Rosslare MD-IO84 User manual

MD-IO84
Installation Instructions
Access Controller I/O
Expansion Board
1 0706-0960199+00
1. Introduction
The MD-IO84 is an optional I/O expansion board for use with
Rosslare Security's family of state-of-the-art networked access
controllers. The expansion board adds an additional four relay
outputs and eight supervised inputs to the access control
panel.
The host access controller has complete control over the
additional inputs and outputs of the MD-IO84 expansion
board. The inputs and outputs can be configured using an
access control software system such as Rosslare Security's
VeriTrax AS-225. The software system also configures the MD-
IO84's input connection topology.
This guide explains how to install and begin working with your
new MD-IO84 access controller expansion board.
2. Technical Specifications
2.1 Electrical Characteristics
MD-IO84 Input
Voltage:
12V DC
MD-IO84 Input
Current:
(not including attached devices)
Standby: 30mA
Maximum: 135mA
Number of Inputs: 8
Number of Outputs: 4
Output Relays: 5A Form C Relays, NO, NC and
COM contacts and Form C Relays
Inputs Voltage: 5V DC
2.2 Physical Characteristics
Dimensions: 100mm L x 75.9mm W x 32.5 D (3.93
in. x 2.98 in. x 1.28 in.)
Weight: 98.2g (0.21 lbs)
2.3 Input Characteristics
Input Type: Selectable as
•Normally open
•Normally closed
•Non-supervised (two states)
•Supervised with one resistor
(three states)
•Supervised with two resistors
(four states)
2.4 LED Indicators
Power LED: Active when connected to a power
source.
Output LEDs: Four LEDs.
Each output LED is active when an
output relay is energized and NO to
COM contacts are closed circuit.
3. Installation
3.1 Attaching the MD-IO84
1) Disconnect power to the access control panel before
attaching the MD-IO84.
2) To remove the MD-IO84 cover, lightly pull one of the cover
knobs away from the circuit board. The entire cover
comes away from the board.
3) Remove the label on the cover of the access control
panel marked "Remove to install I/O board".
4) Insert the MD-IO84 with its 10 pin male connector fitting
into the access control panel 10 pin female connector.
The text on the MD-IO84 must face the same way as the
text on the panel's cover.
5) Tighten the four Philips screws on the MD-IO84 circuit
board.
6) Ease the corners of the cover back over the board. The
text on the cover must face the same way as the text on
the circuit board.
MDIO84 Expansion
board inserted here
Host Access Control Panel with
MDIO84 expansion board
Host Access
Control Panel

2 0706-0960199+00
4. Wiring Instructions
4.1 Inputs Wiring
There are four input types:
•Normally Open
•Normally Closed
•Normally Open Supervised with one or two resistors
•Normally Closed Supervised with one or two resistors
Figure #1 (below) shows the normally open input connection.
Figure 1 Normally Open Input
Figure #2 (below) shows the normally closed input connection.
Figure 2 Normally Closed Inputs
Figure #3 (below) shows the normally open supervised input
connection with single resistor.
Figure 3 Normally Open Supervised Inputs with Single Resistor
Normally Open Supervised inputs with one resistor must be
connected with an 8.2K resistor in parallel to the input switch
contacts.
NOTE: Always wire resistors on the input switch and not
on the terminal block.
Figure #4 (below) shows the normally open supervised input
connection with double resistor.
Figure 4 Normally Open Supervised Inputs with Double Resistor
Normally Open Supervised inputs with two resistors must be
connected with an 8.2K resistor in parallel and a 2.2K resistor in
series to the input switch contacts.
Figure #5 (below) shows the normally closed supervised input
connection with single resistor.
Figure 5 Normally Closed Supervised Input with Single Resistor
Normally Closed Supervised inputs with a single resistor must be
connected with a 2.2K resistor in series to the input switch
contacts.
Normally Open
Switch
Normally Open
Switch
Normally Closed
Switch
Normally Closed
Switch
Normally Open
Switch

3 0706-0960199+00
Figure #6 (below) shows the normally closed supervised input
connection with double resistor.
Figure 6 Normally Closed Supervised Input with Double
Resistors
Normally Closed Supervised inputs with two resistors must be
connected with an 8.2K resistor in parallel and a 2.2K resistor in
series to the input switch contacts.
4.2 Outputs
Electrical devices can be switched using the voltage free relay
contacts.
Rosslare Security recommends the use of suppression diodes
for all outputs that will be connected to inductive loads and
activated by DC current, such as Magnetic Lock ("Maglock")
or door strike devices.
Each suppression diode must be connected near its inductive
load. Always attach the diode's cathode to the +V terminal of
the load. Attach the diode's anode to the –V terminal.
For more information, refer to your access controller's
Installation and User Guide.
5. Using the MD-IO84
5.1 Operating the MD-IO84
The access control panel detects the MD-IO84 expansion
board when it powers up. When defining the panel in the
access control panel's PC application (such as Veritrax AS-
225), select the option designating Panel name with
following "IO" designation.
Define inputs and outputs using the access system software.
Define each input's type and make sure the connection is
compatible with the input wiring.
Input and outputs type and function selection in the access
control software are usually similar to the host access control
panel general purpose inputs and outputs.
When using VeriTrax AS-225, define input types from the
"Inputs" tree menu. Input and output functions are defined
using the "Links" element within each "Panel" tree menu item.
For more information, refer to the "VeriTrax AS-225 Software
Manual".
Normally Closed
Switch

4 0706-0960199+00
