ROOMS TO GO GLOB 4302-2 User manual

ASSEMBLY INSTRUCTIONS
GLOB 4302-2 BROWN BARSTOOL SKU# 43443023
This product is manufactured by GLOB for Page 1 of 2
Hardware Pack Location (s) :
STEP CODE HARDWARE
Allen Wrench
Q'TY
A1 pc
Bolt Ø5/16" x 18 x 2"
B1
C2
Spring washer Ø5/16"
Flat washer Ø5/16"
Wood Screw Ø5/32" x 1-3/4"
Glue
4 pcs
4 pcs
4 pcs
4 pcs
1 pc
1. Upholstered Cushion - 1pc
2. Front Leg - 1pc
3. Back Leg - 1pc
4. Side Stretchers - 2 pcs
GLUE
GLOB 4302-2B VANILLA BARSTOOL SKU# 43643027
4302-2 BROWN BARSTOOL SKU# 43443023
4302-2B VANILLA BARSTOOL SKU# 43643027

This product is manufactured by GLOB for Page 2 of 2
Attach the Front Leg (2) and Back Leg (3) to
seat frame by hardware with Allen Wrench.
Attach the Side Stretchers (4) to Front Leg
(2) and Back Leg (3) with screws and glue
by screwdriver (not provided).
(Remark: Please put some of glue on
to the tenon before assembly)
GLUE
1
2
3
B
A
4
C
STEP 1: STEP 2:
***Cautions: Please read all instructions carefully before starting the assembly process.
These parts are combersome and heavy. Therefore, two people are recommended in order
to prevent personal injury and ensure the parts are not damage during the assembly.
ASSEMBLY INSTRUCTIONS
GLOB 4302-2 BROWN BARSTOOL SKU# 43443023
GLOB 4302-2B VANILLA BARSTOOL SKU# 43643027

ASSEMBLY INSTRUCTIONS
GLOB 4302-4 SERVER SKU# 43843021
This product is manufactured by GLOB for Page 1 of 2
Hardware Pack Location (s) :
STEP CODE HARDWARE
Allen Wrench
Q'TY
A1 pc
Bolt Ø5/16" x 18 x 1-1/2"
B
1
C
2
Spring washer Ø5/16"
Flat washer Ø5/16"
Wooden dowel Ø3/8" x 1-1/8"
Anti-tipping Kit
12 pcs
12 pcs
12 pcs
8 pcs
1 pc
1. Front Leg - 2 pcs
3. Server - 1pc
4. Wooden Top - 1pc
D
2. Back Leg - 2 pcs
4302-4 SERVER SKU# 43843021

This product is manufactured by GLOB for Page 2 of 2
Attach the Back Legs (2) to the Server (3) by
hardware with Allen Wrench.
Attach the Front Legs (1) to the Server (3) by
hardware with Allen Wrench.
To put Wooden Top (4) to the Server (3) by hardware
with Allen Wrench.
To attach Server to wall with anti-tipping kit.
Note:
*Keep all hard wave parts out or children's reach
*Keep these instruction forfuture reference.
3
C
2
A
B
3
1
C
A
B
3
4
A
B
B
D
STEP 1: STEP 2:
STEP 3:
A
***Cautions: Please read all instructions carefully before starting the assembly process.
These parts are combersome and heavy. Therefore, two people are recommended in order
to prevent personal injury and ensure the parts are not damage during the assembly.
STEP 4:
ASSEMBLY INSTRUCTIONS
GLOB 4302-4 SERVER SKU# 43843021

ASSEMBLY INSTRUCTIONS
GLOB 4302-1 BAR TABLE SKU# 43243029
This product is manufactured by GLOB for Page 1 of 2
Hardware Pack Location (s) :
STEP CODE HARDWARE
Allen Wrench
Q'TY
A1 pc
Bolt Ø5/16" x 18 x 1"
B
1
CMetal Plate 4" x 3-1/2" x 3mm
9 pcs
3 pcs
1. Legs - 3 pcs
2. Table Top - 1pc
3. Shelf - 1pc
Bolt Ø5/16" x 18 x 3/4"
D2 Spring washer Ø5/16"
Flat washer Ø5/16"
15 pcs
15 pcs
15 pcs
Bolt Ø5/16" x 18 x 1-3/4"
E
3Spring washer Ø5/16"
Flat washer Ø5/16"
"L"Metal Plate
2-1/2" x 1-3/4" x 3mm 3 pcs
F
4
6 pcs
6 pcs
6 pcs
4302-1 BAR TABLE SKU# 43243029

1
This product is manufactured by GLOB for Page 2 of 2
Attach the Metal Plate to the Legs (1) by hardware
with Allen Wrench.
Attach the Legs (1) to the Table Top (2) by hardware
with Allen Wrench.
Attach the Apron block to the Legs (1) by hardware
with Allen Wrench.
Screw the "L" Metal Plate to the Shelf (3) and Legs (1)
by hardware with Allen Wrench.
1
2
A
D
A
E
STEP 1: STEP 2:
STEP 3: STEP 4:
***Cautions: Please read all instructions carefully before starting the assembly process.
These parts are combersome and heavy. Therefore, two people are recommended in order
to prevent personal injury and ensure the parts are not damage during the assembly.
ASSEMBLY INSTRUCTIONS
GLOB 4302-1 BAR TABLE SKU# 43243029

ASSEMBLY INSTRUCTIONS
GLOB 4302-3 BROWN BENCH SKU# 43543025
This product is manufactured by GLOB for Page 1 of 2
Hardware Pack Location (s) :
STEP CODE HARDWARE
Allen Wrench
Q'TY
A1 pc
1-3-4-5 1. Base Frame - 1 pc
2. Leg Panel - 2 pcs
Bolt Ø5/16" x 18 x 1-3/4"
CSpring washer Ø5/16"
Flat washer Ø5/16"
17 pcs
17 pcs
17 pcs
8 pcs
3. Rails - 2 pcs
4. Seat Panel - 1pc
5. Top Cushion - 1pc
Plastic Cap
B
Wooden dowel Ø3/8" x 1-1/8"
D
4 pcs
GLOB 4302-3B VANILLA BENCH SKU# 43743029
4302-3 BROWN BENCH SKU# 43543025
4302-3B VANILLA BENCH SKU# 43743029

This product is manufactured by GLOB for Page 2 of 2
Attach Base Frame (1) to Leg Panel (2) by hardware
with Allen Wrench. Then cover the hole with Plastic Cap.
Attach the two Rails (3) to Leg Panel (2).
Attach the another Leg Panel (2) by hardware
with Allen Wrench. Then cover the hole with
Plastic Cap.
Attach Seat Panel (4) to Side Leg (2) by hardware
with Allen Wrench.
Attach the Top Cushion (5) to Seat Panel (4) by hardware with Allen Wrench.
2
2
3
5
4
B
C
B
2
A
C
A
C
4
2
D
2
A
CA
C
STEP 1:
A
STEP 2:
STEP 3: STEP 4:
STEP 5:
***Cautions: Please read all instructions carefully before starting the assembly process.
These parts are combersome and heavy. Therefore, two people are recommended in order
to prevent personal injury and ensure the parts are not damage during the assembly.
1
ASSEMBLY INSTRUCTIONS
GLOB 4302-3 BROWN BENCH SKU# 43543025
GLOB 4302-3B VANILLA BENCH SKU# 43743029
