Thank you for choosing and for your trust in our brand name. Plaese read this manual
carefully before using the apparatus. It is important thar you handle and use the
apparatus according to the instructions, to prolong its life, and to avoid problems and
accidents.
After reading the manual, keep it for ready reference.
INDEX
1. Specification……………...………………………………….……………………...11
2. Description………….……………………………………….…….………………...11
3. Warnings………….……………………………………….…….…………………..12
4. Fixing and Installation ……………………………….…………………………......13
5. Electric conection…………………………………….……….………………….....14
6. Turning on the appliance…………..………………………………………………..15
7. Maintenance………………………………………………………………………...15
8. Garantee………………………………………………………………….………….16
9. After-service…………………………………………………………….…………..17
10. Environmental protection…………………………………………………………..17

11
1. Specifications
The Dry-towel are apparatus of classe II.
They have a control knob of the power of heating with 5 positions: (1) stop, (2) cold
ventilation, (3) tepid air (1000 W), (4) hot air (2000W), (5) thermostat. The position
thermostat controls the operation of the apparatus when it is with 2000 Watts.
SDB-SS 2010
Output Power (W) 1000W/2000W
Power supply (V) 230v/50Hz
Weight (kg) 6,2
Protection class II, IP24
SDB 2000
1000W/2000W
230/50Hz
4,5
II, IP24
2. Description
1) Timer
2) Power switch & Thermostat
3) Hot air outlet
4) Towel rack for model SDB-SS 2010
3
4
1
2
3
4

12
3. Warnings
VERY IMPORTANT
• Never cover
 It is normal for a slight door to be smelt when the appliance is turned on for the fist
time or after cleaning (dust deposited on the appliance).In order to avoid
overheating, do not cover the heater.
 Do not swing on the towel rack.(model SDB-SS 2010)
 This appliance is designed for wall-mounted installation.
 The heater must be installed so that the switch & control can not be touched by
persons in the a bath or shower.
 This appliance is designed solely for domestic use. It can not therefore be used for
industrial applications.
 This appliance is only designed for drying items washed in water.(model SDB-SS
2010)
 Don’t insert or allow any other object to enter any ventilation or exhaust opening
because this may cause an electrical shock, fire or damage to the heater.
 Don’t leave the heater unattended. Always unplug the heater when not in use.
 The supply cord must never be pulled over sharp edges or jammed.
 Don’t cover the heater at any time when operating.
 If the appliance is faulty or damaged, it must be repaired by an authorizer service
center.
 The appliance must only be cleaned externally by use of a dry or slightly moist
cloth.
 Observe your appliance when turning it on for the first time.
 Before hanging the towel, please make sure that there is no water drop from the
towel..(model SDB-SS 2010)
 The heater must not be located immediately below a socket-outlet
 Means for disconnection must be incorporated in the fixed wiring in accordance
with the wiring rules.
 It is recommended that installation shall be conducted by quality electrician.
If the supply cord is damaged, it must be replaced by a special cord or assembly
available from the manufacturer or its service agent.

13
Minimal distance of installation to be respected
The apparat can be placed on volume 2 and 3 of the bathroom (see picture above).
You ensure that the installation of the apparatus respects the distances minima strictly: to
60 cm of flammable objects and 140 cm of the level of the ground.
Installation
To placed correctly the apparat,
1. For the model SDB-SS 2010, assemble the dry-towels on the support fixed at the wall
(fig1) without you support on the bottom of the heating
2. Hang the apparatus on its support (fig2). There are 3 points of fixing to the back of the
apparatus. Place the apparatus against the wall with the 2 higher points of fixing above the
support fixed at the wall. Make slide the apparatus downwards until the 2 points are fixed
on the legs of the support. Press to the bottom firmly.
4. Fixing and installation

14
3. For the model SDB-SS 2010, assemble the heater on the towel rack by fitting the slots
of the heater to the pins of the towel rack. Then screw the upper screw as mentioned in
point 3 to assemble the heater and the towel rack together. (see fig 3)
The electric installation wich it is be connected must be conform with the
requirements of the norm NF C 15-100. In a bathroom, the electric connection of the
apparat must be protected by an individual fuse whose residual current amperage should
not exceed 30 Am.
It is not necessary to dismount the apparatus to carry out its electric connection. The
apparatus should not be installed under a Socket for plug at fixed station.
Always want with the good state of your electric installation and with wire of connection.
If the electric cable is damaged, made call with the manufacturer, his service after sale or
a person of similar qualification to replace it in order to avoid a danger.
Before all intervention, do not forget to to cut off the electric supply of the circuit.
5. Electric connection

15
 Turn the switch knob to select:
OFF
Cool Drying
Warm Drying
Hot Drying
There are two controls device. They are timer and thermostat.
1/ Timer
It works during the mode of cool drying and the mode of warm drying.
2/ Thermostat
During the mode of hot drying, turn the thermostat knob to the max position. Once the
room temperature has reached the desired temperature, turn the thermostat knob slowly
until a faint “Click” is heard and felt. This is the current temperature and the heater will
now maintain this setting. The appliance will automatically maintain the set temperature.
The thermostat will switch the appliance off when the room temperature is above the set
temperature, and switch on if below.
To preserve the performances of the apparatus, it is necessary to remove the dust from
the interior of this one while passing the vacuum cleaner on the radiator grille of the
apparatus. It is also necessary to carry out a de-dusting of the outsides parts:
* Control board
* Between the apparatus and the wall
* Underneath and on the apparatus
ENSURE YOU THAT the apparatus is off (button M/A is in position A) then:
To remove dust, use a soft rag.
To remove a spot, humidify the rag slightly
CAUTION:
Never not to use abrassive or corrosive products which would
be likely to deteriorate the apparatus. Never not use cutting,
conducting objects of electricity which would be likely to deteriorate
the apparatus.
6. Turning on the appliance
7. Maintenance

16
A) Condition general of guarantee
The heating system must be installed according to the instructions indicated in the
intructions, according to the norm in force. The apparatus must be used under normal
conditions and regularly maintained. Under these condition, it is guaranteed within
the framework of the legislation in force.
B) Effect and Lasted
The guarantee takes effect as from the date of purchase of the apparatus against vice of
manufacture. To be taken into account, any request for repair under guarantee will have
obligatorily to satisfy the presentation of the invoice or the sales slip (name of the
product being reproduced on the proof of purchase). Its duration is 24 months. The
replacement of a component or a product cannot to in no case to prolong the initial
duration of the guarantee.
C) Territory of applicability
The guarantee applies only in Metropolitan France, Belgium, Luxembourg, Holland,
Italy, Germany, Switzerland, Norway, Denmark, the United Kingdom, Spain, Portugal,
Poland
D) Field of application
The guarantee applies only if the apparatuses were the subject of a normal use and does
not cover deteriorations which result from:
• Bad assembly or connection
• Overpressure or problem with the electric installation
• Various products (water, solvents, products domestic…...)
• Deposit of foreign objects inside or on the apparatus
• Deposits of dust
• Moisture of the part
The guarantee is limited to the repair of the apparatuses and components which we will
have recognized defective origin. For that, prior agreement of our service after sale will
be necessary before any return of apparatus. The displacement and packing, carriage
costs will remain with the load of the user as well to the outward journey as with the
return. The guarantee does not cover the nondetectable damage immediately resulting
from problem because of the choice of the site of the apparatus (difficult to reach place).
8. Garantee

17
The guarantee applies only to the heating and its components other than whole or part of
the electric installation of the apparatus.
E) Litigations
This guarantee at all does not limit the statutory rights of the customer under the
national laws into force, nor the rights of the customer opposite to the retailer, fixed in
their contract of sale/purchase. (In France, you profit in any event from the legal
provisions relating to the guarantee of the hidden defects: articles 1641 and following of
the civil code.) We dismissing expressly any other complaint and request for
compensation whatever they are.
For all technical questions, thank you to contact your retailer, in the event of
dissatisfaction, you can contact us via our electronic mail: [e-mail]
