RSA Lighting MINI ACCURUS ACM502IC User manual

DESCRIPTION Catalog # Type
Project
Comments Date
Prepared by
SPECIFICATION FEATURES
www.cooperlighting.com
10.00”
17.50”
14.25”
5.00”
7.63”
0.5” - 1.0”
Ceiling
Cut-Out
3.63”dia.
A...Housing
Housing and plaster frame: 18 gauge CRS
with flat black powder coated internal
finish. Adjustable plaster frame can
accommodate up to 1” ceiling thickness.
B ...System Protection:
Thermal protection provided to guard
against overheating and misuse of
insulation over and around fixture.
C ...Electrical
Integral j-box and low voltage (12V)
transformer . 120V input, 12V output.
Junction box is U.L. listed for through
branch wiring. Includes seven 1/2 trade
size knockouts.
D...Lamp
12V MR16 50 watts max. (not included)
Internal rotation ring with locking
adjustment. Provides 360º rotation of
trim and secures original trim position
after relamping. “POSI-GRIP” bi-pin
lamp socket for firm, mechanical lamp
connection.
E ...Mounting
Hanger Bars included.
Ceiling Cut-Out: 3.63” dia.
MINI
ACCURUS
ACM502IC
Insulated Ceiling
Air Tite
I.C. Housing
for Round Trim
FOR 12V MR16 50 watts max.
ORDERING INFORMATION
Housing
ACM502IC =
Mini Accurus
I.C. Housing
for Round Trim
w/ Integral Transformer
Voltage
120 =120 volts primary
277 =277 volts primary
New construction I.C. housing for Mini Accurus small aperture round
trims. (ACM5001, ACM5002, ACM5003, ACM5004).
For use in insulated ceiling I.C. applications. Housing may be covered on
all sides with insulation material.
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX [phone]
Transformer
ELC =Electronic
MAG =Magnetic
ACM502IC
rev. 091806
