RSA Lighting LYNX LX3001 User manual

DESCRIPTION Catalog # Type
Project
Comments Date
Prepared by
www.cooperlighting.com
SPECIFICATION FEATURES
18.00”
Flexible Conduit
3.50” dia.
1.75” dia.
6.00”
2.00”
A
D
B
C
E
5.50”
A...Housing
All aluminum construction with 18” of
flexible conduit attached to a cylindrical
transformer/wiring enclosure. Swing
out mounting clips form pressure fit for
mounting in 1/2” - 3/4” drywall.
B ...Trim:
3.5” o.d. round trim with regressed black
baffle. Finished in white, black, industrial
silver, stainless steel (painted), and cus-
tom colors.
C ...System Protection:
Thermal protection inside housing.
Vent holes in housing provide cooler
operation. All aluminum construction
provides overall reduced temperatures.
D...Electrical
Electronic or magnetic transformer
housed in a separate metal enclosure.
Enclosure includes a separated wiring
compartment and entry for primary
leads.
E ...Lamp
12V MR16 37 watts max. (not included)
“POSI-GRIP” bi-pin lamp socket for firm,
mechanical lamp connection. Can accept
up to two (2) optical accessories.
Ceiling Cut-Out: 3.19” dia.
LYNX
LX3001
Miniature Round
Trim w/ Regress
Black Baffle
Cylindrical Housing
Transformer/Wiring
Enclosure
12V MR16 37 watts max.
ORDERING INFORMATION
Fixture
LX3001
Regressed Black Baffle Lynx
Trim with Housing & Trans-
former Enclosure
Miniature cylindrical recessed housing and round trim with regressed
black baffle. Includes enclosure with integral transformer and wiring
compartment.
For new construction or remodel applications. Insulation must be kept 3”
from all sides and at least 1” above the housing.
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX [phone]
LX3001
Finish
WH =White
BK =Black
S =Industrial Silver
SS =Stainless Steel (painted)
PM =Primer
Transformer
ELC =Electronic
MAG =Magnetic
Voltage
120 =120 volts
277 =277 volts
U.L. Listed. Suitable for use in
combustible ceilings.
rev. 011007
