Samsung AR Series User manual

Air conditioner
User manual
AR**BY*Y**** / AR**BY*Z****
• Thank you for purchasing this Samsung air conditioner.
• Before operating this unit, please read this manual carefully and retain it for future reference.
RAC084-00_IB_22Y AR9500T SIEL GEO Wind 2way_TL_EN_.indd 1RAC084-00_IB_22Y AR9500T SIEL GEO Wind 2way_TL_EN_.indd 1 2021-11-02 오후 4:13:012021-11-02 오후 4:13:01

2
English
Contents
Safety Information 4
Safety Information 4
At a Glance 11
Indoor Unit Overview 11
Display 12
Remote Control Overview 13
Replacing the remote control batteries 13
Remote Control Operation 14
Selecting an operation mode 14
To set the temperature • To adjust the fan speed • To adjust the airflow direction 15
Smart Features 16
Power Smart Features 16
Auto mode • Cool mode 16
Dry mode • Fan mode 17
Variety Smart Features 18
Fast function 18
5 Step Cooling function 19
Quiet function 20
Electricity consumption check • Beep function 21
Auto clean function 22
Display lighting function 23
Time Scheduling 24
Timed on/ Timed off function 24
good'sleep function 25
RAC084-00_IB_22Y AR9500T SIEL GEO Wind 2way_TL_EN_.indd 2RAC084-00_IB_22Y AR9500T SIEL GEO Wind 2way_TL_EN_.indd 2 2021-11-02 오후 4:13:012021-11-02 오후 4:13:01

3
English
Cleaning and Maintenance 26
Schedule 26
Cleaning 27
Appendix 29
Troubleshooting 29
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic
accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste
at the end of their working life. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, please separate these items from other types of waste and recycle them
responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local
government office, for details of where and how they can take these items for environmentally safe
recycling.
Business users should contact their supplier and check the terms and conditions of the purchase
contract. This product and its electronic accessories should not be mixed with other commercial wastes
for disposal.
For more information on safe disposal and recycling, visit our website www.samsung.com/in/support or
contact our Helpline numbers - 1800 40 SAMSUNG (1800 40 7267864)
1800 5 SAMSUNG (1800 5 7267864).
Correct disposal of batteries in this product
This marking on the battery, manual or packaging indicates that the batteries in this product should not
be disposed of with other household waste at the end of their working life. Where marked, the chemical
symbols Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference
levels in EC Directive 2006/66.
RAC084-00_IB_22Y AR9500T SIEL GEO Wind 2way_TL_EN_.indd 3RAC084-00_IB_22Y AR9500T SIEL GEO Wind 2way_TL_EN_.indd 3 2021-11-02 오후 4:13:012021-11-02 오후 4:13:01

4
Safety Information
English
Safety InformationSafety Information
Safety Information
WARNING: Read This Manual
Read and follow all safety information and instructions before installation, use, or maintenance of this
appliance. Incorrect installation, use, or maintenance of this appliance can result in death, serious injury, or
property damage. Keep these instructions with this appliance. This manual is subject to change. For the latest
version, visit www.samsung.com.
Because the instructions in this manual covervarious models, the characteristics of your air conditioner may
differ slightly from those described. If you have any questions, please contact your service provider orvisit
www.samsung.com.
Notices and notes
To make you aware of safety messages and highlighted information, we use the following notices and notes
throughout this manual:
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or property damage.
IMPORTANT
Information of special interest
NOTE
Supplementary information that may be useful
Safety Information
RAC084-00_IB_22Y AR9500T SIEL GEO Wind 2way_TL_EN_.indd 4RAC084-00_IB_22Y AR9500T SIEL GEO Wind 2way_TL_EN_.indd 4 2021-11-02 오후 4:13:012021-11-02 오후 4:13:01

5
English
Safety InformationSafety Information
WARNING: Low burning velocity material
(This appliance is filled with R-32.)
The user and installer guides should be read carefully.
The user and installer guides should be read carefully.
The service guide should be read carefully.
FOR GENERAL
This appliance is not intended foruse by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible fortheir safety. Children
should be supervised to ensure that they do not playwith the appliance.
FOR INSTALLATION
WARNING
Use a power cord with this product's power specifications or higher and use the power cord for this
appliance only. In addition, do not use an extension cord.
• Extending the power cord may result in electric shock or fire.
• Do not use an electric transformer. This may result in electric shock or fire.
• If the voltage/frequency/rated current condition is different, it may cause fire.
The installation of this appliance must be performed by a qualified technician or service company.
Do not attempt to install the air conditioneryourself.
• Failing to do so may result in electric shock, fire, explosion, problems with the product, or injury
and may also void warranty on the installed product.
Install an Isolation Switch next to the AirConditioner (but not on the panels of the Air Conditioner)
and circuit breaker dedicated to the air conditioner.
• Failing to do so may result in electric shock or fire.
Safety Information
RAC084-00_IB_22Y AR9500T SIEL GEO Wind 2way_TL_EN_.indd 5RAC084-00_IB_22Y AR9500T SIEL GEO Wind 2way_TL_EN_.indd 5 2021-11-02 오후 4:13:012021-11-02 오후 4:13:01

6
Safety Information
English
Safety InformationSafety Information
Fix the outdoor unit firmly so that the electric part of the outdoor unit is not exposed.
• Failing to do so may result in electric shock, fire, explosion, or problems with the product.
Do not install this appliance near a heater, or inflammable material. Do not install this appliance in a
humid, oily ordusty location, in a location exposed to direct sunlight and water(orrain). Do not install
this appliance in a location where gas may leak.
• This may result in electric shock or fire.
Never install the outdoor unit in a location such as on a high external wall where it could fall.
• If the outdoor unit falls, it may result in injury, death or property damage.
This appliance must be properly grounded. Do not ground the appliance to a gas pipe, plastic, water
pipe, or telephone line.
• Failing to do so may result in electric shock, fire, and explosion.
• Make sure to use a socket-outlet with ground.
The product shall be stored in a room with no ignition sources (e.g. open flames, gas appliance,
electric heater, etc.).
• Note that the refrigerant has no odour.
CAUTION
Install your appliance on a level and hard floorthat can support its weight.
• Failing to do so may result in abnormal vibrations, noise, or problems with the product.
Install the drain hose properly so that water drains correctly.
• Failing to do so may result in water overflowing and property damage. Avoid adding drain to
waste pipes as odours may arise in the future.
When installing the outdoor unit, make sure to connect the drain hose so that draining is performed
correctly.
• The water generated during heating by the outdoor unit may overflow and result in property
damage.
In particular, in winter, if a block of ice falls, it may result in injury, death or property damage.
Do not install the product in a place where thermo-hygrostat is needed (such as serverroom,
machinery room, computer room, etc.)
• Those places do not provide guaranteed operation condition of the product therefore
performance can be poor in these places.
RAC084-00_IB_22Y AR9500T SIEL GEO Wind 2way_TL_EN_.indd 6RAC084-00_IB_22Y AR9500T SIEL GEO Wind 2way_TL_EN_.indd 6 2021-11-02 오후 4:13:012021-11-02 오후 4:13:01

7
English
Safety InformationSafety Information
FOR POWER SUPPLY
WARNING
When the circuit breaker is damaged, contact your nearest service centre.
Do not pull or excessively bend the power line. Do not twist ortie the powerline. Do not hook the
power line over a metal object, place a heavy object on the power line, insert the powerline between
objects, or push the power line into the space behind the appliance.
• This may result in electric shock or fire.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
CAUTION
When not using the air conditioner for a long period of time or during a thunder/lightning storm, cut
the power at the circuit breaker.
• Failing to do so may result in electric shock or fire.
FOR USING
WARNING
If the appliance is flooded, please contact your nearest service centre.
• Failing to do so may result in electric shock or fire.
If the appliance generates a strange noise, a burning smell or smoke, cut off the power supply
immediately and contact the nearest service centre.
• Failing to do so may result in electric shock or fire.
If the air conditioner malfunctions orrequires repair, immediately stop its operation and disconnect
the entire power system. Then consult the authorized service personnel.
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate immediatelywithout touching
the power line. Do not touch the appliance or power line.
• Do not use a ventilating fan.
• A spark may result in an explosion or fire.
RAC084-00_IB_22Y AR9500T SIEL GEO Wind 2way_TL_EN_.indd 7RAC084-00_IB_22Y AR9500T SIEL GEO Wind 2way_TL_EN_.indd 7 2021-11-02 오후 4:13:012021-11-02 오후 4:13:01

8
Safety Information
English
Safety InformationSafety Information
To reinstall the airconditioner, please contact your nearest service centre.
• Failing to do so may result in problems with the product, water leakage, electric shock, or fire.
• Delivery service for the product is not provided. If you reinstall the product in another location,
additional construction expenses and an installation fee will be charged.
• Especially, when you wish to install the product in an unusual location such as in an industrial
area or near the seaside where it is exposed to salt in the air, please contact your nearest service
centre.
Do not touch the circuit breakerwith wet hands.
• This may result in electric shock.
Do not turn the airconditioner off with the circuit breakerwhile it is operating.
• Turning the air conditioner off and then on again with the circuit breaker may cause a spark and
result in electric shock or fire.
After unpacking the air conditioner, keep all packaging materials well out of the reach of children, as
packaging materials can be dangerous to children.
• If a child places a bag over its head, it may result in suffocation.
Do not touch the airflow blade with yourhands or fingers during heating.
• This may result in electric shock or burns.
Do not insert yourfingers or foreign substances into the air inlet/outlet of the air conditioner.
• Take special care that children do not injure themselves by inserting their fingers into the
product.
Do not strike orpull the air conditionerwith excessive force.
• This may result in fire, injury, or problems with the product.
Do not place an object nearthe outdoor unit that allows children to climb onto the machine.
• This may result in children seriously injuring themselves.
Do not use this air conditioner for long periods of time in badlyventilated locations or near infirm
people.
• Since this may be dangerous due to a lack of oxygen, open a window at least once an hour.
Do not use means to accelerate the defrost operation or to clean, other than those recommended by
Samsung.
Do not pierce or burn.
Be aware that refrigerants may not contain an odour.
If any foreign substance such as waterhas entered the appliance, cut off the power supply and
contact the nearest service centre.
• Failing to do so may result in electric shock or fire.
Do not attempt to repair, disassemble, or modify the appliance yourself.
• Do not use any fuse (such as copper, steel wire, etc.) other than the standard fuse.
• Failing to do so may result in electric shock, fire, problems with the product, or injury.
RAC084-00_IB_22Y AR9500T SIEL GEO Wind 2way_TL_EN_.indd 8RAC084-00_IB_22Y AR9500T SIEL GEO Wind 2way_TL_EN_.indd 8 2021-11-02 오후 4:13:012021-11-02 오후 4:13:01

9
English
Safety InformationSafety Information
CAUTION
Do not place objects or devices under the indoor unit.
• Water dripping from the indoor unit may result in fire or property damage.
Check that the installation frame of the outdoor unit is not broken at least once a year.
• Failing to do so may result in injury, death or property damage.
To prevent personal injury, make sure that you change the directions of the horizontal airflowblades after
stopping the movements of the vertical airflowblade. (In case of adjusting the horizontal airflow manually)
When the air conditioner does not operate properly for cooling or heating, there is a possibility of
refrigerant leakage. If any leakage, stop operation, ventilate the room, and consult your dealer
immediately for recharging refrigerant.
The refrigerant is not harmful. However, if it comes in contact with fire, it may generate harmful
gases and there is risk of fire.
During transportation of the indoor unit, the pipe lines shall be covered with brackets for protection.
Do not move the product with holding the pipe lines.
• It may cause gas leakage.
Do not install the product in a ship or a vehicle (such as a campervan).
• Salt, vibration or other environmental factor may cause the product malfunction, electric shock or fire.
Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted
cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.
• This may result in electric shock, fire, problems with the product, or injury.
Do not operate the appliance with wet hands.
• This may result in electric shock.
Do not spray volatile material such as insecticide onto the surface of the appliance.
• As well as being harmful to humans, it may also result in electric shock, fire or problems with the
product.
Do not drink the water from the airconditioner.
• The water may be harmful to humans.
Do not hit, shake, drop, orattempt to disassemble the remote control.
When replacing the remote control batteries, keep them out of the reach of infants.
• If an infant eats batteries, contact a doctor immediately.
When replacing the remote control batteries, be careful not to get the battery fluid on your skin.
• Battery fluid is harmful to humans.
RAC084-00_IB_22Y AR9500T SIEL GEO Wind 2way_TL_EN_.indd 9RAC084-00_IB_22Y AR9500T SIEL GEO Wind 2way_TL_EN_.indd 9 2021-11-02 오후 4:13:012021-11-02 오후 4:13:01

10
Safety Information
English
Safety InformationSafety Information
Do not touch the pipes connected with the product.
• This may result in burns or injury.
Do not cut or burn the refrigerant container or pipings.
Do not point the air direction to the fireplace or heater.
Do not use this air conditioner to preserve precision equipment, food, animals, plants or cosmetics, or
for any other unusual purposes.
• This may result in property damage.
Avoid directly exposing humans, animals or plants to the airflowfrom the air conditionerfor long
periods of time.
• This may result in harm to humans, animals or plants.
FOR CLEANING
WARNING
Do not clean the appliance by spraying waterdirectly onto it. Do not use benzene, thinner or alcohol
to clean the appliance.
• This may result in discolouration, deformation, damage, electric shock or fire.
Before cleaning, servicing, or performing maintenance, make sure to disconnect the product from its
power source and wait until the fan stops.
• Failing to do so may result in electric shock or fire.
CAUTION
Take care when cleaning the surface of the heat exchanger of the outdoor unit since it has sharp
edges.
• This should be done by a qualified technician. Please contact your installer or service centre.
Do not clean the inside of the air conditioner byyourself.
• For cleaning inside the appliance, contact your nearest service centre.
• When cleaning the filter, refer to the descriptions in the 'Cleaning' section.
• Failing to do so may result in damage, electric shock or fire.
• Make sure to prevent any injury from sharp edges of the surface when handling the heat
exchanger.
RAC084-00_IB_22Y AR9500T SIEL GEO Wind 2way_TL_EN_.indd 10RAC084-00_IB_22Y AR9500T SIEL GEO Wind 2way_TL_EN_.indd 10 2021-11-02 오후 4:13:022021-11-02 오후 4:13:02
