Rola HOLDEN RMX Series User manual

Fig. 8
1
3
PUSH ASSEMBLY
DOWNWARDS This side is already
ATTACH
STRAP
FLEX STRAP
AROUND DOOR RETURN
2
Fig 3b.
‘B’ PILLAR
Front
ALLEN KEY
ANCHOR POINT
BOLT
SOME FITMENTS
MAY ALSO
FEATURE THE
FOLLOWING
COMPONENTS: BOTTOM STRAP
BRACKET BOLT COVER
x1 x4
x4 x4
REPRESENTATIVE
ONLY
Issue B
RMX Series Roof Racks
HOLDEN
Commodore Sedan ZB 10/17 ON
RMX441
CARRYING CAPACITY 50 kg
END SUPPORT
(RIGHT)
MOUNT PAD
(RIGHT)
END SUPPORT
(LEFT)
MOUNT PAD
(LEFT)
SNAP-ON
COVER
SECURITY
COVER
STRAP
BRACKET
SCREW SECURITY
BOLT
SECURITY
BOLT
ASSEMBLY
KEY CROSS-BAR ASSEMBLY
x2 x2 x2 x2 x4 x4 x4 x4 x4 x4 x1
x2
REPRESENTATIVE
ONLY
REPRESENTATIVE
ONLY
REPRESENTATIVE
ONLY
Please Note: You will require the following tools
Rubber Mallet Safety Knife
Phillips Head Screwdriver Flat Head Screwdriver
All straps are the same
GENERIC
STRAP FOR
REFERENCE
ONLY
GENERIC
STRAP FOR
REFERENCE
ONLY
ALTERNATIVE COVERIF APPLICABLE
ASSEMBLY OF CROSS-BARS
1. Ensure the roof is clean, free from dust and grease.
accessed.(Fig. 2) Using a Phillips Head Screwdriver, fasten the screw through
the cross-bar and into the End Support.
NOTE:
labelling on the underside of the cross-bar.
Screw hole
Screw
Fig. 5 Fig. 6
Fig. 7
Fig. 3a - IF APPLICABLE Fig. 3b
Fig 4a.
Fig. 9
FITTING CROSS-BARS TO VEHICLE
4. Identify your Strap Brackets
markings on them (if applicable) - refer to Fig 3 & Fig. 4
Place the Cross-bar assemblies (Front & Rear) in their respective positions onto
the pads.
5. Next, open all 4 vehicle doors and leave them ajar whilst mounting and
fastening the strap brackets.
Ensuring the strap brackets correspond with their position on the vehicle,
proceed to fasten the Front Right Strap brackets through the End Support
using the security bolt provided. (Fig. 5) The Strap Bracket should intimately
cup around the vehicle roof body in the door under-hang area.
6. Go around to the left side of the car and lift up the Cross-bar Assy away from
the Mount Pad and roof body of the car. (Refer to Fig. 8)
Next, attach the Strap Bracket into the End Support using the security bolt
- whilst still holding the Cross-bar Assy away from the roof.
7. As you bring the Cross-bar Assy and connected strap down onto the vehicle
in its intended position - cupping the door underhang.
- Please be careful as not to stratch/damage the paint when
installing the strap brackets.
8. Insert the anchor bolt through the strap and tighten in the anchor
point hole (Fig. 7).
9. Tighten the Strap Brackets via the Security Bolts whilst pushing the straps
hard up against the vehicle body. Alternate sides whilst tightening for even
retention across both sides.
10. Proceed to follow steps 5 to 8 when mounting the Rear Cross-bar Assy.
11. You are now ready to mount your“Accessories”set onto the cross-bars
using the Global Mount Channel. Once installed, insert the ‘Global Channel’
Covers into the End Supports.
Note: You have a choice of 2 - (a) quick access snap-on cover or (b) long term
1
2
3
page 1 of 2
Security
Cover
Quick Access
Snap-on Cover
Anchor
point
Anchor
point
Position your mount pads on the roof over the anchor point holes (Fig 4a.)

page 2 of 2
RMX, PMX, TMX, TBX Series Roof Racks
RBX
For full warranty information, visit our website: www.rola.com.au
General Usage Information
Warnings
APPENDICES & ADDITIONAL ‘FITMENT SPECIFIC’ FITTING STEPS - IF REQUIRED
INSERTING COVERS
This area has been intentionally left blank.
It is essential for the proper assembly, operation and use of the Roof Rack that the instructions and safety precautions
supplied are strictly observed. Read any fitting, care and usage instruction carefully.
The maximum permissible load for your Roof Bar is the lower of the maximum load capacity specified in your vehicle opera-
tion manual, or specified as applying to the Roof-Rack. Do not exceed the maximum specified load capacity.
Maximum permissible load = weight of the Roof Rack + weight of accessories + weight of load (cargo).
When fitting the Roof-Rack and transporting a load, ensure the vehicle’s functions are not impaired (eg, sunroof, aerials,
windscreen wipers, mirrors). Rear doors on Hatch- and Wagon-type vehicles should be inspected for adequate clearance for
full opening operation of the boot/tailgate.
Stop and check all screw connections, bolts and retaining straps after a short distance of travel.Repeat these checks at regular
intervals.
Remember that the fitting of a Roof Rack and the transport of a load increases the overall height of the carrying vehicle.
Where the Roof-Rack is to be used in off-road conditions, a safety weight reduction of 1.5 should be observed from the total
carrying capacity. (eg. 60kg becomes 40kg)
Cequent will not be liable to the purchaser or any other person for any consequential, incidental, direct or indirect loss,
damage or costs incurred of suffered by the purchaser or any other person including but not limited to damage to persons or
property, loss of turnover, loss of profits, loss of business or goodwill, arising from or in relation to the assembly and use of the
Roof rack, or the non-observance of the fitting and care instructions.
