Rowe 4900JR SERIES Quick start guide

General Information
This page contains general information on installing,
operating and maintaning the BA**B Series Bill Acceptor.
Taking time to read this information and becoming
familiar with it will help you obtain the best performance
from your BA**B.
The BA**B Series Bill Acceptor is designed to fit into
existing standard openings established by vending
machine manufacturers. These mountings usually consist
of four studs in the vending machine to which the bill
acceptor is mounted. If an additional mounting bracket
and/or hardware is required, please contact your nearest
Coinco office for additional kit information.
NOTE: The BA**B requires one of the following
power harnesses.
#407052-1 (8 Pin Jones Interface)
#407419-1 (4 Pin Interface)
#407420 (Multi Drop Bus Interface)
On most controller-type vending machines, the BA**B
power cable interfaces directly to the vending machine
electronic controller board through an additional
vendor interface harness. Contact your nearest Coinco
office for additional harness information.
Installation and Operation
Before installing the BA**B series bill acceptor into the
vendor, set the BA**B option switches, (if desired settings
are different from those set at the factory.) The BA**B is
currently set to accept one dollar bills only, face up in both
directions. See “BA**B Option Switches: and “Setting
Option Switches” sections for detailed infromation.
BA**B SERIES BILL ACCEPTOR
Installation & Operation Guide
With Multi Drop Bus
Coinco Publication #921223 Rev. 6 5/99
1. Turn OFF vending machine power.
2. Install the BA**B into mounting hole of vending.
3. Connect the BA**B power cable (not included)
between the BA**B control box and the changer/
vending machine.
4. Install a Coinco coin changer or the equivalent into the
vending machine according to the coin changer
instructions.
5. Load the coin changer coin tubes with a minimum of
ten coins in each tube making sure all coins lie flat.
6. Restore power to vending machine (BA**B stacker
will cycle upon power-up).
Figure 2
** = 30
32
50
52
70
72
90
92
Bill Box Size Voltage 0=110V
2= 24V
Figure 1

7. Observe that power indicator light on back of BA**B
control box is ON continuously. If light is off or
blincking, check the following:
Power to vendor
Coin changer tube levels
Vendor has product
Vendor does not have credit already established
8. With the vend price set below one dollar, insert a one
dollar bill as shown on the front of the BA**B.
9. One dollar bill will be accepted and stacked into the
bill box.
10. Verify one dollar credit has been established by
making a vend and verifying that the proper amount
of change is returned.
11. Check the bill box to see that the one dollar bill is
properly stored.
BA**B Option Switches
The BA**B control board contains eight option
switches. These switches allow the unit to be customized
to the installation requirements. The BA**B option
switches are pre-set at the factory and shipped with
switches 3 and 8 set to the ON positiion. All other
switches are off. When the top of the rocker switch is
pushed in, it is set to the ON position. (See Figure 3 for
option switch functions.)
Setting Option Switches
(See Figure 3)
Remove power to the BA**B. To access option
switches, remove the bill box to access the option switch
access hole on the inner side of the logic board case.
Remove the clear tape seal from the access hole. Using a
small screwdriver, set the option switches as desired
through the access hole. Replace the clear tape seal when
completed.
Removing Accepted Bills
(See Figure 4)
Accepted bills may be removed from the BA**B by
releasing the bill box lid exposing the bills for collection
or by removing the bill box from the bill acceptor unit.
Clearing Jams & Cleaning
(See Figure 4)
Trapped bills/debris or dirt can result in poor bill
acceptance or bill rejection. Remove bill box and lower
housing to access bill path for clearing trappped bills or
debris. Clean bill path plastic parts and belts with a cloth
moistened with a mild soap and water solution. Clean the
magnetic head and optic sensors using a swab and
isopropyl alcohol. Do not use any petroleum based
cleaning solvents, scouring pads or stiff brushes for
cleaning. The BA**B requires no lubrication at any
time.
Figure 3 Figure 4
To remove bill box, push tab in
the direction of the arrow and
slide the bill box up. Pull bill box lid
open to
rem ove bills.
Bill Box
Lower
Housing
To service lower housing,
push tab on bottom up
and pull to the rear.
Flash Codes
A steady light indicates normal operation.
=Bill Box Full
2=Bill Box Off/Open
3=Check Bill Path
4=All Bill Accept Switches OFF
5=Bill Jam
6 or more=Reset or Service
