MODEL
NUMBER 5390
5390-37: 1 of 4; Rev. 3: 11/04
GoCartTM Organizer
For questions or concerns, please call
Safco Consumer Hot Line 1-800-664-0042
available Monday-Friday 8:00 AM to 4:30 PM (Central Time)
(English-speaking operators)
ASSEMBLY INSTRUCTIONS
Safco Products Company, New Hope, MN 55428
TOOLS REQUIRED: Screwdriver, Hammer or Mallet
B
C
E
D
P
G
N
F
O
O
H
H
J
I
I
M
K
L
Back Panel 1 5390-07
Left Side Panel 1 5390-02
Right Side Panel 1 5390-03
Fixed Shelf 1 5390-05
Rail 2 5390-04
Base Panel 1 5390-01
LETTER
CODE
A
B
C
D
E
F
DESCRIPTION QTY. PART NO.
Vertical Divider 1 5390-06
Cam 20 5390-23
Short Screw Post 20 5390-21
Wood Dowel 20 5390-30
Caster 2 5390-25
LETTER
CODE DESCRIPTION QTY. PART NO.
PARTS LIST
G
H
I
J
K
Caster with Brake 2 5390-24
Small Screw 16 5390-27
Plastic Shelf 6 5390-09
Shelf Glide Push Pin 24 5390-26
Plastic Bin 4 5390-10
LETTER
CODE DESCRIPTION QTY. PART NO.
L
M
N
O
P
ASSEMBLED UNIT
J
A
Insert four more Cams into the largeholes of the Vertical
Divider. Screw the I Screw Posts into each small hole
that has a plastic insert (do not over-tighten).
Tap J Wood Dowels into each hole located next to a
Screw Post on the Side Panels and the Fixed Shelf.
5390-37: 2 of 4; Rev. 3: 11/04 Safco Products Company, New Hope, MN 55428
Work on a smooth, clean surface. Locate the A Back
Panel and position it with the large holes up. Lay the B Left
Panel and the C Right Panel on the left and right sides of
the Back Panels with the holes facing up as shown.
Arrange the D Fixed Shelf and two E Rails above the Back
Panel withthe holes up. Place the G Vertical Divider below
the Back Panels with the four large holes up.
Insert four H Cams into the large holes at the corners of
the Back Panel, the Fixed Shelf and both Rails, with the
arrows pointing toward the nearest hole in the edge.
1
Locate the F Base Panel. Position the Panel with
the four large holes up. Attach the K Casters to the
two corners along one long edge using four M
Small Screws per Caster. Attach the L Casters with
Brakes to the two corners along one long edge
using four M Small Screws per Caster.
2
B
C
I
G
Turn the base panel upright onto the Casters. Insert
two I Screw Posts into the two small holes that
have a plastic insert (do not over-tighten).
Tap two J Wood Dowels into the holes located
next to the Screw Posts as shown.
3
L
K
F
I
M
AH
HI
D
J
E
J
5390-37: 3 of 4; Rev. 3: 11/04 Safco Products Company, New Hope, MN 55428
Raise the G Vertical Divider upright with the
group of small holes near the upper end.
Raise the D Fixed Shelf and guide the posts
and dowels into one end of the Vertical
divider. Gently tap the Fixed Shelf to seat the
dowels. Use a screwdriver to fasten the Cams
by turning them clockwise until they stop.
Raise the Base Panel with Casters and guide
the posts and dowels into the other end of
the Vertical divider. Gently tap the bottom of
the Base Panel to seat the dowels. Use a
screwdriver to fasten the Cams by turning
them clockwise until they stop.
Insert four H Cams into each large hole in
the bottom of the Base Panel with the cam
arrow pointing to the nearest edge hole.
4
Raise the C Right Side Panel and guide the
posts and dowels into the holes on the
edges of the Base Panel and Fixed Shelf.
Gently tap the Side Panel to seat the dowels.
Use a screwdriver to fasten the Cams by
turning them clockwise until they stop.
5
Slide the A Back Panel down onto the
posts and dowels between the Base Panel
and Fixed Shelf. Fasten the Cams as previ-
ously instructed.
Position the two E Rails so the cam sides
face each other. Slide the Rails down onto
the posts and dowels. Gently tap the upper
end of the Rails to seat the dowels. Use a
screwdriver to fasten the Cams by turning
them clockwise until they stop.
6
G
C
H
D
A
E
5390-37: 4 of 4; Rev. 3: 11/04 Safco Products Company, New Hope, MN 55428
Insert six O Shelf Glide Push Pins into the small holes
on the insides of the Side Panels and each side of the
Vertical divider.
Next install the six N Plastic Shelves: guide the back
of each Shelf onto the Push Pins, tilt the Shelf enough
to start the Shelf moving, and lower the shelf to push it
all the way into position.
8
Place the P Plastic Bins into the
upper compartment so the side
handles rest on top of the Rails.
Insert your file folders into the Bins.
9
Raise the B Left Side Panel and guide the
posts and dowels into the holes on the
exposed edges. Gently tap the Side Panel to
seat the dowels. Use a screwdriver to fasten
the Cams by turning them clockwise until they
stop.
7
ASSEMBLED UNIT
P
N
B
O
