Samson 3273 Service manual

Mounting and
Operating Instructions
EB 8312-2 EN
Translation of original instructions
Edition April 2017
Type3273 Side-mounted Handwheel
30mm rated travel

2 EB 8312-2 EN
Note on these mounting and operating instructions
These mounting and operating instructions assist you in mounting and operating the device
safely. The instructions are binding for handling SAMSON devices.
ÎFor the safe and proper use of these instructions, read them carefully and keep them for
later reference.
ÎIf you have any questions about these instructions, contact SAMSON‘s After-sales Service
Department (aftersalesser[email protected]).
The mounting and operating instructions for the devices are included in
the scope of delivery. The latest documentation is available on our website
(www.samson.de) > Product documentation. You can enter the document
number or type number in the [Find:] eld to look for a document.
Denition of signal words
Hazardous situations which, if not avoided,
will result in death or serious injury
Hazardous situations which, if not avoided,
could result in death or serious injury
Property damage message or malfunction
Additional information
Recommended action
DANGER
!
WARNING
!
NOTICE
!
Note
Tip

Contents
EB 8312-2 EN 3
1 Safety instructions and measures ...................................................................5
1.1 Notes on possible severe personal injury .........................................................7
1.2 Notes on possible personal injury ...................................................................8
1.3 Notes on possible property damage ................................................................8
2 Markings on the device .................................................................................8
2.1 Nameplate of the side-mounted handwheel .....................................................8
2.2 Valve nameplate ............................................................................................9
2.3 Actuator nameplate ........................................................................................9
3 Design and principle of operation ................................................................10
3.1 Versions ......................................................................................................11
3.2 Technical data .............................................................................................12
4 Measures for preparation............................................................................15
4.1 Unpacking ..................................................................................................15
4.2 Transporting and lifting ................................................................................15
4.2.1 Transporting ................................................................................................15
4.2.2 Lifting ..........................................................................................................16
4.3 Storage .......................................................................................................16
4.4 Preparation for installation ............................................................................17
5 Mounting and start-up.................................................................................18
5.1 Mounting the handwheel onto the valve .........................................................19
5.2 Mounting the actuator onto the handwheel.....................................................19
5.3 Quick check ................................................................................................21
6 Operation...................................................................................................22
6.1 Working in automatic operation ....................................................................22
6.2 Working in manual operation .......................................................................23
7 Servicing.....................................................................................................25
7.1 Preparation for return shipment .....................................................................25
7.2 Ordering spare parts and operating supplies .................................................25
8 Malfunctions ...............................................................................................26

4 EB 8312-2 EN
Contents
9 Decommissioning and disassembly ..............................................................27
9.1 Decommissioning .........................................................................................27
9.2 Removing the handwheel from the actuator and valve .....................................27
9.3 Final steps ...................................................................................................28
9.4 Disposal ......................................................................................................28
10 Annex.........................................................................................................29
10.1 After-sales service ........................................................................................29
10.2 Spare parts .................................................................................................29

EB 8312-2 EN 5
Safety instructions and measures
1 Safety instructions and measures
Intended use
The SAMSON Type3273 Hand-operated Actuator is mounted on a valve and is intended for
the following activities in combination with a pneumatic actuator, e.g. SAMSON Type3271
or Type3277 Actuator:
−To manually move the valve to the closed or open position for maintenance or repair
work, e.g. to exchange the actuator.
−To manually move the valve upon air supply failure
−To keep the fail-safe action of the pneumatic actuator also during maintenance and re-
pair work on the actuator
−Special version: to operate a mounted valve without pneumatic actuator
The side-mounted handwheel is not suitable to perform control tasks. The side-mounted
handwheel is designed to operate under exactly dened conditions (e.g. thrust, travel,
actuator area). Therefore, operators must ensure that the side-mounted handwheel is only
used in applications that meet the specications used for sizing at the ordering stage. In case
operators intend to use the handwheel in other applications or conditions than specied,
contact SAMSON.
SAMSON does not assume any liability for damage resulting from the failure to use the de-
vice for its intended purpose or for damage caused by external forces or any other external
factors.
ÎRefer to the technical data and nameplate for limits and elds of application as well as
possible uses.
Reasonably foreseeable misuse
The handwheel is not suitable for the following applications:
−To limit the valve travel
−To control the ow rate through the mounted valve (on/off only)
−Use outside the limits dened during sizing and in the technical data
Furthermore, the following activities do not comply with the intended use:
−Use of non-original spare parts
−Performing service and repair work not described in these instructions

6 EB 8312-2 EN
Safety instructions and measures
Qualications of operating personnel
The handwheel must be mounted, started up, serviced, and repaired by fully trained and
qualied personnel only; the accepted industry codes and practices are to be observed. Ac-
cording to these mounting and operating instructions, trained personnel refers to individuals
who are able to judge the work they are assigned to and recognize possible hazards due to
their specialized training, their knowledge and experience as well as their knowledge of the
applicable standards.
Personal protective equipment
We recommend wearing the following protective equipment:
−Safety gloves due to the moving parts (actuator stem, threaded rod, plug stem, hand-
wheel)
ÎCheck with the plant operator for details on further protective equipment.
Revisions and other modications
Revisions, conversions or other modications to the product are not authorized by SAMSON.
They are performed at the user's own risk and may lead to safety hazards, for example. Fur-
thermore, the product may no longer meet the requirements for its intended use.
Safety devices
The side-mounted handwheel is locked by a locking bolt, which locks the gear, to prevent ac-
cidental adjustment of the valve travel (see Fig.7 and section6.1).
Warning against residual hazards
To avoid personal injury or property damage, plant operators and operating personnel must
prevent hazards that could be caused in the handwheel by the signal pressure or moving
parts by taking appropriate precautions. They must observe all hazard statements, warning
and caution notes in these mounting and operating instructions, especially for installation,
start-up, and service work.
Responsibilities of the operator
The operator is responsible for proper operation and compliance with the safety regulations.
Operators are obliged to provide these mounting and operating instructions as well as the
referenced documents to the operating personnel and to instruct them in proper operation.
Furthermore, the operator must ensure that operating personnel or third persons are not ex-
posed to any danger.

EB 8312-2 EN 7
Safety instructions and measures
Responsibilities of operating personnel
Operating personnel must read and understand these mounting and operating instructions as
well as the referenced documents and observe the hazard statements, warning and caution
notes specied in them. Furthermore, the operating personnel must be familiar with the ap-
plicable health, safety and accident prevention regulations and comply with them.
Referenced documentation
The following documents apply in addition to these mounting and operating instructions:
−Mounting and operating instructions for mounted actuator, e.g. for SAMSON Type3271
and Type3277 Actuators:
uEB8310-2 (1000cm²) (Type3271 only)
uEB8310-3 (1400-60cm²) (Type3271 only)
uEB8310-4 (355cm²)
uEB8310-5 (175 and 750cm²)
uEB8310-6 (240, 350, and 700cm²)
−Mounting and operating instructions for the mounted valve
−uAB0100 for tools, lubricant, and tightening torques
1.1 Notes on possible severe personal injury
DANGER
!
The handwheel poses no hazard with possible severe personal injury.
ÎObserve hazard statements in the associated valve and actuator documentation.

8 EB 8312-2 EN
Safety instructions and measures
1.2 Notes on possible personal injury
WARNING
!
Crush hazard arising from moving parts.
The handwheel contains moving parts (actuator stem, threaded rod, plug stem, hand-
wheel), which can injure hands or ngers if inserted into it.
ÎDo not insert hands or ngers into the yoke while the valve is in operation.
ÎWhile working on the handwheel, disconnect and lock the pneumatic air supply as
well as the control signal.
ÎUse the locking bolt to lock the handwheel.
1.3 Notes on possible property damage
NOTICE
!
Risk of handwheel damage due to the use of unsuitable tools.
ÎTo turn the handwheel, do not use any additional tools, such as a lever or wrench.
Risk of handwheel damage due to the use of excessive force.
ÎDo not turn the handwheel in the end position any further by exerting force.
Risk of damage to control valve components due to excessively high or low tighten-
ing torques.
Observe the specied torques on tightening control valve components. Excessively
tightened torques lead to parts wearing out quicker. Parts that are not tightened far
enough may loosen.
ÎObserve the specied tightening torques (uAB0100).

EB 8312-2 EN 9
Markings on the device
2 Markings on the device
2.1 Nameplate of the side-
mounted handwheel
It includes all details required to identify the
handwheel:
5
4
6
SAMSON 3273
2
1
3
Made in Germany
Var-ID
Serial no.
1Conguration ID
2 Serial number
3Year of manufacture
4Operating travel (mm)
5Operating travel (inch)
6Maximum thrust (kN)
Fig.1: Nameplate
The nameplate is located on the top bonnet
(see Fig.2).
2.2 Valve nameplate
See associated valve documentation.
2.3 Actuator nameplate
See associated actuator documentation.
Nameplate
Fig.2: Nameplate position

10 EB 8312-2 EN
Design and principle of operation
3 Design and principle of oper-
ation
The Type3273 Side-mounted Handwheel
with 30mm travel is suitable for mounting
on Series240, 250, 280, and 290 Valves or
on suitable interfaces together with the
Type3271 or Type3277 Pneumatic Actua-
tors with areas of 175 to 1400-60cm². A
special version of the side-mounted hand-
wheel can also be used to move the valve on
which a pneumatic actuator is not mounted.
The side-mounted handwheel is mounted be-
tween the valve and actuator. The handwheel
can remain mounted on the valve during
maintenance and repair work or while ex-
changing the pneumatic actuator. The hand-
wheel can be used in this case to move the
valve manually to its closed or open position.
The handwheel can be used to move the
valve manually opposing the spring force of
the pneumatic actuator upon air supply fail-
ure.
The worm shaft unit, consisting of the worm
shaft and worm-geared wheel, is driven over
the handwheel. The spindle nut transfers the
rotary motion to the threaded rod, which
moves the valve. Depending on the direction
of rotation and mounted valve, the threaded
rod extends or retracts.
G6 Handwheel
G7 Handle
G11 Locking bolt
G16 Threaded rod
G63 Spindle nut
G64 Worm shaft
G65 Worm-geared wheel
G11
G16
G6
G63
G64
G65
G7
Fig.3: Sectional drawing of Type3273 Side-mounted Handwheel

EB 8312-2 EN 11
Design and principle of operation
For mounted SAMSON globe valves
The handwheel is marked 'Open/Close' and
has directional arrows.
−Turn the handwheel clockwise: the globe
valve closes.
−Turn the handwheel counterclockwise: the
globe valve opens.
For mounted SAMSON three-way valves
A label is afxed to the handwheel, which
indicates in which direction the threaded rod
is moved by turning the handwheel (see
Fig.4).
The gear is locked by the locking bolt to pre-
vent accidental adjustment.
3.1 Versions
−Version with 30mm Ø connection for
Type3271 and Type3277 Actuators
with 175 to 750cm² actuator areas (see
Table1)
−Version with 60mm Ø connection for
Type3271 Actuators with 1000 or
1400-60cm² actuator area (see Table1)
−Special version without pneumatic actu-
ator · On request
Verteilventil
close A
open B
Diverting valve
AB
A
B
Vanne de distribution
Mischventil
close B
open A
Mixing valve
AB
A
B
Vanne mélangeuse
Fig.4: Label on handwheel for mounted SAMSON three-way valves

12 EB 8312-2 EN
Design and principle of operation
3.2 Technical data
Table1: Technical data for Type3273 up to 30mm rated travel
Type3273
Version with connection
Ø30mm
(see dimensional drawing
on p.13)
Ø60mm
(see dimensional drawing
on p.14)
Rated travel 30mm1) 30mm1)
Max. travel range 38mm 38mm
Max. thrust 35kN 50kN
Operating forces According to DINEN12570
Max. number of turns With 30mm travel: 147
With 15mm travel: 73.5
Max. handwheel diameter 180mm 250mm
Mounting to actuators with
actuator areas
175, 240, 350, 355,
700, 750cm² 1000, 1400-60cm²
Compliance etc.
Materials
Body material and permissible
ambient temperature
1.0619/A216 WCC: –29 to +120°C
1.5638/A352 LC3: –60 to +90°C
Spindle 1.4404/A479 316L
Threaded nut 1.4104/A582 430F
Handwheel Cast iron or aluminum
Weight (gear only) 26kg 37kg
1) Also for pneumatic actuators with 30mm rated travel and up to 25% (7.5mm) spring compression

EB 8312-2 EN 13
Design and principle of operation
Dimensional drawings · Version with Ø30mm connection
90…52
Ø30
Ø180
Ø16
425
M30 x 1.5
~292
~133 85
90…52

14 EB 8312-2 EN
Design and principle of operation
Dimensional drawings · Version with Ø60mm connection
Ø60
120…82*
(135…97)*
Ø250
Ø22
543
M60 x 1.5
~298
85 ~140
(135…97)*
120…82*
* For "Actuator stem retracts" direction of action: swap top and bottom stem connector nuts

EB 8312-2 EN 15
Measures for preparation
4 Measures for preparation
After receiving the shipment, proceed as fol-
lows:
1. Check the scope of delivery. Compare
the shipment received against the
delivery note.
2. Check the shipment for transportation
damage. Report any damage to
SAMSON and the forwarding agent
(refer to delivery note).
4.1 Unpacking
Proceed as follows to lift and install the
handwheel:
1. Remove the packaging from the hand-
wheel.
2. Dispose of the packaging in accordance
with the valid regulations.
4.2 Transporting and lifting
Hazard due to suspended loads falling.
Stay clear of suspended or moving loads.
Risk of lifting equipment tipping and risk of
damage to lifting accessories due to exceed-
ing the rated lifting capacity.
−Only use approved lifting equipment and
accessories whose minimum lifting
capacity is higher than the weight of the
valve (including actuator, if applicable).
−Refer to section3.2 or Data Sheet
uT8312 for weights.
Risk of handwheel damage due to incorrectly
attached slings.
The handwheel is not designed to lift the en-
tire handwheel unit.
−When lifting the handwheel unit, make
sure that the slings attached to the yoke
bear the entire load.
−Do not attach load-bearing slings to the
handwheel.
−Observe lifting instructions (see sec-
tion4.2.2).
SAMSON's After-sales Service department
can provide more detailed transport and lift-
ing instructions on request.
4.2.1 Transporting
The handwheel can be transported using lift-
ing equipment (e.g. crane or forklift).
ÎLeave the handwheel in its transport
container or on the pallet to transport it.
ÎObserve the transport instructions.
Transport instructions
−Protect the handwheel against external
inuences (e.g. impact).
−Do not damage the corrosion protection
(paint, surface coatings). Repair any
damage immediately.
DANGER
!
WARNING
!
NOTICE
!
Tip

16 EB 8312-2 EN
Measures for preparation
−Protect the handwheel against moisture
and dirt.
−Observe the permissible ambient tem-
peratures (see sectionTable1).
4.2.2 Lifting
To mount the handwheel, use lifting equip-
ment (e.g. crane or forklift) to lift it.
Lifting instructions
−Secure slings against slipping.
−Make sure the slings can be removed af-
ter mounting the handwheel.
−Prevent the handwheel from tilting or tip-
ping.
−Do not leave loads suspended when in-
terrupting work for longer periods of
time.
Lifting the handwheel
1. Attach the lifting tackle to the yoke.
2. Carefully lift the handwheel. Check
whether the lifting equipment and
accessories can bear the weight.
3. Move the handwheel at an even pace to
the site of installation.
4. Mount the handwheel. See section5.
5. Remove the lifting tackle.
We recommend using a hook with safety
latch. The safety latch prevents the slings
from slipping during lifting and transporting.
4.3 Storage
Risk of handwheel damage due to improper
storage.
−Observe storage instructions.
−Avoid long storage times.
−Contact SAMSON in case of different stor-
age conditions or long storage periods.
Storage instructions
−Protect the handwheel against external
inuences (e.g. impact).
−Do not damage the corrosion protection
(paint, surface coatings). Repair any
damage immediately.
−Protect the handwheel against moisture
and dirt. Store it at a relative humidity of
less than 75%. In damp spaces, prevent
condensation. If necessary, use a drying
agent or heating.
−Make sure that the ambient air is free of
acids or other corrosive media.
−Observe the permissible ambient tem-
peratures (see Table1).
−Do not place any objects on the hand-
wheel.
−Pack the handwheel in airtight packag-
ing.
SAMSON's After-sales Service department
can provide more detailed storage instruc-
tions on request.
Tip
NOTICE
!
Tip

EB 8312-2 EN 17
Measures for preparation
4.4 Preparation for installation
Proceed as follows:
ÎRemove the actuator rst if the valve and
actuator have already been assembled
without handwheel. See associated actu-
ator documentation.
ÎCheck the handwheel for damage.
ÎCheck whether the handwheel (model,
travel, thrust, and handwheel diameter)
ts the actuator and valve.

18 EB 8312-2 EN
Mounting and start-up
5 Mounting and start-up
−The actuator must be removed rst before
mounting the handwheel if the valve and
actuator have already been assembled.
See instructions on how to remove the
actuator in the associated actuator
documentation.
−In case, the valve, actuator, and hand-
wheel are delivered separately, assemble
components as described in following.
−See associated valve and actuator
documentation for additional mounting
instructions.
Risk of damage to control valve components
due to excessively high or low tightening
torques.
Observe the specied torques on tightening
control valve components. Excessively tight-
ened torques lead to parts wearing out
quicker. Parts that are not tightened far
enough may loosen.
Observe the specied tightening torques
(uAB0100).
Risk of damage to control valve components
due to the use of unsuitable tools.
Certain tools are required to work on the
control valve.
Only use tools approved by SAMSON
(uAB0100).
Risk of damage to control valve components
due to the use of unsuitable lubricants.
The lubricants to be used depend on the ma-
terial of the control valve. Unsuitable lubri-
cants may corrode and damage the valve
surface.
Only use lubricants approved by SAMSON
(uAB0100).
Risk of malfunction due to different travels.
Make sure that the travels of the actuator,
handwheel, and valve match. If necessary,
contact SAMSON's After-sales Service de-
partment.
Risk of control valve damage due to the in-
correct mounting.
Versions with anti-rotation xture at the plug
stem must only be mounted by SAMSON's
After-sales Service department or after they
have given their consent.
Risk of malfunction due to incorrect mounting
of the stem connector nut.
Two different stem connector nuts with vary-
ing lengths exist for mounting the handwheel
on Type3271 Actuators with 1000 or 1400-
60cm² actuator area.
−For "stem extends" direction of action,
screw the long stem connector nut (G70)
Note
NOTICE
!
NOTICE
!
NOTICE
!
NOTICE
!
NOTICE
!
NOTICE
!

EB 8312-2 EN 19
Mounting and start-up
from above and the short stem connector
nut (G71) from below onto the threaded
rod.
−For "stem retracts" direction of action,
screw the short stem connector nut (G71)
from above and the long stem connector
nut (G70) from below onto the threaded
rod.
5.1 Mounting the handwheel
onto the valve
1. Place the handwheel on the yoke (G4) so
that it faces the operating side. The in-
scription on the valve body (1) serves as
a guide (as it also faces the operating
side).
2. Apply a suitable lubricant to the thread
of the fastening nut (G9).
3. Slide the fastening nut (G9) over the stem
connector nut (G71) and screw it tight at
the yoke (G4). Observe tightening
torques.
4. Move the handwheel to the neutral posi-
tion (see section6.1).
5. Place the stem connector nut (G5) on the
plug stem, screw it tight and use a suit-
able tool to lock it at the lock nut. Ob-
serve tightening torques.
6. Turn the handwheel to slowly extend the
threaded rod downward until the
ready-mounted stem connector nut (G71)
on the threaded rod touches the stem
connector nut (G5) on the valve.
7. Connect the threaded rod and plug stem
using the stem connector clamps
(G26/27). Tighten the hex screws (G29).
Observe tightening torques.
8. Optionally, a protective bellows (G69)
can be mounted around the plug stem on
the valve side.
5.2 Mounting the actuator onto
the handwheel
The handwheel and actuator are assembled
with special attention paid to the actuator's
bench range and direction of action. These
details are specied on the actuator name-
plate (see the associated actuator documen-
tation).
1. Move the handwheel to the neutral posi-
tion (see section6.1).
2. Remove the clamps of the stem connector
(A26/27) and the ring nut (A8) from the
actuator.
3. Apply a suitable lubricant to the thread-
ed nipple on the top bonnet (G60).
4. In the "actuator stem extends" version:
apply a signal pressure to the connection
on the bottom diaphragm chamber to
completely retract the actuator stem (A7).
In the "actuator stem retracts" version:
vent the actuator to retract the actuator
stem (A7) completely.
5. Place the actuator on the top bonnet
(G60) of the handwheel.
6. Apply a suitable lubricant to the ring nut
(A8).
Tip

20 EB 8312-2 EN
Mounting and start-up
1Valve body
G4 Yoke1)
A7 Actuator stem
A8 Ring nut
A26/27 Stem connector clamp
A29 Hex screw
G5 Stem connector nut2)
G6 Handwheel
G9 Fastening nut
G 26/27 Stem connector clamp
G29 Hex screw
G42 Lock nut
G60 Top bonnet (with yoke)
G69 Protective bellows
G70 Stem connector nut
G71 Stem connector nut
1) Replaces the ange of the valve (2)
2) Replaces the stem connector nut of the
valve (9)
A8
A26/27
G5
1G9
G6
A29
A7
G60
G70
G71
G42
G42
G69
G4
G26/2
7
G29
Fig.5: Type3273 Side-mounted Handwheel between valve and actuator ("stem extends" direction
of action)
