1. Product compliance & safety information
02 iT500BM Installer Manual
These instructions are applicable to the SALUS Controls model stated on the front
cover of this manual only, and must not be used with any other make or model.
This accessory must be tted by a competent person, and installation must
comply with the guidance provided in the current IEE Wiring Regulations and
current Building Regulations. Failure to comply with the requirements of these
publications could lead to prosecution.
When tting batteries, do not mix old and new batteries together.
Do not use rechargeable batteries.
Please leave these instructions with the end user where they should be kept in
a safe place for future reference.
Always isolate the AC Mains supply before installing or working
on any components that require 230 VAC 50Hz supply.
iT500BM Installer Resized 003_Layout 1 13/11/2013 09:31 Page 2

2. Installation of the boiler module
iT500BM Installer Manual 03
RXVBC605
INTRODUCTION
The RXVBC605 is an integral plug-in RF boiler control. The RF boiler control is a direct
replacement for the basic time clock or blanking plate usually supplied with the boiler.
Installing the RF boiler control takes minutes. Once installed, you will benet from all
the control features of the Salus room thermostat.
INTEGRAL RF BOILER CONTROL
The Integral RF boiler control is the RF receiving unit for your RF room thermostat. This
unit uses a plug-in connection to connect directly to your boiler and provides the ON/OFF
switching.
Features
• LED status indication
• Plug-in connection to boiler
• 3 position switch
• 868 MHz communication
Mounting the RF Integral Boiler Control to the boiler
DANGER!
• 24V & 230V: Do not touch electrical components or circuits
• Isolate mains electricity supply before starting any
work and observe all relevant safety precautions
• Follow electro static discharge precaution
• Do not touch any visible PCB parts or components
Page 03 - 05
RXBC605
Page 10 - 11
RXWBC605
Page 06 - 09
iT500BM Installer Resized 003_Layout 1 13/11/2013 09:31 Page 3

2. Installation of the boiler module RXVBC605
04 iT500BM Installer Manual
For ECOTEC post April 2012 -
remove and discard pins.
For ECOTEC models prior to
April 2012, use as supplied.
1. Switch o the boiler at its main supply.
2. Remove cover panel or existing control.
3. Insert the integral boiler control ensuring correct location
of the rear connection pins.
RXVBC605 RECEIVER
iT500BM Installer Resized 003_Layout 1 13/11/2013 09:31 Page 4

2. Installation of the boiler module RXVBC605
iT500BM Installer Manual 05
Now move the switch back to AUTO .
Before switching the boiler on at its mains
supply, ensure the module switch is in the
OFF position.
To ensure the boiler control is connected
properly, please now move the switch to
ON . The boiler should now go on and
the LED on the your boiler control should
illuminate.
iT500BM Installer Resized 003_Layout 1 13/11/2013 09:31 Page 5

2. Installation of the boiler module RXWBC605
06 iT500BM Installer Manual
RXWBC605 RECEIVER
INTRODUCTION
The RXWBC605 comprises of an integral plug-in RF boiler control. The RF boiler
control is a direct replacement for the basic time clock or blanking plate usually
supplied with the boiler. Installing the RF boiler control takes minutes. Once
installed, you will benet from all the control features of the Salus thermostat.
INTEGRAL RF BOILER CONTROL
The Integral RF boiler control is the RF receiving unit for your thermostat.
This unit uses a plug-in connection to connect directly to your boiler and provides
the ON/OFF switching.
Features
• LED status indication
• Plug-in connection to boiler
• 3 position switch
• 868 MHz communication
Mounting the RF Integral Boiler Control to the boiler
DANGER!
• 24V & 230V: Do not touch electrical components or circuits
• Isolate mains electricity supply before starting any
work and observe all relevant safety precautions
• Follow electro static discharge precaution
• Do not touch any visible PCB parts or components
iT500BM Installer Resized 003_Layout 1 13/11/2013 09:31 Page 6

2. Installation of the boiler module RXWBC605
iT500BM Installer Manual 07
RF Transmission
The receiving range between your thermostat and the RF Boiler Control is around
100 metres in open air, however many factors can aect the RF transmission
and shorten the operating distance, e.g. shielding by thick walls, foil back
plasterboard, metal objects such as ling cabinets, general RF interference, and
so on.The operating range is generally around 30 metres, which is large enough
for most household applications.
RXWBC605 RECEIVER
C
First plug in the connector block C ensuring
correct orientation. Remember to ensure
the block is fully connected.
B
A
1. Switch o the boiler at its main supply.
Remove the outer casing and front fascia to
allow access to the main control panel.
2. Remove cover panel A upwards to remove.
3. Pull top tab B upwards, then outwards to
remove blanking plate or existing control.
iT500BM Installer Resized 003_Layout 1 13/11/2013 09:31 Page 7

2. Installation of the boiler module RXWBC605
08 iT500BM Installer Manual
A
Now locate the boiler control’s four hooks then
press in and down. Replace cover panel A.
Replace the front fascia and boiler’s outer casing.
RXWBC605 RECEIVER
Before switching the boiler on at its mains supply,
ensure the module switch is in the OFF position .
iT500BM Installer Resized 003_Layout 1 13/11/2013 09:31 Page 8

2. Installation of the boiler module RXWBC605
iT500BM Installer Manual 09
RXWBC605 RECEIVER
To ensure the boiler control is connected
properly, please now move the switch to
ON . The boiler should now re and the LED
on the your boiler control should illuminate.
Now move the switch back to AUTO .
iT500BM Installer Resized 003_Layout 1 13/11/2013 09:31 Page 9

2. Installation of the boiler module RXBC605
10 iT500BM Installer Manual
RXBC605 RECEIVER
INTRODUCTION
The RXBC605 comprises of an integral plug-in RF boiler control. The RF boiler
control is a direct replacement for the basic time clock or blanking plate usually
supplied with the boiler. Installing the RF boiler control takes minutes. Once
installed, you will benet from all the control features of the Salus thermostat.
INTEGRAL RF BOILER CONTROL
The Integral RF boiler control is the RF receiving unit for your thermostat. This
unit uses a plug-in connection to connect directly to your boiler and provides the
ON/OFF switching.
Features
• LED status indication
• Plug-in connection to boiler
• 3 position switch
• 868 MHz communication
DANGER!
Always isolate the AC Mains supply
before opening or removing the unit
from the boiler.
iT500BM Installer Resized 003_Layout 1 13/11/2013 09:31 Page 10

2. Installation of the boiler module RXBC605
iT500BM Installer Manual 11
INSTALLING THE RF BOILER CONTROL
1. Remove the front panel from the boiler.
2. Pull out the mechanical timer.
3. Do not remove boiler loop.
4. Connect the electrical plug.
5. Push t boiler control into housing.
6. Replace the front panel ensuring a good seal is made.
7. Power up the boiler and check the correct operation.
Connections:
1 - Neutral input
2 - Live input
3 - Common input
4 - Normally open output
RXBC605 RECEIVER
iT500BM Installer Resized 003_Layout 1 13/11/2013 09:31 Page 11

3. Installation of wall bracket docking (optional)
12 iT500BM Installer Manual
12
3
Attach the wall mounting bracket to a
suitable wall using the ttings supplied
and the built in level.
After rst ensuring that the bracket is
secure, clip the iT500 into place by
aligning the recess on the back of the unit
to the bracket and clipping into place.
Once clipped into place, ensure the unit is
securely seated on the bracket.
For best results mount the
iT500 1.5m from ground level.
i
iT500BM Installer Resized 003_Layout 1 13/11/2013 09:31 Page 12

4. Desk mount option iT500
iT500BM Installer Manual 13
For the desk mounted option, simply clip the clear
stand supplied separately into the back of the unit.
iT500BM Installer Resized 003_Layout 1 13/11/2013 09:31 Page 13

5. Connecting the Gateway to your existing router
14 iT500BM Installer Manual
Flashing red light
on setup.
Constant green light when the iT500 is
connected to the SALUS Controls Server.
iT500BM Installer Resized 003_Layout 1 13/11/2013 09:31 Page 14

6. Inserting the batteries in the iT500Thermostat
iT500BM Installer Manual 15
1 2
34
Insert the second battery supplied into the left
hand side of the base of the iT500 Thermostat.
Remove the battery cover from
the base of the iT500 Thermostat.
Make a note of the serial number printed
in the base of the iT500 Thermostat.
With the unit face down, insert the rst
battery supplied into the right hand side
of the base of the iT500 Thermostat.
iT500BM Installer Resized 003_Layout 1 13/11/2013 09:31 Page 15

6. Inserting the batteries in the iT500Thermostat
16 iT500BM Installer Manual
56
Replace the battery cover to the
base of the iT500 Thermostat.
Ensure the batteries are tted securely
in the base of the iT500 Thermostat.
Why not make a note of your STA
number here for future reference.
STA
iT500BM Installer Resized 003_Layout 1 13/11/2013 09:31 Page 16

7. Setting up the iT500 Thermostat
iT500BM Installer Manual 17
After powering up iT500 for the rst time the display will go through the following sequence.
OTA* Revision number
iT500 Software revision
1
2
3
4
The globe icon will appear
when the unit automatically
connects to the internet via
the SALUS iTG500 Gateway.
This should take approximately
20 seconds.
i
* OverThe Air operated software
iT500BM Installer Resized 003_Layout 1 13/11/2013 09:31 Page 17

8. LCD Overview
18 iT500BM Installer Manual
LCD ICONS DESCRIPTION FUNCTION
Day of the week Displays the number of the day of the week. 1 being Monday
Temperature indicator Displays set or measured temperature
Clock display Displays time
Program number indicator Displays the number of the active (selected) program
Heat mode indicator Indicates heating output is turned on*
Heat indicator Indicates heating zone
Hot water mode indicator Indicates hot water output is turned on*
RF signal indicator Indicates the unit is transmitting a wireless signal to the
iT500RX or is receiving the signal from the iT300*
Touch lock indicator Indicates touch lock is activated
Battery status Indicates battery is low
Holiday indicator Indicates holiday operation mode is selected
Internet indicator Indicates connection to iTG500 and SALUS server
AUTO indicator Automatic program mode
OFF indicator O mode
Setting indicator Manual override or settings mode
iT500BM Installer Resized 003_Layout 1 13/11/2013 09:31 Page 18

iT500BM Installer Manual 19
System conguration - iT500 time zone* and DST
At any time press and hold
for 5 seconds to
return to the home screen.
i
* If the iT500 is to be used in
the UK, then there is no need
to enter system conguration
setup, please proceed to
bottom of page 17.
i
iT500BM Installer Resized 003_Layout 1 13/11/2013 09:32 Page 19

20 iT500BM Installer Manual
Select for heating application
GMT Time setting**
Centigrade to Fahrenheit
System conguration - iT500 time zone* and DST
iT500BM Installer Resized 003_Layout 1 13/11/2013 09:32 Page 20
