RSIalarm videofied SE600 Instruction sheet

www.videofied.com
Product Summary
The Interior Siren Model SE 600 is a wireless siren
designed for use in RSIalarm™ security systems.
The siren includes the following features:
> Totally wireless, battery operated
> Dual tamper function provides detection for both wall
and cover tamper.
> Transmits check-in/status signal every 8 minutes
Installation Guidelines
For easier installation, programming and RF testing
should be done to check for good communication between
the control panel and all system devices before mounting
system devices. Install the siren and other system devices
in the following order:
>Programming/RF Testing—program detector
and all other devices into the control panel and test
RF communication from each intended device location
to the control panel.
>Mounting—mount detector at the tested location.
Programming/RF Testing
The following provides summarized steps for device
programming and testing. For complete details, refer
to the control panel installation manual.
1Remove bottom screws,
separate cover from siren
and install batteries.
2Put control panel
into programming/
configuration mode.
3Using a programmed
alphanumeric keypad,
proceed through menus
until the display shows
ADD A NEW DEVICE.
4Press Yes. The display
shows PRESS PROGRAM
BUTTON OF DEVICE.
5Press and release
program button on siren
using a paper clip end.
The siren LED flashes.
Wait for keypad display
to show SIREN (1 - 25)
RECORDED.
6Press Yes. The display shows RADIO RANGE TEST?
Press Yes again. The siren LED starts flashing and
keypad display shows TEST IN PROGRESS.
7Take siren to its intended mounting location and
make sure LED flashes continuously, indicating good
communication with control panel.
8Press Yes to end radio range test, then press Esc/No.
9The display shows RECORDING A NEW DEVICE?
Repeat steps 4 - 8 for remaining sirens.
10 When finished, exit from configuration mode.
Screws
Program Button
INSTALLATION INSTRUCTIONS
Interior Siren Model SE 600
Manufactured by RSIalarm Document No. 1011-c November 2006

4455 White Bear Parkway, Suite 700
White Bear Lake, MN 55110
USA
Toll Free: 877-206-5800
Fax: [phone]
www.videofied.com
© 2007 RSIalarm™ Videofied®is a Registered Trademark of RSIalarm™.
S2View is a registered trademark of RSIalarm™. Specifications subject to change without notice.
Mounting
>
Use proper tools and hardware.
>
Mount where siren can be heard by occupants.
>
Mount out-of-reach of intruders to help prevent
disabling of unit.
Regulatory Information
FCC Part 15
This device complies with FCC Rules Part 15. Operation
is subject to the following two conditions:
1.) This device may not cause harmful interference
and, 2.) this device must accept any interference that
may be received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved
by RSIalarm, Inc. can void the user’s authority to operate
the equipment.
Specifications
Panel Compatibility V-6000
Operating Frequency 915 MHz.25 frequencies
Radio type Spread Spectrum Bidirectional RF
Power Requirements Four 1.5 V Alkaline batteries
Battery Type D size alkaline
Output Level 110 dB @ 1 meter
Operating Temperature 32° - 104° F (0° - +40° C)
Maximum Relative Humidity 70%, non-condensing
Dimensions (LxWxD) 11 in. x 6-1/4 in. x 2-1/4 in.
(280 mm x 158mm x 57 mm)
Weight 26 oz./740 g (without batteries)
UL Listings 1023 (applied for)
1Remove batteries.
2Hold unit up
against mounting
surface and mark
the three mounting
holes.
3Drill pilot holes
and install anchors
where needed.
4Place unit on mounting surface so mounting holes
line up with pilot holes/anchors and secure unit with
appropriate screws.
5Install batteries, observing correct polarity.
6Attach front cover.
Mounting Holes
INSTALLATION INSTRUCTIONSInterior Siren Model SE 600
