XtendVue
WWW.ROSE.COM
LCD Display with Built-in
KVM Extender
Extend the video from a computer up to 1,000 feet
away over CAT5 cable
Direct CAT5 input to the display
Optional Keyboard, mouse, audio, serial, and
Touchscreen
Available in: 15" / 17” Digital display
Interactive Touchscreen
15" / 17" Panel mount, interactive
touchscreen
Features and Benefits
JBuilt-in high quality CrystalView KVM extender
JRugged design for use in commercial and retail
environments
JHigh quality LCD monitor (15”, or 17”)
JResolutions up to 1600 x 1200
JOptional PS/2 keyboard and mouse connections for
accessing the controlling computer
JPS/2 keyboard, mouse, and stereo speakers
connect directly to the display unit (optional)
JInteractive Touchscreen capability (optional)
JSaves floor space by locating the computer in a
central secure location away from the users.
JIdeal for offices, hotels, airports, retail stores and
kiosk displays
JPlug-and-play, easy installation
JInstall as a self-help / training kiosk
JUse to provide self-service information
JAll Rose Electronics products come with a 30 Day
Money Back Guarantee and free Technical Support
The XtendVue™ Advantage . . .
The XtendVue extension display is the ideal solution
when your display needs to be extended away from
the computer.
The XtendVue can be located up to 1,000 feet away
from the computer using industry standard CAT5
cable and a Rose KVM Extender transmitter. This
allows control of the display but keeps your computer
safe and secure in a remote location.
Several Rose Electronics KVM extender transmitters
can be used, depending on your specific application.
Adding the local keyboard and mouse option gives
the user access to the controlling computer.
The optional Touchscreen capability can provide
information to employees or customers. Interactive
requests can provide help in locating in-store
products, inventory availability, and much more.
An interactive kiosk is a computer based device
which allows customers to seek products and service
information without the need of staff interaction. The
XtendVue is the perfect solution for kiosk
applications.
Self-Help Centers

Phone: [phone] E-mail: [email protected] 
10707 Stancliff Rd. Houston, TX 77099
Rose Electronics – Europe: [phone] Rose Electronics – Asia: [phone]
DS-XV 1.8 Copyright 2004 Rose Electronics. All rights reserved WWW.ROSE.COM
Typical Application
Locate your computer up to 1,000 feet
away using standard CAT5 cable
Introduction The XtendVue panel mount and LCD flat panel displays
excel in their image quality, rugged design, and versatility. The XtendVue
allows you to locate your computer up to 1,000 feet away from the display
unit in a safe and secure location. The computer video and optional
keyboard, mouse, and stereo audio features are transmitted over the same
CAT5 cable. The modular design of the XtendVue offers a variety of
mounting options.
Models The XtendVue LCD flat panel display is available in the
following models:
J15" / 17" interactive model with Touchscreen and optional keyboard,
mouse, serial, and stereo audio
J17" Panel mount with Touchscreen and optional keyboard, mouse,
serial, and stereo audio
XtendVue has many different applications that can enhance your business
presence and provide useful and interactive information for your
employees, visitors, and customers. Some of the useful applications are:
Office buildings The XtendVue can be used as a detailed building
directory, showing the tenants and their business information.
Company Directory Provide employees an easy way to find
information about their benefits, request vacations, and more!
Retail stores Display the in store directory, catalog, and specialty
items not normally stocked.
Health Care Provide patients information about health topics, doctor
directory by specialty, and visitor information
Virtual Receptionist Install the XtendVue in your business lobby to
provide visitors and vendors information about your company, employment,
goals, and more.
Part numbers
Model Description
15" CAT5 interactive display
15" CAT5 interactive panel mount display
XVL-17AFTSD312B 17" CAT5 interactive display
17" CAT5 interactive panel mount display
Specifications
Display area: 15" / 17” diagonal
Driver Element a-Si TFT active matrix
Display colors 16.7 M (true)
Resolution 1280 x 1024
Pixel pitch 0.264mm(H) x.0254mm(V)
Contrast ratio 300 (typical)
Viewing angle 100° (H) / 120° (V)
Connectors
Link RJ45 (CAT5)
Keyboard PS/2 (MiniDin6)
Mouse PS/2 (MiniDin6)
Audio 3.5mm audio in/out (optional)
Power External 12VDC adapter or
External 24VDC adapter
Rearview – display and panel mount models
Convenient front Neatly arranged rear
panel controls panel connectors
on select models
Dimensions (W) (D) (H)
15" Display 14.0" 1.87" 11.45"
17" Display 16.3” 1.87” 13.25”
15" Panel 13.0" 1.75" 10.75"
17" Panel 17.0" 2.00" 15.75"
