Ruijie RG-SAP845-SP Installation and operating manual

Ruijie RG-SAP845-SP Access Point
Hardware Installation and Reference Guide
Document Version: V1.0
Date: 2023.08.21
Copyright © 2023 Ruijie
Networks

Copyright
Copyright © 2023 Ruijie Networks
All rights are reserved in this document and this statement.
Any reproduction, excerption, backup, modification, transmission, translation or commercial use of this
document or any portion of this document, in any form or by any means, without the prior written consent
of Ruijie Networks is prohibited.
Trademark and are owned by Ruijie Networks.
All other trademarks or registered trademarks mentioned in this document are owned by their respective
owners.
Disclaimer
The products, services, or features you purchase are subject to commercial contracts and terms. Some or
all of the products, services or features described in this document may not be within the scope of your
purchase or use. Unless otherwise agreed in the contract, Ruijie Networks does not make any express or
implied statement or guarantee for the content of this document.
Due to product version upgrades or other reasons, the content of this document will be updated from
time to time. Ruijie Networks reserves the right to modify the content of the document without any notice
or prompt.
This manual is for reference only. Ruijie Networks endeavors to ensure content accuracy and will not
shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or
errors.

I
Preface
Intended Audience
This document is intended for:
Network engineers
Technical support and servicing engineers
Network administrators
Technical Support
Ruijie Networks Website: https://www.ruijienetworks.com/
Technical Support Website: https://ruijienetworks.com/support
Case Portal: https://caseportal.ruijienetworks.com
Community: https://community.ruijienetworks.com
Technical Support Email: [email protected]
Skype: [email protected]
Conventions
1. Signs
The signs used in this document are described as follows:
Warning
An alert that calls attention to important rules and information that if not understood or followed can
result in data loss or equipment damage.
Caution
An alert that calls attention to essential information that if not understood or followed can result in
function failure or performance degradation.
Note
An alert that contains additional or supplementary information that if not understood or followed will
not lead to serious consequences.
Specification
An alert that contains a description of product or version support.

II
2. Note
The manual offers information (including model, port type and command line interface) for indicative
purpose only. In case of any discrepancy or inconsistency between the manual and the actual version, the
actual version prevails.

i
Contents
Preface...................................................................................................................................................I
1 Product Overview .............................................................................................................................1
1.1 Overview ...................................................................................................................................1
1.2 Appearance...............................................................................................................................1
1.3 Package Contents.....................................................................................................................4
1.4 Product Technical Specifications ............................................................................................4
1.4.1 Dimensions and Weight...............................................................................................4
1.4.2 RF Specifications...........................................................................................................5
1.4.3 Port Specifications........................................................................................................6
1.4.4 Power Supply and Consumption ................................................................................7
1.4.5 Environment and Reliability ........................................................................................8
1.5 LED and Button Description....................................................................................................8
1.6 SFP Module Description...........................................................................................................9
2 Installation Preparation .................................................................................................................11
2.1 Safety Recommendations......................................................................................................11
2.1.1 Universal Safety Recommendations.........................................................................11
2.1.2 Moving Safety .............................................................................................................11
2.1.3 Electrical Safety...........................................................................................................11
2.1.4 Storage Safety.............................................................................................................12

ii
2.2 Installation Environment Requirements..............................................................................12
2.2.1 Load-bearing Requirements .....................................................................................12
2.2.2 Ventilation Requirements..........................................................................................12
2.2.3 Space Requirements ..................................................................................................13
2.2.4 Temperature and Humidity Requirements..............................................................13
2.2.5 Cleanliness Requirements.........................................................................................13
2.2.6 Anti-interference Requirements ...............................................................................14
2.2.7 Lightning Protection Requirements .........................................................................14
2.2.8 Checking the Installation Conditions........................................................................15
2.3 Installation Tools....................................................................................................................15
3 Installation ......................................................................................................................................16
3.1 Installation Process................................................................................................................16
3.2 Installation Preparation.........................................................................................................16
3.3 Precautions.............................................................................................................................17
3.4 Installing the Master AP ........................................................................................................18
3.4.1 Ceiling-Mounted.........................................................................................................18
3.4.2 Wall-Mounted .............................................................................................................20
3.4.3 Disassembling Device ................................................................................................22
3.5 Installing Other Modules.......................................................................................................23
3.5.1 Installing Security Lock ..............................................................................................23
3.5.2 Installing SFP Module ................................................................................................24

iii
3.6 Connecting Cables .................................................................................................................25
3.7 Bundling Cables......................................................................................................................25
3.7.1 Precautions.................................................................................................................25
3.7.2 Simplified Steps of Cable Bundling...........................................................................25
3.8 Check After Installation .........................................................................................................25
3.8.1 Master AP Check.........................................................................................................25
3.8.2 Cable Connection Check............................................................................................25
3.8.3 Power Check ...............................................................................................................25
4 Commissioning ...............................................................................................................................27
4.1 Setting Up Configuration Environment................................................................................27
4.2 Power-on.................................................................................................................................27
4.2.1 Check Before Power-on .............................................................................................27
4.2.2 Check After Power-on ................................................................................................27
5 Monitoring and Maintenance........................................................................................................28
5.1 Monitoring ..............................................................................................................................28
5.1.1 Indicator......................................................................................................................28
5.1.2 CLI................................................................................................................................28
5.2 Remote Maintenance.............................................................................................................28
5.3 Hardware Maintenance .........................................................................................................28
6 Troubleshooting .............................................................................................................................29
6.1 Universal Troubleshooting Process......................................................................................29

iv
6.2 Typical Troubleshooting Cases .............................................................................................29
6.2.1 Ethernet Port Does Not Work After Being Connected to an Ethernet Cable........29
6.2.2 Indicator Is Off for a Long Time................................................................................29
6.2.3 Indicator Remains Red for a Long Time...................................................................29
6.2.4 Indicator Remains Green for a Long Time...............................................................30
6.2.5 Indicator Fast Blinks in Blue (Fit AP) .........................................................................30
6.2.6 Indicator Is Not Steady Blue or Does Not Blink in Blue..........................................30
6.2.7 Users Cannot Find Wireless Signals..........................................................................30
7 Appendix .........................................................................................................................................31
7.1 Connector and Connection Media Description ...................................................................31
7.2 SFP Module Type and Technical Specifications ...................................................................33
7.3 Recommendations on Wiring During Installation .................................................................I
7.4 DC Power Connector Specifications .......................................................................................V

Hardware Installation and Reference Guide Product Overview
1
1 Product Overview
1.1 Overview
RG-SAP845-SP is an 802.11ax-compliant wireless access point product developed for indoor scenarios
such as higher education, government, general education, finance, and business. It uses dual-radio
technology, of which the 2.4 GHz frequency can provide up to 574 Mbps access rate and 5 GHz can provide
up to 4.804 Gbps access rate. The whole machine can provide the maximum wireless access rate of 5.378
Gbps. The ultra-fast wireless access rate takes performance out of the equation.
The important factors such as wireless network security, RF control, mobile access, service quality
assurance, and seamless roaming are fully considered in the design of RG-SAP845-SP. It works with a
wireless controller to guarantee data forwarding, security and access control of wireless users.
RG-SAP845-SP can be operated in 802.11ax, 802.11ac, and 802.11n modes concurrently. The product
supports ceiling and wall-mounted installation modes, and can be safely and conveniently installed on
ceiling and walls. RG-SAP845-SP supports local power feeding or power feeding over Ethernet (PoE). You
can flexibly select appropriate power feeding methods according to the on-site power feeding
environment. The product is especially suitable for large campus, enterprise offices, and operating
hotspots.
1.2 Appearance
RG-SAP845-SP provides two radio frequency ports, two Ethernet copper ports (LAN1 supports PoE in
compliance with IEEE 802.3af, 802.3at and 802.3bt, and LAN2/IoT port supports power feeding to IoT units
(48 V/0.27 A, MAX: 12.95 W), one 5G SFP, one RJ45 Console port, one DC power connector, one USB port,
and one reset button. The appearance is as follows:
Figure 1-1 Top view

Hardware Installation and Reference Guide Product Overview
2
Figure 1-2 Bottom view
Figure 1-3 Front view

Hardware Installation and Reference Guide Product Overview
3
Table 1-1 Front view description
No.
Button and Port
Function Description
1
Indicator
Indicates the system working status.
Figure 1-4 Side view
Table 1-2 Button and port description
No.
Button and Port
Function Description
1
USB port
Connected to USB flash drive.
2
DC power port
Connected to 54 V DC power source to supply power to APs.
3
LAN1/PoE copper port
Uplinked to service port for wired Ethernet connection and service
data transmission, supporting PoE in compliance with IEEE 802.3af,
802.3at and 802.3bt.
4
LAN2/IoT copper port
Downlinked to service port for wired Ethernet connection and service
data transmission, providing power to IoT units (48 V/12.95 W).
5
Console port
Connected to serial port cable management device.
6
Reset button
Restarts the device or restores the factory settings.
7
5G SFP
Uplinked to service port for service data transmission.
8
Lock slot
Connected to security lock.

Hardware Installation and Reference Guide Product Overview
4
Note
The nameplate is at the bottom of the access point.
1.3 Package Contents
Table 1-3 Package contents
Name
Quantity
Master AP
1
Mounting plate
1
Wall anchor
4
Phillips pan head tapping screw 4.2*20
4
Hardware Installation and Reference Guide
1
1.4 Product Technical Specifications
1.4.1 Dimensions and Weight
Table 1-4 Dimensions and weight description
Dimensions and weight
RG-SAP845-SP
Product dimensions (W x D x H)
230 mm x 230 mm x 51 mm (9.06 in. × 9.06 in. × 2.01 in.)
Weight
Master AP: 1.0 kg (2.20 lb.)
Mounting plate: 0.1 kg (0.22 lb.)
Mounting mode
Ceiling and wall-mounted
Lock Option
Kensington lock, and built-in lock
Mounting plate dimensions (W x D
x H)
120 mm x 120 mm x 8 mm (4.72 in. × 4.72 in. × 0.31 in.)

Hardware Installation and Reference Guide Product Overview
5
Dimensions and weight
RG-SAP845-SP
Mounting plate hole interval
53 mm x 53 mm (2.09 in. × 2.09 in.)
For the diagram of mounting plate, see 3.2 Installation
Preparation.
Mounting plate hole diameter
6.5 mm (0.26 in.)
1.4.2 RF Specifications
Table 1-5 RF specifications description
RF specifications
RG-SAP845-SP
RF design
Dual-radio. A whole machine supports 6 spatial streams.
Radio1: 2.4 GHz, 2 streams: 2x2, MU-MIMO
Radio2: 5 GHz, 4 streams: 4x4, MU-MIMO
Working frequency band
802.11b/g/n/ax: 2.400 GHz to 2.4835 GHz
802.11a/n/ac/ax: 5.150 GHz to 5.350 GHz, 5.470 GHz to 5.725GHz, 5.725
GHz to 5.850 GHz
Note: The working frequency band varies according to the configuration
of different countries.
Transmission rate
Radio1: 2.4 GHz, 574 Mbps
Radio2: 5 GHz, 4.804 Gbps
Combined transmission rate:
2.4 GHz + 5 GHz, 5.378 Gbps
Antenna type
Built-in omnidirectional antenna
Antenna gain
2.4GHz: 5.9 dBi
5GHz: 6.2 dBi

Hardware Installation and Reference Guide Product Overview
6
RF specifications
RG-SAP845-SP
Maximum transmit power
20 dBm
Note: The actual transmit power varies according to country and region
regulations.
Power adjustment step
1 dBm
Modulation type
802.11b: BPSK, QPSK, and CCK
802.11a/g/n: BPSK, QPSK, 16-QAM, and 64-QAM
802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, and 256-QAM
802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, and 1024-QAM
Receiving sensitivity
IEEE 802.11b: -96 dBm (1 Mbps), -93 dBm (5 Mbps), and -89 dBm (11 Mbps)
IEEE 802.11a/g: -91 dBm (6 Mbps), -85 dBm (24 Mbps), -80 dBm (36 Mbps),
and -74 dBm (54 Mbps)
IEEE 802.11n: -90 dBm@MCS0, -70 dBm@MCS7, -89 dBm @MCS8, and -68
dBm@MCS15
IEEE 802.11ac: HT20: -88 dBm (MCS0) and -63 dBm (MCS9)
IEEE 802.11ac: HT40: -85 dBm (MCS0) and -60 dBm (MCS9)
IEEE 802.11ac: HT80: -82 dBm (MCS0) and -57 dBm (MCS9)
IEEE 802.11ax: HE80: -82 dBm (MCS0), -57 dBm (MCS9), and -52 dBm
(MCS11)
IEEE 802.11ax: HE160: -79 dBm (MCS0), -53 dBm (MCS9), and -50 dBm
(MCS11)
1.4.3 Port Specifications
Table 1-6 Port specifications description
Port specifications
RG-SAP845-SP
Bluetooth
Bluetooth 5.1

Hardware Installation and Reference Guide Product Overview
7
USB
USB3.0
Fixed service ports
Uplink: One 100/1000/2500/5000Base-T adaptive Ethernet port, supporting
IEEE 802.3af/802.3at/802.3bt-compliant PoE
One 5G SFP port, compatible with 1 GHz and 2.5 GHz SFP ports, a combo port
Downlink: One 10/100/1000Base-T adaptive Ethernet port, providing power
to IoT units (48 V/12.95 W)
Fixed management port
One RJ45 Console port
LED
One system LED
Button
One reset button
1.4.4 Power Supply and Consumption
Power Supply and
Consumption
RG-SAP845-SP
Powered type
(1) DC Power supply (DC input voltage/current: 54 V/1.1 A)
(2) PoE/PoE+/PoE++ (comply with 802.3af/at/bt Ethernet powering
standards)
The 802.3bt standard is recommended, in which the device can provide the
best performance.
Powering external
devices
Supported. Expand IoT units through the Ethernet ports.
Maximum power
consumption of the
whole machine
40 W
Caution
When the device provides PoE powering, it is necessary to ensure that the other end of the Ethernet
has 802.3af-compliant power feeding capability.

Hardware Installation and Reference Guide Product Overview
8
This product uses a fanless design. When placing the AP, ensure that there is enough space around
to facilitate air circulation.
By default, the AP works in the 802.3at power feeding mode. To enable bt-related functions, run
commands.
If 802.3af is used for power feeding, when the AP starts, the 2.4 GHz and 5 GHz frequencies can only
work in 1-stream mode, and the LAN2 port and USB port cannot supply power to external devices.
If 802.3at is used for power feeding, when the AP starts, the LAN2 port and USB port cannot supply
power to external devices.
1.4.5 Environment and Reliability
Table 1-7 Standards Compliance
Environment and
Reliability
RG-SAP845-SP
Temperature
Working temperature: -10°C to 50°C (14°F to 122°F)
Storage temperature: -40°C to 70°C (–40°F to +158°F)
At a height between 3000 m (9842.52 ft.) and 5000 m (16404.20 ft.) above
the sea level, every time the altitude increases by 220 m (721.78 ft.), the
maximum temperature decreases by 1°C (1.8°F).
Humidity
Working humidity: 5%RH to 95%RH (non-condensing)
Storage humidity: 5%RH to 95%RH (non-condensing)
Safety regulation
EN 300 328，EN 301 893，EN 300 440，FCC Part 15，EN IEC 62311，IEC
62368-1，EN 62368-1
EMC regulation
EN 55032，EN 55035，EN 61000-3-3，EN IEC 61000-3-2，EN 301 489-1，EN
301 489-3，EN 301 489-17
1.5 LED and Button Description
Note
In the description of the indicator status, unless otherwise specified, the indicator status description
applies to both Fit AP and Fat AP.

Hardware Installation and Reference Guide Product Overview
9
Table 1-8 System indicator status description
Indicator
Color
Blinking
Frequency
Description
Off
None
The AP is not powered on, or has been powered on but the indicator is
turned off by software.
Steady
green
None
The AP is performing software system initialization.
Steady red
None
The system is running normally, but the uplink service port of the AP is
Link Down.
Slow blink in
red
On for 3s
Off for 1s
In Fit AP mode, the establishment of a CAPWAP tunnel between the AP
and the AC times out.
Fast blink in
blue
On for 0.2s
Off for 0.2s
In Fit AP or MACC AP mode, the AP is updating software system.
Steady blue
None
The software system is running normally, and the AP is working
normally but no wireless users are online.
Blinking blue
On for 1s
Off for 1s
The software system is running normally. The AP is working normally
and wireless users are online.
Fast blink in
red
On for 0.2s
Off for 0.2s
In Fit AP mode, the AP enables the indicator positioning function to find
a specific AP.
Table 1-9 Reset button description
Button Type
Action
Result
Reset button
Press and hold for
less than 2s
The device restarts.
Press and hold for
more than 5s
Restore the factory settings.
1.6 SFP Module Description
The peer device that is directly connected to the 5G SFP port of the AP supports fiber ports and copper
ports. However, the negotiated rates are different when the devices at both ends use different port rates
or use different SFP modules. For details, see Table 1-10 and Table 1-11.
Table 1-10 Rate negotiation result when the peer is fiber port (unit: bps)
AP SFP Port
Rate
SFP Module Rate
Negotiation Rate Supported by Peer Port
1G
1G/10G/auto
1G/2.5G/5G/10G/auto
1G
3G
1G
1G
1G
1G
1G
1G
1G
1G

Hardware Installation and Reference Guide Product Overview
10
AP SFP Port
Rate
SFP Module Rate
Negotiation Rate Supported by Peer Port
1G
1G/10G/auto
1G/2.5G/5G/10G/auto
2.5G
3G
Not supported
Not supported
2.5G
2.5G
1G
1G
1G
1G
5G
6G
Not supported
Not supported
5G
5G
1G
1G
1G
1G
Table 1-11 Rate negotiation result when the peer is copper port (unit: bps)
AP SFP Port
Rate
O/E Converter
Rate
Negotiation Rate Supported by Peer Port
1G
1G/10G/auto
1G/2.5G/5G/10G/auto
1G
2.5G
Not supported
Not supported
Not supported
1G
1G
1G
1G
1G
2.5G
2.5G
Not supported
Not supported
2.5G
2.5G
1G
Not supported
Not supported
Not supported
5G
5G
Not supported
Not supported
5G
5G
1G
Not supported
Not supported
Not supported
Caution
1. The 2.5G SFP port of the AP does not support rate negotiation. When the O/E converter is used,
ensure that the rates of AP, O/E converter, and peer port are the same.
2. The device supports the combo ports. If both the uplink fiber port and the uplink copper port are
connected to cables, the AP will preferentially select the fiber port as the data transmission port
(automatically disables the copper port). When the cable is removed from uplink fiber port, the
copper port is automatically enabled.

Hardware Installation and Reference Guide Installation Preparation
11
2 Installation Preparation
2.1 Safety Recommendations
Note
To avoid injury to human body and equipment, read the safety recommendations in this manual
carefully before installation.
The following safety recommendations may not cover all possible hazardous situations.
2.1.1 Universal Safety Recommendations
High temperature, dust, harmful gas, flammable and explosive factors, electromagnetic interference
(large radar stations, transmitting stations, or substations) and the environment with unstable voltage,
large vibration or strong noise may affect the operating of AP. Do not install the device in such
environment.
It is strictly forbidden to install the device in places prone to water accumulation, seepage, dripping,
or condensation. When performing engineering design, comprehensively consider the factors such as
climate, hydrology, geology, earthquake, electricity, transportation, and select the address that meets
the requirements of communication device engineering environment design according to the
communication network planning and technical requirements.
The installation site should be dry, and it is not recommended to install the device in a place very close
to the sea. The distance between the device and the sea should be greater than 500 meters, and it is
not recommended to place the device on the windward side of the sea.
Do not place the device in walking areas.
During installation and maintenance, do not wear loose clothing, jewelry, or other items that may be
hooked by the chassis.
Keep tools and device away from walking areas.
2.1.2 Moving Safety
Do not move the device frequently.
Turn off all power sources and unplug all power sources and cables before moving or handling the
device.
2.1.3 Electrical Safety
Warning
Irregular and improper electrical operations may cause accidents such as fire or electric shock, and
cause serious or fatal injury to human body and device.

Hardware Installation and Reference Guide Installation Preparation
12
Do not directly contact high voltage and mains or contact them through wet objects; otherwise, it may
bring fatal danger.
When performing electrical operations, comply with local regulations and rules. The relevant staff
must have the corresponding qualifications.
Check carefully whether there are potential dangers in the work area, such as whether the ground is
wet.
Before installation, you need to know the location of the emergency power switch in the room. When
an accident occurs, the power switch must be turned off.
Check carefully before turning off the power.
Do not place the device in moist places and prevent liquid from entering the device.
It is not recommended to use the AP working ground together with the ground device of electrical
equipment or lightning protection ground device, and separate them as far as possible.
Keep the device far away from wireless transmitters, radar transmitters, high-frequency high-current
devices, microwave ovens and other high-power wireless devices.
2.1.4 Storage Safety
To ensure the normal operating of the device, see the storage temperature/humidity requirements in the
specifications for the storage environment of the device.
Caution
If the storage time exceeds 18 months, the device needs to be powered on and run for 24 hours without
interruption for device activation.
2.2 Installation Environment Requirements
The device must be used indoors to ensure normal operating and prolong its service life.
The installation site should meet the following requirements.
2.2.1 Load-bearing Requirements
Evaluate the floor load-bearing requirements according to the actual weight of the installed device and
its accessories (such as mounting plate and power supplies), and ensure that the load-bearing capacity
of the installation site meets the requirements.
2.2.2 Ventilation Requirements
Reserve the position for vent to ensure heat dissipation. After connecting all cables, arrange them into
bundles or place them on the cable distribution frame to avoid blocking the air inlet.
