RSA Lighting Microgem MLV3064 User manual

DESCRIPTION Catalog # Type
Project
Comments Date
Prepared by
www.cooperlighting.com
SPECIFICATION FEATURES
A Trim
50˚ adjustable slot aperture trim for
downlight and accent applications. 4.3”
o.d. trim face.
B Lamp
For use with 12V MR16 lamp 71W max.
Lamp not included.
C Socket
GU5.3 bi-pin socket for 12V MR16.
(Included with Microgem housing sold
separately)
D Lens
Includes clear protective glass lens.
Can hold up to 2 optical accessories total.
E Finish
MLV3064 Powder coated white trim.
MLV3066 Powder coated black trim.
MLV3067 Powder coated industrial
silver trim.
MICROGEM
RECESSED
MLV3064 - 3067
4.3” O.D.
Round Die Cast Slot
Aperture Trim 50˚
Adjustability
FOR 12V MR16 71W max.
Compatible Housings:
C500 / C500-SH
C600 / C600-EL
C700
C800
C900
SH2A
ORDERING INFORMATION
Fixture
MLV3064 White Trim
MLV3066 Black Trim
MLV3067 Industrial Silver Trim
4.3” round recessed adjustable slot trim for downlight and accent
applications. For use with 12V MR16 lamp 71W max.
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX [phone]
rev. 102406
2.52”
4.31” dia.
1.375”
2.25”
50˚
A
B
C
D
E
