Salus Quantum SQ610 User manual

IX 2019

2 3
Introduction
The SQ610 Quantum is a ZigBee temperature controller for wireless control of iT600 series devices, such as the
KL08RF wiring centre, mini TRV head, RX10RF boiler control module.
In order to control SQ610 over the Internet or via the SALUS Smart Home mobile app (ONLINE mode), it
must be installed together with the UGE600 Internet gateway (sold separately). From the application level, it
is possible to pair SQ610 with other system elements, e.g. Smart Plug SPE600, Smart Relay SR600 or window/
door sensor OS600/SW600.
SQ610 can be used locally without an Internet connection (OFFLINE mode), however, it’s communication with
other devices must be done using the CO10RF coordinator (sold separately).
Use in accordance to national and EU regulations. Use the device as intended, keeping it in dry condition. Product for
indoor use only. Installation must be carried out by a qualied person in accordance to national and EU regulations.
Disconnect your equipment before cleaning it with a dry cloth.
Please always ensure the AC 230V mains power is switched o before installing or working on any components.
Product Compliance
Safety Information
Warning:
This product complies with the essential requirements and other relevant provisions of Directives 2014/30/ EU,
2014/35/EU, 2014/53/EU and 2011/65/EU. The full text of the EU Declaration of Conformity is available at the
following internet address: www.saluslegal.com.
Before you start: Wiring diagram:
Symbols explanation:
S - volt-free contact
T - temperature sensor
L, N - 230V AC pover supply
COM, NO -Voltage free output
S1,S2 Terminals:
- air or oor temperature sensor
- external volt-free contact to connect any ON/
OFF switch or occupancy sensor (Hotel card)
Mounting: to mount thermostat you can use included
accessories (mounting screws). Remove plate from
the back to mount it to the wall. After that just put
thermostat on the plate.
Please note:
The ideal position to thermostat mounting is about 1,5m
under oor level far from heating or cooling sources.
Thermostat can’t be exposed to sunlight or any extreme
conditions like for example draft.
Package Content:
1) SQ610 Quantum Thermostat
2) Mounting screws
3) Manual instruction
COM
SQ610
NO L
L
230V~,50Hz
S1 S2
N
N
T
S
MM
150 cm
min 20 cm
Select correct thermostat location
THERMOSTAT SQ610 Quantum can work without Universal Gateway or CO10RF Coordinator as a standalone device.
Full manual in PDF format is available at www.salus-controls.eu site.
AC 230V
Français Deutsch
Nederlands English

4 5
1. Menu/Settings description + Clock
2. AM/PM
3. Temperature unit
4. Heating indicator (icon is animating when
there is heating demand)
5. Cooling indicator (icon is animating when
there is cooling demand)
6. RF Connection indicator
7. Internet connection indicator
8. Occupancy sensor (hotel card)
9. Key lock function
10. Standby mode icon
11. Current Temperature / Setpoint Temperature
12. Holiday mode
13. Temporary override mode
14. Settings icon
15. External / Floor temp sensor indicator
16. Schedule program number
17. Schedule mode icon
18. Day indicator/ SET information
19. Current Humidity value
2
8
9
10111214
19
18
17
16
15
1
3
4
5
6
7
13
LCD Icon Description
Buttons DescriptionButtons Description
1) Menu button / Return button.
2) In the MAIN SCREEN: Press and hold for 3 sec to change the thermostat operating mode
(Schedule mode / Permanent mode / Temporary override mode).
3) In the SETTINGS SCREEN: Press and hold for 3 sec to go back without saving the changes.
4) In the PAIRING SCREEN (in SYSTEM TYPE Menu): Press and hold for 3 sec to see other
pairing options.
+
In the MAIN SCREEN - press and hold these buttons together for 3 seconds to LOCK / UNLOCK
the Thermostat keys).
“Up”Button (Increase parameter value/moving on the menu in‘UP’direction)
„Down”Button (Decrease parameter value/moving on the menu in‘DOWN’direction)
1)“OK / Tick”Button (Conrm parameter value / Go to the next menu / Save settings)
2) In the MAIN SCREEN: Press and hold for 3 seconds to enter Standby mode
3) In the SETTINGS SCREEN: Press and hold for 3 sec to go back to the MAIN SCREEN & SAVE all the changes.
Button Function
Français Deutsch
Nederlands English

6 7
COMPATIBILTY WITH OTHER SALUS CONTROLS DEVICES
Quantum Thermostat can work in ONLINE or OFFLINE mode. *Quantum Thermostat can work in ONLINE or OFFLINE mode. *
At rst step you need to decide in which mode your thermostat will work.At rst step you need to decide in which mode your thermostat will work.
ONLINE MODE OFFLINE MODE
Universal Gateway is
CONNECTED TO THE INTERNET
You can congure and use all your
devices in the Smart Home App
Download the Smart Home
App on your iOS or Android
device for remote access to your
SALUS equipment. SALUS
Smart Home
CO10RF Coordinator - You can use
standard ZigBee network coordinator
to install and use your devices.
Universal Gateway is NOT
CONNECTED TO THE INTERNET
You can use your devices locally
without the SmartHome App.
Gateway works in this mode as
standard ZigBee coordinator.
Compatibile devices:
KL08RF
Wiring Centre for 8-zone
underoor heating (UFH).
TRV
(Thermostatic
Radiator Valve) with
wireless communication.
RX10RF
receiver
First power up sequence
To power on the Thermostat you
have to connect it to the 230V power
then...
For easier installation, please make sure you have already added other devices to your ZigBee network, such as
Underoor Heating Control Box (KL08RF) or Radiator heads (TRV’s) etc.
Please note:
Now, choose your language by
„” or „ ”buttons. Conrm
your language by button.
...display will showall icons... ...then thermostat will display
the software version.
2
1
4
3
SR600*
Smart Relay
SPE600*
Smart Plug
OR
SQ610 Quantum Thermostat can work without coordinators (ONLINE/
OFFLINE MODE) as a standalone device with the wires use.
*Only with Online Mode
5
Thermostat work as a standalone device
for pump, boiler, receivers etc. That is, you
can directly connect thermostat to selected
device without any network system. You
can add it later anytime.
NO - STANDALONE.
You can congure your thermostat
with universal gateway or CO10RF
coordinator.That is, add it to the Salus
Smart Home system.
GET IT ON
Download on the
Please note:
Français Deutsch
Nederlands English
YES - ONLINE, OFFLINE MODE.

8 9
Installation in ONLINE mode
After Language selection follow below steps to add your device to the Smart Home app and pair with other devices:
21
SALUS
SmartHome
Go to SALUS Smart Home app
3
Français Deutsch
Nederlands English
Once your thermostat is added to
the app you will see above screen
on the LCD.
9
7
45 6
8
10
13
After that thermostat will show
main screen.
Congratulations!
You succesfully configured SQ610
QuantumThermostat.
15
14
1211
Name this equipment
SQ610 230V Thermostat
Connect equipment
Finish
3

10 11
Installation in OFFLINE mode
123
Open the ZigBee network
456
Select system type: UNDERFLOOR,
press button to conrm
Using and buttons select the Control
Box number (press PAIR button on the Control
Box to see its address number). Press button
to conrm
Use or buttons to select
the zone number and press
button to conrm.
8
7
Now you can pair your thermostat
with additional zones. Select one
more zone or nish the pairing
process by button.
OR
5 sec
5 sec
9
Close the ZigBee network
OR
5 sec.
5 sec
Pairing with Wiring Centre / Control Box (Installthe Wiring Centre / Control Box according to the
instructions included with product)
7
54
3
6
Open the ZigBee network
Select system type:
RADIATORS
Now hold antenna button for 10
sec. on all TRV’s which you want
to pair with your Termostat.
Pairing with TRV radiator head (Install the TRV accordingtothe instructionsincludedwith
product)
On the LCD you will see the number of
pairedTRV’s. Once allTRV’s are paired - press
button to nish the pairing process.
OR
5 sec
5 sec.
10 sec
12
98
Close the ZigBee network
OR
5 sec
5 sec
You can pair up to 6 TRV’s with
1 Thermostat. All TRV’s have
to within the same room with
Thermostat.
33
33
Français Deutsch
Nederlands English

12 13
Wired device
Thermostat SQ610 Quantum can work without Universal Gateway or CO10RF Coordinator as a standalone device.
Please note:
Please note:
Wiring diagram for volt-free connection (e.g. boiler control):
1
3
2Wiring diagram for 230VAC connections:
Wiring diagram for control box connection:
N L
N
1-8 Zones
SLL
S1
S2
L
N
AC 230V
Power
N
L
L
N
AC 230V
S1
S2
BOILER CONNECTIO
N
NO
N
N
L
L
S1
S2
L
N
AC 230V
COM NO
COM
COM
NO
Legend:
Boiler connection * - Boiler’s contacts
for ON/OFF thermostat (according to the
boiler’s instructions)
Pump
Boiler
Valve actuator
Heating mat
*
KL08NSB
Self-acting SQ610 Quantum Thermostat without application support can be easily added to the
Smart Home app anytime. All settings made before adding to the application are automatically
copied to the Smart Home app.
MAX 3(1)A
S
S
Français Deutsch
Nederlands English

14 15
SQ610 Full menu structure
Schedule settings
User settings
Admin settings
Language
TIME/DATE
HOLIDAY MODE
THERMOSTAT CALIBRATION
SHOW/HIDE DISPLAY HUMIDITY
SHOW/HIDE DISPLAY FLOOR
STANDBY TEMP SETPOINT
HEAT/COOL
RESET USER SETTINGS
ENGLISH
DANISH
POLISH
...
DISABLE
MO-FR+SA-SU
MO-SU
SINGLE DAYS
Main menu
TEMPERATURE SCALE
DISPLAY TEMPERATURE RESOLUTION
1.
HEAT CONTROL ALGORITHM
2.
COOL CONTROL ALGORITHM
S1/S2 INPUT
3.
MINIMUM SETPOINT
MAXIMUM SETPOINT
VALVE PROTECTION
4.
INTERNAL RELAY (NO / NC)
5.
MINIMUM TURN OFF TIME
6.
OPTIMISATION FEATURE
7.
COMFORT WARM FLOOR
8.
PIN CODE
DEVICE INFORMATION
9.
CONNECT WITH GATEWAY
FACTORY RESET
10.*
Short description of some selected functions
(all functions are described in the full version of the SQ610 manual):
1. DISPLAY TEMP RESOLUTION: This function determines the resolution of the displayed
temperature ( 0.5°C or 0.1°C ).
2. CONTROL ALGORITHM: This function denes how to control the room temperature. Available
options are: ITLC for Underoor Heating / Radiators / Electrical Heating (that’s advanced algorithm for
precise maintenance of room temperature), hysteresis +/-0.5°C or +/-0.25°C, THB Actuator (option
recommended for systems withTHB auto balancing actuators).
3. S1/S2 INPUT: A oor sensor, an external temperature sensor or an occupancy sensor can be
connected to the S1/S2 input of SQ610RF. Additionally, by connecting a NO type of ON/OFF voltage-
free contact, you can use this input as a OneTouch rules trigger (programmed in the Salus Smart Home
app) or as a Heat/Cool changeover.
4. VALVE PROTECTION: This function activates all actuators once a week for 5 minutes (in summer,
this function helps to prevent the actuators stuck).
6. MIN TURN OFF TIME: Minimum switch-o time (thermostat will not send the signal for
heating/cooling more often than specied in this parameter).
7. OPTIMISATION FEATURE: Optimum Start and Optimum Stop functions are energy saving feature
that makes thermostat most cost eective (in combination with ITLC control algorithm).
9. DEVICE INFORMATION: In this menu user can check: Software Version, RF range value, Paired
devices or also user can activate Identication mode.
*10. FACTORY RESET: Here you can RESET your device to factory settings. After successfull reset
device will be removed from ZigBee network and you will need to add / pair your device again.
8. COMFORT WARM FLOOR: This function helps to keep the oor warm, even if the room is warm
enough and there is no need to turn on the heating. User can select 3 levels of warm oor feature.
Please note it is not an economy feature, as your heating system may be ON even if there is no heating
demand from the room thermostat. It is COMFORT feature which keeps your oor warm all the time.
5. INTERNAL RELAY (COM/NO): Internal relay activation or deactivation with COM/NO outputs use. Default
is enable.
Français Deutsch
Nederlands English

58 59
QUANTUM SQ610
Power Supply AC 230 V
Temperature range 5-40°C
Display temperature accuracy 0.5°C or 0.1°C
Control algorithm ITLC
SPAN
(±0.25°C / ±0.5°C)
THB
S1-S2 Input
(multifunctional input)
Floor temperature
Air temperature
Occupancy sensor
One Touch
Changeover
(heating/cooling)
Output control COM – NO
(volt-free)
Max current 3 (1) A
Communication protocol ZigBee 2,4GHz
Mounting Flush mounting
Working temperature 0-45°C
IP protection class IP30
Dimensions
[Width x Height x Deep]
86 x 86 x 10 mm
Thickness after mounting in a
wall-box φ60
10 mm
English
