ROHO Hybrid ELITE Cushion User manual

1
SUPPLIER: This manual must be given to the user of this product.
USER: Before using this product, read instructions and save
for future reference.
ROHO® Hybrid ELITE™ Cushion

1
ROHO, Inc. has a policy of continual product improvement and reserves the right to amend specifications presented
in this manual.
ROHO® Cushioning Products are manufactured by ROHO, Inc.,
100 North Florida Avenue, Belleville, Illinois 62221-5429, www.therohogroup.com.
U.S.A.: 1-800-851-3449, Fax [phone]
Outside the U.S.A.: 1-618-277-9150, Fax [phone]
Email: [email protected]
© ROHO, Inc., 2009
The following are trademarks and registered trademarks of ROHO, Inc.: ROHO®, DRY FLOATATION®,
shape fitting technology®, and Hybrid ELITE™.
Velcro® is a registered trademark of Velcro Industries B.V.
INTENDED USE 2
PRODUCT SPECIFICATIONS 2
CAUTIONS 3
PARTS DETAIL 4
PLACEMENT AND ADJUSTMENT INSTRUCTIONS 5
COVER AND CUSHION INSERT REMOVAL 6
COVER AND CUSHION INSERT REPLACEMENT 6
CLEANING AND DISINFECTING PRODUCT 6 - 7
TROUBLESHOOTING 7
RETURN POLICY 8
DISPOSAL 8
LIMITED WARRANTY 8
SPANISH 9
FRENCH 16
TABLE OF CONTENTS

2
The ROHO® Hybrid ELITE™ Cushion is a therapeutic cushioning device intended for users who weigh
500 lbs. (225 kg) or less and who require basic postural and positioning support, have a Stage I or
Stage II ischemic ulcer, as well as prevention of soft tissue breakdown. The contoured foam base of
the Hybrid ELITE Cushion is designed to enhance seating stability and support while the adjustable
ROHO DRY FLOATATION® cushion insert provides an environment to protect the user from soft tissue
breakdown. The ROHO Hybrid ELITE Cushion must be properly sized to the user and the wheelchair.
The cover provided must be used with the ROHO Hybrid ELITE Cushion.
For best positioning results when using a wheelchair with a sling seat, ROHO, Inc. recommends the
use of the ROHO Contour Base, the ROHO Solid Seat Insert, or a drop seat in conjunction with the
ROHO Hybrid ELITE Cushion.
CLINICIAN CONSULTATION:
ROHO, Inc. recommends that a clinician, such as a physician or therapist experienced in seating and
positioning, be consulted to determine if the ROHO Hybrid ELITE Cushion is appropriate for the user’s
particular seating needs.
CONTRA-INDICATIONS:
The ROHO Hybrid Elite Cushion is not intended for use by individuals who have a Stage III or Stage
IV ischemic ulcer. It is not intended for use by individuals with aggressive postural needs. It is
not intended for use by individuals weighing more than 500 lbs. (225 kg). The ROHO Hybrid ELITE
Cushion must not be used with a cover other than the one provided.
INTENDED USE:
PRODUCT SPECIFICATIONS:
MATERIALS:
The contoured foam base is comprised of water resistant polyethylene closed cell foam.
The cushion insert is made of neoprene rubber with nickel plated brass inflation valve(s).
The cover top layers and side materials are flame resistant polyester. Bottom and valve opening
reinforcements are polyester reinforced PVC. Comfort foam inside the cover is polyurethane.
The ROHO Hybrid ELITE Cushion with cover complies with EN 1021-1 and EN 1021-2 flammability
requirements.
Average product height is 4 in. (10.0 cm).
Average product weight based on a 17.75 in. x 18.5 in. (45.0 cm x 47.0 cm) cushion is 3.5 lbs. (1.5
kg).
NOTE: All measurements are approximate.
For specific cushion sizes, contact ROHO Customer Service at 1-800-851-3449 toll free in the U.S.A.
Outside the U.S.A., contact your country’s ROHO International distributor. For a current list of ROHO
International distributors, visit our website at www.therohogroup.com, contact ROHO International at
1-618-277-9150 or email us at [email protected].
SIZING SPECIFICATIONS:
Assembled Cushion
Smallest Width Smallest Depth Largest Width Largest Depth
13.5 in.
(34.5 cm)
14.25 in.
(36.0 cm)
23.5 in.
(59.5 cm)
20.25 in.
(51.5 cm)

3
CAUTIONS
• CHECK INFLATION AT LEAST ONCE A DAY!
• UNDER-INFLATION: DO NOT use an under-inflated cushion insert. Doing so reduces or eliminates
the cushion’s benefits, increasing risk to the skin and other soft tissue. If cushion insert appears
under-inflated or does not appear to be holding air, see Troubleshooting in this manual. If cushion
insert is still not holding air, contact a clinical caregiver, distributor, or ROHO, Inc. immediately.
• OVER-INFLATION: DO NOT use an over-inflated cushion insert. Doing so will not allow user to sink
into the cushion insert and will reduce or eliminate the cushion’s benefits, increasing risk to the skin
and other soft tissue.
• CUSHION AND COVER ORIENTATION: Product must be used with the provided cover, air cells facing
up, contoured foam area in the front portion of the chair and the cushion insert in the back portion
of the chair. If the cover is not used correctly or if the cover is the wrong size, it may reduce or
eliminate the cushion’s benefits and could increase risk to the skin and other soft tissue.
• PRODUCT USE: DO NOT use the ROHO Hybrid ELITE Cushion in conjunction with any other seat
cushioning products except as indicated in Intended Use section. DO NOT use the components of the
ROHO Hybrid ELITE Cushion separately. DO NOT use the components of the ROHO Hybrid ELITE in
conjunction with any other seat cushioning products.
• DO NOT use cushion as a water flotation device (e.g. a life preserver).
• DO NOT use any pump, cover or repair kit other than those provided by ROHO, Inc. Doing so may
damage the cushion insert and void product’s warranty.
• OBSTRUCTIONS: DO NOT place any obstructions between the user and the cushion or the cushion
insert and the contoured foam. Doing so will reduce product effectiveness.
• WEIGHT LIMIT: The cushion is not intended for use by individuals weighing more than 500 lbs. (225
kg).
• SIZE: The cushion must be properly sized to the user and the wheelchair.
• PRESSURE: Changes in altitude may require adjustment to cushion insert. Check cushion insert
when changing altitude of 1,000 feet (300 meters) or greater.
• PUNCTURE: Keep cushion insert away from sharp objects which may puncture the air cells and
cause deflation.
• HEAT/FLAME: DO NOT expose cushion to high heat, open flames or hot ashes.
• CLIMATE: If a cushion has been in temperatures less than 32ºF / 0ºC and exhibits unusual stiffness,
allow the cushion insert to warm to 72ºF / 22ºC. Open corner air valve(s). Refer to Cover and
Cushion Insert Removal. Roll up the cushion insert and then unroll it until the neoprene is soft and
pliable again. Refer to Cover and Cushion Insert Replacement. Repeat Adjustment Instructions
before using.
• HANDLING: DO NOT use any valve as a handle for carrying or pulling cushion. Carry cushion either
by the cover’s carrying handle or by holding the cushion base.
• SOLUTIONS: DO NOT allow oil-based lotions or lanolin to come in contact with product. Doing so
may degrade materials used in the manufacture of product.
• OZONE GENERATORS: Prolonged exposure to ozone will degrade materials used in the ROHO Hybrid
ELITE Cushion and may affect the product performance and invalidate the product warranty. Avoid
prolonged exposure of the cushion to direct sunlight or other sources of ultraviolet (UV) light.

4
A. Cover: Used to protect cushion. Includes comfort foam sewn inside two-layer top, reinforced
valve openings, carrying handle and non-skid bottom with Velcro® to help secure cushion in chair.
Additional Velcro tabs included if needed.
B. Cushion Insert: Individual interconnected air cells. Velcro on bottom to help secure to contoured
foam base.
C. Inflation Tube: Used to transfer air to and from the cushion insert. Some models may have two
inflation tubes.
D. Inflation Valve: Used to open and close the cushion insert’s airway. Some models may have two
inflation valves.
E. Contoured Foam Base: Enhances stability and helps to position pelvis and thighs. Velcro on top to
help secure cushion insert.
F. Operations Manual: Instructions on adjustment, care, warranty and other important information
about cushion.
G. Repair Kit: Patch kit for minor repairs of the cushion insert.
H. Hand Pump: Used to inflate cushion.
I. Product Registration Card: Used to register product. Complete card and mail to ROHO, Inc. or
register online at www.therohogroup.com.
PARTS DETAIL:
F. Operations
Manual
G. Repair
Kit
H. Hand Pump
I. Product Registration
Card
B. Cushion Insert
E. Contoured Foam Base
A. Cover
C. Inflation Tube(s)
D. Inflation Valve(s)

5
STEP 1: Place ROHO Hybrid ELITE
Cushion in wheelchair seat so the
user will be properly supported and
immersed when in their normal sitting
position. Use the directional patch on
the right side of the cover as a guide.
STEP 2: Turn valve counterclockwise
to open. Slide the pump’s rubber
nozzle over a valve and inflate the
cushion insert until it begins to
slightly arch upward.
STEP 3: Pinch the pump’s nozzle
and turn valve clockwise to close.
Remove pump.
(Repeat steps 2 and 3 for
remaining valve on dual valve
cushion inserts.)
STEP 4: Have the user sit on the
cushion, making sure the boniest
prominences are supported by the
air cells. Check to make sure the
cushion is properly sized to the
user and the wheelchair. Consult a
clinician as needed.
ROHO HYBRID ELITE PLACEMENT AND ADJUSTMENT INSTRUCTIONS:
STEP 5: Slide hand between the
cushion and the user's bottom.
Lift the user’s leg slightly and feel
for the lowest bony prominence*.
Then lower the user’s leg to a
sitting position.
STEP 6: Turn valve counterclockwise
to let out air, while keeping hand under
the user's lowest bony prominence.
Release air until finger tips barely
move – no more than 1 inch (2.5 cm)
and no less than 1/2 inch (1.25 cm).
Turn valve clockwise to close.
(Repeat steps 5 and 6 for remaining
air valve on dual valve cushion
inserts.)
NOTE: DO NOT sit on an improperly inflated cushion insert. Doing so reduces or eliminates the
cushion’s benefits and could increase risk to the skin and other soft tissue. The cushion is most
effective when there is 1/2 inch (1.25 cm) to 1 inch (2.5 cm) of air maintained between the cushion
insert and the user’s lowest bony prominence.
*Dual Compartment Cushion Inserts: Dual compartment cushion inserts may be used for side-to-side
positioning. To maximize the positioning benefits for individuals with a pelvic obliquity, the side with
the deepest bony prominence must be adjusted first. Once both adjustments are made, recheck each
compartment to ensure proper adjustment.
NOTE: Cover not shown for demonstration purposes only. Product must be used with provided cover.

6
COVER AND CUSHION INSERT REMOVAL:
To Remove The Cover:
1. Unzip the zipper.
2. Carefully push the inflation valve(s) back through the valve opening(s) in the cover.
3. Gently remove contoured foam base and cushion insert from cover.
To Remove the Cushion Insert:
1. Gently remove the inflation tube(s) from the groove(s) in the contoured foam base.
2. Extract the inflation tube(s) from the corresponding hole in the foam base corner by gently pushing
and pulling until the entire tube, including the valve, is out.
3. Peel the cushion insert away from the foam base and separate the Velcro strips.
COVER AND CUSHION INSERT REPLACEMENT:
To Replace the Cushion Insert:
1. Place the cushion insert, cell side up, in the cutout section of the contoured foam base with the BACK
of the cushion insert facing the BACK of the foam base. Refer to directional labels.
2. Line up the Velcro strips on the bottom of the cushion insert and top of the foam base then press
firmly to secure.
3. Insert the inflation valve(s) into the corresponding hole on the back corner of the foam base and
carefully push the inflation tube(s) through until the valve(s) protrude on the side.
4. Gently pull the inflation tube(s) toward the front of the cushion until the tube(s) extend the length of
the foam base.
5. Press the inflation tube(s) into the groove(s) in the foam base. Inflation valve(s) must be accessible
in the front of the cushion.
To Replace The Cover:
1. Place cover with non-skid surface side facing DOWN and zipper unzipped. Refer to directional patch
for confirmation of orientation.
2. With the cushion insert placed into the contoured foam base, insert the cushion into the cover FRONT
first, cells up.
3. Reach inside the cover valve openings and carefully pull the inflation valve(s) through the opening(s).
4. Zip the cover. If hook Velcro strips were removed prior to washing, replace the strips.
5. Follow adjustment instructions.
CLEANING AND DISINFECTING PRODUCT:
Cleaning and disinfecting are two separate processes. To be effective, cleaning must precede
disinfecting. Product components must be cleaned and disinfected separately. Product must be cleaned,
disinfected and checked for proper functioning between multiple patient use.
To Clean the Cover: Remove the cover from the cushion. If detachable hook Velcro strips are in
place on bottom of cover, remove prior to washing to help prevent damage to cover or
other fabrics in wash. Machine wash cover in warm water (105°F / 40°C) with mild
detergent, gentle cycle, or wipe clean with neutral detergent and warm water. Tumble
dry low.
To Disinfect the Cover: Hand wash in warm water using 1/2 cup household liquid bleach
per quart of water (125 ml bleach to 1 liter of water), then rinse thoroughly. The cover can
also be machine washed in hot water (140°F / 60°C) to disinfect. Tumble dry low.
NOTE: Follow safety guidelines on bleach container.

7
To Clean the Cushion Insert: Remove the cover from the cushion and the cushion insert from the
contoured foam base (See Cover and Cushion Insert Removal). Deflate the cushion insert and close the
inflation valve(s). Place only the cushion insert in large sink. Use a soft plastic bristle brush, sponge or
washcloth to gently scrub all cushion insert surfaces. ROHO, Inc. suggests using a dishwashing soap,
laundry detergent or other multi-purpose detergent used for general cleaning. For institutional cleaning,
a general housekeeping disinfectant cleaner may be used. Rinse with fresh water. Pat dry with towel or
air dry.
To Disinfect the Cushion Insert: Repeat cleaning instructions using a germicidal that meets infection
control needs (ROHO, Inc. suggests a disinfectant with tuberculocidal properties). A solution of 1/2 cup
liquid household bleach per quart of warm water (125 ml bleach to 1 liter of warm water) can also be
used. Keep the clean cushion insert wet with bleach solution for 10 minutes. Rinse and dry per cleaning
instructions. NOTE: Most germicidal disinfectants are safe for use with the cushion insert if used
following the disinfectant manufacturer’s dilution directions.
To Sterilize the Cushion Insert: ROHO, Inc. highly discourages sterilization methods using temperatures
greater than 200°F / 93°C. High temperatures accelerate aging and may cause damage to the cushion
insert. If institution protocol demands sterilization, open the valves and use the lowest temperature
possible for the shortest time possible. Gas sterilization is preferable to steam autoclave, but neither is
recommended. If steam autoclaving, make sure all valves are open.
NOTE: DO NOT use oil-based lotions, lanolin, or phenolic-based disinfectants on cushion insert. Doing so
may compromise the integrity of the neoprene.
To Clean the Contoured Foam Base Surface: Wipe lightly with a damp cloth. DO NOT use soap. DO NOT
submerge in water. Wipe off with a clean cloth. Let completely air dry before reassembly.
NOTE: Disinfectants are not effective on porous surfaces such as foam. If the foam becomes soiled or
contaminated, DO NOT use with multiple users. Replacement foam parts may be purchased. Replace with
ROHO foam parts only.
TROUBLESHOOTING:
Cushion Insert Not Holding Air: First, make sure all valves are closed tightly by turning clockwise. If
still not holding air, visibly check for holes. If no holes are visible, close all valves and immerse ONLY the
inflated cushion insert in sink or tub of water and look for air bubbles.
If ‘pin-hole’ sized holes are found, see “Minor Repairs” below. If large holes or other leaks are found, see
“Limited Warranty”.
Cushion is Uncomfortable/Unstable: Make sure cushion insert is not over-inflated (see Placement and
Adjustment Instructions). Make sure air cells, contoured foam base, and the cover’s stretch top are facing
UP*. Make sure the FRONT of the contoured foam is facing the front of the chair and the cushion insert
is in the back portion of the chair. Make sure cushion is not too big or too small for the wheelchair. Allow
the user to sit on the cushion for at least one hour to get used to the texture of the product’s surfaces and
immersion into the air cells.
Cushion Slides On Wheelchair: Make sure non-skid bottom of the cushion cover is facing DOWN*.
*NOTE: Use directional labels as guides.
Minor Repairs:
If cushion insert develops a small leak, use the repair kit that came with product and follow repair kit
instructions.

8
RETURN POLICY:
All products returned must be new and unused, require prior authorization from ROHO, Inc. and are
subject to a restocking charge. Before returning product, contact our Customer Service Department at
1-800-851-3449 toll free in the U.S.A.
Outside the U.S.A., contact your country’s ROHO International distributor. For a current list of ROHO
International distributors, visit our website at www.therohogroup.com, contact ROHO International at
1-618-277-9150 or email us at [e-mail].
DISPOSAL:
When properly used and disposed, there are no known environmental hazards associated with
the components of the ROHO Hybrid ELITE Cushion. Dispose of the product and/or components in
accordance with the applicable regulations in your jurisdiction. DO NOT INCINERATE.
LIMITED WARRANTY:
What is covered?
ROHO, Inc. covers any defects in materials or workmanship of the product.
For how long?
24 months from the date the product was originally purchased, with the exception of the cover, which
has a 6-month Limited Warranty.
What is not covered?
A product that has been misused, damaged by an accident, or damaged from "an act of Nature", e.g.,
flood, tornado, earthquake, fire. Any substitutions of supplied hardware or modification to the product
will void the warranty.
What the customer must do.
Within the U.S.A., the customer must contact ROHO, Inc. Warranty Department at 1-800-851-3449
toll free. Outside the U.S.A., contact your country’s ROHO International distributor. For a current
list of ROHO International distributors, visit our website at www.therohogroup.com, contact ROHO
International at 1-618-277-9150 or email us at [e-mail].
Questions?
Call our Warranty Department toll free from the U.S.A. at 1-800-851-3449. Outside the U.S.A.,
contact your country’s ROHO International distributor. For a current list of ROHO International
distributors, visit our website at www.therohogroup.com, contact ROHO International at
1-618-277-9150 or email us at [e-mail].
Disclaimer.
Any implied warranties, including the MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE are
limited to the same time period of the product types referenced above in the "For How Long" section and
any action for a breach of such warranties or any express warranties herein must be commenced within
that time. ROHO, Inc. shall not be responsible for any incidental or consequential damages with respect to
economic loss to property, whether as a result of a breach of express or implied warranties or otherwise.
Your Rights and the Effect of this Warranty upon Them
This warranty restricts the duration of all implied warranties as noted above and limits or excludes recovery
for incidental or consequential damages. Some jurisdictions do not allow limitations on how long implied
warranties will last and some jurisdictions do not allow the exclusion or limitation of consequential or
incidental damages, so those provisions may not apply to you. While this warranty gives you specific legal
rights, you may also have other rights which vary from jurisdiction to jurisdiction.

23
100 North Florida Avenue
Belleville, IL 62221-5429 U.S.A.
www.therohogroup.com [email protected]
U.S.A.: 1-800-851-3449 Fax [phone]
Outside the U.S.A.: 1-618-277-9150 Fax [phone]
T20192 11/09
A L L I A N C E
A PRODUCT SUPPORTED BY:
