Roland v-1hd User manual

Remote Control Guide
Copyright © 2015 ROLAND CORPORATION
Contents
MIDI Control Modes of the V-1HD .................................2
SETUP Menu.....................................................2
Receiving the Remote Control Messages ..........................3
Sending the Messages to an External MIDI Device .................4
MIDI Implementation ............................................5
This manual describes the settings used when remotely operating the
V-1HD via MIDI.

2
MIDI Control Modes of the V-1HD
The V-1HD supports remote control via an external MIDI device. MIDI remote control for the V-1HD comprises the following three modes.
MEMO
You can also operate the V-1HD to send MIDI messages to an external MIDI device. The output MIDI messages are shared by the three modes.
Standard Mode
This is the MIDI remote-control mode specic to the V-1HD. You use it when remotely operating the V-1HD from a keyboard or other external MIDI
device.
MIDI Visual Control (MVC) Mode
This is the mode for remote controlling the V-1HD from an external MVC (MIDI Visual Control) device.
MIDI Visual Control (MVC) is a new world-wide standard of MIDI. It aims to link music and video during live performances. By connecting the two
devices via MIDI, you can remotely control the V-1HD with an electronic musical instrument in time to the music or audio. The V-1HD switches to MVC
mode when it receives an MVC“On” command from a MIDI device.
V-LINK Mode
This is the mode for remote controlling V-1HD from an external V-LINK device.
V-LINK is a Roland original feature to link music and visual performances. You can remotely control the V-1HD via a MIDI connection from another
V-LINK enabled Roland product.
The V-1HD can turn on its V-LINK mode when it receives a V-LINK “On” command from another Roland V-LINK enabled product.
SETUP Menu
Detailed settings for MIDI remote control are made via the SETUP menu on the V-1HD. Press the [MENU] button to display the MIDI menu.
Setting item Value Explanation
MIDI Rx SOURCE USB, MIDI IN This sets the connector for receiving MIDI messages. MIDI Rx SOURCE MIDI OUT
V-1HD
MIDI IN
USB MIDI
MIDI OUT
USB MIDI
MIDI OUT THRU, OUT
This sets the operation of the MIDI OUT/THRU connector.
• OUT:
MIDI messages are sent from the V-1HD.
• THRU:
Received MIDI messages are sent unchanged. The V-1HD sends
no MIDI messages itself.
MIDI Tx CHANNEL 1–16 This sets the Tx channel for sending MIDI messages from the V-1HD..
MIDI DEVICE ID 1 (00h)–32 (1Fh) This sets the device ID to receive/send the system exclusive messages.
* This also doubles as the device ID in the MIDI Visual Control (MVC) mode and V-LINK mode.
MIDI Rx CHANNEL 1–16, OFF This sets the Rx channel of MIDI messages. If this is “OFF”, the channel voice messages of standard mode will not be received.
MIDI Rx TEMPO CLOCK ON, OFF Setting this to “ON”makes the unit receive a MIDI tempo clock for BPM sync.

3
Receiving the Remote Control Messages
Receiving in Standard Mode
In order to receive remote control messages, set parameters as below.
MIDI OUT If you are connecting multiple V-1HD units in a chain, set this to“THRU.”
MIDI Rx CHANNEL Set this value according to the master device channel.
You can remote control the following functions from an external MIDI device.
* For corresponding MIDI messages, refer to “MIDI Implementation”(p. 5).
• Audio input volume control for HDMI 1–4, AUDIO IN, and MIC.
• Volume control of output audio.
• Selection of input video channel.
• Output fade of the video.
• Selection of the transition eect.
• Adjustment of transition time.
• Selection of the composition eect and On/O.
• Key composition function on/o.
• Selection of the key channel.
• Adjustment of key level
• Turning On/O of the freeze function.
• Adjustment of the video eect.
• Switching between memory numbers.
Receiving in MVC Mode
In order to receive remote control messages, set parameters as below.
MIDI OUT If you are connecting multiple V-1HD units in a chain, set this to“THRU.”
MIDI DEVICE ID Set this value according to the master device channel.
You can remote control the following functions from a device supporting MVC after sending MVC ON message to the V-1HD.
* For corresponding MIDI messages, refer to “1-2. MIDI Visual Control Mode” (p. 6) in“MIDI Implementations.”
• Volume control of output audio.
• Selection of input video channel.
• Output fade of the video.
• Selection of the transition eect.
• Adjustment of transition time.
Receiving in V-LINK Mode
In order to receive remote control messages, set parameters as below.
MIDI OUT If you are connecting multiple V-1HD units in a chain, set this to“THRU.”
MIDI DEVICE ID Set this value according to the master device channel.
You can remote control the following functions from a device supporting V-LINK after sending V-LINK ON message to the V-1HD.
* For corresponding MIDI messages, refer to “1-3. V-LINK Mode”(p. 7) in“MIDI Implementations.”
• Volume control of output audio.
• Selection of input video channel.
• Output fade of the video.
• Selection of the transition eect.

4
Sending the Messages to an External MIDI Device
If you are sending MIDI messages to an external MIDI device from the V-1HD, set parameters as below.
MIDI OUT Set this to “OUT.”
MIDI Tx CHANNEL Select the Tx channel.
You can send MIDI messages corresponding to the panel operations of the V-1HD as below.
* For corresponding MIDI messages, refer to “2. MIDI Messages Transmitted from MIDI OUT” (p. 10) in“MIDI Implementations.”
• Audio input volume-control operation for AUDIO IN, MIC, and HDMI 1–4.
• Audio output volume-control operation.
• Selection of the video channel.
• Controlling of the output fade.
• Adjustment of the transition time.
• Selection of the composition eect and turning On/O.
• Key composition function on/o.
• Selection of the key channel.
• Adjustment of the key level.
• Turning On/O of the freeze function.
• Adjustment of the video eect.
• Switching between memory numbers.

5
MIDI Implementation
Model: V-1HD
Date: November 20. 2015
Version: 1.00
Symbol Item Setting Range
n MIDI Channel 0H–FH (ch.1–ch.16)
vv Control Value,
Velocity Value etc.
00H–7FH (0–127)
* If note on velocity, it changes to 01H-7FH (1–127).
* If there is a center value, 40H (64) should be the
center.
kk Note Number 00H–7FH (0–127)
xx Turning ON/OFF 00H–3FH (0–63) OFF
40H–7FH (64–127) ON
1. MIDI Messages Received at MIDI IN
1-1. Standard Mode
Channel Voice Messages
* When “MIDI Rx CHANNEL” (p. 2) is set to“OFF,” channel voice messages are not
received.
z Control Change
{ Bank Select (Controller Number 0, 32)
Status 2nd Byte 3rd Byte
BnH 00H mmH
BnH 20H llH
mm,ll= Bank Number: 00 00H, 01 00H (bus A, bus B)
* This selects one from among video input on bus A. video input on bus B, or a
memory number.
* If unavailable bank select is received, the unit ignores it and receives program
change only.
* The received bank select information is withheld until the unit receives new bank
select.
* Select video input or memory number to match the program change. Control for
bank selects and program changes is as follows.
MSB LSB Program No. Control
00H 00H 00H–03H A ch. INPUT 1–4
01H 00H 00H–03H B ch. INPUT 1–4
50H 00H 00H–07H MEMORY 1–8
{ Panpot (Controller Number 10)
Status 2nd Byte 3rd Byte
BnH 0AH vvH
* This controls the value of the AUDIO MIXER’s HDMI 1 audio input level.
{ Expression (Controller Number 11)
Status 2nd Byte 3rd Byte
BnH 0BH vvH
* This controls the value of the AUDIO MIXER’s HDMI 2 audio input level.
{ Eect Control 1 (Controller Number 12)
Status 2nd Byte 3rd Byte
BnH 0CH vvH
* This controls the value of the AUDIO MIXER’s HDMI 3 audio input level.
{ Eect Control 2 (Controller Number 13)
Status 2nd Byte 3rd Byte
BnH 0DH vvH
* This controls the value of the AUDIO MIXER’s HDMI 4 audio input level.
{ Undened (Controller Number 14)
Status 2nd Byte 3rd Byte
BnH 0EH vvH
* This controls the value of the AUDIO MIXER’s AUDIO IN audio input level.
{ Undened (Controller Number 15)
Status 2nd Byte 3rd Byte
BnH 0FH vvH
* This controls the value of the AUDIO MIXER’s MIC audio input level.
{ General Purpose Controllers 1 (Controller Number 16)
Status 2nd Byte 3rd Byte
BnH 10H vvH
* This controls the value of the AUDIO MIXER’s MASTER audio output level.
{ General Purpose Controllers 2 (Controller Number 17)
Status 2nd Byte 3rd Byte
BnH 11H vvH
* This controls the A/B fader.
{ General Purpose Controllers 3 (Controller Number 18)
Status 2nd Byte 3rd Byte
BnH 12H vvH
* This controls the value of TRANSFORMER TIME.
{ General Purpose Controllers 4 (Controller Number 19)
Status 2nd Byte 3rd Byte
BnH 13H ttH
tt= Transition Select: 00H–02H (WIPE, MIX, CUT)
* This controls the type of transition eect.
{ Undened (Controller Number 20)
Status 2nd Byte 3rd Byte
BnH 14H vvH
* This turns the TRANSFORMER [ ] button on/o.
{ Undened (Controller Number 21)
Status 2nd Byte 3rd Byte
BnH 15H vvH
* This turns the TRANSFORMER [ ] button on/o.
{ Undened (Controller Number 22)
Status 2nd Byte 3rd Byte
BnH 16H vvH
* This turns the BPM SYNC function on/o.
{ Undened (Controller Number 23)
Status 2nd Byte 3rd Byte
BnH 17H vvH
* This controls the state of the [EFFECTS A] knob. When this is set to“00H,” the eect
on bus A is turned o.

MIDI Implementation
6
{ Undened (Controller Number 24)
Status 2nd Byte 3rd Byte
BnH 18H vvH
* This controls the state of the [EFFECTS B] knob. When this is set to “00H,” the eect
on bus B is turned o.
{ Undened (Controller Number 25)
Status 2nd Byte 3rd Byte
BnH 19H vvH
* This controls the state of the [OUTPUT FADE] knob.
{ Undened (Controller Number 26)
Status 2nd Byte 3rd Byte
BnH 1AH eeH
* This turns the FREEZE function on/o.
z Program Change
Status 2nd Byte
CnH ppH
pp= Program Number: 00H–7FH (1–128)
* Select video input or memory number to match the bank select. For information on
control for bank select and program change, refer to “Bank Select”(p. 5).
* Unselectable program change will be ignored.
1-2. MIDI Visual Control Mode
Channel Voice Messages
z Note On
Status 2nd Byte 3rd Byte
9nH kkH vvH
* This is received when Note Message Enabled of MVC is turned on.
* This selects the video channel corresponding to the note number.
* The setting range of note number is xed by Keyboard Range Upper and Lower of
MVC.
* Unselectable note number or velocity will be ignored.
* The receiving channel is specied by Clip Control Ch. of MVC.
z Control Change
{ Bank Select (Controller Number 0, 32)
Status 2nd Byte 3rd Byte
BnH 00H mmH
BnH 20H llH
mm,ll= Bank Number: 00 00H–7F 7FH (bank.1–bank.16384)
* The bank select processing is reserved until the unit receives program change.
* If unavailable bank select is received, the unit ignores it and receives program
change only.
* The received bank select information is withheld until the unit receives new bank
select.
* The receiving channel is specied by Clip Control Ch. of MVC.
* Select video input or memory number to match the program change. Control for
bank selects and program changes is as follows.
MSB LSB Program No. Control
00H 00H 00H–03H A ch. INPUT 1–4
01H 00H 00H–03H B ch. INPUT 1–4
50H 00H 00H–07H MEMORY 1–8
{ General Purpose Controllers
(Controller Number 1-31, 64-95)
Status 2nd Byte 3rd Byte
BnH ccH vvH
cc= Controller Number: 01H–1FH, 40H–5FH
* The receiving channel of eect control and output fade control is specied by
Eect Control Ch. of MVC. The receiving channel for all the other controls is
specied by Clip Control Ch. of MVC.
z Program Change
Status 2nd Byte 3rd Byte
CnH ppH
pp= Program Number: 00H–7FH (prog.1–prog.128)
* Select video input or memory number to match the bank select. For information
on control for bank select and program change refer to the“Bank Select” section
mentioned above.
* The receiving channel is specied by Clip Control Ch. of MVC.
* If unavailable program change is received, the unit ignores.

MIDI Implementation
7
z Channel Pressure
Status 2nd Byte 3rd Byte
DnH vvH
* The receiving channel of eect control and output fade control is specied by
Eect Control Ch. of MVC. The receiving channel for all the other controls is
specied by Clip Control Ch. of MVC.
z Pitch Bend Change
Status 2nd Byte 3rd Byte
EnH llH mmH
mm,ll= Pictch bend value: 00 00H–40 00H–7F 7FH (-8192–0–+8191)
* The receiving channel of eect control and output fade control is specied by
Eect Control Ch. of MVC. The receiving channel for all the other controls is
specied by Clip Control Ch. of MVC.
1-3. V-LINK Mode
Channel Voice Messages
z Note On
Status 2nd Byte 3rd Byte
9nH kkH vvH
* This is received when Note Message Enabled of V-LINK is set to 49 Keys or Assignable.
* Selects the video input channel corresponding to the note number.
* In case of Assignable, the range of note numbers is xed by Keyboard Range Upper
and Lower of V-LINK.
* The receiving channel is specied by Clip Control Ch. of V-LINK.
* In case of 49 Keys, input channels corresponding to note numbers are:
Note No. Input
24H
26H
28H
29H
A Ch. 1
A Ch. 2
A Ch. 3
A Ch. 4
2BH
2DH
2FH
30H
B Ch. 1
B Ch. 2
B Ch. 3
B Ch. 4
* Ignores unavailable note number and velocity.
z Control Change
{ Bank Select (Controller Number 0, 32)
Status 2nd Byte 3rd Byte
BnH 00H mmH
BnH 20H llH
mm,ll= Bank Number: 00 00H–7F 7FH (bank.1–bank.16384)
* The bank select processing is reserved until the unit receives program change.
* If unavailable bank select is received, the unit ignores it and receives program
change only.
* The received bank select information is withheld until the unit receives new bank
select.
* The receiving channel is specied by Clip Control Ch. of V-LINK.
* Select video input or memory number to match the program change. Control for
bank selects and program changes is as follows.
MSB LSB Program No. Control
00H 00H 00H–03H A ch. INPUT 1–4
01H 00H 00H–03H B ch. INPUT 1–4
50H 00H 00H–07H MEMORY 1–8
{ General Purpose Controllers
(Controller Number 1-31, 64-95)
Status 2nd Byte 3rd Byte
BnH ccH vvH
cc= Controller Number: 01H–1FH, 40H–5FH
* The receiving channel of eect control and output fade control is specied by Color
Control Ch. of V-LINK. The receiving channel for all the other controls is specied by
Clip Control Ch. of V-LINK.

MIDI Implementation
8
z Program Change
Status 2nd Byte
CnH ppH
pp= Program Number: 00H–7FH (prog.1–prog.128)
* The receiving channel is specied by Clip Control Ch. of V-LINK.
* If unavailable program change is received, the unit ignores.
* Select video input or memory number to match the bank select. For information on
control for bank select and program change, refer to “Bank Select” (p. 7).
z Channel Pressure
Status 2nd Byte
DnH vvH
* The receiving channel of eect control and output fade control is specied by Color
Control Ch. of V-LINK. The receiving channel for all the other controls is specied by
Clip Control Ch. of V-LINK.
z Pitch Bend Change
Status 2nd Byte 3rd Byte
EnH llH mmH
mm,ll= Pitch Bend Value: 00 00H–40 00H–7F 7FH (-8192–0–+8191)
* The receiving channel of eect control and output fade control is specied by Color
Control Ch. of V-LINK. The receiving channel for all the other controls is specied by
Clip Control Ch. of V-LINK.
1-4. Common Messages for All Modes
System Exclusive Messages
z Active Sensing
Status
FEH
* When the unit receives active sensing, the unit status changes to observe the
message intervals. In this status, the unit executes receiving error process if a
message interval exceeds 400 msec. Then the unit returns to status of no interval
observation.
* These are not received when“MIDI Rx SOURCE” is set to “USB.”
z Timing Clock
Status
F8H
* When“MIDI Rx TEMPO CLOCK” is set to“ON,”BPM SYNC synchronization is performed.
z Start
Status
FAH
* When “MIDI Rx TEMPO CLOCK” is set to “ON,” the start of the BPM SYNC beat is set.
z Continue
Status
FBH
* When “MIDI Rx TEMPO CLOCK” is set to “ON,” the start of the BPM SYNC beat is set.
System Exclusive Messages
Status Data Byte Status
F0H iiH,ddH,...,eeH F7H
F0H: Status of the system exclusive message
ii= ID number: This is to specify the manufacturer of the product that
generates the message. The manufacture ID of Roland is 41H.
The ID numbers of 7EH and 7EF are the expansion of MIDI
standard and used as universal non-realtime message (7EH) and
universal realtime message (7FH).
dd,...,ee=data: 00H–7FH (0–127)
F7H: EOX (End of Exclusive)
z Data Request 1 (RQ1)
This is the message to request of“send data” to the connected device. Specify data
type and amount using address and size. When this is received, the unit sends the
requested data as“Data Set 1 (DT1)” message in case the unit is in status where the
sending of data is possible and requested address and size are appropriate. If not, the
unit sends nothing.
Status Data Byte Status
F0H 41H, dev, 00H, 00H, 00H, 20H, 11H, aaH, F7H
bbH, ccH, ssH, ttH, uuH, sum
Byte Explanation
F0H Exclusive Status
41H Manufacturer ID (Roland)
dev Device ID (dev : 00H–1FH, 10H is default)
00H 1st byte of model ID (V-1HD)
00H 2nd byte of model ID (V-1HD)
00H 3rd byte of model ID (V-1HD)
20H 4th byte of model ID (V-1HD)
11H Command ID (RQ1)
aaH Address upper byte
bbH Address middle byte
ccH Address lower byte
ssH Size upper byte
ttH Size middle byte
uuH Size lower byte
sum Checksum
F7H EOX (end of exclusive)
* Depending on the data type, the amount of single-time transmission is specied.
It is necessary to execute data request according to the specied rst address and
size. Refer to the“3. Parameter Address Map”(p. 12) for address and size.
* See “Example of an Exclusive Message and Calculating a Checksum”(p. 20) for
checksum.

MIDI Implementation
9
z Data Set 1 (DT1)
This is the message of actual data transmission. Use this when you want to set data
to the unit.
Status Data Byte Status
F0H 41H, dev, 00H, 00H, 00H, 20H, 12H, aaH, F7H
bbH, ccH, ddH, ..., eeH, sum
Byte Explanation
F0H Exclusive Status
41H Manufacturer ID (Roland)
dev Device ID (dev: 00H–1FH,10H is default)
00H 1st byte of model ID (V-1HD)
00H 2nd byte of model ID (V-1HD)
00H 3rd byte of model ID (V-1HD)
20H 4th byte of model ID (V-1HD)
12H Command ID (RQ1)
aaH Address upper byte
bbH Address middle byte
ccH Address lower byte
ddH Data: actual data to transmit. Multiple byte data is sent in address order.
: :
eeH Data
sum Checksum
F7H EOX (end of exclusive)
* Depending on the data type, the amount of single-time transmission is specied.
It is necessary to execute data request according to the specied rst address and
size. Refer to the“3. Parameter Address Map”(p. 12) for address and size.
* See “Example of an Exclusive Message and Calculating a Checksum”(p. 20) for
checksum.
* Data exceeding 256 bytes should be divided into packets of 256 bytes or smaller. If
you send data set 1 successively, set interval of 20 ms or longer between packets.
z MIDI Visual Control Message
Status Data Byte Status
F0H 7EH, dev, 0CH, 01H, F7H
aaH, bbH, ccH, ddH, ...,eeH, sum
Byte Explanation
F0H System Exclusive Status
7EH Universal System Exclusive Non-Realtime Header
dev Device ID (dev : F00H–1FH; MVC default= 00H)
0CH Sub ID #1 (MIDI Visual Control)
01H Sub ID #2 (MVC command set ID; 01H=“Version 1.0”)
aaH Upper byte of the address
bbH Address
ccH Address
ddH Actual Data: The data body. The data of multiple bytes should
be submitted in address order.
: :
eeH Data
sum Checksum
F7H EOX (End of Exclusive)
* Depending on the data type, the amount of single-time transmission is specied.
It is necessary to execute data request according to the specied rst address and
size. Refer to the“3-2. MIDI Visual Control”(p. 18) for address and size.
* See “Example of an Exclusive Message and Calculating a Checksum”(p. 20) for
checksum.
* Data exceeding 256 bytes should be divided into packets smaller than 256 bytes. If
you send sequentially, the intervals of packets should be longer than 20 ms.
z V-LINK Message
Status Data Byte Status
F0H 41H, dev, 00H, 51H, 12H, F7H
aaH, bbH, ccH, ddH, ...,eeH, sum
Byte Explanation
F0H System Exclusive Status
41H ID Number (Roland)
dev Device ID (dev : 00H–1FH ; default is 10H)
00H Model ID upper byte (V-LINK)
51H Model ID lower byte (V-LINK)
12H Command ID (DT1)
aaH Upper byte of the address
bbH Address
ccH Address
ddH Actual Data : The data body. The data of multiple bytes should
: :
eeH Data
sum Checksum
F7H EOX (End of Exclusive)
* Depending on the data type, the amount of single-time transmission is specied.
It is necessary to execute data request according to the specied rst address and
size. Refer to“3.3 V-LINK” (p. 19) for the address and data.
* See “Example of an Exclusive Message and Calculating a Checksum”(p. 20) for
checksum.
* Data exceeding 256 bytes should be divided into packets smaller than 256 bytes. If
you send sequentially, the intervals of packets should be longer than 20 ms.

MIDI Implementation
10
2. MIDI Messages Transmitted from
MIDI OUT
2-1. Transmission of the Received Messages
When “MIDI OUT” (p. 2) is set to “THRU,” received messages are transmitted from
MIDI OUT.
2-2. Transmission of the Generated Messages
Messages that the V-1HD generates are always transmitted to USB MIDI.
When“MIDI OUT” (p. 2) is set to“OUT,” messages are also transmitted from MIDI OUT.
Channel Voice Messages
z Control Change
{ Bank Select (Controller Number 0, 32)
Status 2nd Byte 3rd Byte
BnH 00H mmH
BnH 20H llH
mm, ll= Bank Number: 00 00H, 01 00H (bank.1, bank.2)
* When a video input or memory number has been selected, this transmits a bank
number along with a program change. Control for bank selects and program
changes is as follows.
MSB LSB Program No. Control
00H 00H 00H–03H A ch. INPUT 1–4
01H 00H 00H–03H B ch. INPUT 1–4
50H 00H 00H–07H MEMORY 1–8
{ Panpot (Controller Number 10)
Status 2nd Byte 3rd Byte
BnH 0AH vvH
* This transmits the value when the AUDIO MIXER’s HDMI 1 audio input level has
been changed.
{ Expression (Controller Number 11)
Status 2nd Byte 3rd Byte
BnH 0BH vvH
* This transmits the value when the AUDIO MIXER’s HDMI 2 audio input level has
been changed.
{ Eect Control 1 (Controller Number 12)
Status 2nd Byte 3rd Byte
BnH 0CH vvH
* This transmits the value when the AUDIO MIXER’s HDMI 3 audio input level has
been changed.
{ Eect Control 2 (Controller Number 13)
Status 2nd Byte 3rd Byte
BnH 0DH vvH
* This transmits the value when the AUDIO MIXER’s HDMI 4 audio input level has
been changed.
{ Undened (Controller Number 14)
Status 2nd Byte 3rd Byte
BnH 0EH vvH
* This transmits the value when the AUDIO MIXER’s AUDIO IN audio input level has
been changed.
{ Undened (Controller Number 15)
Status 2nd Byte 3rd Byte
BnH 0FH vvH
* This transmits the value when the AUDIO MIXER’s MIC audio input level has been
changed.
{ General Purpose Controllers 1 (Controller Number 16)
Status 2nd Byte 3rd Byte
BnH 10H vvH
* This transmits the value when the AUDIO MIXER’s MASTER audio output level has
been changed.
{ General Purpose Controllers 2 (Controller Number 17)
Status 2nd Byte 3rd Byte
BnH 11H vvH
* This transmits the value when the A/B fader has been controlled.
{ General Purpose Controllers 3 (Controller Number 18)
Status 2nd Byte 3rd Byte
BnH 12H vvH
* This transmits the value when TRANSFORMER TIME has been changed.
{ General Purpose Controllers 4 (Controller Number 19)
Status 2nd Byte 3rd Byte
BnH 13H ttH
tt= Transition Select: 00H–02H (WIPE, MIX, CUT)
* This transmits the value when the [WIPE], [MIX], or [CUT] button has been operated.
{ Undened (Controller Number 20)
Status 2nd Byte 3rd Byte
BnH 14H ttH
* This transmits the value when the TRANSFORMER [ ] button has been operated.
{ Undened (Controller Number 21)
Status 2nd Byte 3rd Byte
BnH 15H vvH
* This transmits the value when the TRANSFORMER [ ] button has been operated.
{ Undened (Controller Number 22)
Status 2nd Byte 3rd Byte
BnH 16H vvH
* This transmits the value when the [BPM SYNC] button has been operated.
{ Undened (Controller Number 23)
Status 2nd Byte 3rd Byte
BnH 17H vvH
* This transmits the value when the [EFFECT A] knob has been operated.
{ Undened (Controller Number 24)
Status 2nd Byte 3rd Byte
BnH 18H vvH
* This transmits the value when the [EFFECT B] knob has been operated.
{ Undened (Controller Number 25)
Status 2nd Byte 3rd Byte
BnH 19H vvH
* This transmits the value when the [OUTPUT FADE] knob has been operated.
{ Undened (Controller Number 26)
Status 2nd Byte 3rd Byte
BnH 1AH eeH
* This transmits the value when the [FREEZE] knob has been operated.
