Ruijie RG-AP520 Series Installation and operating manual

RG-AP520 Series Access Point
Hardware Installation and Reference Guide V1.0

·
Copyright statement
Ruijie Networks© 2016
Ruijie Networks reserves all copyrights of this document. Any reproduction, excerption, backup,
modification, transmission, translation or commercial use of this document or any portion of this document,
in any form or by any means, without the prior written consent of Ruijie Networks is prohibited.
, , , ,
, ,
, , ,
, , are registered trademarks of Ruijie
Networks. Counterfeit is strictly prohibited.
Exemption statement
This document is provided “as is”. The contents of this document are subject to change without any notice.
Please obtain the latest information through the Ruijie Networks website. Ruijie Networks endeavors to
ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to
content omissions, inaccuracies or errors.

·
Preface
Thank you for using our products. This manual will guide you through the installation of the access point.
Scope
It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it
is assumed that the users are already familiar with the related terms and concepts.
Obtaining Technical Assistance
Ruijie Networks Website: http://www.ruijienetworks.com/
Service Email: [email protected]
Technical Support: http://www.ruijienetworks.com/service.aspx
Technical Support Hotline: [phone]
Related Documents
Documents
Description
Configuration Guide
Describes network protocols and related mechanisms that supported by the
product, with configuration examples.
Command Reference
Describes the related configuration commands, including command modes,
parameter descriptions, usage guides, and related examples.
Documentation Conventions
The symbols used in this document are described as below:
This symbol brings your attention to some helpful suggestions and references.
This symbol means that you must be extremely careful not to do some things that may damage the device or
cause data loss.

·
Chapter 1 Product Overview
RG-AP520 is a wireless LAN access point (AP) designed by Ruijie Networks for demanding indoor deployments. It can
serve as a Fit AP and operate in conjunction with a unified wired/wireless switch or a wireless controller; or it can serve as
a standalone Fat AP and provide wireless access for mobile clients.
Technical Specifications
Table 1-1 Technical Specifications of RG-AP520
Hardware Specifications
Radio
RF
2.4GHz: 2 x 2MIMO
5GHz: 2 x 2MIMO
Transmission
Protocol
2.4GHz: 802.11b/g/n
5GHz: 802.11a/n/ac
Operating Bands
802.11b/g/n: 2.4 GHz to 2.4835 GHz
802.11a/n/ac: 5.15 GHz to 5.35 GHz, 5.47 GHz to 5.725 GHz, 5.725 GHz to 5.85GHz
(Depending on which country the AP is installed)
Antenna
Built-in omnidirectional, antenna gain: 3dBi
Spatial Streams
2
Access Rates
2.4GHz: up to 300Mbp
5GHz: up to 867Mbps
Total: up to 1.167Gbp
Modulation
OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps
DSSS: DBPSK@1Mbps, DQPSK@2Mbps, and [email protected]/11Mbps
MIMO-OFDM: BPSK, QPSK, 16QAM , 64QAM and 256QAM
Receive Sensitivity
802.11b: -99 dBm (1 Mbps), -93 dBm (5.5 Mbps) , -90 dBm (11 Mbps)
802.11a/g: -93 dBm (6 Mbps), -85 dBm (24 Mbps), -82 dBm (36 Mbps), -77 dBm (54 Mbps)
802.11n: -92 dBm@MCS0, -74 dBm@MCS7, -92 dBm@MCS8, -73dBm@MCS15
802.11ac HT20: -90dBm (MCS0) , -65dBm (MCS8)
802.11ac HT40: -85dBm (MCS0) , -60dBm (MCS9)
802.11ac HT80: -82dBm (MCS0) , -58dBm (MCS9)
Maximum Transmit
Power
27 dBm
(Depending on the country of use, laws and regulations)
Transmit Power
Adjustment
1 dBm
Physical
Dimensions
(W x D x H)
194 mm x194 mm x 37 mm
Weight
0.2 kg
Service Ports
One 10/100/1000BASE-T Ethernet port (PoE-capable)
Management Ports
One RJ45 Console port

·
LED
1 LED (red, green, blue, orange, and flashing modes, breathing flashing mode for smart device
access, and the indicator can be switched off to silent mode)
Power Supply
Adapter: DC 12V (optional)
PoE: IEEE 802.3af/802.3at-compliant (compatible).
Power Consumption
Maximum: 12.95W
Temperature
Operating: -10 to 55℃(14 to 131 ℉)
Storage: -40 to 70℃(-40 to 158 ℉)
Humidity
Operating: 5% to 95% (non-condensing)
Storage: 5% to 95% (non-condensing)
Installation
Ceiling/wall mount
IP Rating
IP41
Safety Standards
GB4943
IEC 60950-1
EMC Standards
GB9254
EN301 489
EN50155
EN50121
Vibration Standards
IEC61373
Radio
China Radio Transmission Equipment Type Approval Certificate
EN300 328
EN301 893
MTBF
>400,000H
Software Functions
Security
Data encryption
WPA(TKIP), WPA2 (AES), WPA-PSK, WEP
(64 or 128 bits), and WAPI (hardware)
Frame Filtering
White list
Static blacklist
Dynamic blacklist
Rogue AP detection and countermeasure
Support
Dynamic ACL assignment
Support
RADIUS
Support
CPU Protection Policy (CPP)
Support
User isolation
Support
Network Foundation Protection Policy (NFPP)
Support
Routing
IPv4 address
Static IP address or DHCP reservation
IPv6 CAPWAP tunnel
Support
ICMPv6
Support
IPv6 address
Manual or automatic configuration
IPv6 tunnel
Manual or automatic configuration
ISATAP
Support
Multicast
Multicast to unicast conversion
Management and
Maintenance
Network management
SNMP v1/v2C/v3, Telnet, SSH, TFTP, and
FTP and Web management

·
Fault detection and alarm
Support
Statistics and logs
Support
FAT/FIT switching
Support
Maximum stations per AP
128 (The actual number of users depends on
environmental factors.)
The recommended number of stations per AP
32
Virtual AP
A maximum of 32 SSIDs
SSID hiding
Support
Configuring the authentication mode,
encryption mechanism, and VLAN attributes
for each SSID
Support
WDS (bridge mode)
Support
Remote Intelligent Perception Technology
(RIPT)
Support
Fair scheduling
Support
Intelligent identification of smart device
Support
Intelligent load balancing based on the number
of users or traffic
Support
STA control
SSID/radio-based
Bandwidth control
STA/SSID/AP-based speed control
5G band select
Support
The weight refers to the weight of host and bracket.
Product Image
The AP provides 5 ports, including 2 internal RF antenna ports, 1 Ethernet ports (PoE-capable), 1 Console port, and 1
power port for external power supply.
Figure 1-1 Top Panel of RG-AP520

·
LED Indicators
Fit AP
State
Frequency
Meaning
Off
N/A
The AP is NOT receiving power. Or the AP is in Do Not Disturb mode, which
can be disabled by software.
Blinking green
3Hz
Initialization in progress
Solid green
N/A
Initialization in progress
Blinking red
3Hz
Initialization is complete, but no Ethernet activity.
Blinking blue
3Hz
Initialization is complete, and the AP is establishing a CAPWAP connection
with an AC.
Blinking orange
3Hz
Firmware upgrade in progress. Do not power off.
Solid blue
N/A
Normal operation, but no wireless clients are associated with the AP.
Breathing blue
16 breaths/min
Normal operation, at least one wireless client is associated with the AP.
Solid red
N/A
Warnings(defined by software)
Double blinking
red
3Hz (on and off for
2 cycles
alternately)
Locate AP.
Fat AP
State
Frequency
Meaning
Off
N/A
The AP is NOT receiving power. Or the AP is in Do Not Disturb mode, which

·
can be disabled by software.
Blinking green
3Hz
Initialization in progress
Solid green
N/A
Initialization in progress
Blinking red
3Hz
Initialization is complete, but no Ethernet activity.
Blinking orange
3Hz
Firmware upgrade in progress. Do not power off.
Solid blue
N/A
Normal operation, but no wireless clients are associated with the AP.
Breathing blue
16 breaths/min
Normal operation, at least one wireless client is associated with the AP.
Solid red
N/A
Warnings(defined by software)
Double blinking
red
3Hz (on and off for
2 cycles
alternately)
Locate AP.
Power Sources
The AP can be powered either with a power adapter or through Power over Ethernet (PoE).
The AP requires Ruijie power adapters (If needed, you can buy them from Ruijie).
To use a PoE device, make sure it supports the IEEE 802.3af/at PoE standard.
Cooling Solution
The AP adopts fanless design.
Leave sufficient space at the surrounding of the AP when place the AP to permit airflow for proper ventilation.

·
Chapter 2 Preparing for Installation
To prevent device damage and bodily injury, please read carefully the safety recommendations described in
this chapter.
The recommendations do not cover all possible hazardous situations.
Installation
The AP must be installed indoors. To ensure its normal operation, the installation site must meet the following
requirements.
Install the AP in a well-ventilated environment. If it is installed in a closed room, make sure there is a good cooling
system.
Make sure the site is sturdy enough to support the AP and its accessories.
Make sure the site has enough space for installing the AP and leave sufficient room around the AP for ventilation.
Do not expose the AP to high temperature, dusts, or harmful gases.
Do not install the AP in an inflammable or explosive environment.
Keep the AP away from EMI sources such as large radar stations, radio stations, and substations.
Do not subject the AP to unstable voltage, vibration, and noises.
Keep the AP at least 500 meters away from the seaside and do not face it toward the wind from the sea.
The installation site should be free from water flooding, seepage, dripping, or condensation.
The installation site shall be selected according to network planning and features of communications equipment, and
considerations such as climate, hydrology, geology, earthquake, electric power, and transportation.
Please follow the correct method described in the installation guide to install and remove the device.
Movement
Avoid moving the device frequently.
Turn off all power supplies and unplug all power cables before you remove the device.
EMI
Please observe local regulations and specifications when performing electrical operations. Relevant operators must
be qualified.
Please carefully check for any potential danger in the working area, for example, damp/wet ground or floor.

·
Find out the location of the emergency power supply switch in the room before installation. First cut off the power
supply in case of an accident.
Be sure to make a careful check before you shut down the power supply.
Do not place the device in a damp/wet location. Do not let any liquid enter the chassis
Keep the AP far away from the grounding or lightning protection devices of power equipment.
Keep the AP away from radio stations, radar stations, high-frequency high-current devices, and microwave ovens.
Any nonstandard and inaccurate electrical operation can cause an accident such as fire or electric shock, thus
causing severe even fatal damages to human bodies and device.
Direct or indirect touch through a wet object on high voltage and power line can bring a fatal danger.
Ventilation
For proper ventilation, leave sufficient space around the AP.
Temperature and Humidity
To ensure normal operation and service life of the device, maintain appropriate temperature and humidity levels in your
equipment room. See Table 2-1. Improper room temperature and humidity can cause damages to the device.
High relative humidity may affect insulation materials, resulting in poor insulation and even electrical leakage, and
sometimes may lead to change of mechanical properties of materials and corrosion of metal parts.
Low relative humidity may dry and shrink insulation sheets and cause static electricity that can damage the circuitry
inside the device.
High temperature greatly reduces reliability of the device and shortens its service life.
Table 2-1 Required Temperature and Humidity for the RG-AP520
Temperature
Relative Humidity
-10 to 55 ºC
5% to 95%
Cleanness
Dust poses a serious threat to device operation. Dust that falls onto the surface of the device can be absorbed onto metal
contact points by static electricity, resulting in poor contact. Electrostatic absorption of dust occurs more easily when the
relative humidity is low, which may shorten the service life of the device and cause communication failures. Table 2-2
shows the maximum concentration and diameter of dust allowed in the equipment room.
Table 2-2

·
Maximum diameter (μm)
0.5
1
3
5
Maximum concentration
(Particles/m3)
1.4 x 10
7 x 10
2.4 x 10
1.3 x 10
Besides, the contents of salts, acids and sulfides in the air are also strictly limited for the equipment room. These
substances can accelerate metal corrosion and the aging of some parts. Table 2-3 describes the limit of some hazardous
gases such as SO2, H2S, NO2and Cl2 in the equipment room.
Table 2-3
Gas
Average (mg/m3)
Maximum (mg/m3)
SO2
0.2
1.5
H2S
0.006
0.03
NO2
0.04
0.15
NH3
0.05
0.15
Cl2
0.01
0.3
Power Supply
DC power adapter: 11.4 V DC to 12.6 V DC (input voltage), 15 W (minimum power)
PoE injector: IEEE 802.3af/802.3at compliant
The DC input power should be greater than the power actually consumed by the system. The input power for
the RG-AP520 should be greater than 12.95 W.
Please use Ruijie recommended power adapters.
Please use Ruijie certified PoE injectors.
Installation Tools
Common Tools
Phillips screwdriver, related copper and fiber cables, bolts, diagonal pliers, cable ties
Special Tools
Wire stripper, crimping pliers, RJ-45 crimping pliers, punch down tool
Meter
Multimeter, bit error rate tester (BERT)
The listed tools are customer supplied.

·
Unpacking the Access Point
Package Contents
Items
Verify that all parts are installed and debugged.
Screws
Mounting brackets
Product quick installation guide
Packing list
The above listed items are for general situations, which may vary in the actual shipment. The purchase order
shall prevail in any case. Please check each item carefully according to the packing list or purchase order. If
any item is damaged or missing, notify the sales person.

·
Chapter 3 Installing the Access Point
The RG-AP520 series must be fixed and installed indoors.
Before installing the AP, make sure you have carefully read the requirements described in Chapter 2.
Installation Flowchart
Before You Begin
Before you install the AP, verify that:
The installation site provides sufficient ventilation for the AP.
The installation site meets temperature and humidity requirements.
The installation site is equipped with proper power supply.
Network cables are in place.
The installation site meets all described requirements.
The custom AP meets the customers’requirements.
Precautions
To avoid damages to the AP, observe the following safety precautions:
Do not power the device during installation.
Install the device in a well-ventilated location.
Do not subject the device to high temperatures.
Keep away from high voltage cables.
Install the device indoors.
Do not expose the device in a thunderstorm or strong electric field.
Keep the device clean and dust-free.

·
Disconnect the device before cleaning it.
Do not wipe the device with a damp cloth.
Do not wash the device with liquid.
Do not open the enclosure when the AP is working.
Fasten the device tightly.
Installing the Access Point
Ceiling Mount
1) Drill four 6 mm diameter holes (61 mm apart) on the ceiling. Tap wall anchors into the holes, and drive screws
through the mounting bracket into the anchors to fix the bracket. See Figure 3-1.
Figure 3-1 Attaching the Mounting Bracket on the Ceiling
2) Align the square feet on the rear of the AP over the mounting holes on the bracket. See Figure 3-2.
Figure 3-2 Aligning the Square Feet with the Mounting Holes
Before mounting the AP on the bracket, you must first install the Ethernet cables.
3) Slide the AP into the holes until it clicks into place. See Figure 3-3.
Figure 3-3 Mounting the AP on the Bracket

·
The AP can be installed in any of four directions on the mounting bracket depending on how you route your
Ethernet cable.
The square feet should fit easily into the mounting slots. Do not forcibly push the AP into the slots.
After installation, verify that the AP is securely fastened.
Wall Mount
1) Drill four 6 mm diameter holes (61 mm apart) on the wall. Tap wall anchors into the holes, and drive screws through
the mounting bracket into the anchors to fix the bracket. See Figure 3-4.
Figure 3-4 Attaching the Mounting Bracket on the Wall

·
2) Align the square feet on the rear of the AP over the mounting holes on the bracket. See Figure 3-5.
Figure 3-5 Aligning the Square Feet with the Mounting Holes
Before mounting the AP on the bracket, you must first install the Ethernet cables.
3) Slide the AP into the holes until it clicks into place. See Figure 3-6.
Figure 3-6 Mounting the AP on the Bracket
When mounting the AP on the wall, keep the logo of Ruijie point upward.
The square feet should fit easily into the mounting slots. Do not forcibly push the AP into the slots.
After installation, verify that the AP is securely fastened.
Securing the Access Point
1) Press the button and insert the lock hasp into the lock slot on the back of the bracket.
Figure 3-1 Inserting Lock Hasp into the Slot

·
Press the button and unplug the lock hasp.
2) Align the lock loop protruding from the AP with the lock hasp hole.
Figure 3-2 Aligning the Lock Loop with the Lock Hasp
Before mounting the AP on the bracket, you must first install the Ethernet cables.
3) Install the padlock.
Figure 3-3 Installing the Padlock

·
Install the padlock as needed.
Padlocks are customer supplied.
Removing the Access Point
1) Remove the padlock if there is one.
Figure 3-4 Removing the Padlock
2) If the AP is installed on the wall, hold the AP in your hands and push it upward and away from the bracket in the LAN
port direction.
Figure 3-5 Removing the Wall-Mount AP
3) If the AP is installed on the ceiling, hold the AP in your hands and push it sideward and away from the bracket in the
LAN port direction.
Figure 3-6 Removing the Ceiling-Mount AP

·
Connecting Cables
Connect UTP/STP to the LAN/PoE port on the AP. See Appendix A for supported wiring of twisted pairs.
By default, baud rate is set to 9600, data bit 8, parity none, stop bits 1 and flow control none on the console port
of the AP. The console port is used only when you want to configure the AP manually.
Avoid bending the cable to a small radius close to the connector.
Ruijie recommends you not use Ethernet cables with protective sleeves that may cause inconvenience to
installation of Ethernet cables.
Bundling Cables
Precautions
Make sure the cable bundles are neat and orderly.
Bend twisted pairs naturally or to a large radius close to the connector.
Do not over tighten cable bundle as it may reduce the cable life and performance.
Bundling Steps
1) Bundle the drop UTP/STP cables and route them to the LAN/PoE port.
2) Attach the cables in the cable tray of the rack.
3) Extend the cables under the AP and run in straight line.
Checking after Installation
Checking the Cabinet

·
Make sure the external power supply matches the specifications of the patch panel in the cabinet.
After installation, make sure you can close the front and rear cabinet doors.
Make sure the cabinet is stable and level.
Make sure the device and all cables are securely fastened in the rack.
Checking Cable Connection
Make sure the UTP/STP cable matches the interface type.
Make sure cables are properly bundled.
Checking the Power Supply
Make sure all power cables are properly connected and safe.
Make sure the AP is operational after power-on.
