battery Management (1329.8815.02)
●R&S®EVSG-B3 Battery Pack (1329.8821.02)
●R&S®EVSG-K1 ILS CRS/CLR Analysis (1329.9005.02)
●R&S®EVSG-K2 VOR Analysis (1329.9011.02)
●R&S®EVSG-K3 MB Analysis (1329.9028.02)
●R&S®EVSG-K4 GBAS Analysis (1329.9034.02)
●R&S®EVSG-K5 SCAT-I Analysis (1329.9040.02)
●R&S®EVSG-K6 COM Analysis (1329.9057.02)
●R&S®EVSG1-K7 LF-Analysis (1329.9163.02)
●R&S®EVSG-K10 RF Spectrum Analysis (1329.9063.02)
●R&S®EVSG-K11 AF Spectrum Analysis (1329.9070.02)
●R&S®EVSG-K12 AF Time Domain Analysis (1329.9086.02)
●R&S®EVSG-K20 GPS Support (1329.9092.02)
●R&S®EVSG-K21 Data Recording (1329.9105.02)
●R&S®EVSG-K22 High Measurement Rate (1329.9111.02)
●R&S®EVSG-K23 Preselector (1329.9128.02)
●R&S®EVSG-K24 Power Sensor Support (1329.9134.02)
●R&S®EVSG1-K25 I/Q Data Streaming (1329.9157.02)
© 2020 Rohde & Schwarz GmbH & Co. KG
Mühldorfstr. 15, 81671 München, Germany
Phone: [phone] - 0
Email: [email protected]
Internet: www.rohde-schwarz.com
Subject to change – data without tolerance limits is not binding.
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
Trade names are trademarks of the owners.
1178.6227.02 | Version 06 | R&S®EVSG1000
The following abbreviations are used throughout this manual: R&S®EVSG1000 is abbreviated as R&S EVSG1000.

Contents
R&S®EVSG1000
3User Manual 1178.6227.02 ─ 06
Contents
1 Getting Started..................................................................................... 13
1.1 Safety Information.......................................................................................................13
1.1.1 Safety Instructions.........................................................................................................13
1.1.2 Labels on the Product................................................................................................... 17
1.1.3 Warning Messages in the Documentation.....................................................................17
1.2 Documentation Overview........................................................................................... 18
1.2.1 Getting Started Manual................................................................................................. 18
1.2.2 User Manuals and Help.................................................................................................18
1.2.3 Printed Safety Instructions............................................................................................ 18
1.2.4 Data Sheets and Brochures.......................................................................................... 18
1.2.5 Release Notes and Open-Source Acknowledgment (OSA)..........................................19
1.3 Key Features................................................................................................................19
1.4 Preparing for Use........................................................................................................ 19
1.4.1 Unpacking and Checking.............................................................................................. 20
1.4.2 Lifting and Carrying....................................................................................................... 20
1.4.3 Choosing the Operating Site......................................................................................... 20
1.4.4 Setting Up the R&S EVSG1000.................................................................................... 21
1.4.4.1 Placing the R&S EVSG1000 on a Bench Top............................................................... 21
1.4.4.2 Mounting the R&S EVSG1000 in a Rack...................................................................... 21
1.4.4.3 Portable Operation........................................................................................................ 22
1.4.5 Connecting to Power.....................................................................................................22
1.4.5.1 Connecting the Provided AC/DC Power Supply Connector..........................................23
1.4.5.2 Connecting an External DC Power Source................................................................... 23
1.4.5.3 Using an Optional Battery Pack (R&S EVSG-B3).........................................................24
1.4.6 Switching On or Off....................................................................................................... 25
1.4.7 Performing an Auto-Calibration.....................................................................................26
1.4.8 Connecting Devices for Signal Input and Output.......................................................... 27
1.4.9 Connecting to LAN........................................................................................................ 27
1.5 Instrument Tour...........................................................................................................28
1.5.1 Front Panel....................................................................................................................28
1.5.1.1 Power Key.....................................................................................................................29

Contents
R&S®EVSG1000
4User Manual 1178.6227.02 ─ 06
1.5.1.2 Display.......................................................................................................................... 29
1.5.1.3 RX1 IN / RX2 IN............................................................................................................ 29
1.5.1.4 USB...............................................................................................................................29
1.5.1.5 AF Out...........................................................................................................................30
1.5.1.6 12 V DC Out..................................................................................................................30
1.5.1.7 System Keys................................................................................................................. 30
1.5.1.8 Softkeys........................................................................................................................ 30
1.5.1.9 Function Keys............................................................................................................... 30
1.5.1.10 Keypad.......................................................................................................................... 31
1.5.1.11 Rotary Knob.................................................................................................................. 32
1.5.1.12 Navigation Keys............................................................................................................ 32
1.5.2 Rear Panel.................................................................................................................... 33
1.5.2.1 Power Supply................................................................................................................ 33
1.5.2.2 Li-Ion Battery Pack........................................................................................................34
1.5.2.3 LAN (Ethernet).............................................................................................................. 34
1.5.2.4 RS232 GPS...................................................................................................................34
1.5.2.5 PPS In........................................................................................................................... 34
1.5.2.6 Trigger In.......................................................................................................................34
1.5.2.7 LF In (Baseband/Low Frequency Input)........................................................................34
1.5.2.8 Demod Out....................................................................................................................35
1.5.2.9 Loudspeaker................................................................................................................. 35
1.5.2.10 Device ID.......................................................................................................................35
1.5.3 Accessories...................................................................................................................35
1.6 Operating Basics.........................................................................................................38
1.6.1 Understanding the Display Information......................................................................... 38
1.6.2 Manual Operation..........................................................................................................40
1.6.2.1 Changing Settings and Activating Functions.................................................................40
1.6.2.2 Entering Data................................................................................................................ 41
1.6.2.3 Getting Help.................................................................................................................. 43
1.6.3 Manual Operation from a VNC Viewer..........................................................................44
1.6.4 Remote Control............................................................................................................. 47
2 Measurements and Results.................................................................48
3 Configuring the Input Signal and Measurement Mode.....................51

Contents
R&S®EVSG1000
5User Manual 1178.6227.02 ─ 06
3.1 Input Signal Settings.................................................................................................. 51
3.2 Receiver Board............................................................................................................52
3.3 Measurement Mode.....................................................................................................52
4 Numeric Measurement Modes............................................................ 54
4.1 ILS Localizer and ILS Glidepath (GP) Modes........................................................... 54
4.1.1 Localizer Basics............................................................................................................ 54
4.1.2 Glide Slope Basics........................................................................................................ 55
4.1.3 ILS Localizer and Glidepath Measurements and Results............................................. 56
4.1.3.1 RF Level and Frequency Display.................................................................................. 61
4.1.3.2 IF Spectrum Preview.....................................................................................................62
4.1.3.3 LF Level, Frequency, and Spectrum Display.................................................................63
4.1.3.4 ILS Localizer and Glidepath Main View.........................................................................64
4.1.3.5 ILS Localizer Distortion View.........................................................................................69
4.1.3.6 ILS Localizer ID Analysis View......................................................................................71
4.1.3.7 ILS Localizer Recording View....................................................................................... 74
4.1.4 ILS Localizer and Glidepath Configuration....................................................................75
4.1.4.1 Configuring the Input Signal..........................................................................................75
4.1.4.2 Channel and Frequency Configuration......................................................................... 76
4.1.4.3 Ampt..............................................................................................................................80
4.1.4.4 Bandwidth (BW)............................................................................................................ 81
4.1.4.5 LF Input Configuration...................................................................................................82
4.1.4.6 Setting the Measurement Time (MTime).......................................................................86
4.1.4.7 DDM and SDM Configuration........................................................................................86
4.2 ILS Marker Beacon Mode (Option R&S EVSG-K3)................................................... 87
4.2.1 Basics on Marker Beacons........................................................................................... 87
4.2.2 ILS Marker Beacon Measurements and Results...........................................................88
4.2.2.1 RF Level and Frequency Display.................................................................................. 89
4.2.2.2 IF Spectrum Preview.....................................................................................................90
4.2.2.3 ILS Marker Beacon Main View......................................................................................91
4.2.2.4 ILS Marker Beacon ID Analysis.................................................................................... 92
4.2.2.5 ILS Marker Beacon Recording View............................................................................. 94
4.2.3 Configuring ILS Marker Beacon Measurements........................................................... 95
4.2.3.1 Setting the Receiver Frequency....................................................................................95

Contents
R&S®EVSG1000
6User Manual 1178.6227.02 ─ 06
4.2.3.2 Ampt..............................................................................................................................96
4.2.3.3 Setting the Measurement Time (MTime).......................................................................97
4.3 VOR Mode (Option R&S EVSG-K2)............................................................................97
4.3.1 VOR Basics...................................................................................................................98
4.3.1.1 VHF Omni Directional Radio Range (VOR).................................................................. 98
4.3.1.2 VOR Demodulator.......................................................................................................101
4.3.1.3 Phase Notation in VOR Measurements...................................................................... 103
4.3.2 VOR Measurements and Results................................................................................104
4.3.2.1 RF Level and Frequency Display................................................................................ 105
4.3.2.2 IF Spectrum Preview...................................................................................................106
4.3.2.3 VOR Main View...........................................................................................................106
4.3.2.4 VOR Distortion View....................................................................................................108
4.3.2.5 VOR ID Analysis View.................................................................................................110
4.3.2.6 VOR Recording View...................................................................................................112
4.3.3 Configuring VOR Measurements.................................................................................113
4.3.3.1 General Measurement Configuration.......................................................................... 113
4.3.3.2 Channel Frequency Configuration (CH FREQ)........................................................... 115
4.3.3.3 Ampt............................................................................................................................ 116
4.3.3.4 Bandwidth (BW)...........................................................................................................117
4.3.3.5 Setting the Measurement Time (MTime)..................................................................... 117
4.4 COM Mode (Option R&S EVSG-K6)......................................................................... 118
4.4.1 COM Measurement Results........................................................................................ 118
4.4.1.1 RF Level and Frequency Display................................................................................ 119
4.4.1.2 IF Spectrum Preview...................................................................................................120
4.4.1.3 COM Main View.......................................................................................................... 121
4.4.1.4 COM Recording View..................................................................................................123
4.4.2 COM Configuration..................................................................................................... 124
4.4.2.1 Channel and Frequency Configuration....................................................................... 124
4.4.2.2 Ampt............................................................................................................................126
4.4.2.3 Bandwidth (BW).......................................................................................................... 127
4.4.2.4 Setting the Measurement Time (MTime).....................................................................127
4.5 Non-Directional Beacon Mode (Option R&S EVSG1-K7).......................................128
4.5.1 Basics on Non-Directional Beacons............................................................................128

Contents
R&S®EVSG1000
7User Manual 1178.6227.02 ─ 06
4.5.2 NDB Measurement and Results..................................................................................128
4.5.2.1 RF Level, Frequency and IF Spectrum Display.......................................................... 129
4.5.2.2 NDB ID Analysis..........................................................................................................130
4.5.2.3 NDB Distortion View....................................................................................................132
4.5.2.4 NDB Recording View...................................................................................................133
4.5.3 Configuring NDB Measurements................................................................................ 134
4.5.3.1 General Measurement Settings.................................................................................. 135
4.5.3.2 Receiver Frequency.................................................................................................... 135
4.5.3.3 Amplitude.................................................................................................................... 136
4.5.3.4 Setting the Bandwidth................................................................................................. 137
4.5.3.5 Setting the Measurement Time (MTime).....................................................................137
5 Graphic Measurement Modes...........................................................139
5.1 RF Spectrum Mode (Option R&S EVSG-K10)......................................................... 139
5.1.1 Configuring the Frequency Range.............................................................................. 140
5.1.2 Configuring the Bandwidth.......................................................................................... 141
5.1.3 Configuring the Amplitude (Y-Axis)............................................................................. 142
5.1.4 Configuring the Trace..................................................................................................143
5.2 IF Spectrum Mode (Option R&S EVSG-K10)...........................................................144
5.2.1 Configuring the Frequency Range.............................................................................. 145
5.2.2 Configuring the Bandwidth.......................................................................................... 146
5.2.3 Configuring the Amplitude (Y-Axis)............................................................................. 146
5.2.4 Configuring the Trace..................................................................................................148
5.3 AF Spectrum Mode (Option R&S EVSG-K11)......................................................... 149
5.3.1 Configuring the Input Signal........................................................................................151
5.3.2 Configuring the Frequency Range.............................................................................. 152
5.3.3 Configuring the Bandwidth.......................................................................................... 153
5.3.4 Configuring the Amplitude (Y-Axis) for RF Input......................................................... 154
5.3.5 Configuring the Amplitude (Y-Axis) for LF Input.......................................................... 155
5.3.6 Configuring the Trace..................................................................................................157
5.4 AF Time Domain Mode (Option R&S EVSG-K12)................................................... 158
5.4.1 Configuring the Input Signal........................................................................................161
5.4.2 Configuring the Frequency Range and Bandwidth..................................................... 162
5.4.3 Configuring the Amplitude (Y-Axis) for RF Input......................................................... 162

Contents
R&S®EVSG1000
8User Manual 1178.6227.02 ─ 06
5.4.4 Configuring the Amplitude (Y-Axis) for LF Input.......................................................... 163
5.4.5 Configuring the Measurement Time............................................................................165
5.4.6 Configuring the Trigger................................................................................................165
5.4.7 Configuring the Trace..................................................................................................166
5.5 Using Markers in the Graphical Displays............................................................... 167
6 GBAS/SCAT-I Mode (Options R&S EVSG-K4/-K5)...........................170
6.1 Basics on GBAS and SCAT-I Analysis ................................................................... 171
6.1.1 GBAS Specifics...........................................................................................................171
6.1.2 Broadcast Timing Structure.........................................................................................173
6.1.3 Final Approach Segment (FAS) Construction Data.....................................................173
6.1.4 Time Slot Synchronization via PPS.............................................................................174
6.2 GBAS / SCAT-I Measurement Information.............................................................. 174
6.3 GBAS / SCAT-I Measurement Views and Results...................................................176
6.3.1 Sequence View........................................................................................................... 176
6.3.2 Frame View................................................................................................................. 178
6.3.2.1 Frame Power Vs. Time Diagram.................................................................................179
6.3.2.2 Frame Results Table................................................................................................... 180
6.3.3 Burst View................................................................................................................... 182
6.3.3.1 Slot Power vs. Time Diagram......................................................................................183
6.3.3.2 Slot Results Table....................................................................................................... 184
6.3.4 Constellation View.......................................................................................................185
6.3.5 Message View.............................................................................................................186
6.3.6 Recording View........................................................................................................... 187
6.4 GBAS/ SCAT-I Measurement Configuration............................................................189
6.4.1 View Configuration...................................................................................................... 189
6.4.2 Frequency Configuration.............................................................................................190
6.4.3 Amplitude Configuration..............................................................................................191
6.4.4 Bandwidth Configuration............................................................................................. 191
6.4.5 General Configuration................................................................................................. 192
6.5 Message XML Interface............................................................................................ 193
6.5.1 General Processing.....................................................................................................194
6.5.2 Output Elements and Control Elements......................................................................195
6.5.3 XML File Format Description.......................................................................................198

Contents
R&S®EVSG1000
9User Manual 1178.6227.02 ─ 06
6.5.4 Format Description of Elements..................................................................................200
6.5.5 Output Elements......................................................................................................... 200
6.5.5.1 Unsigned Type............................................................................................................ 200
6.5.5.2 Signed Type................................................................................................................ 201
6.5.5.3 Longitude Type............................................................................................................202
6.5.5.4 Latitude Type...............................................................................................................203
6.5.5.5 Id Type........................................................................................................................ 204
6.5.5.6 Fixed Type...................................................................................................................204
6.5.5.7 Value Type...................................................................................................................204
6.5.5.8 FEC Type.................................................................................................................... 205
6.5.5.9 CRC Type....................................................................................................................205
6.5.5.10 List Type......................................................................................................................206
6.5.5.11 Enum Type.................................................................................................................. 207
6.5.5.12 Dummy Type............................................................................................................... 208
6.5.6 Control Elements.........................................................................................................208
6.5.6.1 Link_sel Type.............................................................................................................. 208
6.5.6.2 Loop Type....................................................................................................................211
6.5.6.3 While Type...................................................................................................................211
6.5.7 Auxiliary Elements.......................................................................................................212
6.5.7.1 Fill Type.......................................................................................................................212
7 Power Sensor Support (Option R&S EVSG-K24)............................ 213
8 Data Management.............................................................................. 215
8.1 Storing and Recalling Measurement Settings (Preset)......................................... 215
8.1.1 Storage and Recall Functions..................................................................................... 215
8.2 Recording Measurement Data................................................................................. 217
8.2.1 GPS Data Synchronization......................................................................................... 218
8.2.2 I/Q Data Recording and Streaming (R&S EVSG1-K25)..............................................218
8.2.3 Recording Settings......................................................................................................219
8.2.4 Activating Data Recording...........................................................................................221
8.2.5 Viewing Recorded Data...............................................................................................223
8.2.6 Analyzing Recorded I/Q Data......................................................................................223
8.3 Creating and Storing Screenshots.......................................................................... 223

Contents
R&S®EVSG1000
10User Manual 1178.6227.02 ─ 06
9 Common Instrument Settings...........................................................226
9.1 Audio Output Settings.............................................................................................. 226
9.2 Display....................................................................................................................... 227
9.3 Demodulation Output Settings................................................................................ 229
9.4 Network (Remote) Settings...................................................................................... 230
9.5 System Settings........................................................................................................ 232
9.6 Instrument Configuration and Operating Status Settings.....................................234
9.7 GPS Configuration.................................................................................................... 240
10 Remote Commands........................................................................... 242
10.1 Common Instrument and Measurement Setup...................................................... 242
10.1.1 Common Measurement Settings.................................................................................243
10.1.2 Signal Input................................................................................................................. 247
10.1.3 Trigger Settings...........................................................................................................249
10.1.4 Baseband Input........................................................................................................... 249
10.1.5 Result Display Settings............................................................................................... 250
10.1.6 Audio, Demodulation and Output Configuration..........................................................253
10.1.7 Retrieving Instrument Information............................................................................... 258
10.1.8 GPS Data.................................................................................................................... 261
10.1.9 System Settings.......................................................................................................... 266
10.1.10 Calibration................................................................................................................... 269
10.1.11 Network Settings and Remote Operation....................................................................270
10.1.12 Deprecated Commands.............................................................................................. 271
10.2 ILS Localizer (LOC) and Glidepath (GP) Modes..................................................... 273
10.2.1 Configuring the ILS LOC and GP Modes.................................................................... 273
10.2.2 Configuring ILS Localizer Measurements................................................................... 273
10.2.3 Configuring ILS Glidepath Measurements.................................................................. 283
10.2.4 Retrieving ILS Loc and GP Results.............................................................................292
10.2.5 Retrieving ID Results.................................................................................................. 301
10.2.6 Deprecated Commands.............................................................................................. 302
10.3 ILS Marker Beacon (MB) Mode................................................................................ 305
10.3.1 Configuring ILS MB Measurements............................................................................ 305
10.3.2 Retrieving ILS MB Results.......................................................................................... 307
10.3.3 Retrieving ILS MB Identifier Results........................................................................... 309

Contents
R&S®EVSG1000
11User Manual 1178.6227.02 ─ 06
10.3.4 Deprecated Commands...............................................................................................311
10.4 VOR Mode.................................................................................................................. 312
10.4.1 Configuring VOR Measurements................................................................................ 312
10.4.2 Retrieving VOR Results.............................................................................................. 316
10.4.3 Deprecated Commands.............................................................................................. 321
10.5 COM Mode................................................................................................................. 322
10.5.1 Configuring COM Measurements................................................................................322
10.5.2 Retrieving COM Results..............................................................................................326
10.6 GBAS/ SCAT-I Mode.................................................................................................. 333
10.6.1 Configuring GBAS/ SCAT-I Measurements.................................................................333
10.6.2 Retrieving GBAS/ SCAT-I Results...............................................................................337
10.7 NDB Mode.................................................................................................................. 345
10.7.1 Configuring an NDB Measurement............................................................................. 345
10.7.2 Retrieving NDB Measurement Results....................................................................... 348
10.8 RF Spectrum Mode................................................................................................... 350
10.8.1 Configuring RF Spectrum Measurements...................................................................350
10.8.2 Retrieving RF Spectrum Results.................................................................................354
10.9 IF Spectrum Mode..................................................................................................... 355
10.9.1 Configuring IF Spectrum Measurements.................................................................... 355
10.9.2 Retrieving IF Spectrum Results.................................................................................. 359
10.10 AF Spectrum Mode................................................................................................... 359
10.10.1 Configuring AF Spectrum Measurements................................................................... 359
10.10.2 Retrieving AF Spectrum Results................................................................................. 366
10.11 AF Time Domain Mode..............................................................................................367
10.11.1 Configuring AF Time Domain Measurements............................................................. 367
10.11.2 Retrieving RF Spectrum Results.................................................................................372
10.12 Data Management..................................................................................................... 372
10.12.1 Data Recording........................................................................................................... 372
10.12.2 Data Streaming........................................................................................................... 377
10.12.3 Results for Data Streaming......................................................................................... 379
10.12.3.1 ILS LOC Mode............................................................................................................ 380
10.12.3.2 ILS GP Mode...............................................................................................................381
10.12.3.3 ILS MB Mode.............................................................................................................. 382

Contents
R&S®EVSG1000
12User Manual 1178.6227.02 ─ 06
10.12.3.4 VOR Mode.................................................................................................................. 383
10.12.3.5 COM Mode..................................................................................................................384
10.12.3.6 GBAS Mode................................................................................................................ 384
10.12.3.7 NDB Mode...................................................................................................................385
10.13 Information on Commands...................................................................................... 386
11 Maintenance, Storage and Disposal.................................................387
11.1 Cleaning..................................................................................................................... 387
11.2 Handling Batteries.................................................................................................... 387
11.3 Storage.......................................................................................................................389
11.4 Disposal..................................................................................................................... 389
12 Transporting....................................................................................... 391
13 Contacting Customer Support..........................................................392
Annex.................................................................................................. 393
A ILS Channel Frequency List..............................................................393
B VOR Channel Frequency List............................................................395
C References..........................................................................................397
D Format Description of GBAS and SCAT-I Data................................398
List of Commands..............................................................................404
Index....................................................................................................417

Getting Started
R&S®EVSG1000
13User Manual 1178.6227.02 ─ 06
1 Getting Started
Note: the following chapters are identical to those in the printed R&S EVSG1000 Get-
ting Started manual.
1.1 Safety Information
The product documentation helps you use the product safely and efficiently. Follow the
instructions provided here and in the Chapter 1.1.1, "Safety Instructions",
on page 13.
Intended use
The product is intended for maintenance and servicing of ILS, VOR and marker bea-
con ground stations and analyzing ATC COM signals. The portable, robust design and
the integrated battery allow for network-independent measurements also outdoors.
Use the product only for its designated purpose. Observe the operating conditions and
performance limits stated in the data sheet.
Where do I find safety information?
Safety information is part of the product documentation. It warns you of potential dan-
gers and gives instructions on how to prevent personal injury or damage caused by
dangerous situations. Safety information is provided as follows:
●In Chapter 1.1.1, "Safety Instructions", on page 13. The same information is pro-
vided in many languages as printed "Safety Instructions". The printed "Safety
Instructions" are delivered with the product.
●Throughout the documentation, safety instructions are provided when you need to
take care during setup or operation.
1.1.1 Safety Instructions
Products from the Rohde & Schwarz group of companies are manufactured according
to the highest technical standards. To use the products safely, follow the instructions
provided here and in the product documentation. Keep the product documentation
nearby and offer it to other users.
Use the product only for its intended use and within its performance limits. Intended
use and limits are described in the product documentation such as the data sheet,
manuals and the printed safety instructions. If you are unsure about the appropriate
use, contact Rohde & Schwarz customer service.
Using the product requires specialists or specially trained personnel. These users also
need sound knowledge of at least one of the languages in which the user interfaces
and the product documentation are available.
If any part of the product is damaged or broken, stop using the product. Never open
the casing of the product. Only service personnel authorized by Rohde & Schwarz are
Safety Information

Getting Started
R&S®EVSG1000
14User Manual 1178.6227.02 ─ 06
allowed to repair the product. Contact Rohde & Schwarz customer service at http://
www.customersupport.rohde-schwarz.com.
Lifting and carrying the product
The maximum weight of the product is provided in the data sheet. To move the product
safely, you can use lifting or transporting equipment such as lift trucks and forklifts. Fol-
low the instructions provided by the equipment manufacturer.
The product is heavy. Do not move or carry the product by yourself. A single person
can only carry a maximum of 18 kg safely depending on age, gender and physical con-
dition. Look up the maximum weight in the data sheet. Use the product handles to
move or carry the product. Do not lift by the accessories mounted on the product.
Accessories are not designed to carry the weight of the product.
To move the product safely, you can use lifting or transporting equipment such as lift
trucks and forklifts. Follow the instructions provided by the equipment manufacturer.
Choosing the operating site
Only use the product indoors. The product casing is not waterproof. Water that enters
can electrically connect the casing with live parts, which can lead to electric shock,
serious personal injury or death if you touch the casing. If Rohde & Schwarz provides a
carrying bag designed for your product, you can use the product outdoors.
Unless otherwise specified, you can operate the product up to an altitude of 2000 m
above sea level. The product is suitable for pollution degree 2 environments where
nonconductive contamination can occur. For more information on environmental condi-
tions such as ambient temperature and humidity, see the data sheet.
Setting up the product
Always place the product on a stable, flat and level surface with the bottom of the prod-
uct facing down. If the product is designed for different positions, secure the product so
that it cannot fall over.
If the product has foldable feet, always fold the feet completely in or out to ensure sta-
bility. The feet can collapse if they are not folded out completely or if the product is
moved without lifting it. The foldable feet are designed to carry the weight of the prod-
uct, but not an extra load.
If stacking is possible, keep in mind that a stack of products can fall over and cause
injury.
If you mount products in a rack, ensure that the rack has sufficient load capacity and
stability. Observe the specifications of the rack manufacturer. Always install the prod-
ucts from the bottom shelf to the top shelf so that the rack stands securely. Secure the
product so that it cannot fall off the rack.
Connecting to power
The product is an overvoltage category II product and has to be connected to a fixed
installation used to supply energy-consuming equipment such as household applian-
Safety Information

Getting Started
R&S®EVSG1000
15User Manual 1178.6227.02 ─ 06
ces and similar loads. Be aware that electrically powered products have risks, such as
electric shock, fire, personal injury or even death.
Take the following measures for your safety:
●Before switching on the product, ensure that the voltage and frequency indicated
on the product match the available power source. If the power adapter does not
adjust automatically, set the correct value and check the rating of the fuse.
●If a product has an exchangeable fuse, its type and characteristics are indicated
next to the fuse holder. Before changing the fuse, switch off the instrument and dis-
connect it from the power source. How to change the fuse is described in the prod-
uct documentation.
●Only use the power cable delivered with the product. It complies with country-spe-
cific safety requirements. Only insert the plug into an outlet with protective conduc-
tor terminal.
●Only use intact cables and route them carefully so that they cannot be damaged.
Check the power cables regularly to ensure that they are undamaged. Also ensure
that nobody can trip over loose cables.
●If the product needs an external power supply, use the power supply that is deliv-
ered with the product or that is recommended in the product documentation or a
power supply that conforms to the country-specific regulations.
●Only connect the product to a power source with a fuse protection of maximum
20 A.
●Ensure that you can disconnect the product from the power source at any time.
Pull the power plug to disconnect the product. The power plug must be easily
accessible. If the product is integrated into a system that does not meet these
requirements, provide an easily accessible circuit breaker at the system level.
Cleaning the product
Use a dry, lint-free cloth to clean the product. When cleaning, keep in mind that the
casing is not waterproof. Do not use liquid cleaning agents.
Meaning of safety labels
Safety labels on the product warn against potential hazards.
Potential hazard
Read the product documentation to avoid personal injury or product damage.
Heavy product
Be careful when lifting, moving or carrying the product. Carrying the product requires at least
two people or transport equipment.
Electrical hazard
Indicates live parts. Risk of electric shock, fire, personal injury or even death.
Safety Information

Getting Started
R&S®EVSG1000
16User Manual 1178.6227.02 ─ 06
Hot surface
Do not touch. Risk of skin burns. Risk of fire.
Protective conductor terminal
Connect this terminal to a grounded external conductor or to protective ground. This protects
you against electric shock should an electric problem occur.
Handling batteries safely
The product contains lithium polymer or lithium ion cells or batteries. The use of the
word battery in the following always means all types. Only the battery contents are
potentially hazardous. As long as a battery is undamaged and the seals remain intact,
there is no danger.
Impact, shock or heat can cause damage such as dents, punctures and other deforma-
tions. A damaged battery poses a risk of personal injury. Handle a damaged or leaking
battery with extreme care. Immediately ventilate the area since the battery releases
harmful gases. If you come into contact with the battery fluid, immediately remove all
contaminated clothing. Irritation can occur if the battery fluid comes in contact with your
skin or eyes. Immediately and thoroughly rinse your skin or eyes with water and seek
medical aid.
For safe handling, follow these rules:
●Do not short-circuit the battery.
●Do not mechanically damage the battery. Do not open or disassemble the battery.
●Do not expose the battery to high temperatures such as open flames, hot surfaces
and sunlight.
●Only use the battery with the designated Rohde & Schwarz product.
●Only use the appropriate Rohde & Schwarz charger to charge the batteries. If the
batteries are improperly charged, there is a risk of explosion. For charging and dis-
charging temperature ranges, see the product documentation.
●Store the battery at room temperature (approximately 20 °C) enclosed in the origi-
nal packaging.
●Dispose of batteries separately from normal household waste as specified by the
local waste disposal agency.
If you disregard these rules, you risk serious personal injury or even death due to
explosion, fire or hazardous chemical substances. The product documentation pro-
vides further details.
When replacing a defective battery, only use the same Rohde & Schwarz battery type.
When returning batteries to Rohde & Schwarz subsidiaries, choose a carrier qualified
to transport dangerous goods and follow the carrier’s transport stipulations in line with
IATA-DGR, IMDG-Code, ADR or RID. If you need assistance, contact the carrier or
Rohde & Schwarz customer service.
Safety Information

Getting Started
R&S®EVSG1000
17User Manual 1178.6227.02 ─ 06
Connecting headphones
Take the following measures to prevent hearing damage. Before using headphones,
check the volume and reduce it if necessary. If you monitor varying signal levels, take
off the headphones and wait until the signal has settled. Then adjust the volume.
Using laser products
Warning: laser beam
The product contains a laser.
Avoid exposure to direct or reflected laser beam.
Lasers are classified according to their potential risk.
Class 1M lasers
Safe for the naked eye. If you look into the laser beam with optical instruments such as
binoculars or eye loupes, you risk damaging your eyes.
Class 2 lasers
If you stare into the beam, you risk damaging your eyes.
1.1.2 Labels on the Product
Labels on the casing inform about:
●Personal safety, see "Meaning of safety labels" on page 15
●Product and environment safety, see Table 1-1
Table 1-1: Labels regarding product and environment safety
Labeling in line with EN 50419 for disposal of electrical and electronic equipment after the prod-
uct has come to the end of its service life.
For more information, see "Electrical and electronic equipment" on page 390.
For more information, see the R&S EVSG1000 user manual, chapter "Disposal".
Labeling in line with directive 2006/66/EC for disposal of batteries after they have come to the
end of their service life.
For more information, see "Batteries" on page 390.
For more information, see the R&S EVSG1000 user manual, chapter "Disposal".
1.1.3 Warning Messages in the Documentation
A warning message points out a risk or danger that you need to be aware of. The sig-
nal word indicates the severity of the safety hazard and how likely it will occur if you do
not follow the safety precautions.
Safety Information

Getting Started
R&S®EVSG1000
18User Manual 1178.6227.02 ─ 06
CAUTION
Potentially hazardous situation
Could result in minor or moderate injury if not avoided.
NOTICE
Potential risks of damage
Could result in damage to the supported product or to other property.
1.2 Documentation Overview
This section provides an overview of the R&S EVSG1000 user documentation. You
find it on the product page at:
www.rohde-schwarz.com/manual/EVSG1000
1.2.1 Getting Started Manual
Introduces the R&S EVSG1000 and describes how to set up and start working with the
product. A printed version is delivered with the instrument.
1.2.2 User Manuals and Help
Contains the description of all instrument modes and functions. It also provides an
introduction to remote control, a complete description of the remote control commands
with programming examples, and information on maintenance, instrument interfaces
and error messages. Includes the contents of the getting started manual.
The contents of the user manual are also available as online help on the
R&S EVSG1000.
1.2.3 Printed Safety Instructions
Provides safety information in many languages. The printed document is delivered with
the product.
1.2.4 Data Sheets and Brochures
The data sheet contains the technical specifications of the R&S EVSG1000. It also lists
the firmware applications and their order numbers, and optional accessories.
The brochure provides an overview of the instrument and deals with the specific char-
acteristics.
Documentation Overview

Getting Started
R&S®EVSG1000
19User Manual 1178.6227.02 ─ 06
See www.rohde-schwarz.com/brochure-datasheet/evsg/
1.2.5 Release Notes and Open-Source Acknowledgment (OSA)
The release notes list new features, improvements and known issues of the current
firmware version, and describe the firmware installation.
The open-source acknowledgment document provides verbatim license texts of the
used open source software.
See www.rohde-schwarz.com/software/EVSG1000.
1.3 Key Features
The R&S EVSG1000 offers the following key features:
●Detailed analysis of ILS, VOR and Marker Beacon ground measurements (based
on ICAO Doc. 8071 and ICAO Annex 10)
●Spectrum preview and detailed signal analysis in frequency and time range
●Dynamic measurements up to 100 measurements per second in high measure-
ment rate modus
●Parallel course and clearance signal analysis in two-frequency systems (ILS)
●Simple remote operation via standard interfaces
●Software options for specific use cases
●Integrated data recording
1.4 Preparing for Use
This chapter describes the basic steps to be taken when setting up the product for the
first time.
●Unpacking and Checking........................................................................................ 20
●Lifting and Carrying.................................................................................................20
●Choosing the Operating Site...................................................................................20
●Setting Up the R&S EVSG1000..............................................................................21
●Connecting to Power...............................................................................................22
●Switching On or Off.................................................................................................25
●Performing an Auto-Calibration...............................................................................26
●Connecting Devices for Signal Input and Output.................................................... 27
●Connecting to LAN..................................................................................................27
Preparing for Use

Getting Started
R&S®EVSG1000
20User Manual 1178.6227.02 ─ 06
1.4.1 Unpacking and Checking
1. Unpack the R&S EVSG1000 carefully.
2. Retain the original packing material. Use it when transporting or shipping the prod-
uct later.
3. Using the delivery notes, check the equipment for completeness.
The instrument comes with the following accessories:
● AC/DC power supply connector with cable
● Printed Getting Started manual
4. Check the equipment for damage.
If the delivery is incomplete or equipment is damaged, contact Rohde & Schwarz.
1.4.2 Lifting and Carrying
The carrying handle is designed to lift or carry the instrument. Do not apply excessive
external force to the handle.
See "Lifting and carrying the product" on page 14.
1.4.3 Choosing the Operating Site
The R&S EVSG1000 can be operated in a variety of places without detrimental effects
on its features. Even the movement caused by transportation or mobile use does not
impair its functioning.
Specific operating conditions ensure accurate measurements and avoid damage to the
product and connected devices. For information on environmental conditions such as
ambient temperature and humidity, see the data sheet.
See also "Choosing the operating site" on page 14.
Electromagnetic compatibility classes
The electromagnetic compatibility (EMC) class indicates where you can operate the
product. The EMC class of the product is given in the data sheet under "General data".
●Class B equipment is suitable for use in:
– Residential environments
– Environments that are directly connected to a low-voltage supply network that
supplies residential buildings
●Class A equipment is intended for use in industrial environments. It can cause
radio disturbances in residential environments due to possible conducted and radi-
ated disturbances. It is therefore not suitable for class B environments.
If class A equipment causes radio disturbances, take appropriate measures to
eliminate them.
Preparing for Use
