RYOBI
JIG SAW
MODEL NO. JS550L
REPAIR SHEET

Figure A
RYOBI JIG SAW – MODEL NUMBER JS550L
2
1
2
13
10 21
14
16
9
20
12 22
18
19
23
17
24
25
5
6
8
7
4
3
11
15
26

RYOBI JIG SAW – MODEL NUMBER JS550L
3
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
JIG SAW or when ordering repair parts.
KEY PART
NO. NUMBER DESCRIPTION QTY
WARNING: Improper repair of a double insulated tool can result in damage to the double insulation system possibly causing electrical shock or
electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi Authorized Service
Center. For the service center nearest you call 1-800-525-2579.
1 511772001 SCROLLING COVER .........................................1
2 640770001 SCROLLING ......................................................1
3 660206025 * SCREW (M3.5 X 10 mm PAN HD.) ....................2
4 671142002 SAW BAR GUIDE BUSHING ............................1
5 301011001 SCROLLING RELEASE KNOB ASSEMBLY .......1
6 511773001 SCROLLING RELEASE BLOCK ........................1
7 671146001 SPRING .............................................................1
8 680436006 WASHER ...........................................................1
9 300306016 HEAT SINK ASSEMBLY ....................................1
10 630845001 SLIDE GUIDE PLATE ........................................1
11 680899001 BEARING SLEEVE .............................................1
12 550427001 WASHER ...........................................................1
13 671038001 BEARING SLEEVE .............................................1
14 631303001 SAW BAR SLIDE BRACKET .............................1
15 631304001 CROSS SLIDE BRACKET ..................................1
16 690072002 SPRING PIN .....................................................2
17 690072003 SPRING PIN ......................................................2
18 300877007 SAW BAR ..........................................................1
19 691966001 COIL SPRING ...................................................1
20 690377003 LINKAGE ARM (RIGHT SCM440) ......................1
21 511826003 BLADE CLAMP LEVER ......................................1
22 671318001 ROLLER .............................................................1
23 690377004 LINKAGE ARM (LEFT SCM440) ........................1
24 671319001 E-RING ..............................................................2
25 691965001 COIL SPRING ....................................................1
26 301007002 SAW BAR & BLADE CLAMP ASSEMBLY
(INC. KEY NOS. 18-25) ......................................1

1
5
2
11
10
13
6
7
9
8
43
12
Figure B
RYOBI JIG SAW – MODEL NUMBER JS550L
4

RYOBI JIG SAW – MODEL NUMBER JS550L
5
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
JIG SAW or when ordering repair parts.
WARNING: Improper repair of a double insulated tool can result in damage to the double insulation system possibly causing electrical shock or
electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi Authorized Service
Center. For the service center nearest you call 1-800-525-2579.
1 301124001 KNOB BOLT ASSEMBLY ..............................................................................................1
2 671143001 PIN STEEL ....................................................................................................................1
3 300577015 BLADE GUIDE ASSEMBLY ..........................................................................................1
4 631082001 LINK ROD ......................................................................................................................1
5 660213008 * SCREW (M4 X 10 mm FLAT HD.) ..................................................................................6
6 631109001 BASE COVER ................................................................................................................1
7 660176006 * SCREW (M4 X 8 mm) ....................................................................................................1
8 631083001 FIX NUT (M5) .................................................................................................................1
9 671150001 ADJUSTABLE PAD ........................................................................................................1
10 640783001 DIE CASTING BASE ......................................................................................................1
11 301010001 BASE TOOL-LESS LEVER ASSEMBLY ............................................................................1
12 678050001 FLAT WASHER ..............................................................................................................1
13 301008001 FIX WEDGE ASSEMBLY ...............................................................................................1

Figure C
SEE
FIGURE A
SEE
FIGURE B
RYOBI JIG SAW – MODEL NUMBER JS550L
6
1
5
2
30
14
11
21
32
15
31
16
29
32
10
5
13
12
35
27
9
22
18
28
19
23
17
24
25
33
26
6
79
8
4
3
34
36 12
10
20
17
37
39
40
41
38
26
25

RYOBI JIG SAW – MODEL NUMBER JS550L
7
1 940299683 CORD LABEL .................................................... 1
2 730377003 POWER CORD ................................................. 1
3 590274004 BEND RELIEF .................................................. 1
4 940304062 LOGO LABEL .................................................... 1
5 301320001 FRONT COVER ASSEMBLY ............................. 1
6 550424001 DETENT BUTTON ............................................. 1
7 680909001 SPRING
............................................................ 1
8 511774001 ORBITAL KNOB ............................................... 1
9 940299682 DANGER LABEL FOR LASER ......................... 2
10 660182006 * SCREW (M6 X 12 mm PAN HD.) ....................... 4
11 671147003 GUIDE WIRE (LEFT) .......................................... 1
12 200202329 HOUSING ASSEMBLY ...................................... 1
13 671209002 SPRING FOR LASER ........................................ 1
14 760342001 SWITCH ............................................................ 1
15 280013051 PCB ASSEMBLY .............................................. 1
16 511824001 LENS ................................................................ 1
17 6620805 * SCREW (M4 X 16 mm PAN HD.) ......................12
18 512963001 * SCREW (M3 X 6 mm PAN HD.) ......................... 1
19 671147002 GUIDE WIRE (RIGHT) ....................................... 1
20 631252001 SPRING PLATE ................................................. 1
21 660165003 * SCREW (M4 X 18 mm PAN HD.) ...................... 1
22 940301020 DATA LABEL ...................................................... 1
23 680898001 SLEEVE BEARING ............................................ 1
24 740588001 FIELD .................................................................. 1
25 790009001 CLOSE END CONNECTOR ............................... 2
26 290069044 BRUSH ASSEMBLY ........................................... 2
27 740589001 ARMATURE ........................................................ 1
28 300926005 BEARING PLATE ASSEMBLY ............................ 1
29 630844001 WASHER ............................................................ 1
30 301627001 DRIVE PLATE ASSEMBLY ................................. 1
31 671008001 BALANCE BLOCK ............................................. 1
32 680911001 NEEDLE BEARING ........................................... 2
33 610388001 OUTPUT GEAR .................................................. 1
34 300019002 BUSHING ASSEMBLY W/BEARING .................. 1
35 590501001 CORD CLAMP ................................................... 1
36 671154001 ORBITAL ADJUSTABLE ROD ............................ 1
37 301009001 VACUUM ASSEMBLY ........................................ 1
38 671208001 METAL CUTTING BLADE (18-24 TPI) ................ 1
39 671207001 WOOD CUTTING BLADE (6-8 TPI) .................... 1
40 631097001 EDGE GUIDE ..................................................... 1
41 300912051 CARRYING CASE .............................................. 1
983000574 OPERATOR’S MANUAL (960223251)
02-09-07
(REV:05)
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
JIG SAW or when ordering repair parts.
KEY PART
NO. NUMBER DESCRIPTION QTY
WARNING: Improper repair of a double insulated tool can result in damage to the double insulation system possibly causing electrical shock or
electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi Authorized Service
Center. For the service center nearest you call 1-800-525-2579.

WIRING DIAGRAM
BLACK
LEAD
BRUSH TUBE
BRUSH TUBE
CLOSE END
RED
LEAD
PCB
ASSEMBLY
MOTOR
SWITCH
POWER CORD
WHITE
LEAD
BLACK
LEAD
BLACK
LEAD
RED
LEAD
RED
LEAD
CLOSE
END
RYOBI JIG SAW – MODEL NUMBER JS550L
8
