Samsung SGH-E780 User manual

World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.: GH68-XXXXXA
English. 01/2006. Rev. 1.0
* Depending on the software installed or your service provider or country,
some of the descriptions in this guide may not match your phone exactly.
* Depending on your country, your phone and accessories may appear
different from the illustrations in this guide.

World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.: GH68-XXXXXA
English. 01/2006. Rev. 1.0
* Depending on the software installed or your service provider or country,
some of the descriptions in this guide may not match your phone exactly.
* Depending on your country, your phone and accessories may appear
different from the illustrations in this guide.

Draft
2006.01.20
(Version:E780XAFA1)
SGH-E780
User’s Guide

Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
Drive safely at all times
Do not use a hand-held phone while driving. Park
the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them
in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.

Important safety precautions
1
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency call
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorised accessories could
damage your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 92.
• The phone could explode if the battery is
replaced with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.

2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to “Get
started” and “Step outside the phone.”
In this guide, the following instruction icons appear:
Indicates that you need to pay careful attention
to the subsequent information regarding safety or
phone features.

Indicates that you can get more information on
the referenced page.
→
Indicates that you need to press the Navigation
keys to scroll to the specified option and then
select it.
[ ]
Indicates a key on the phone. For example, [ OK ]
< >
Indicates a soft key, whose function is displayed
on the phone screen. For example, <
Menu >
• Camera and camcorder
Use the camera module on your
phone to take a photo or record a
video.
Special features of your phone
•Musicplayer
Play MP3 music files using your
phone as a music player.
• Image editor
Crop, resize, rotate, and decorate
your photos.
• Voice recognition
Just say a command to dial a
phone number or access a menu
function.

3
Special features of your phone
•Bluetooth
Transfer media files and personal
data and connect to other devices
using free, wireless Bluetooth
technology. You can also use a
Bluetooth stereo headset to let you
enjoy music with high quality
stereo sound.
• Get personal with photo caller
ID
See who’s calling you when their
very own photo displays.
• Name card
Create name cards with your
number and profile. Whenever
introducing yourself to others, use
this convenient electronic name
card.
•Java
Enjoy Java ™ -based embedded
games and download new games.
• Voice clarity
Use the voice clarity feature to increase the
volume and clarity of an incoming call, even in the
midst of a crowd.
• Multimedia Message Service (MMS)
Send and receive MMS messages with a
combination of text, images, video, and audio.
•E-mail
Send and receive e-mails with images, video, and
audio attachments.
•Printingdata
Print images, messages, and other
personal data directly from your
phone.

4
Contents
Unpack 6
Make sure you have each item
Your phone 6
Buttons, features, and locations
Get started 7
First steps to operating your phone
Install and charge the phone ..................................... 7
Power on or off........................................................ 8
Keys and display ..................................................... 9
Access menu functions ............................................ 11
Customise your phone............................................. 12
Make/Answer calls .................................................. 14
Step outside the phone 15
Begin with your camera, the music player, and other special
features
Use the camera ...................................................... 15
Play music files....................................................... 16
Browse the web...................................................... 17
Use Phonebook ...................................................... 17
Send messages ...................................................... 18
View messages....................................................... 20
Use Bluetooth ........................................................ 21
Use voice recognition .............................................. 22
Enter text 23
ABC, T9, Number, and Symbol modes
Call functions 25
Advanced calling features
Menu functions 29
All menu options listed
Solve problems 90
Help and personal needs
Health and safety information 92
Index 97

5
1 Call log  p.29
1 Recent contacts
2 Missed calls
3 Dialled calls
4 Received calls
5 Delete all
6 Call time
7 Call costs
*
 p.29
 p.30
 p.30
 p.30
 p.30
 p.31
 p.31
2 Phonebook  p.31
1 Contact list
2 FDN list
3 Add new contact
4 Group
5 Speed dial
6 My name card
7 Own number
8 Management
9 Service number *
 p.32
 p.32
 p.33
 p.34
 p.34
 p.35
 p.35
 p.35
 p.36
3 Applications  p.36
1 Music player
2 Voice recorder
3 Image editor
4 Decision maker
5 Bluetooth
6 Java world
7 Voice commands
8 SIM-AT *
 p.36
 p.38
 p.39
 p.40
 p.41
 p.43
 p.44
 p.46
4 Browser  p.46
1 Home
2 Bookmarks
3 Enter URL
4 Clear cache
5 Profile settings
6 Current profile
 p.46
 p.47
 p.48
 p.48
 p.48
 p.49
5 Messages  p.49
1 Create new message
2 My messages
3 Templates
 p.49
 p.53
 p.57
5 Messages (continued)  p.49
4 Delete all
5 Settings
6 Broadcast messages
7 Memory status
 p.58
 p.58
 p.64
 p.65
6 My files  p.65
1 Images
2 Videos
3 Music
4 Sounds
5 Other files
6 Memory status
 p.65
 p.66
 p.67
 p.67
 p.68
 p.68
7 Planner  p.68
1 Alarm
2 Calendar
3 Memo
4 World time
5 Calculator
6 Converter
7 Timer
8 Stopwatch
 p.69
 p.69
 p.73
 p.73
 p.74
 p.74
 p.75
 p.75
8 Camera  p.76
1 Take a photo
2 Record video
3 Go to photos
4 Go to videos
 p.76
 p.79
 p.81
 p.81
9 Settings  p.81
1 Time & Date
2 Phone settings
3 Display settings
4 Sound settings
5 Network services
6 Security
7 Memory status
8 Reset settings
 p.81
 p.82
 p.83
 p.84
 p.86
 p.88
 p.89
 p.89
* Shows only if supported by your
SIM card.
Overview of menu functions
To access Menu mode, press < Menu > in Idle mode.

6
Unpack
Make sure you have each item
You can obtain various accessories
from your local Samsung dealer.
Phone Travel Adapter
Battery User’s Guide
The items supplied with your phone
and the accessories available at your
Samsung dealer may vary, depending
on your country or service provider.
Your phone
Buttons, features, and locations
Headset
jack
Left soft key
Special
function keys
Camera
lens
Alphanumeric
keys
Web access/
Confirm key
Dial key
Display
Earpiece
Volume keys Power on/off/
Menu exit key
Right soft key
Microphone
Navigation keys
(Up/Down/
Left/Right)
Delete key
Camera
Key
Music player
control keys
External
speaker

7
Get started
First steps to operating your phone
SIM card information
When you subscribe to a cellular network, you receive
a plug-in SIM (Subscriber Identity Module) card
loaded with your subscription details, such as your
PIN, and available optional services.
Install and charge the phone
Remove the battery
cover.
If the phone is already
on, first turn it off by
holding [ ].
Insert the SIM card.
Make sure that the gold-
coloured contacts on the
card face down into the
phone.
Install the battery. Replace the cover.
Plug the travel adapter into the phone.
Plug the adapter into a standard AC wall outlet.

8
Get started
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the battery low message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
When the phone is completely charged (the
battery icon becomes still), unplug the adapter
from the power outlet.
Remove the adapter from the phone.
Power on
Do not turn on
the phone when
mobile phone
use is prohibited.
1. Open the phone.
2. Press and hold [] to turn on
the phone.
3. If necessary, enter the PIN and
press < OK >.
Power off 1. Open the phone.
2. Press and hold [] .

9
Get started
Keys and display
Keys
Perform the function indicated on the bottom
line of the display.
In Idle mode, access your favourite menus
directly.
 p. 82
In Menu mode, scroll through menu options.
In Idle mode, launch the web browser.
In Menu mode, select the highlighted menu
option or confirm input.
Send or answer a call.
In Idle mode, retrieve numbers recently
dialled, missed, or received.
Delete characters from the display and
selected item in an application.
End a call.
Press and hold to switch the phone on or off.
In Menu mode, cancel input and return the
phone to Idle mode.
Enter numbers, letters, and some special
characters.
In Idle mode, press and hold
[1] to access
your voicemail. Press and hold [
0 ] to enter
an international call prefix.
Enter special characters.
In Idle mode, press and hold [
] to activate
or deactivate Quiet mode. Press and hold
[
] to enter a pause between numbers.
Adjust the phone volume.
In Idle mode, with the phone open, adjust
the keypad tone volume. With the phone
closed, press and hold to turn on the external
display.
In Idle mode, access the Camera menu:
press and hold to turn on the camera.
In Camera mode, take a photo or record a
video.

10
Get started
Display
Layout
Icons
*
Received signal strength
Call in progress
Out of your service area; you
cannot send or receive calls
Alarm set
 p. 69
New text message
New voicemail
New multimedia message
New e-mail
Text and graphics
display messages,
instructions, and
information you enter.
Soft key function
indicators
show the current
functions assigned to
the two soft keys.
Icons
display various icons.
Menu Contacts
One of the message Inboxes is full
Call diverting feature active
 p. 86
Bluetooth active
 p. 40
Synchronised with a PC
GPRS network
EDGE network
Home Zone, if registered for the
appropriate service
Office Zone, if registered for the
appropriate service
Ringer type
 p. 84
• None: Melody
•:Vibration
• : Melody and vibration
• : Vibration then melody
• : Melody then vibration
Silent mode
 p. 13
Battery power level
* Depending on your country or service provider, the icons
shown on the display may vary.

11
Get started
Access menu functions
Use the soft
keys
The roles of the soft keys vary
depending on the function you are
using. The bottom line of the
display indicates their current role.
Press the left soft
key to select the
highlighted
option.
Press the right soft
key to return to the
previous menu
level.
Select Back
Select an
option
1. Press the appropriate soft key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press < Select > or [ OK ] to
confirm the function displayed
or option highlighted.
4. To exit, choose either of the
following methods:
•Press< Back > to move up
one level.
• Press [ ] to return to Idle
mode.
Use shortcuts Press the number key
corresponding to the option you
want.

12
Get started
Customise your phone
1. In Idle mode, press < Menu >
and select Settings → Phone
settings → Language .
2. Select a language.
1. In Idle mode, press < Menu >
and select Settings → Sound
settings → Incoming call →
Ring tone .
2. Select a ringtone category.
3. Select a ringtone.
4. Press < Save >.
Display
language
Call ringer
melody
You can set wallpaper for the idle
screen on each display.
For the main display:
1. In Idle mode, press < Menu >
and select Settings → Display
settings → Wallpaper → Main
display .
2. Select an image category.
3. Select an image.
For the external display:
1. In Idle mode, press < Menu >
and select Settings → Display
settings → Wallpaper →
Cover display .
2. Select an image type.
Idle mode
wallpaper

13
Get started
3. For Clock , scroll to a clock type
and press < Save >.
For Cover title , enter a
greeting and press [ OK ].
For Wallpaper images , select
an image category and then an
image. Press < Save >.
You can change the colour for the
display components, such as title
bars and highlight bars.
1. In Idle mode, press < Menu >
and select Settings → Display
settings → Skin .
2. Select a colour pattern.
Menu mode
skin colour
You can set the Navigation keys to
function as shortcuts to access
your favourite menus.
1. In Idle mode, press < Menu >
and select Settings → Phone
settings → Short cut .
2. Select a key.
3. Select a menu to be assigned to
the key.
You can switch the phone to Silent
mode to avoid disturbing other
people.
Press and hold [ ] in Idle mode.
Menu
shortcuts
Silent mode

14
Get started
Make/Answer calls
You can protect the phone against
unauthorised use with a phone
password. The phone will require
the password on power-up.
1. In Idle mode, press < Menu >
and select Settings →
Security → Change
password .
2. Enter the default password,
00000000 , and press < OK >.
3. Enter a new 4- to 8-digit
password and press < OK >.
4. Enter the new password again
and press < OK >.
5. Select Phone lock .
6. Select Enable .
7. Enter the password and press
< OK >.
Phone lock
1. Enter an area code and phone
number.
2. Press [ ].
3. To end the call, press [ ].
1. When the phone is ringing,
press [ ].
2. To end the call, press [ ].
Press [ / ].
Make a call
Answer a call
Adjust the
volume during
a call

15
Step outside the phone
Begin with your camera, the music player, and other
special features
Use the camera
1. In Idle mode, press and hold
[ ] to turn on the camera.
2. Aim the lens at the subject and
make any desired adjustments.
3. Press [] to take a photo. The
photo is saved automatically.
4. Press < Back > to take another
photo.
1. In Idle mode, press < Menu >
and select My files → Images
→ Photos .
2. Select the photo you want.
Take a photo
View a photo
1. In Idle mode, press [ ] and
select Record video .
2. Press [] to start recording.
3. Press []or <>tostop
recording. The video is saved
automatically.
4. Press the right soft key to
record another video.
1. In Idle mode, press < Menu >
and select My files → Videos →
Videos .
2. Select the video clip you want.
Record a video
Play a video

16
Step outside the phone
Play music files
Use these methods:
• Download from the wireless
web  p. 46
• Download from a computer
using the optional Samsung PC
Studio  Samsung PC Studio
User’s Guide
• Receive via Bluetooth  p. 43
1. In Idle mode, press < Menu >
and select Applications →
Music player .
2. Press < Options > and select
Add music .
3. Press [ OK ] to select the files
you want and press < Add >.
Copy music
files to the
phone
Create a play
list
1. From the music player screen,
press [ OK ] .
2. During playback, use the
following keys:
• OK : pauses or resumes
playback.
• Up: accesses the current
play list.
• Left: moves back to the
previous file. Moves
backward in a file when held
down.
• Right: skips to the next file.
Skips forward in a file when
held down.
• / : adjusts the volume.
• Down: stops playback.
Play music files
