INSTRUCTION MANUAL FOR SAMSON 4-WAY VALVE DN125
4-WAY VALVE DN125
INSTRUCTION MANUAL
Accessories
• Technical data
• Functional description
• Installation
• Maintenance

2

CONTENTS
1 Introduction .............................................................................................................................. 4
1.1 Declaration of incorporation.................................................................................................... 4
1.2 Explanation of warning symbols.............................................................................................. 5
1.3 Field of application.................................................................................................................. 5
2 Technical data.......................................................................................................................... 6
2.1 Dimensions - With pneumatic actuator.................................................................................... 6
2.2 Dimensions - With handle bar ................................................................................................. 7
2.3 Specifications.......................................................................................................................... 8
2.4 Operating the 4-way valve ...................................................................................................... 8
2.5 Storage ................................................................................................................................... 8
2.6 Materials ................................................................................................................................ 9
2.6.1 Pneumatic actuator kit, DN125.............................................................................................. 10
2.6.2 4-way valve, DN125 .............................................................................................................. 11
3 Design........................................................................................................................................12
3.1 Position - With pneumatic actuator ....................................................................................... 12
3.2 Position - With handle bar..................................................................................................... 12
4 Installation and start-up...................................................................................................13
4.1 Securing the 4-way valve....................................................................................................... 13
4.2 Adjusting the 4-way valve ..................................................................................................... 13
5 Inspection intervals.............................................................................................................14
5.1 Inspecting for leakage........................................................................................................... 14
5.2 Inspection and cleaning ........................................................................................................ 14
5.3 Inspection and lubrication..................................................................................................... 14
4-way valve 3

E-Mail
[email protected] Samson Pumps A/S Petersmindevej 21
Web www.samson-pumps.com Phone | [phone] DK-8800 Viborg
DOC4036E
Declarationofincorporation
AnnexIIB
SamsonPumpsA/S
Petersmindevej21
DK-8800Viborg
Herebydeclaresthatthefollowingproduct:
4-wayvalveDN100withpneumaticactuator,itemNo.:1634740(ATEXapproved)
4-wayvalveDN100withpneumaticactuator,itemNo.:1634244(Standard)
4-wayvalveDN100withhandlebar,itemNo.:157.360(Standard)
4-wayvalveDN100withhandlebar,itemNo.:157.355(Standard)
4-wayvalveDN125withhandlebar,itemNo.:9255000053(Standard)
4-wayvalveDN125withpneumaticactuator,itemNo.:1634245(Standard)
Conformstothefollowingdirectives:
MachineryDirective2006/42/EC
ATEXDirective2014/34/EU(ATEXapprovedproductsonly)
Explosionprotectionasfollows:
II1GExhT95°CGaInternal
II2GExhT95°CGbExternal 
Iherebydeclare,thattheproductareinconformitywiththefollowingharmonizedstandards:
DS/ENISO12100:2011Safetyofmachinery-Generalprinciplesfordesign-Riskassessmentandrisk
reduction
DS/EN1127-1:2011Explosiveatmospheres-Explosionpreventionandprotection-part1:Basic
conceptsandmethodology
DS/ENISO80079-36:2016 Explosiveatmospheres-Part36:Non-electricalequipmentforexplosive
atmospheres-Basicmethodandrequirements
DS/ENISO80079-37:2016Explosiveatmospheres-Part37:Non-electricalequipmentforexplosive
atmospheres-Non-electricaltypeofprotectionconstructionalsafety"c",control
ofignitionsources"b",liquidimmersion"k"
Thestandardsaboveonlyappliestotheextentthatitisrelevantforthepurposeoftheproduct.
TheproductisonlydeclaredinaccordancewiththeATEXDirectiveinthecasewheretheitem,hasbeen
orderedforuseinexplosiveenvironment.StandardproductsarenotinaccordancewiththeATEXDirective.
Hand-operatedvalvesarenotinscopeoftheATEXDirective.
Theproductmustnotbeusedbeforethecompletesystem,whichitmustbeincorporatedin,hasbeen
conformityassessedandfoundtocomplywithallrelevanthealthandsafetyrequirementsof2006/42/ECand
otherrelevantdirectives.Theproductmustbeincludedintheoverallriskassessment.
Viborg,08.05.2019________________________________________
JanS.Christiansen–Manager,Technicaldept.
1 INTRODUCTION
1.1 Declaration of incorporation
DOC4036E
4

To be used with all safety instructions that must be followed. A failure to follow the
instructions may result in injury and/or incorrect machine operation.
1.2 Explanation of warning symbols
1.3 Field of application
The 4-way valve may only be used with media that are not aggressive to the valves materials. See section
2.6 for components and appertaining materials.
Inlet of foreign objects can damage the 4-way valve.
Important technical and safety instructions is showed by symbols. If instructions are not performed
correctly, it may lead to personnel injury or incorrect function of the 4-way valve.
4-way valve 5

2.1 Dimensions - With pneumatic actuator
2 TECHNICAL DATA
HA
F
A
H
D
C
E
HB
B
P
L
N
DOC1634613_3
Dimensions [mm]
A B C D E F H HA HB L N P Weight [Kg]
225 225 220 220 150 150 420 180 300 M12 1/8” Ø153 42
DOC1634613_3
6

2.2 Dimensions - With handle bar
DOC1627338_3
A
H
DAC AB
HB
F
HA
B
P
L
C
E
Dimensions [mm]
A AB AC B C D E F H HA HB L P Weight [Kg]
335 60 60 250 220 220 150 150 335 195 160 M12 Ø153 38
DOC1627338_3
4-way valve 7

2.3 Specifications
Description Minimum Maximum
Ambient temperature, operation -20°C 40°C
Ambient temperature, storage -20°C 60°C
Pressure 65 mbar abs. 3 bar(g)
Lubricating grease SKF LAGD 125/WA2
A failure to meet these specifications may result in damage to the 4-way valve.
2.4 Operating the 4-way valve
The 4-way valve must be inspected for damages upon delivery. If the 4-way valve is damaged, it must not
be used and the damage must be reported to the dealer.
The 4-way valve can be transported in the following ways:
DOC11093A
After operation, the 4-way valve can be stored for 30 days without further action.
If the 4-way valve is stored / not in use more than 30 days, it must be greased before use. See section 5.
The 4-way valve may not be used if it is damaged.
2.5 Storage
8

2.6 Materials
DOC1634613_6
3 2
1
Term Pos. Material Description
4-way valve 1 - -
Actuator set 2 - -
Handle bar 3 - -
The 4-way valve is composed by two main components:
• Pneumatic operated Pos.1 & Pos.2
• Manually operated Pos.1 & Pos.3
DOC1634613_6
4-way valve 9

2.6.1 Pneumatic actuator kit, DN125
DOC1634225_1
3
9
6
5
1
4
8
7
2
Term Pos. Material Description
Flange for 4-way valve DN125 1 Stainless steel AISI 316
Spacer 2 Stainless steel AISI 316
Pneumatic actuator AT251U D B 3 Aluminum Alodur hard anodization
Carrier for 4-way valve 4 Stainless steel AISI 316
M12 Washer Ø13/Ø24 x 2.5 5 Stainless steel DIN 125A A4
M12x80 Bolt 6 Stainless steel DIN 931 A4
M8 Washer Ø8,4/Ø17x1,6 7 Stainless steel DIN 125 A4
M8x20 Hex-Head Bolt 8 Stainless steel DIN 933 A4
Spring pin Ø8x50 9 Stainless steel DIN 1481 / ISO 8752 A2
DOC1634225_1
10

Term Pos. Material Description
Valve housing DN125 1 Cast iron -
Cover plate, machined 2 Cast iron -
Valve cone, machined 3 Cast iron -
Grease nipple 4 Steel -
Washer M12 5 Steel -
Hex-head bolt M12x35 6 Steel -
Handle 7 Steel -
Cutter pin 8 Steel -
6
5
2
4
3
1
8
7
DOC925500053_1
2.6.2 4-way valve, DN125
DOC925500053_1
4-way valve 11

By connecting compressed air to connection 4 on
the 4-way valve. See below.
3.1 Position - With pneumatic actuator
By connecting compressed air to connection 2
on the 4-way valve. See below.
3 DESIGN
A-A ( 1 : 2,5 )
AA
DOC1627337_1
4
A-A ( 1 : 2,5 )
AA
DOC1627337_2
2
A-A ( 1 : 2 )
A A
DOC1627338_1
A-A ( 1 : 2 )
A A
DOC1627338_2
DOC1627338_1 DOC1627338_2
Position A achieved by turning the handle
clockwise (CW). See below.
3.2 Position - With handle bar
Position B achieved by turning the handle
counter clockwise (CCW). See below.
DOC1627337_2DOC1627337_1
12

4 INSTALLATION AND START-UP
4.1 Securing the 4-way valve
The 4-way valve must be installed on a stable foundation, which must be level and stable, so that the
4-way valve is not twisted or exposed to a ±0.1 mm profile distortion.
Bolts must be tightened in accordance with supplier’s instructions.
Ensure that the flow direction is correct before assembly.
The 4-way valve’s end stop can only be used as a stop when operating with manual handle bar. When
activated with a cylinder, the cylinder’s own end stop is used.
4.2 Adjusting the 4-way valve
The cone in the 4-way valve can be adjusted by turning the set screw (Pos.2):
• Clockwise to lift the cone.
• Counter clockwise to lower the cone.
It is important to lock the screw after adjustment by tighten the nut (Pos.1) clockwise.
If the 4-way valve is blocked, it is possible to adjust the cone.
DOC1634740_7
1 2
DOC1634740_7
4-way valve 13

A failure to observe the inspection intervals described in table below, may result in
damage to the 4-way valve.
5 INSPECTION INTERVALS
Section Operation Interval Category 1 Category 2
5.1 Visually inspect for leakage Weekly X X
5.2 Inspection and cleaning (if necessary) Monthly X X
5.3 Inspection and lubrication 3 months X X
5.1 Inspecting for leakage
The 4-way valve and pipe system around must be inspected for leakage once a week. The inspection must
be performed when the 4-way valve is both operating and idle. Any leaks must be repaired before operation
may continue.
The pipe connections of 4-way valves must be inspected at least once a month, and any contaminants
must be removed.
The 4-way valve must always run easily and effortlessly, otherwise it must be cleaned.
5.2 Inspection and cleaning
Only qualified personnel may carry out repairs.
Repairs must be carried out according to manufacturer recommendations.
Use only original materials and components as described, during repair and maintenance.
During repair or disassembly, check that the flow direction remains unchanged.
For repair of the actuator, see accompanying supplier instructions.
Bolts must be re-tightened in accordance with supplier’s instructions.
Each grease nipple must be greased every 3 months, with 6-8 g of LGWA2 grease.
If 4-way valve not in use for 1 month or more, it must be greased before start.
5.3 Inspection and lubrication
14

Notes:
