RYOBI
10 in. COMPOUND MITER SAW
MODEL NO. TS1343L
REPAIR SHEET

RYOBI 10 in. COMPOUND MITER SAW – MODEL NUMBER TS1343L
2
FIGURE A
74
1
2
42
40
39
38
34
33
13
12
910 11
5
814
73
72
72
71
27
19
18
32
30
31
21
20
22
23
24 25
26
29
22
20
23
29
29
67
66
70
69
65
64
68
63
56
57
55
58
59
35
36
37
7
7
77
4
36
15
16
17
41
75
43
76
53
52
51
50 49
48
47
46
44
45
28
54
60 61
62
5
5
5

RYOBI 10 in. COMPOUND MITER SAW – MODEL NUMBER TS1343L
3
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence
regarding your MITER SAW or when ordering repair parts.
KEY PART
NO. NUMBER DESCRIPTION QTY.
FIGURE A PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 080006014904 Cord Wrap Warning Label (Fr/Sp).............................. 1
2 080006014056 Cord Assembly........................................................... 1
3 089100207100 Bend Relief................................................................. 1
4 089100200129 Cord Clamp................................................................ 1
5 089100207087 Screw (M4 x 16 mm, Pan w/Washer Hd.) .................. 7
6 080009002068 Screw (M3 x 12 mm) .................................................. 1
7 080006014706 D-Handle Assembly ................................................... 1
8 080006014074 Screw (M5 x 20 mm) .................................................. 2
9 080009004038 Screw (M3 x 8 mm, Pan Hd.) ..................................... 1
10 080006014057 Battery Compartment ................................................ 1
11 089240001065 Laser Switch .............................................................. 1
12 080006014062 Battery Box Cover...................................................... 1
13 080006014061 Screw (M4 x 10 mm) .................................................. 1
14 089240001052 Screw (M5 x 30 mm, Pan Hd.) ................................... 2
15 089100207090 Switch Actuator ......................................................... 1
16 080006014060 Compression Spring .................................................. 1
17 089100207098 Switch ........................................................................ 1
18 080006014053 Screw w/Washer (M5 × 65 mm, Pan Hd.).................. 2
19 080006014703 Field Assembly........................................................... 1
20 080009002077 Brush.......................................................................... 2
21 080006014901 Data Label.................................................................. 1
22 080006014048 Holder Cap................................................................. 2
23 080009002078 Brush Holder.............................................................. 2
24 080006014047 Motor Housing ........................................................... 1
25 080009005116 Screw (M5 × 5 mm, Set) ............................................ 2
26 080009002080 Screw (M5 × 6 mm, Set) ............................................ 2
27 080006014902 Warning/Danger Label ............................................... 1
28 080006014709 Motor Housing Assembly (Inc. Key Nos. 18-27)........ 1
29 080006014046 Screw (M5 x 35 mm, Pan Hd.) ................................... 4
30 080009002086 Ball Bearing (6200TU/TZ/CM/5C) .............................. 1
31 080009002085 Ball Bearing (608 2RS C3) ......................................... 1
32 080006014705 Armature Assembly (Inc. Key Nos. 30-31)................. 1
33 080006014037 Baffle.......................................................................... 1
34 080009002053 O-Ring........................................................................ 1
35 080006014038 Spindle Lock Pin ........................................................ 1
36 089100207065 Compression Spring .................................................. 1
37 089100207066 E-Ring ........................................................................ 1
38 080006014702 Arm Assembly (Inc. Key Nos. 34, 42, 44 and 55) ...... 1
39 089100208104 Screw (M5 x 8 mm, Set)............................................. 2
40 080006014049 Laser Cover................................................................ 1
41 080006014050 Screw (M4 x 6 mm, Pan Hd.) ..................................... 1
42 080006014906 Logo Label ................................................................. 1
43 089100207047 Stop Block ................................................................. 1
44 080009002050 Needle Bearing .......................................................... 1
45 080006014042 Gear ........................................................................... 1
46 080006014043 Lock Ring................................................................... 1
47 080009002055 C-Ring (STW15) ......................................................... 1
48 080009005104 Bearing Cover ............................................................ 1
49 089100302119 O-Ring........................................................................ 1
50 080009002056 Ball Bearing (6002TU/TZ/CM/5C) .............................. 1
51 080006014044 Gear Shaft.................................................................. 1
52 080009002913 Gasket........................................................................ 1
53 089240001044 Bearing Holder Plate.................................................. 1
54 080006014710 Arbor Assembly (Inc. Key Nos. 45-53)....................... 1
55 080006014908 Pivot Plate Screw Warning Label............................... 1
56 089100207027 Screw (M3) ................................................................. 1
57 080006014708 Linkage Assembly...................................................... 1
58 089100207028 Lock Nut (M6)............................................................. 1
59 089100207031 Washer (D6 x D16 x 1t) .............................................. 1
60 089100207102 Retaining Ring............................................................ 1
61 089100207103 Guide Roller ............................................................... 1
62 080006014063 Lower Guard .............................................................. 1
63 089100207097 No Hands Warning Label........................................... 1
64 080006014066 Return Spring............................................................. 1
65 089100207051 Blade Direction Warning Label .................................. 1
66 080006014064 Rotating Cover........................................................... 1
67 089100207039 Screw (Special) .......................................................... 1
68 080006014707 Lower Blade Guard Assembly
(Inc. Key Nos. 57-67) ................................................. 1
69 089240001064 Screw (M5 x 10 mm, Shoulder).................................. 1
70 A19001040091 Screw (M4 x 9 mm, Pan Hd.) ..................................... 1
71 089100207042 Arbor Blade Bolt ........................................................ 1
72 089100207043 Flange ........................................................................ 2
73 089100207045 Blade (Carbide - 10 in. x 24t) ..................................... 1
74 080006014027 Dust Bag Assembly.................................................... 1
75 080006014026 Screw (M4 x 12 mm, Pan Hd.) ................................... 1
76 089100208108 Screw (M4 x 20 mm, Pan Hd.) ................................... 2
77 089240001093 Screw (M4 x 16 mm, Pan Hd.) ................................... 2

RYOBI 10 in. COMPOUND MITER SAW – MODEL NUMBER TS1343L
4
FIGURE B
13
19
18
17
16
15
14
2
1
12
11
10
5
6
9
8
7
4
3
8
7
23
22
21
20
24
26
25
28
21
55
56
27
29
30
42
41
48
57
52
53
54
51 50 49
47
46
36
41
43
44
45
39
38
37
35
34
40
36
35
33
32
31
12
11

RYOBI 10 in. COMPOUND MITER SAW – MODEL NUMBER TS1343L
5
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence
regarding your MITER SAW or when ordering repair parts.
KEY PART
NO. NUMBER DESCRIPTION QTY.
FIGURE B PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 080006014701 Base Assembly .......................................................... 1
2 089240001018 Bolt (M8 x 23 mm, Hex Soc Hd.) ............................... 1
3 089100207013 Grommet .................................................................... 1
4 089100207113 Hex Key (M35 x 115 mm)........................................... 1
5 089240001085 Spring......................................................................... 1
6 080009005182 Ball (8 mm) ................................................................. 1
7 089100207019 Spring Washer (M8).................................................... 2
8 089240001021 Screw (M8 x 30 mm, Hex Soc. Hd.)........................... 2
9 080006014012 Fence ......................................................................... 1
10 080006014907 Small Fence Logo ...................................................... 1
11 080006014909 No Hands Boundary Label......................................... 2
12 089100207097 No Hands Warning Label........................................... 2
13 080006014704 Work Clamp Assembly (Inc. Key Nos. 14-19)............ 1
14 080052001543 C-Ring........................................................................ 1
15 089240001079 Press Plate ................................................................. 1
16 080006014073 Thread Rod ................................................................ 1
17 080006014072 Block .......................................................................... 1
18 089240001082 Knob........................................................................... 1
19 089240001083 Roll Pin (D4 x 16 mm) ................................................ 1
20 089100207009 Screw (M6 x 25 mm, Soc. Hd.).................................. 2
21 089100302038 Screw (M4 x 8 mm, Pan Hd.) ..................................... 4
22 080006014006 Table Hold Down........................................................ 1
23 080006014002 Wear Ring................................................................... 8
24 089100207010 Spring Washer (M6).................................................... 2
25 080006014005 Miter Lock Handle...................................................... 1
26 089100207011 Control Arm................................................................ 1
27 080006014003 Table........................................................................... 1
28 080006014007 Pointer........................................................................ 1
29 080006014903 Aperature Warning Label ........................................... 1
30 080006014011 Screw (M10 x 15 mm, Hex Soc Hd.).......................... 1
31 080006014076 Washer (D10.4 x D26 x 1.5T) ..................................... 1
32 089240001087 Washer (D8.2 x D20 x 1.5t) ........................................ 1
33 080006014010 Hex Nut (M8) .............................................................. 1
34 080006014022 Bevel Scale ................................................................ 1
35 080006014026 Screw (M4 x 12 mm, Pan Hd.) ................................... 2
36 089100302032 Washer (D4.2 x D10 x 1t) ........................................... 3
37 080006014025 Laser Bracket............................................................. 1
38 089240001029 Screw (M4 x 5 mm, Special Hex Soc. Hd.)................ 1
39 080006014029 Laser Module ............................................................. 1
40 080006014021 Bevel Indicator ........................................................... 1
41 089240001023 Screw (M8 x 18 mm, Set)........................................... 2
42 080006014014 Pivot Support ............................................................. 1
43 080006014018 Lock Pin ..................................................................... 1
44 089083001092 O-Ring........................................................................ 1
45 080006014019 Lock Pin Cap ............................................................. 1
46 080006014033 Sleeve ........................................................................ 1
47 080006014034 Spring......................................................................... 1
48 080006014032 Pivot Shaft.................................................................. 1
49 080006014024 Stop Block ................................................................. 1
50 089240001091 Screw (M5 x 12 mm) .................................................. 1
51 080006014017 Washer (D10 x D20 x 3t) ............................................ 1
52 089240001031 Washer (D10.2 x D20 x 0.5t) ...................................... 1
53 080006014030 Screw (M10 x 48 mm, Hex Hd.)................................. 1
54 080006014015 Bevel Handle.............................................................. 1
55 080006014004 Table Insert................................................................. 1
56 089100207038 Screw (M4 x 8 mm, Flat Hd.) ..................................... 5
57 080006014075 Washer (D10.5 x D23 x 2t) ......................................... 1
Not Shown:
987000845 Operator’s Manual ..................................................... 1
6-24-10
(Rev:01)

RYOBI 10 in. COMPOUND MITER SAW – MODEL NUMBER TS1343L
6
YELLOW LEAD
YELLOW
LEAD
BRUSH
ASSEMBLY
BRUSH
ASSEMBLY
SLEEVE
POWER
CORD
YELLOW
LEAD
BROWN
LEAD
BLACK
LEAD
WHITE
LEAD
MOTOR
WIRING DIAGRAM
