Salus 091FLRF User manual

091FL RF Quick Guide Programming
1. Setting Time
To set the day, press D until the present day is shown. For example: 1=Monday 7=Sunday. This number
is displayed at the top of the LCD display
To set the hour, press H until you reach the correct hour
To set the Minutes, press M until you reach the current time
2. Standard Thermostat
For ease of use the 091FL comes factory set. The factory setting can be used with no adjustment to the
thermostat after the time has been set. The highest Temperature (SUN) is 19 Deg. C and the lowest
Temperature (Moon) is 15 Deg. C. The thermostat will work on the high temperature between 6am and
11pm and the low temperature between 11pm and 6am. Switching between the high and low
temperature is simple and is explained in section 3
3. Manual Override
The easiest way to override the thermostat is to press either the SUN or the MOON button to the
reverse the program. For example if you feel it is too hot then press the MOON button on the front of
the thermostat this will temporarily change the program so that the thermostat will follow the lowest
temp even though it is in the high temperature part of the program. This works the same for pressing
the SUN button in the low temperature part of the program. You can determine what part of the
program you are in by the symbol displayed on the LCD. For example: SUN/MOON. If the thermostat is
in override a small hand will be displayed in the bottom right of the display. Press OK to cancel any
override. Additionally you can use the MOON button if you exit the property during a high temperature
period, however remember to check the thermostat on entry and adjust accordingly
4. Changing Standard Temperatures
If you find that the factory set temperatures are not suited to your lifestyle they can be simply changed.
The highest temp is displayed by the SUN symbol and the lowest temperature is displayed by the MOON
symbol. Once these High and Low temperatures have been selected the thermostat will follow the
profile of Program 1 (default).
To set the comfort temperature press the TEMP button, the displayed temperature will flash
Then press the SUN button to adjust the Highest temperature
Press the MOON button to adjust the Lowest temperatures
Press OK to Finish
Note these temperatures can be changed at any time
For more information about changing the factory default settings please refer to the back of this guide
Technical Help –Tel: [phone] or Email: [e-mail]

Changing the Default Programming
5. Changing default programs 1-3
For ease of use the unit has been pre-programmed with 3 default programs for typical time and temperature settings. These
programs are numbered 1, 2 and 3. As explained in item 1, the default program is number 1. Details of all programs can be
found on page 18 of the full instruction Manual. You can select the same program or a combination of 1, 2 or 3 for the
complete week. For example: Program 1 for Mon-Friday and program 3 for Sat & Sunday. Program 0 and 4-8 will be
explained later
Press the PROG button. You are now ready to enter the program selection for the current day.
Now press the PROG# to select you choice of 1, 2 or 3. The number is displayed bottom right of the LCD display
Press the PROG button again; you can now enter your program selection for the next day by repeating the above
process. Do this for all 7 days of the week
Press OK when you are finished
6. Programming default programs 0 , 4 & 5
In addition to programs 1-3 there are 3 more default programs. Again these can be mixed with programs 1-3
Program 0 - this allows you to select frost protection only. For example: if you select on a specific day or days there
will be no comfort or economy temperatures. This is ideal for holidays or if the property is unoccupied for long
periods of time.
Program 4 –this uses the selected comfort temperature for the complete day(s)
Program 5 –this uses the selected economy temperature for the complete day(s)
7. Programs 6 , 7 & 8
Unlike the other programs, programs 6-8 can be changed. To set your own program select 6, 7 or 8 using the method in item
4 above. You will notice that when 6 -8 are selected the first black square is flashing on the LCD display shown below
By pressing the SUN button the comfort temperature will be selected for that hour, keep pressing the SUN button for every
hour that the comfort temperature is required. The example above shows a complete day of comfort temperature
When you require the economy temperature for a specific period of time press the moon button, when comfort is selected
there is no black square shown in the time period. The display above shows economy from mid-night until 1pm
Once you are happy with your program settings press OK to save
Technical Help –Tel: [phone] or Email: [e-mail]
