RSA Lighting ACM5002 User manual

DESCRIPTION Catalog # Type
Project
Comments Date
Prepared by
www.cooperlighting.com
SPECIFICATION FEATURES
A...Recessed Trim
Fixed position wall wash trim. 3.9” o.d. trim
face with 1.7” aperture. Includes bullet
plunger retainers for smooth snap-in action
during installation and removal of trim for
relamping. Helps guard against plaster
cracking.
B ...Lamp
For use with 12V MR16 lamp 50W max.
*CMH MR16 20W or *ES16 BriteSpot 39W.
Lamp not included.
C ...Socket
Posi-Grip bi-pin socket for 12V MR16. GX10
for metal halide lamps. (Included with Mini
Accurus Housing sold separately)
D...Lens
Frosted lens included. Can hold up to two (2)
optical accessories total.
E ...Reflector
Includes internal “kicker” reflector for
optimized light output.
F....Finish
Trim face is powder coated in white, black,
industrial silver, stainless steel or primer
finish for painting in existing ceiling color.
All other internal components are flat black.
G...Safety
Steel safety cable provided. Attaches to
tab inside housing to prevent falling during
maintenance or as a result of accidental
dislodging of the trim.
MINI
ACCURUS
RECESSED
ACM5002
3.9” O.D.
1.7” Aperture
Round Fixed
Wall Wash Trim
FOR 12V MR16 50W max.
*CMH MR16 20W
*ES16 BriteSpot 39W
Compatible Housings:
ACM500 / ACM500MH
ACM502IC / ACM502ICMH
ACM504RM / ACM504RMMH
ORDERING INFORMATION
Fixture
ACM5002 =
3.9” Recessed Fixed Position
Round Wall Wash Trim
1.7” Aperture
3.9” small aperture fixed position round recessed wall wash trim.
For use with 12V MR16 lamp 50W max., *CMHMR16 20W, or *ES16
BriteSpot 39W.
For use in wall washing applications where small aperture, recessed
ceiling fixtures are desired.
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX [phone]
Finish
WH =White
BK =Black
S =Industrial Silver
SS =Stainless Steel (painted)
PM =Primer
ACM5002
A
B
D
E
C
G
3.90” dia.
1.70"
dia.
* Consult factory for metal halide lamps
rev. 091806
