Roland VR-3 Service manual

Remote Control Reference
The VR-3 supports remote control via MIDI. This document describes settings for remote control.
Copyright © 2011 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the written
permission of ROLAND CORPORATION.
1PS

2
Contents
About Remote Control Modes .......................................................................3
MIDI Setup Menu ............................................................................................4
Receiving the Remote Control Messages .....................................................7
Sending the Messages to an External MIDI Device......................................8
MIDI Implementations ...................................................................................9
1. MIDI Messages Received at MIDI IN ............................................................................................. 9
1-1. Standard Mode ...................................................................................................................................9
1-2. MIDI Visual Control Mode.............................................................................................................12
1-3. V-LINK Mode ......................................................................................................................................14
1-4. Common Messages for All Modes .............................................................................................16
2. MIDI Messages Transmitted from MIDI OUT...........................................................................18
2-1. Transmission of the Received Messages .................................................................................18
2-2. Transmission of the Generated Messages ..............................................................................18
Parameter Address Map......................................................................................................................21
3-1. MIDI Visual Control..........................................................................................................................21
3-2. V-LINK...................................................................................................................................................22
4. Appendices .........................................................................................................................................23

3
About Remote Control Modes
You can remotely control the VR-3 from an external MIDI device such as a keyboard. You can also send operational status updates
from the VR-3 to another MIDI device.
There are three remote control modes.
Standard Mode
This is the exclusive MIDI remote control mode of the VR-3. You can remotely control the following operations of the VR-3 with an
external MIDI device.
• Audio level
• Transition select
• On/Off of key composition
• Setup of transition or key parameters
• Output fade
• Channel selection
MIDI Visual Control (MVC) Mode
MIDI Visual Control (MVC) is a new world-wide standard of MIDI. It aims to link music and video during live performances. By
connecting the two devices via MDI, you can remotely control the VR-3 with an electronic musical instrument in time to the music
or audio. The VR-3 switches to MVC mode when it receives an MVC "On" command from a MIDI device. .
* When the VR-3 receives MVC OFF message, the remote control mode automatically returns to standard mode.
V-LINK Mode
V-LINK is a Roland original feature to link music and visual performances. You can remotely control the VR-3 via a MIDI connection
from another V-LINK enabled Roland product.
The VR-3 can turn on its V-LINK mode when it receives a V-LINK "on" command from another Roland V-LINK enabled product.
* When the VR-3 receives the V-LINK OFF message, the remote control mode automatically returns to standard mode.

4
MIDI Setup Menu
You can modify the MIDI remote control settings of the VR-3 from [MIDI] in [SYSTEM] menu.
* For menu operations and menu items, refer to [Menu Operations and Menu List] in the owner’s manual.
COM : Setup Menu
Make settings common to the three MIDI modes.
COM : MIDI OUT
When set to OUT, the MIDI OUT jack will send messages generated by the VR-3. When set to THRU, all incoming MIDI messages
will be re-transmitted to the MIDI OUT jack.
COM : Tx CHANNEL
This sets the Tx channel for output of MIDI messages.
STD : Setup Menu
Set items here for standard mode.
STD : Rx CHANNEL
This sets the Rx channel of MIDI messages. If this is [OFF], the channel voice messages of standard mode will not be received.
STD : VIDEO SEL TYPE
This sets the method of video channel switching as below.
VLNK
With this method, you can switch using bank select (BS) and program change (PC). See below for channel selection.
PC 1 PC 2 PC 3 PC 4
BS MSB:0 LSB:0 Video 1 Video 2 Video 3 Video 4
BS MSB:1 LSB:0 Sub Video 1 Sub Video 2 Sub Video 3 Sub Video 4
* Sub Video is the channel for composition.
AR
With this method, you can switch using program change (PC) and note on. See below for channel selection.
PC Note No. Assign
21 0-3 Video 1-4
22 0-3 Sub Video 1-4
* Sub Video is the channel for composition.

5
MIDI Setup Menu
MVC : Setup Menu
You can perform settings for MIDI Visual Control (MVC) mode here. These settings are valid when the VR-3 is placed in MVC mode
by an MVC ON message; these settings will not affect similar settings made in Normal mode.
If you find a value is "DFLT xxx", this is the typical value specified by the MVC standard. It can also mean the value previously
specified by an MVC setup message. TWhen the unit receives an MVC OFF message, any previously sent MVS setup data will
revert to the default values of the MVC standard. This will also occur when you power cycle the VR-3.
If you have selected the value other than [DFLT] in the menu, the MVC setup message will be ignored and the value you have set
in the menu will take priority.
MVC : DEVICE ID
This sets Device ID to receive MVC message.
MVC : CLIP CTRL CH
This sets Rx channel for video switching.
MVC : NOTE CTRL MODE
This sets control mode when you switch video channels using note messages.
MVC : NOTE CTRL UPPKEY
This sets the upper key of the note when you switch video channels using note messages.
MVC : NOTE CTRL LOWKEY
This sets the lower key of the note when you switch video channels using note messages.
MVC : TRANSITION TIME
This sets assignment of the transition time control.
MVC : TRANSITION SEL
This sets assignment of the transition type selection. (You cannot select [DFLT] as this is out of the standard.)
MVC : AUDIO LEVEL CTRL
This sets assignment of the output audio level control. (You cannot select [DFLT] as this is out of the standard.)
MVC : COLOR CTRL CH
This sets the Rx channel of the video output fade control.
MVC : OUTPUT FADE CTRL
This sets assignment of the video output fade control. (You cannot select [DFLT] as this is out of the standard.)

6
MIDI Setup Menu
V-L : Setup Menu
You can perform settings for the V-LINK mode. These settings will go into effect when the VR-3 receives a V-LINK ON message;
these settings will not affect settings made for normal mode.
If you find a value is "DFLT xxx", this is the typical value specified by the V-LINK standard. It can also mean the value previously
specified by a V-LINK setup message. When the unit receives a V-LINK OFF message, any previously sent V-LINK setup data will
revert to the default values of the V-LINK standard. This will also occur when you power cycle the VR-3.
If you have selected the value other than [DFLT] in the menu, the V-LINK setup message will be ignored and the value you have
set in the menu will take priority.
V-L : DEVICE ID
This sets Device ID to receive V-LINK message.
V-L : CLIP CTRL CH
This sets Rx channel for video switching.
V-L : NOTE CTRL MODE
This sets control mode when you switch video channels using note messages.
V-L : NOTE CTRL UPPKEY
This sets the upper key of the note when you switch video channels using note messages.
V-L : NOTE CTRL LOWKEY
This sets the lower key of the note when you switch video channels using note messages.
V-L : TRANSITION TIME
This sets assignment of the transition time control.
V-L : TRANSITION SEL
This sets assignment of the transition type selection.
V-L : AUDIO LEVEL CTRL
This sets assignment of the output audio level control.
V-L : COLOR CTRL CH
This sets the Rx channel of the video output fade control.
V-L : OUTPUT FADE CTRL
This sets assignment of the video output fade control.

7
Receiving the Remote Control Messages
Receiving in Standard Mode
In order to receive remote control messages, set parameters as below.
COM : MIDI OUT
* If you are connecting multiple VR-3 units in a chain, set this to [THRU].
STD : Rx CHANNEL
* Set this value according to the master device channel.
You can remote control the following functions from an external MIDI device.
• Volume control of the audio mixer 1-4, 5/6, 7/8 and internal mic.
• Volume control of master audio output and USB output.
• Selection of input video channel.
• Selection of video channels for compositions.
• Output fade of the video.
• Selection of the transition effect.
• Adjustment of transition time.
• Selection of the composition effect and On/Off.
• Adjustment of key level
• On/Off of the freeze function.
* For corresponding MIDI messages, refer to “MIDI Implementations” (p. 9).
Receiving in MVC Mode
In order to receive remote control messages, set parameters as below.
COM : MIDI OUT
* If you are connecting multiple VR-3 units in a chain, set this to [THRU].
MVC : DEVICE ID MVC
* Set this value according to the master device channel.
You can remote control the following functions from a device supporting MVC after sending MVC ON message to the VR-3.
• Volume control of the master output.
• Selection of input video channel.
• Output fade of the video.
• Selection of the transition effect.
• Adjustment of transition time.
* For corresponding MIDI messages, refer to “MIDI Visual Control Mode” (p. 12) in “MIDI Implementations”.
Receiving in V-LINK Mode
In order to receive remote control messages, set parameters as below.
COM : MIDI OUT
* If you are connecting multiple VR-3 units in a chain, set this to [THRU].
V-L : DEVICE ID V-LINK
* Set this value according to the master device channel.
You can remote control the following functions from a device supporting V-LINK after sending V-LINK ON message to the VR-3.
• Volume control of the master output.
• Selection of input video channel.
• Output fade of the video.
• Selection of the transition effect.
• Adjustment of transition time.
* For corresponding MIDI messages, refer to “V-LINK Mode” (p. 14) in “MIDI Implementations”.

8
Sending the Messages to an External MIDI Device
If you are sending MIDI messages to an external MIDI device from the VR-3, set parameters as below.
COM : MIDI OUT
* Set this to [OUT].
COM : Tx CHANNEL
* Select the Tx channel.
You can send MIDI messages corresponding to the panel operations of the VR-3 as below.
• Controlling the volume of audio mixer 1-4, 5/6, 7/8 and internal mic.
• Controlling of the master and USB output volume.
• Selection of the video channel.
• Controlling of the output fade.
• Selection of the transition effect type.
• Adjustment of the transition time.
• Selection of the composition effect and turning On/Off.
• Adjustment of the key level.
• Turning On/Off of the freeze function.
* For corresponding MIDI messages, refer to “2. MIDI Messages Transmitted from MIDI OUT” (p. 18) in “MIDI Implementations”.

9
MIDI Implementations
Model : VR-3
Version : 1.00
Date : December 10. 2011
Symbol Item 1Setting Range
————————————————————————————————————————————
n : MIDI Channel 0H-FH(ch.1 - ch.16)
vv : Control Value, Velocity Value etc. 00H-7FH(0 - 127)
(If note on velocity, it changes to 01H-7FH(1 - 127).)
(If there is a center value, 40H(64) should be the center.)
kk : Note Number 00H-7FH(0 - 127)
xx : Turning ON/OFF 00H-3FH(0 - 63) : OFF
40H-7FH(64 - 127) : ON
————————————————————————————————————————————
* If [OFF] is selected as STD:Rx CHANNEL value, the following channel voice messages will not be received.
■Channel Voice Messages
●Note On
Status 2nd Byte 3rd Byte
———- ——— ———
9nH kkH vvH
* This is received when the VIDEO SEL TYPE is [AR].
* In combination with program change, this switches the video input to the channel corresponding to the note number.
* Unselectable note number or velocity will be ignored.
* For corresponding combination of program change/note number and the video channels, refer to “STD:VIDEO SEL TYPE” (p. 4).
●Control Change
❍Bank Select (Controller Number 0,32)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 00H mmH
BnH 20H llH
mm,ll = Bank Number : 00 00H, 01 00H (Main, Composition)
* This is received when the VIDEO SEL TYPE is [VLINK].
* You can select a channel for main video input or a channel for composition.
* Unselectable bank select will be ignored and only the program change will be received.
* The received bank select information will be kept until a new bank select message is received.
* For corresponding combination of bank select/program change and the video channels, refer to “STD:VIDEO SEL TYPE” (p. 4).
❍Panpot (Controller Number 10)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 0AH vvH
* This controls [1] slider of the audio mixer.
❍Expression (Controller Number 11)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 0BH vvH
* This controls [2] slider of the audio mixer.
1. MIDI Messages Received at MIDI IN
1-1. Standard Mode

10
MIDI Implementations
❍Effect Control 1 (Controller Number 12)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 0CH vvH
* This controls [3] slider of the audio mixer.
❍Effect Control 2 (Controller Number 13)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 0DH vvH
* This controls [4] slider of the audio mixer.
❍Undefined (Controller Number 14)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 0EH vvH
* This controls [5/6] slider of the audio mixer.
❍Undefined (Controller Number 15)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 0FH vvH
* This controls [7/8] dial of the audio mixer.
❍General Purpose Controllers 1 (Controller Number 16)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 10H vvH
* This controls [INTERNAL MIC LEVEL] dial of the audio mixer.
❍General Purpose Controllers 2 (Controller Number 17)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 11H vvH
* This controls [MASTER] slider of the audio mixer.
❍General Purpose Controllers 3 (Controller Number 18)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 12H vvH
* This controls [USB LEVEL] dial of the audio mixer.
❍General Purpose Controllers4 (Controller Number 19)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 13H ttH
tt = Transition Select : 00H - 02H (CUT, MIX, WIPE)
* This selects the type of transition effect.
❍Undefined (Controller Number 20)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 14H vvH
* This adjusts the transition time.

11
MIDI Implementations
❍Hold 1 (Controller Number 64)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 40H ccH
cc = Composition Select : 00H-03H (OFF, PinP, SPLIT, KEY)
* This selects the type of composition effect.
❍Portamento (Controller Number 65)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 41H vvH
* This controls the key level.
❍Sostenuto (Controller Number 66)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 42H vvH
* This controls the [OUTPUT FADE] dial.
❍Soft (Controller Number 67)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 43H xxH
* This turns on/off the [FREEZE] button.
●Program Change
Status 2nd Byte
———- ———
CnH ppH
pp = Program Number : 00H - 7FH (1 - 128)
* In combination with bank select or note on, this switches the video input to the corresponding channel.
* Unselectable program change will be ignored.
* For corresponding combination of program change/note on and the video channels, refer to “STD:VIDEO SEL TYPE” (p. 4).

12
MIDI Implementations
■Channel Voice Messages
●Note On
Status 2nd Byte 3rd Byte
———- ——— ———
9nH kkH vvH
* This is received when MVC Note Message Enabled parameter is turned on.
* This selects the video channel corresponding to the note number.
* The setting range of note number is fixed by parameters of Keyboard Range Upper and Lower.
* Unselectable note number or velocity will be ignored.
●Control Change
❍Bank Select (Controller Number 0,32)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 00H mmH
BnH 20H llH
mm,ll = Bank Number : 00 00H, 01 00H (Main, Composition)
* This selects main or composition video channel.
* Unselectable bank select will be ignored and receives program change only.
* The received bank select information will be kept until a new bank select message is received.
* For corresponding combination of bank select/program change and the video channels, refer to Program Change.
❍General Purpose Controllers (Controller Number 1-31, 64-95)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH ccH vvH
cc = Controller Number : 00H-1FH, 40H-5FH
* It is possible to assign the functions below.
• Transition Time control.
• MASTER volume control. (This is out of the MVC spec and should be manually set in the VR-3 menu. )
• Output fade control. (This is out of the MVC spec and should be manually set in the VR-3 menu. )
• Transition type select. (This is out of the MVC spec and should be manually set in the VR-3 menu. )
●Program Change
Status 2nd Byte
———- ———
CnH ppH
pp = Program Number : 00H - 7FH (1 - 128)
* In combination with bank select, this switches to the corresponding video channel.
* Unselectable program change will be ignored.
* The combination of bank select/program change and the corresponding video channel are as below.
PC 1 PC 2 PC 3 PC 4
BS MSB:0 LSB:0 Video 1 Video 2 Video 3 Video 4
BS MSB:1 LSB:0 Sub Video 1 Sub Video 2 Sub Video 3 Sub Video 4
* Sub Video is the channel for composition.
1-2. MIDI Visual Control Mode

13
MIDI Implementations
●Channel Pressure
Status 2nd Byte
———- ———
DnH vvH
* Following functions can be assigned using the MVC parameters.
• Transition time control.
• MASTER volume control. (This is out of the MVC spec and should be manually set in the VR-3 menu. )
• Output fade control. (This is out of the MVC spec and should be manually set in the VR-3 menu. )
• Transition type select. (This is out of the MVC spec and should be manually set in the VR-3 menu. )
●Pitch Bend Change
Status 2nd Byte 3rd Byte
———- ——— ———
EnH llH mmH
mm,ll = Pictch bend value : 00 00H - 40 00H - 7F 7FH (-8192 - 0 - +8191)
* Following functions can be assigned using the MVC parameters.
• Transition time control.
• MASTER volume control. (This is out of the MVC spec and should be manually set in the VR-3 menu. )
• Output fade control. (This is out of the MVC spec and should be manually set in the VR-3 menu. )
• Transition type select. (This is out of the MVC spec and should be manually set in the VR-3 menu. )

14
MIDI Implementations
■Channel Voice Messages
●Note On
Status 2nd Byte 3rd Byte
———- ——— ———
9nH kkH vvH
* This is received when [Assignable] is selected as V-LINK Note Message Enabled value.
* This selects the video channel corresponding to the note number.
* The note number range is specified by values of V-LINK Keyboard Upper and Lower.
* Unselectable note number and velocity will be ignored.
■Control Change
❍Bank Select (Controller Number 0,32)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 00H mmH
BnH 20H llH
mm,ll = Bank Number : 00 00H, 01 00H (Main, Composition)
* This selects main or composition video channel.
* Unselectable bank select will be ignored and receives program change only.
* The received bank select information will be kept until a new bank select message is received.
* For corresponding combination of bank select/program change and the video channels, refer to Program Change.
❍General Purpose Controllers (Controller Number 1-31, 64-95)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH ccH vvH
cc = Controller Number : 00H-1FH, 40H-5FH
* Following functions can be assigned using the V-LINK parameters.
• Transition time control.
• MASTER volume control.
• Output fade control.
• Transition type select.
●Program Change
Status 2nd Byte
———- ———
CnH ppH
pp = Program Number : 00H - 7FH (1 - 128)
* In combination with bank select, this switches to the corresponding video channel.
* Unselectable program change will be ignored.
* See below for the combination of bank select/program change and the corresponding video channel.
PC 1 PC 2 PC 3 PC 4
BS MSB:0 LSB:0 Video 1 Video 2 Video 3 Video 4
BS MSB:1 LSB:0 Sub Video 1 Sub Video 2 Sub Video 3 Sub Video 4
* Sub Video is the channel for composition.
1-3. V-LINK Mode

15
MIDI Implementations
●Channel Pressure
Status 2nd Byte
———- ———
DnH vvH
* Following functions can be assigned using the V-LINK parameters.
• Transition time control.
• MASTER volume control.
• Output fade control.
• Transition type select.
●Pitch Bend Change
Status 2nd Byte 3rd Byte
———- ——— ———
EnH llH mmH
mm,ll = Pitch Bend Value : 00 00H - 40 00H - 7F 7FH (-8192 - 0 - +8191)
* Following functions can be assigned using the V-LINK parameters.
• Transition time control.
• MASTER volume control.
• Output fade control.
• Transition type select.

16
MIDI Implementations
■System Exclusive Messages
Status Data Byte Status
———- ————– ———-
F0H iiH,ddH,...,eeH F7H
F0H : Status of the system exclusive message.
ii = ID number : This is to specify the manufacturer of the product that generates the message. The manufacture ID of Roland is
41H. The ID numbers of 7EH and 7EF are the expansion of MIDI standard and used as universal non-realtime message (7EH) and
universal realtime message (7FH).
dd,...,ee = data : 00H - 7FH (0 - 127)
F7H : EOX (End of Exclusive)
●MIDI Visual Control Message
Status Data Byte Status
———- ————– ———-
F0H 7EH, dev, 0CH, 01H, F7H
aaH, bbH, ccH, ddH, ...,eeH, sum
Byte Explanation
—— —-
F0H System Exclusive Status
7EH Universal System Exclusive Non-Realtime Header
dev Device ID (devÅF00H - 1FH; MVC default = 00H)
0CH Sub ID #1 (MIDI Visual Control)
01H Sub ID #2 (MVC command set ID; 01H = “Version 1.0”)
aaH Upper byte of the address
bbH Address
ccH Address
ddH Actual Data : The data body. The data of multiple bytes should be submitted in address order.
: :
eeH Data
sum Checksum
F7H EOX (End of Exclusive)
* Refer to “3-1 MIDI Visual Control” for the address and data.
* Refer to the “4. Appendices” (p. 23) for the address, size or checksum calculation.
* Data exceeding 256 bytes should be divided into packets smaller than 256 bytes. If you send sequentially, the intervals of packets should be
longer than 20 ms.
1-4. Common Messages for All Modes

17
MIDI Implementations
●V-LINK Messages
Status Data Byte Status
———- ————– ———-
F0H 41H, dev, 00H, 51H, 12H, F7H
aaH, bbH, ccH, ddH, ...,eeH, sum
Byte Explanation
—— —-
F0H Exclusive Status
41H ID Number (Roland)
dev Device ID (dev : 00H - 1FH ; default is 10H)
00H 1st byte of model ID (V-LINK)
51H 2nd byte of model ID (V-LINK)
12H Command ID (DT1)
aaH Upper byte of the address
bbH Address
ccH Address
ddH Actual Data : The data body. The data of multiple bytes should be submitted in address order.
: :
eeH Data
sum Checksum
F7H EOX (End of Exclusive)
* Refer to “3-2. V-LINK” (p. 22) for address and data.
* Data exceeding 256 bytes should be divided into packets smaller than 256 bytes. If you send sequentially, the intervals of packets should be
longer than 20 ms.

18
MIDI Implementations
When COM:MIDI OUT is [THRU], this unit transmits the received messages.
When COM:MIDI OUT is [OUT], this unit generates and transmits the messages as below.
■Channel Voice Messages
●Note Off
Status 2nd Byte 3rd Byte
———- ——— ———
8nH kkH 40H
* Transmits the same note number when note on is transmitted.
●Note On
Status 2nd Byte 3rd Byte
———- ——— ———
9nH kkH 40H
* Transmits when [AR] is selected as VIDEO SEL TYPE.
* When video switching is performed, note number is transmitted after program change.
* For corresponding combination of bank select/program change and the video channels, refer to “STD:VIDEO SEL TYPE” (p. 4).
●Control Change
❍Bank Select (Controller Number 0,32)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 00H mmH
BnH 20H llH
mm,ll = Bank Number : 00 00H, 01 00H (bank.1, bank.2)
* Transmits when [VLINK] is selected as VIDEO SEL TYPE.
* When video switching is performed, bank number is transmitted prior to program change.
* For corresponding combination of bank select/program change and the video channels, refer to “STD:VIDEO SEL TYPE” (p. 4).
❍Panpot (Controller Number 10)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 0AH vvH
* Transmits value when [1] slider of the audio mixer is controlled.
❍Expression (Controller Number 11)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 0BH vvH
* Transmits value when [2] slider of the audio mixer is controlled.
❍Effect Control 1 (Controller Number 12)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 0CH vvH
* Transmits value when [3] slider of the audio mixer is controlled.
2. MIDI Messages Transmitted from MIDI OUT
2-1. Transmission of the Received Messages
2-2. Transmission of the Generated Messages

19
MIDI Implementations
❍Effect Control 2 (Controller Number 13)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 0DH vvH
* Transmits value when [4] slider of the audio mixer is controlled.
❍Undefined (Controller Number 14)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 0EH vvH
* Transmits value when [5/6] slider of the audio mixer is controlled.
❍Undefined (Controller Number 15)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 0FH vvH
* Transmits value when [7/8] dial of the audio mixer is controlled.
❍General Purpose Controllers1 (Controller Number 16)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 10H vvH
* Transmits value when [INTERNAL MIC LEVEL] dial of the audio mixer is controlled.
❍General Purpose Controllers2 (Controller Number 17)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 11H vvH
* Transmits value when [MASTER] slider of the audio mixer is controlled.
❍General Purpose Controllers3 (Controller Number 18)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 12H vvH
* Transmits value when [USB AUDIO] dial of the audio mixer is controlled.
❍General Purpose Controllers4 (Controller Number 19)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 13H ttH
tt = Transition Select : 00H - 02H (CUT, MIX, WIPE)
* Transmits value when [TRANSITION] button is controlled.
❍Undefined (Controller Number 20)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 14H vvH
* Transmits value when transition time is changed.
❍Hold 1 (Controller Number 64)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 40H ccH
cc = Composition Select : 00H-03H (OFF, PinP, SPLIT, KEY)
* Transmits value when [COMPOSITION] button is controlled.

20
MIDI Implementations
❍Portamento (Controller Number 65)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 41H vvH
* Transmits value when [KEY LEVL] dial is controlled.
❍Sostenuto (Controller Number 66)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 42H vvH
* Transmits value when [OUTPUT FADE] dial is controlled.
❍Soft (Controller Number 67)
Status 2nd Byte 3rd Byte
———- ——— ———
BnH 43H xxH
* Transmits value when [FREEZE] button is controlled.
●Program Change
Status 2nd Byte
———- ———
CnH ppH
pp = Program Number : 00H - 7FH (1 - 128)
* When video switching is performed, program number is transmitted together with bank select or note on.
* For corresponding combination of bank select/program change and the video channels, refer to “STD:VIDEO SEL TYPE” (p. 4).
* For corresponding combination of program change/note on and the video channels, refer to “STD:VIDEO SEL TYPE” (p. 4).
■System Realtime Messages
●Active Sensing
Status
———-
FEH
* Transmitted with approximately 250 ms intervals.
