Salda SMARTY XV Series Guide

SMARTY XV
EN MOUNTING AND INSTALLATION INSTRUCTION

2 | EN SMARTY XV v2020.2
CONTENT
2.SYMBOLS AND MARKING 3
3.SAFETY INSTRUCTIONS AND PRECAUTIONS 4
4.INFORMATION ABOUT THE PRODUCT 5
4.1. DESCRIPTION 5
4.2. DIMENSIONS AND WEIGHT 5
4.3. TECHNICAL DATA 6
4.4. OPERATING CONDITIONS 7
4.5. STANDART PACKAGE OF COMPONENTS 7
4.6. DESCRIPTION OF COMPONENTS 7
5. INSTALATION 8
5.1. RECEPTION OF GOODS 8
5.2. TRANSPORTATION AND STORAGE 8
5.3. UNPACKING 8
5.4.PIPING AND INSTRUMENTATION DIAGRAM 9
5.5. MOUNTING 10
5.6.PLACE REQUIREMENTS FOR THE EQUIPMENT AND MOUNTING POSITIONS 11
5.7. FLOOR MOUNTING 11
5.8. MOUNTING ON WALL 11
5.9. DRAINAGE 11
5.10. CONNECTION OF THE AIR DUCT 12
5.11.CONNECTION OF THE UNIT TO ELECTRIC NETWORK 13
5.12. START-UP RECOMMENDATIONS 13
5.12.1. SYSTEM PROTECTION 13
5.12.2.PRE-STARTUP RECOMENDATIONS OF THE UNIT (IN THE PRESENCE OF THE ENDUSER) 13
6. MAINTENANCE 14
6.1. SAFETY INSTRUCTION 14
6.2.GENERAL RECOMMENDATIONS FOR THE MAINTENANCE OF VENTILATION SYSTEM 14
6.3. COVER OPENING 14
6.4. FILTERS MAINTENANCE 15
6.5. FANS MAINTENANCE 15
6.6. HEAT EXCHANGER MAINTENANCE 16
6.7.BYPASS DAMPERS AND PRE-HEATER MAINTENANCE 16
6.8. CONTROL BOARD MAINTENANCE 17
6.9.SMARTY 4XV SWITCHING POWER SUPPLY MAINTENANCE 17
7. CONTROL 18
7.1. DEVICE CONTROL 18
7.2. DEVICE FUNCTIONS 18
8. ACCESSORIES 19
8.1. CONNECTION OF ACCESSORIES 20
8.1.1. HEATER AND PRE-HEATER 20
8.1.2.FIRE PROTECTION SIGNAL INPUT (FIRE PROTECTION INPUT (NC)) 26
8.1.3.EXTERNAL CO2/RH SENSORS 26
8.1.4.ROOM CO2 TRANSMITTER INSTALLATION RECOMMENDATION 27
8.1.5.CO2CONCENTRATION ACCORDING TO PETTENKOFER LIMIT 27
8.1.6.CONNECTION OF SUPPLY AND EXTRACT AIR DAMPERS 27
8.1.7.CONNECTION OF REMOTE CONTROL PANEL OR MODBUS 28
8.1.8.FIRE PLACE CONNECTION (SMARTY XV 1.1) 28
8.1.9.RECOMMENDED SCHEME FOR CONNECTION OF INTERNAL AND EXTERNAL COMPONENTS 29
9. SPARE PARTS 38
10.POSSIBLE FAULTS AND TROUBLESHOOTING 40
11.ECODESIGN DATA TABLE 41
12.DECLARATION OF CONFIMITY 47
13. WARRANTY 48
13.1. LIMITED WARRANTY COUPON 48

EN | 3SMARTY XV v2020.2
2. SYMBOLS AND MARKING
Warning – pay attention Additional information
Stick the auxiliary label on the unit (on an easily accessible place) or on the dashed place of a technical manual in order to keep the important
information about the unit.
Figure. 2.1. Technical label
1 - Logo; 2 - Product code (SKU); 3 - Product name; 4 - Technical data; 5 - Production place; 6 - production date; 7 - Serial number.
Figure. 2.2. Indication for duct connection.
ODA - outdoor air; SUP - supply air; ETA - extract air; EHA - exhaust air.
Figure. 2.3. Smarty 2 XV Technical label place and air duct indica-
tion
Figure. 2.4. Smarty 3XV/4XV Technical label place and air duct
indication
NOTE. Ducts are not the part of unit’s kit.

4 | EN SMARTY XV v2020.2
3. SAFETY INSTRUCTIONS AND PRECAUTIONS
Read this instruction very carefully before installing and using this equipment. Installation, connection and maintenance should be carried out by
a qualifed technician and in accordance with the local rules and legal acts.
The company shall take no responsibility for the injuries su󰀨ered by the people or for the damaged property, if the safety requirements are not
followed or the device is modifed without the permission of the manufacturer.
Main safety rules
Danger
• Before performing any electricity or maintenance tasks make sure, that the device is disconnected from the mains, that all moving parts
of the device have stopped.
• Make sure that the fans can not be entered through air ducts or branch openings.
• If you notice liquids on electric parts or connections that bear voltage, stop the operation of the appliance.
• Do not plug the device into the mains, that di󰀨ers from the one indicated on the label or on the housing.
• Voltage of the mains should comply with the electrotechnical parameters indicated on the label.
• The device should be earthed in accordance with the rules of installation of electric appliances. It is forbidden to turn on and use un-
earthed device. Follow the requirements of the device’s labels that indicate Danger.
Warnings
• Connection of electricity and maintenance of the device should be performed only by a qualied personnel, in accordance with the
manufacturer’s instructions and valid safety requirements.
• In order to reduce the risk during installation and maintenance, suitable protective clothes should be worn.
• Beware of sharp angles while performing installation and maintenance tasks.
• Do not touch heating elements until they haven’t cooled down.
• Some devices are heavy, thus one should be very careful while transporting and installing. Use suitable lifting equipment.
• While connecting electricity to the mains a circuit breaker of suitable size is necessary.
Warning!
• If the device is installed in a cold environment, make sure that all connections and tubes are properly isolated. Intake and discharge air
ducts should be isolated in all cases.
• Openings of the ducts should be covered during transportation and installation.
• Make sure not to damage the heater when connecting the piping of the water heater. For tightening up, use a wrench/spanner.
Before starting the equipment
• make sure, that there are no strange objects inside;
• manually check whether fans are not stuck or blocked;
• if rotary heat exchanger is installed in the device, make sure that it is not stuck or blocked;
• check the grounding;
• make sure that all components and accessories are connected in accordance with the project or provided instructions.
Danger: Fumes
Salda Antifrost system uses dis-balancing of the air ow and it may cause negative pressure in premises. Great care should be taken
when using at the same time in premises as another heating appliance what depend on the air in premises. Such appliances include
gas, oil, wood or coal-red boilers and heaters, replaces, continuous ow or other water heaters, gas hobs, cookers or ovens which
draw air in from the room and duct exhaust gases out through a chimney or extraction ducting. The heating appliance can be starved
of oxygen, impairing combustion. In exceptional cases harmful gases could be drawn out of the chimney or extraction ducting back
into the room. In this case we strictly recommend to turn o󰀨 Salda Antifrost and use an external preheater for heat exchanger anti-frost
protection (see Salda Antifrost function on the Remote controller manual).

EN | 5SMARTY XV v2020.2
4. INFORMATION ABOUT THE PRODUCT
4.1. DESCRIPTION
Smarty X V are residential air handling unit with a high e󰀩ciency (up to 91 %) counter ow heat exchanger. The unit provides ventilation in the
home and takes the heat from the exhausted air. AHU complies with ErP 2018 , Passivhaus, Eurovent requirements. The unit is operated by a
separate remote control panel or though separate MB-Gateway by PC. Remote control panel and MB-Gateway are optional and not included in
standard package. Control functions depend on selected control board type: MiniMCB or MiniMCB basic.
Smarty X V operates within the limits of the airow diagrams and is suitable for indoor operation only. Required ambient temperatures must be from
+5 oC to +40 oC. For the cold climate zones (air temperatures below -2 oC), integrated or optional pre-heater is required if airow misbanancing
is disabled.
Product name Control board Type Heat recov-
ery
Temperature
control
Bypass
damper
Optional heating elements
Duct based Air
Pre-Heater
Duct based Air
Heater
Smarty 2X V 1.1 Mini MCB Premium + + + - +
Smarty 2X V 1.2 Mini MCB Basic Advanced + + + +* +*
Smarty 3X V 1.1 Mini MCB Premium + + + - +
Smarty 3X V 1.2 Mini MCB Basic Advanced + + + +* +*
Smarty 4X V 1.1 Mini MCB Premium + + + + +
Smarty 4X V 1.2 Mini MCB Basic Advanced + + + +* +*
*- only pre-heater or heater
Not suitable for swimming pools, saunas and other similar facilities.
4.2. DIMENSIONS AND WEIGHT
W2
W3
L1 L2
L3 L4
D/D1
W
H1
W1
L
D
D1*
L5
H
[mm] SMARTY 2 XV SMARTY 3 XV SMARTY 4 XV
L 595 599 599
L1 83 110 110
L2 82 113 113
L3 195 110 110
L4 242 265 265
L5 209 193 193
H 697 810 810
H1 732 901 901
W 316 538 538
W1 156 284 284
W2 79 170 170
W3 82 116 116
øD 125 160 160
øD1* 115 150 150

6 | EN SMARTY XV v2020.2
ød 16 G1/2 G1/2
* - depends on unit and its accessories.
WEIGHT
SMARTY
2 XV 1.1 2 XV 1.2 3 XV 1.1 3 XV 1.2 4 XV 1.1 4 XV 1.2
[kg] 25 25 39 39 39 39
4.3. TECHNICAL DATA
SMARTY 2XV 1.1 2XV 1.2 3XV 1.1 3XV 1.2 4XV 1.1 4XV 1.2
Exhaust air fan
phase/voltage [50 Hz/VAC] 1/230 1/230 1/230 1/230 1/230 1/230
power/current [kW/A] 0,035/0,35 0,035/0,35 0,083/0,75 0,083/0,75 0,21/0,92 0,21/0,92
speed [min-1] 4060 4060 3200 3200 4400 4400
control input [VDC] 0-10 0-10 0-10 0-10 0-10 0-10
protection class IP54 IP54 IP54 IP54 IP54 IP54
Supply air fan
phase/voltage [50 Hz/VAC] 1/230 1/230 1/230 1/230 1/230 1/230
power/current [kW/A] 0,035/0,35 0,035/0,35 0,083/0,75 0,083/0,75 0,21/0,92 0,21/0,92
speed [min-1] 4060 4060 3200 3200 4400 4400
control input [VDC] 0-10 0-10 0-10 0-10 0-10 0-10
protection class IP54 IP54 IP54 IP54 IP54 IP54
Integrated electrical preheater [kW/A] 0,6/2,6 -1,2/5,2 - 1,2/5,2 -
Integrated electrical heater [kW/A] - - - - - -
Total power/current consumption [kW/A] 0,67/3,35 0,07/0,75 1,37/6,75 0,17/1,55 1,62/7,09 0,42/1,89
Automatic control integrated miniMCB miniMCB
basic miniMCB miniMCB basic miniMCB miniMCB basic
Insulation of walls [mm] 30 30 30 30 30 30
Exhaust air lter (class, dimensions LxWxH) [mm] MPL 270x187x25 Coarse
65%
MPL 475x180x25 Coarse
65%
MPL 475x180x25 Coarse
65%
Supply air lter (class, dimensions LxWxH) [mm] MPL 270x121x25 Coarse
65%
MPL 475x134x25 Coarse
65%
MPL 475x134x25 Coarse
65%
Device protection class IP 32 IP 32 IP 32 IP 32 IP 32 IP 32
According to EN 13141-7 standard.
SMARTY 2XV SOUND DATA
Duct Sound power 63 Hz 125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz Total
Outdoor LWA, dB(A) 12 44 51 45 40 26 14 4 53
Supply LWA, dB(A) 17 48 57 60 56 51 48 33 63
Extract LWA, dB(A) 12 44 51 52 43 26 19 6 55
Exhaust LWA, dB(A) 21 52 60 64 62 54 51 36 68
Surround LWA, dB(A) 8 32 42 47 43 43 42 38 38
Measured at ow/pressure, (m3/h/Pa) 126/50
SMARTY 3XV SOUND DATA
Duct Sound power 63 Hz 125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz Total
Outdoor LWA, dB(A) 16 48 55 47 37 30 21 14 56
Supply LWA, dB(A) 22 53 62 62 57 52 41 31 66
Extract LWA, dB(A) 19 51 59 50 40 33 23 16 60
Exhaust LWA, dB(A) 25 57 65 64 57 55 48 39 69
Surround LWA, dB(A) 16 38 46 45 41 37 34 30 50
Measured at ow/pressure, (m3/h/Pa) 277/50
SMARTY 4XV SOUND DATA
Duct Sound power 63 Hz 125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 5000 Hz Total
Supply LWA, dB(A) 47 53 58 56 54 51 46 41 62

EN | 7SMARTY XV v2020.2
Extract LWA, dB(A) 44 45 50 47 45 43 38 35 54
Surround LWA, dB(A) 30 35 48 46 40 35 27 24 51
Measured at ow/pressure, (m3/h/Pa) 406/50
4.4. OPERATING CONDITIONS
SMARTY 2XV 1.1 2XV 1.2 3XV 1.1 3XV 1.2 4XV 1.1 4XV 1.2
Minimum outdoor air temperature -15 oC -2 oC -15 oC -2 oC -10 oC -2 oC
Maximum outdoor air temperature +40 oC +40 oC +40 oC +40 oC +40 oC +40 oC
Minimum extracted air temperature +15 oC +15 oC +15 oC +15 oC +15 oC +15 oC
Maximum extracted air temperature +40 oC +40 oC +40 oC +40 oC +40 oC +40 oC
Maximum extracted air relative humidity 60 % 60 % 60 % 60 % 60 % 60 %
Minimum ambient air temperature +5 oC +5 oC +5 oC +5 oC +5 oC +5 oC
Maximum ambient air temperature +40 oC +40 oC +40 oC +40 oC +40 oC +40 oC
Installation indoor only indoor only indoor only indoor only indoor only indoor only
4.5. STANDART PACKAGE OF COMPONENTS
SMARTY 2 XV 3 XV 4 XV
Key M4 Z-type ZPDR00115 1 - -
Outlet pipe G3/8 GNG202_1059 1 - -
Fix - PV gasket 6x20 (white) ZIZJS0005 550 mm 1180 mm 1180 mm
Sealing rubber 15x8x7 427021 ZPDT00007 60 mm 600 mm 600 mm
Bracket2281027 PRT001101 - 1 1
Bracket 3 PRT000556 1 - -
Straight Fiting With O-ring F 1/2 M/M ZPGGM056 - 1 1
Ring gasket 1/2 ZPGGM057 - 1 1
Siphon D25 GNGSRIS003 - 1 1
4.6. DESCRIPTION OF COMPONENTS
10
9
Figure 4.6.1. Smarty 2XV Figure 4.6.2. Smarty 3XV/4XV
1 - Plate heat exchanger; 2 - Supply fan; 3 - Exhaust fan; 5 - Electrical pre-heater; 6 - Control board (version 1.1 only); 7 - Extract air lter (pan-
el); 8 - Supply air lter (panel); 9 - By-Pass damper; 10 - Power supply for fans.

8 | EN SMARTY XV v2020.2
5. INSTALATION
5.1. RECEPTION OF GOODS
Each device is thoroughly checked before transportation. While receiving goods it is recommended to check whether devices were not damaged
during transportation. If a damage to the device is noticed, immediately address the representatives of a transport company. Please inform a rep-
resentative of the manufacturer, if any deviation from the order is noticed.
5.2. TRANSPORTATION AND STORAGE
• All units are packed in the factory to withstand regular conditions of transportation.
• Upon unpacking, check the unit for any damages caused during transportation. It is forbidden to install damaged units!!!
• The package is only for protection purpose!
• While unloading and storing the units, use suitable lifting equipment to avoid damages and injuries. Do not lift units by holding on power supply
cables, connection boxes, air extract or exhaust anges. Avoid hits and shock overloads. Before installation units must be stored in a dry room
with the relative air humidity not exceeding 70% (at +20 °C) and with the average ambient temperature ranging between +5 °C and +30 °C. The
place of storage must be protected against dirt and water.
• The units must be transported to the storage or installation site using forklifts.
• The storage is not recommended for a period longer than one year. In case of storage longer than one year, before the installation it is necessary
to verify whether the bearings of fans and motor rotate easily (turn the impeller by hand) and if the electric circuit insulation is not damaged or
the moisture is accumulated.
H
L
W
SMARTY
H W L QUANTITY ON THE PALLET
[mm] [mm] [mm] [units]
2 XV 480 700 800 1
3 XV 1060 600 800 1
4 XV 1060 600 800 1
Figure 5.2.1. Lifting with forklift.
Only a product placed on a pallet may be lifted in order to prevent damage to the casing.
5.3. UNPACKING
Accessories may be packed together with the product. Prior to transporting the unit, rst unpack the accessories.
• Remove the lm from the unit.
• Remove the bracing packaging tape which keeps the protective proles.
• Remove the protective proles.
•After unpacking the unit, examine it to make sure that it it has not been damaged during transportation. The installation of damaged units is
prohibited!
• Verify that all ordered equipment are delivered before starting the installation. Any deviation from the ordered equipment must be reported to the
supplier of products.

EN | 9SMARTY XV v2020.2
1
2
3
4
Figure 5.3.1. Smarty 2XV Figure 5.3.2. Smarty 3XV/4XV
5.4. PIPING AND INSTRUMENTATION DIAGRAM
Figure 5.4.1. SMARTY XV miniMCB (* Available in 3/4 XV 1.1 mod-
els; ** Check the manual for details; *** Optional)
Figure 5.4.2. SMARTY XV miniMCB basic (* Only heater or
preheater can be connected at a time; ** Check the manual for
details; *** Optional)
LIST OF COMPONENTS
CPlate heat exchanger KE1 Electric heater
PV Supply air fan PE1 Electric pre-heater
IF Extract air lter M1 By-pass damper
PF Supply air lter M2 Outdoor air damper actuator
IV Exhaust fan M3 Exhaust air damper actuator
TA Extract air temperature sensor SK1

10 | EN SMARTY XV v2020.2
TE Exhaust air temperature sensor SK2
TJ Supply air temperature sensor TL Outdoor air temperature sensor
DTJ extract air temperature and humidity sensor (only
version 1.1)
M
CO2
Ventilated premises
CO2CO2sensor* MB-Gateway Network module
RH RH sensor* NET Network
PC Computer RC Stouch or SA-Control remote control panel
POSSIBLE PCB INPUTS/OUTPUTS
FA Fire alarm H1 Working indication output
FPP Fireplace protection H2 Alarm indication output
System mode switch (START/STOP) Fans speed switch (BOOST)
* Component/posibility to connect it depends on model.
5.5. MOUNTING
• Installation should only be performed by qualied and trained sta󰀨.
• When connecting air ducts, consider the labels on the casing of the unit.
• Before connecting to the air duct system, the connection openings of ventilation unit should be closed.
• When connecting the ducts , you should pay attention to the air ow direction indicated on the device housing.
• Do not connect the bends close to connection anges of the unit. The minimum distance of the straight air duct between the unit and the rst
branch of the air duct in the supply air duct must be 1xD, in air exhaust duct 3xD, where D is diameter of the air duct.
• It is recommended to use the accessories-holders. This will reduce vibration transmitted by the unit to the air duct system and environment.
• Enough space must be left for opening of the maintenance door and lter covers.
• If the installed ventilation unit is attached to a wall, it may transmit noise vibrations to the premises. Though the level of noise caused by the
fans is admissible, it is recommended to mount the unit at the distance of 400 mm from the nearest wall. If it is not possible, the mounting of the
unit is recommended on the wall of the room where the level of noise is not important.
• Ducts are connected to the unit in such way that they could be easily disassembled and the heater could be removed from the unit when per-
forming service or repair works
The protective lm is intended to protect the unit during transportation. It is recommended to remove the lm because other-
wise oxidation signs may occur.
Before every heating season the condensate tube shall be lled with water as indicated during the rst startup!
W
α
W
α
α
W
α
W
α
α
Figure 5.5.1. mounting positions (W=400 mm) Figure 5.5.2. mounting positions

EN | 11SMARTY XV v2020.2
5.6. PLACE REQUIREMENTS FOR THE EQUIPMENT AND MOUNTING POSITIONS
L
1,5xL
L
1,5xL
H
H
Figure 5.6.1. Min. distance to open the door - 1,5xL; Min. distance to open control box door - H > 400 mm.
5.7. FLOOR MOUNTING
Figure 5.7.1. oor mounting (optional accessory required)
5.8. MOUNTING ON WALL
b
30 mm
ac d
90
90
Figure 5.8.1. mounting on the wall
5.9. DRAINAGE
Before every heating season the condensate tube shall be lled with water as indicated during the rst start-up! Before every heating
season the condensate tube shall be lled with water as indicated during the rst start-up!

12 | EN SMARTY XV v2020.2
DRAINAGE INSTALLATION SMARTY 2XV
øD
Figure 5.9.1. drainage installation (øD=150 mm)
It’s required to connect condensate drainage system after hanging or placing of air handling unit. Insert condensate draining into AHU. Condensate
draining must be lubricated with a sealant (I-VII) and connected to a condensate removal system.
Remove the sticker on the bottom of the unit, which covers a drainage hole. Then open the unit cover (II) and take out the heat exchanger. Put
condensate outlet pipe to EPP casing through intended hole (V), use silicon gasket (IV). Place from the bottom side gasket and screw a brass nut
on (VII). Screw the nut by holding the pipe with a hand in order prevent spinning (it’s possible to hold with a screwdriver or 1 Euro coin by putting
it in the notch on the pipe). Screw the nut with a wrench (No. 27) until a top part presses in the EPP casing (level with a surface or slightly enters
into it). Attention: Screwing force may not exceed 2 Nm.
Pipe (3) (metal pipe should be connected with G3/8 elbow, plastic pipe – with G3/8 elbow or rubber hose – with strap if the unit is placed on the
legs, in other cases condensate hose can be connected in any direction) should be connected by following order: AHU (1), pipe (2), and drainage
system. Pipes (3) should be bended not less than 3° degrees (1 meter of pipe must be bended 60 mm downwards)! Before turning on AHU (1) the
draining system should be lled up with at least 0.5 l of water (pipe loop (3) must be always lled with water), also check if water reaches sewerage
system! In other case premise can be ooded during AHU operation!
Draining system must be installed in the premise where the temperature is not lower than 1°C. If temperature falls below 0°C the draining system
should be isolated with thermal isolation. The pipe loop 2) not necessarily must be mounted below the AHU (1), but below the AHU (1) level.
Note. If the collector is situated upstream, install a system with a condensate pump (o󰀨ered as an accessory).
DRAINAGE INSTALLATION SMARTY 3XV/4XV
1.Connect the drain couplings (ZPGGM056) part A (G ½ male) to drainage connection into the unit, by turning it clockwise by hand. Do not use
any tools (I-III)!
2. Connect drain couplings part B(G ½ male) to condensate syphon or looped sanitary hose(IV-V).
3.Connect drain couplings A and B parts. Hold back the part A with the key during connection (VI).
5.10. CONNECTION OF THE AIR DUCT
D2 dimensions depend on unit.
• Connected air ducts must be straight and have their own xing.
• Make sure that the fans can not be entered through air duct heads. If it is possible to enter the fan, protective grid should be installed. You can
choose it in our website.
• Do not reduce the diameter of the piping near air inlet or exhaust ducts. If you want to reduce the speed of air in the system, drop of pressure

EN | 13SMARTY XV v2020.2
and noise level, you can increase the diameter.
• In order to reduce the level of the noise in the air supply system, install dampers (see chapter on their installation).
• In order to reduce air loss in the system, the air ducts and prole parts should be of class C and higher. Their catalog can be found in our website.
• Outside air and exhaust system piping should be isolated in order to prevent heat loss and condensation.
• It is recommended to maintain a distance of up to 8 meters between air intake and air exhaust ducts. Air supplying system should be installed
further from potential air pollution sources.
• Use holders while installing air ducts next to the ventilation equipment. They suppress vibration and assure a rm installation of various system
parts. Necessary holders can be found in our catalog or website.
• A common mistake is that air ducts are connected in inappropriate place. On the ventilation equipment there are signs, indicating the air duct to
be connected. Before starting the system carefully check whether the work was performed properly.
Right side connection Left side connection
5.11. CONNECTION OF THE UNIT TO ELECTRIC NETWORK
• Supply voltage to the unit must be connected by a qualied specialist following the manufacturer’s instructions and e󰀨ective safety instructions.
• The unit’s power network voltage must correspond to electrotechnical parameters of the unit indicated in the technical decal.
• The unit’s voltage, power and other technical parameters are provided in the unit’s technical decal (on the unit casing). The unit must be connect-
ed to the voltage plug socket of the grounded power network in compliance with the e󰀨ective requirements.
• The unit must be earthed according to the rules on installing electrical equipment.
• It is prohibited to use extension wires (cables) and power network plug socket distribution devices.
• Prior to carrying out any ventilation unit installation and connection activities (until its hand-over to the customer), the unit must be disconnected
from the power network.
• After installation of the ventilation unit, the power network plug socket must be accessible at any time and disconnection from the power network
is performed through the two-pole circuit breaker (by disconnecting phase pole and neutral).
• The unit must be thoroughly checked against damages (execution, control, measurement nodes) during transportation before it is connected to
the power network.
• The power cable can be replaced only by a qualied specialist upon the evaluation of the rated power and current.
The manufacturer does not assume any liability for personal injuries and property damage due to nonconformance with the
provided instructions.
5.12. START-UP RECOMMENDATIONS
5.12.1. SYSTEM PROTECTION
The control automatics of the unit have integrated protection against a short circuit of those assemblies. The controllers have the following pro-
tectors:
MCB
F1, F2 - 1A(5x20) MCB protection;
To ensure safe maintenance of the unit, it is necessary to turn o󰀨 main switch and/or external protection device.
5.12.2. PRE-STARTUP RECOMENDATIONS OF THE UNIT (IN THE PRESENCE OF THE ENDUSER)
Prior to start-up the system must be thoroughly cleaned. Check whether:
• operation systems and unit elements as well as automation and automation devices were not damaged during installation,
• all electrical devices are connected to power supply and t for service,
• all necessary automation elements are installed and connected to power supply and MCB, EX1, EX2 terminal blocks,
• cable connection to MCB, EX1, EX2 terminal blocks comply with the existing power connection diagrams,
• all electrical equipment protection elements are properly connected (if they are additionally used),
• cables and wires correspond to all applicable safety and functional requirements, diameters, etc.,
• earthing and protection systems are properly installed,
• condition of all seals and sealing surfaces is correct.

14 | EN SMARTY XV v2020.2
6. MAINTENANCE
6.1. SAFETY INSTRUCTION
Unplug unit from mains before opening the door (disconnect the power plug from the outlet or if there is a two-pole automatic circuit
breaker installed – disconnect it as well. It is necessary to ensure that it won’t be turned on by third parties) and wait until the full stop of
the fans (for about 2 min.).
6.2. GENERAL RECOMMENDATIONS FOR THE MAINTENANCE OF VENTILATION SYSTEM
In order to ensure proper functioning of the system, maintenance requirements and its periods should be followed. Otherwise the warranty shall
not be valid. Some recommendations are provided in the table below, but they are just advisory, as the need of system maintenance depends on
the place of the device installation, the pollution of the atmosphere, the population, the working hours and etc.
COMPONENT DURING START-UP AT LEAST EVERY 6 MONTHS
Filters Check the cleanliness of the lters Replace lters every 3 to 4 months or according to the control
device indications.
Fans Check the connections and the
direction of rotation
Check cleanliness. Clean, if necessary
Make sure that the impellers are not unbalanced.
Make sure that the impellers do not cause noise when rotated by
hand.
Make sure that the fastening screws are not loose and free of
mechanical damage.
Check electrical connections and make sure that these are se-
cured properly and are free of signs of corrosion.
Plate Heat exchanger Check the cleanliness of the heat
exchanger Check cleanliness and clean, if necessary
Control panel Check the connections Check the connections
Electric heater Check the connections Clean o󰀨 dust, and check the electrical components and connec-
tions of the heater
Presure senssor Check electrical connections Check the operation
Temperature senssor Check electrical connections Check the operation and tune up, if necessary
Air intake and discharge system Check the connections Clean
Air duct system Check the tightness Clean
Dampers, di󰀨users, grid Check the tightness of connections Clean
Switching unit (contactor)
Every 3 to 4 months, visually assess the functioning of the switch-
ing unit (contactor), i.e. make sure that its casing has no signs
of melting or is not thermally damaged otherwise and does not
produce any unusual sounds. All the contactors in the product or
in its accessories must be checked.
Condensate trap and discharge
assembly
Check the condensate discharge
assembly and make sure that wa-
ter runs from the bath properly.
Clean
6.3. COVER OPENING
Figure 6.3.1. Smarty 2XV Figure 6.3.2. Smarty 3XV/4XV

EN | 15SMARTY XV v2020.2
6.4. FILTERS MAINTENANCE
Figure 6.4.1. Smarty 2XV Figure 6.4.2. Smarty 3XV/4XV
Smarty 2X V lters: In order to remove the lters, use key to open
the doors and take o󰀨 the lters. Use Coarse 65% (ePM1 70% -
optional) lters.
Smarty 3-4X V lters: In order to remove the lters, open lter
cover by pulling the strap and take o󰀨 the lters. Use Coarse 65%
(ePM1 70% - optional) lters.
After changing the lters, please reload the lter timer. Instruction on reloading, you may nd in manual of control panel or
on our website www.salda.lt
Change the lters every 3-4 months or according to the notication on the control device.
6.5. FANS MAINTENANCE
Maintenance should be performed only by experienced and trained sta󰀨. The fan should be inspected and cleaned at least once a year.
• Be sure the fan is disconnected from power source before performing any maintenance or repair.
• Observe sta󰀨 safety regulations during maintenance and repair.
• The motor is of heavy duty ball bearing construction. The motor is completely sealed and requires no lubrication. Supplied air fan from X15, X2,
X4. Extract air fan from X16, X2, X4.
• Detach fan from the unit.
• Impeller should be specially checked for buil-up material or dirt which may cause an imbalance. Excessive imbalance can lead to accelerated
wear on motor bearings and vibration.
• Clean impeller and inside housing with mild detergent, water and damp, soft cloth.
• Do not use high pressure cleaner, abrasives, sharp instruments or caustic solvents that may scratch or damage housing and impeller.
• Do not plunge the motor into any uid while cleaning impeller.
• Make sure, that impeller’s balance weights are not moved.
• Make sure the impeller is not hindered.
• Mount the fan back into the unit. Connect the fan to power supply source.
• If after maintenance the fan does not start or stop itself, contact the producer. Malfunction of the fan can be identied according to the pressure
in the system (when pressure switches are connected). When there is a folt in fans’ motor, any separate notice is shown on the control panel.
Be sure the unit is disconnected from power source before performing any maintenance or repair.
- Remove the fan connectors from the control board. Supplied air fan from X15, X2, X4. Extract air fan from X16, X2, X4.
Note:
- X2, X4 are common for both fans.
- Reassembly shall be executed in the reverse order.
X2
X15
X16
X4
The wiring diagram can be found in the "MCB miniMCB technical manual".

16 | EN SMARTY XV v2020.2
Figure 6.5.1. Smarty 2XV Figure 6.5.2. Smarty 3XV/4XV
6.6. HEAT EXCHANGER MAINTENANCE
• Proceed to maintenance and repair after any rotation in the fan stopped.
• Clean the heat exchanger once a year.
• Firstly take out heat exchanger cassette carefully. Submerge it into a bath and wash with warm soapy water (do not use soda). Then rinse it with
weak hot water stream (too strong stream can fold the plates). Place back the heat exchanger only when it is completely dry.
Figure 6.6.1. Smarty 2XV Figure 6.6.2. Smarty 3XV/4XV
6.7. BYPASS DAMPERS AND PRE-HEATER MAINTENANCE
Bypass damper and pre-heater are mounted on one block. The pre-heater shall be disconnected by removing X29 connector. The bypass damper
shall be disconnected by removing X25 .
X29 X25
Figure 6.7.1. Smarty 2XV Figure 6.7.2. Smarty 3XV/4XV

EN | 17SMARTY XV v2020.2
6.8. CONTROL BOARD MAINTENANCE
- Unscrew the front bolt securing the control board holder to the unit casing.
- Withdraw the automation through the front part.
- Disconnect the connectors from the control board.
- The connectors are marked according to connection location. Thus during automation reassembly please observe the marking of the connection
location of connectors and controller. If the marking on the controller terminals is not visible follow the PCB information provided in this passport
(see miniMCB description: Fig. 2 and Fig. 3):
1. 2.
3.
6.9. SMARTY 4XV SWITCHING POWER SUPPLY MAINTENANCE
• Unscrew screw at the front side;
• After loosening power supply, lift it up in order to disconnect connector below. (2-3).
• Power supply is under the protection cover. Please remove the cover in order to change it (4-5). Then release power supply from the base (6-7).
• Perform assembly in the reverse order.
• Connectors are marked according connection place, therefore, please, pay attention to the marking.
1.
2. 3.
4. 5. 6. 7.

18 | EN SMARTY XV v2020.2
7. CONTROL
7.1. DEVICE CONTROL
Ventilation unit equipped with MCB control board can be controlled with remote controller, WEB interface or mobile app via MB-GATEWAY and
BMS (building management system). More information provided in the table below.
With MB-GATEWAY Remote control panels BMS direct connection Wireless communication
Web interface
SALDA AIR mobile application
BMS over Modbus TCP/IP
BMS over BACnet TCP/IP
Stouch
ST-SA-Control
Modbus RTU (RS485) MB-GATEWAY + WIFI router
7.2. DEVICE FUNCTIONS
All MCB control boards has the same software with all functions included. Full function list and description you can nd on the MCB control board
manual. However, operation and control of the device depends on the following:
1. Selected control interface (remote control panel, MB-GATEWAY and etc.). Chosen interface just a󰀨ects access to the information and settings
but not a󰀨ects the logic of control. Full access to the information and settings are available on ST-SA-Control, MB-GATEWAY WEB application
and SALDA AIR mobile application.
2. Unit conguration (internal/external components, sensors and control board settings)
Refer to the instruction manual of the existing control device for unit control instructions.

EN | 19SMARTY XV v2020.2
8. ACCESSORIES
AP MUTE SKG ALU MPL EKA NIS S-KCO2 S-RCO2-F2 CM230-F-L WSG
ST-SA-
Control
Stouch MB Gate-
way
NPU S-KFF-U S-RFF-U-
D-F2
UG-3-A4O 774451 +
774411
TP-Link
TLWR802N
TJ1TE-
NTC10
K3B4.5
TF 230
DESCRIPTION NAME SKU
ELECTRICAL ACCESSORIES
El. Heater
EKA NIS 160-1.0-1 f ACC000323
EKA NIS 160-1,2-1f ACC003804
EKA NIS 160-1.5-1 f ACC000324
EKA NIS 160-2.0-1 f ACC000325
EKA NIS 160-2.4-1 f ACC000326
EKA NIS 160-3,0-2f ACC003805
EKA NIS 160-5,0-2f ACC003806
EKA NIS 160-6,0-2f ACC003807
EKA NIS 125-0.6-1 f ACC000319
EKA NIS 125-0.9-1 f ACC000320
EKA NIS 125-1,2-1f ACC003803
EKA NIS 125-1.5-1 f ACC000321
EKA NIS 125-1.8-1 f ACC000322
EKA 160-0.3-1 f ACC003723
EKA 160-0.6-1 f ACC003724
EKA 160-1.0-1 f ACC000333
EKA 160-1,2-1f ACC003725
EKA 160-1,5-1 f ACC000334
EKA 160-2,0-1 f ACC000335
EKA 160-2,4-1f ACC003726
EKA 160-3,0-1 f ACC000336
EKA 160-3,0-2f ACC003727
EKA 160-5.0-2 f ACC000337
EKA 125-0.3-1 f ACC003721
EKA 125-0,6-1 f ACC000329
EKA 125-0,9-1 f ACC000330
EKA 125-1,2-1f ACC003722
EKA 125-1,5-1 f ACC000331
EKA 125-1,8-1 f ACC000332
Duct CO2transmitter S-KCO2 ACC000277
Room CO2transmitter S-RCO2-F2 ACC000278
Air damper actuator CM230-1-F-L CM230-F-L ACC000305

20 | EN SMARTY XV v2020.2
Remotre control panel ST-SA -Control ACC005592
Remotre control panel Stouch ACC000272
Network module MB-Gateway MB Gateway ACC000269
Duct humidity transmitter S-KFF-U ACC000279
Room humidity transmitter S-RFF-U-D-F2 ACC000280
Button 774451 + 774411 ZEPSM001
Wireless N Nano Router TP-Link TL-WR802N ACC000273
Sensor temperature TJ1TE-NTC10K3B4.5 ACC002560
Smoke detector UG-3-A4O ACC004464
Air damper actuator TF 230 ACC000316
MECHANICAL ACCESSORIES
Clamp sealing AP 125 (Smarty 2XV) AP 125 FIT000060
Clamp sealing AP 160 (Smarty 3/4XV) AP 160 FIT000062
Attenuator circular Mute 125x900 (Smarty 2XV) Mute 125x900 FIT000288
Attenuator circular Mute 125x600 (Smarty 2XV) Mute 125x600 FIT000287
Attenuator circular Mute 160x600 (Smarty 3/4XV) Mute 160x600 FIT000289
Attenuator circular Mute 160x900 (Smarty 3/4XV) Mute 160x900 FIT000290
Dampers circular shut o󰀨 sealed blade d125 SKG-A 125 FIT000201
Dampers circular shut o󰀨 sealed blade d160 SKG-A 160 FIT000203
Grille outdoor ALU 125 (Smarty 2XV) ALU 125 FIT000126
Grille outdoor ALU 160 (Smarty 3/4XV) ALU 160 FIT000127
Grille outdoor WSG 160 (Smarty 3/4XV) WSG 160 FIT000403
Coupling with sealing NPU 125 (Smarty 2XV) NPU 125 FIT000367
Coupling with sealing NPU 160 (Smarty 3/4XV) NPU 160 FIT000087
Filter set Smarty 2X V (Coarse-65+Coarse-65-2pcs.) ACC005251
Filter set Smarty 3-4X V (Coarse-65+Coarse-65-2pcs.) ACC005255
8.1. CONNECTION OF ACCESSORIES
8.1.1. HEATER AND PRE-HEATER
8.1.1.1. VERSION 1.1.
Smarty XV 1.1. units have one connection for external electrical air heater. Pre-heater is integrated inside the product. Heater can be controlled
by signals:
- 0-10V – EKA NIS
- On-O󰀨 – EKA
