4Install Brackets and Expanding Shelves
A
5Install Adjustable Clothes Rods
End cap
fit on outer
clothes rod
End cap
fit on inner
clothes rod 3" max.
“A” shelf sits in
front notch “B” shelf sits in
back notch
Bracket
Hint: When overlapping sections of shelving, shelves labeled “A” must be placed onto brackets before shelves labeled “B”.
Press firmly
into place
Secure shelves with bracket locks
After all shelves are positioned properly,
lock shelves into brackets by sliding the
plastic locking clip toward the back wall.
It will “snap” into locked position.
Place shelves onto brackets
Shelf labeled “A” sits in front notch of bracket. Shelf labeled “B” sits in back notch. Be
sure each shelf slides back as far as possible before locking shelves into brackets. If
overlapping three sections of shelving, use two “A” sections and one “B” section,
placing “A” sections on the outside and spanning the gap with “B” sections. For four
or more overlapping sections, continue alternating between “A” and “B” sections,
placing “A” shelves on brackets before “B” shelves.
Insert brackets
Insert brackets into uprights at desired
locations. Note: Install brackets and
shelving at the top first and work down.
Brackets will not fit into upper two slots
of each upright.
B
on top
Overlapping shelves
Shelves are fully adjustable and require no
cutting. To adjust width, overlap the shelves
making sure the shelf labeled “A” is placed
first on the brackets and the shelf labeled
“B” is placed on top of “A”.
Install shelves into brackets
Confirm that the bracket locks are
unlocked and install shelving making
sure that the “nose” of the bracket is
projecting out through the front edge of
the shelf. Note: For maximum weight
capacity, do not insert brackets into
bottom slots of upright.
Install rod hanger
Install rod hanger into bottom
of bracket by tilting it backward
until it locks in place. Note: Be
sure to press rod hangers firmly
into place for proper installation.
Adjust rod length
Rods can be used separately
or telescoped together. 48" rods
telescope up to 8' and 26" rods
telescope up to 4'.
Add end caps
Place end caps on the end
of each clothes rod. End caps
will fit either diameter of rod
(as shown above).
Secure rod and hanger
After expanding clothes rod to
desired length, place into rod
hangers and press down to snap
into place. Note: Do not extend
more than 3" past rod hangers.
A B C D
AB
D
C (1)
C(2)
Hint: If shelves are installed in the incorrect notch, shelving weight capacity could be lessened.
3Hang Uprights
2Plan Your Layout
2"
22"
Use anchor if
there is no stud.
Hang uprights
Hang first two 47.5" uprights
over the hang rail.
Position at 2"
Position both outside uprights
2" from the right and left
corners by using the 2" rail
cover for spacing.
Secure
Mark bottom hole of each
upright. Drill 1/8" pilot hole
into stud. (Use wall anchor and
3/8" bit if there is no stud.)
Fasten at bottom
Fasten screws into studs or
wall anchors. Screws are
needed only in bottom holes
of uprights.
Attach 2" rail cover
Clip 2" rail cover over hang rail
so uprights stay in place.
Use 22" rail cover for spacing
Hang another 47.5" upright on the rail and
use one of the 22" rail covers to space over 22".
Drill 1/8" pilot hole and fasten screws in bottom
hole. (Use wall anchor and 3/8" bit if there is
no stud.) Place 22" rail cover over rail between
uprights. Repeat step F for additional upright
(If space allows).
Attach 22" rail cover
If the space between the last uprights is less
than 22", you may choose to cut rail cover with
scissors to fit.
Note: Add-on accessories require uprights to be
placed at 22" apart.
Hint: If the left side of closet is more accessible, space the remaining uprights from left to right. If the right side of the closet is
more accessible, space the remaining uprights from right to left.
Hint: Determine the placement of your shelves and hang rails. Start from the top and work your way down to ensure that you
have enough room.
A
EFG
B C D
Before securing uprights, be sure to assess
your storage needs. If you are using Homefree
accessories, be sure to place your uprights at
22" apart and ensure drawers or sliding
baskets have adequate space.
