Ryobi RPW36X50 User manual

ORIGINAL INSTRUCTIONS
Cordless Pressure
Washer
RPW36X50
RPW3600

Important!
It is essential that you read the instructions in this manual before assembling,
operating, and maintaining the product.
Subject to technical modification.

1
Safety, performance, and dependability have been given
top priority in the design of your cordless pressure washer.
INTENDED USE
The cordless pressure washer is only intended for
use outdoors. For safety reasons the product must be
adequately controlled by using two-handed operation.
The product is designed for home or domestic use. It is
intended to clean machines, vehicles, buildings, oors,
tools, facades, terraces, oors, and concrete walkways by
removal of stubborn dirt using clean water with or without
chemical detergents.
It should be used in dry, well illuminated conditions.
- WARNING This machine has been designed for use
with the cleaning agent supplied or recommended by
the manufacture. The use of other cleaning agents or
chemicals may adversely affect the safety of the machine.
WARNING
The product is designed for use with the cleaning agent
supplied or recommended by the Ryobi. The use of other
cleaning agents or chemicals may adversely affect the
safety of the pressure washer.
GENERAL SAFETY WARNINGS
WARNING
Read all safety warnings and all instructions. Failure
to follow all instructions listed below may result in electric
shock and/or re which will cause death or serious
personal injury.
■The product is not intended for use by persons with
reduced physical, sensory, or mental capabilities, or
lack of experience and knowledge
■Wear a complete personal protective equipment
when operating the product, such as safety boots,
safety gloves, safety helmets with visor, and hearing
protection. Use high-impact visors only with liquid
splash protection.
WARNING
Do not use the product when people are within range
unless they wear protective clothing.
■To reduce the risk of injury, keep children and visitors
away. All visitors should wear safety glasses and be
kept at a safe distance from the work area.
■Inspect the safety devices, such as safety valves, flow
switches, and pressure switches to check if they are in
good working condition. Make sure all safety devices
are operating properly before each use.
■To reduce the risk of kickback, hold the spray wand
securely with both hands when the product is on.
WARNING
During use of pressure washers, aerosols may be
formed. Inhalation of aerosols can be hazardous to
health.
WARNING
Depending on the application, shielded nozzles can
be used for high pressure cleaning, which will reduce
the emission of hydrous aerosols. However, not all
applications allow the use of such a device. If shielded
nozzles are not applicable for the protection against
aerosols, a respiratory mask of class FFP 2 or equivalent
may be needed, depending on the cleaning environment.
■Always switch off the product when leave it unattended.
■The product is designed for use with cleaning agent
supplied or recommended by the manufacturer.
The use of other cleaning agents or chemicals may
adversely affect the safety of the product.
■High pressure jet is dangerous if misused. Do not direct
the jets at persons, live electrical equipment, or the
product itself.
■Do not spray flammable liquids.
■Do not use the product to clean clothes or footwear.
■Be extra careful when opening the trigger gun. Hold the
trigger gun firmly with two hands to avoid injury when
the trigger gun kicks back.
■High pressure hoses, fittings, and couplings are
important for the safety of the product. Use only
hoses, fittings, and couplings recommended by the
manufacturer.
CAUTION
The product must not be used on the drinking water
supply without a backow preventer being installed.
Water owing through a backow preventer is considered
non-drinkable. Always observe the regulations of your
local water utility company when connecting the product
to a water supply line.
■Recharge the battery only with the charger specified by
the manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with
another battery pack.
■When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys, nails,
screws or other small metal objects, that can make a
connection from one terminal to another. Shorting the
battery terminals together may cause burns or a fire.
■Keep the battery and the charger away from wet and
damp conditions.
■Use product only with battery packs specified in this
manual. Use of any other battery packs may create a
risk of injury and fire.
■Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally

2
occurs, flush with water. If liquid contacts eyes, seek
medical help. Liquid ejected from the battery may cause
irritation or burns.
ADDITIONAL SAFETY WARNINGS
■Some regions have regulations that restrict the use of
the product in some operations. Check with your local
authority for advice.
■Never direct a water stream toward people or pets, or
any electrical device.
■Before starting any cleaning operation, close doors and
windows. Clear the area to be cleaned of debris. Toys,
outdoor furniture, or other objects that could create a
hazard.
■Never pick up or carry the product while the motor is
running.
■Do not use the product in temperatures below 0°C.
■Do not use acids, alkalines, solvents, flammable
material, bleaches, or industrial grade solutions in this
product. These products can cause physical injuries to
the operator and irreversible damage to the product.
■Always operate the product on a level surface.
WARNING
High pressure jets can be dangerous if subject to
misuse. The jet must not be directed at persons, animals,
electrical devices, or the product itself.
■Hold the trigger gun securely with both hands. Expect
the trigger handle to move when the trigger is pulled
due to reaction forces. Failure to do so could cause loss
of control and injury to yourself and others.
■Exercise caution to avoid slipping or falling.
■Keep firm footing and balance. Do not overreach.
Overreaching can result in loss of balance.
■Use only recommended accessories. The use of
improper accessories may cause risk of injury.
■Never leave the product running unattended. Turn the
power off. Do not leave the product until it comes to a
complete stop.
■Be familiar with the controls. Know how to stop the
product and bleed the pressure quickly.
■Stay alert and exercise control. Watch what you are
doing and use common sense.
■Do not use a product when you are tired or under the
influence of drugs, alcohol, or medication. A moment
of inattention while operating the product may result in
serious personal injury.
■Do not use the product if the switch does not turn it on
and off. Any product that cannot be controlled with a
switch is dangerous and must be repaired.
■Keep a minimum distance of 30 cm when cleaning
vehicles. The high high-pressure jet may damage or
burst vehicle tires and/or tire valves.
USE OF POTABLE WATER SUPPLY
■The product can use potable water. Use Ryobi suction
hose kit and water bags for the connection.
■When connecting the product to the water supply,
follow the regulations from the local water supplier.
CAUTION
If you connect the product to a potable water supply, you
must install a backflow prevention device to the water
supply system. The installation should be installed by
professional service personnel and should be accepted
by the local water supplier.
■Make sure the water in the hose and pump is released
before you turn on the power switch.
WARNING
If there is no water coming out from the nozzle, stop the
product immediately using the power switch. Working
without water may cause serious damage to the pump.
BOOST MODE
■Boost mode provides extra power. This function is
limited to 8 min of continuous operation. Press the
boost button to switch from normal operation mode to
boost mode.
■Do not use the boost mode for more than 8 min. The
boost mode automatically returns to normal mode after
8 min.
■After 8 min of boost mode usage, the pressure washer
will not return to boost mode until 8 min of normal mode
use or rest. The LED in the boost button flashes when
the boost mode is not available for activation.
TOTAL STOP SYSTEM
■The pressure washer is equipped with a total stop
switch. When you release the trigger of the gun, the
motor stops to save power.
■The LED in the power switch flashes when the total stop
system is active.
■The fan runs continuously to cool the product when the
total stop system is activate.
CAUTION
Bring the product to an authorized service centre when
the motor does not stop after you release the trigger of
the gun.

3
TRANSPORTATION AND STORAGE
CAUTION
Mind the weight of the product when selecting the
storage location and during transportation to prevent
accidents or injuries.
■Stop the product, remove the battery, and disconnect
the product from the water supply before storing or
transporting. Never place the product in any position
other than upright.
■Clean all foreign material from the product. Store it in a
cool, dry, and well-ventilated place that is inaccessible
to children. Keep away from corrosive agents such
as garden chemicals and de-icing salts. Do not store
outdoors.
■For transportation in a vehicle, secure the product
against movement or falling to prevent injury to persons
or damage to the product.
TRANSPORTING LITHIUM BATTERIES
Transport the battery in accordance with local and national
provisions and regulations.
Follow all special requirements on packaging and labelling
when transporting batteries by a third party. Ensure that
no batteries can come in contact with other batteries
or conductive materials while in transport by protecting
exposed connectors with insulating, non-conductive caps
or tape. Do not transport batteries that are cracked or
leaking. Check with the forwarding company for further
advice.
MAINTENANCE
WARNING
Use only original manufacturer’s replacement parts,
accessories, and attachments. Failure to do so can
cause possible injury and poor performance, and may
void your warranty.
WARNING
Servicing requires extreme care and knowledge
and should be performed only by a qualied service
technician. For service, bring the product to an
authorised service centre. When servicing, use only
identical replacement parts.
■Stop the product, remove the battery, and allow the
product to cool. Disconnect the product from the water
supply before:
●cleaning the product
●maintaining the product
●replacing spare parts
■You may make adjustments and repairs described in
the manual. For other repairs, contact the authorised
service centre.
■Regularly inspect and maintain the pressure washer
for safe operation. Ryobi recommends inspecting the
product every 6 months.
■Check all nuts, bolts, and screws at frequent intervals
for proper tightness to ensure the product is in safe
working condition. Any part that is damaged should be
properly repaired or replaced by an authorised service
centre.
RESIDUAL RISKS
Even when the product is used as prescribed, it is still
impossible to completely eliminate certain residual risk
factors. The following hazards may arise in use and the
operator should pay special attention to avoid the following:
■Injury caused by the high pressure jet. Avoid pointing
the high pressure jet to people, animals, and to yourself.
■Injury cause by kickback. Always hold the trigger gun or
the trigger wand firmly with your two hands.
■Injury caused by exposure to noise. Wear ear protection.
RISKS REDUCTION
It has been reported that vibrations from handheld tools
may contribute to a condition called Raynaud’s Syndrome.
Symptoms may include tingling, numbness, and blanching
of the ngers, usually apparent upon exposure to cold.
Hereditary factors, exposure to cold and dampness, diet,
smoking and work practices are all thought to contribute
to the development of the these symptoms. There are
measures that can be taken by the operator to possibly
reduce the effects of vibration:
■Keep your body warm in cold weather. When operating
the product, wear gloves to keep the hands and wrists
warm. It is reported that cold weather is a major factor
contributing to Raynaud’s Syndrome.
■After each period of operation, exercise to increase
blood circulation.
■Take frequent work breaks. Limit the amount of
exposure per day.
If you experience any of the symptoms of this condition,
immediately discontinue use and see your doctor.
WARNING
Injuries may be caused, or aggravated, by prolonged
use of a tool. When using any tool for prolonged periods,
ensure you take regular breaks.
KNOW YOUR PRODUCT
See page 7.
1. Handle
2. Gun
3. Trigger gun lock
4. On/Off trigger
5. Hose strap
6. Water inlet
7. Wheel
8. Bladder
9. Siphon hose

4
10. Water inlet adapter
11. High pressure hose
12. Charger
13. Battery
14. Soap nozzle
15. Spray nozzle
16. Turbo nozzle
17. Soap tank
18. Water outlet
19. Soap tank cap
20. Battery cover
21. Boost button
22. Power switch
23. Wand
SYMBOLS ON THE PRODUCT
Warning
To reduce the risk of injury from
kickback, hold the spary wand securely
with both hands when the product is on.
To reduce the risk of injury, read and
understand the operator’s manual before
using the product.
Wear eye and hearing protection.
To reduce the risk of injury from high
pressure injection, do not direct spary at
persons or animals.
Remove the battery before starting any
maintenance work on the product.
Wear non-slip, heavy-duty protective
gloves when handling.
Appliance not suitable for connection
to the drinking water mains without
backow preventer.
Never point the gun to human, animals,
the machine body, power supply or any
electric appliances
Burst Hazard.
Regulatory Compliance Mark (RCM).
Product meets applicable regulatory
requirements.
Waste electrical products should not
be disposed of with household waste.
Please recycle where facilities exist.
Check with your local authority or retailer
for recycling advice.
79 dB
66
dB
Guaranteed sound pressure level is 66
dB. Guaranteed sound power level is
79 dB.
SYMBOLS IN THIS MANUAL
Parts or accessories sold separately
Note
Warning
The following signal words and meanings are intended to
explain the levels of risk associated with this product.
DANGER
Indicates an imminently hazardous situation, which, if
not avoided, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not
avoided, may result in minor or moderate injury.
CAUTION

5
UNPACKING
x 1
x 1
x 1
x 1
x 1
x 1 x 1
x 1
x 1x 1
x 1x 1
RPW36X50

6
UNPACKING
x 1
x 1
x 1
RPW3600
x 1
x 1
x 1x 1
x 1x 1 x 1

7
Know your product
KNOW YOUR PRODUCT
1 2
3
5
6
7
1112131415
20
19
18
17
16
21
22
23
4
8910

8
GETTING STARTED
1
2
0.5 min
7
1 2
8

GETTING STARTED
1
2
1
2
3
4
1
9
3
10
1
2
4

9
GETTING STARTED
1
2
1
5
1
2
11 12
1
2
6

10

11
OVERVIEW
p.12
p.17
p.13
p.18
p.14
p.19
p.15

12
OPERATION
1
2
1
2
0.5 min
1
2

13
OPERATION
1
2
1
2
1
2
3

14
OPERATION
1
2
1
2
1
2
1
2
3
4

15
OPERATION
2
1
3
1
2
2
1
2
1
1
2
3
4

16
OPERATION
0.5m Min
1
2
1
2
0.5 min
5
6
7
8
