Samsung SM-A505F User manual

SM-A505F/FN/FM/GT/
G/GN Common
Mobile Device
CONTENTS
1. Safety Precautions
2. Specification
3. Product Function
4. Exploded View and Parts list
5. MAIN Electrical Parts List
6. Level 1 Repair
7. Level 2 Repair
8. Level 3 Repair
9. Reference Abbreviation
Notice: All functionality, features, specifications,
and other product information provided in this
document, including but not limited to, benefits,
design, pricing, components, performance,
availability, and capabiliti-es of the product are
subject to change without notice. Samsung
reserves the right to alter this doc-ument or the
product described herein at anytime, without
obligation to provide notification of such
changes.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
2-1. GSM General Specification
Item GSM 850 EGSM 900 DCS1800 PCS1900
Freq. Band[MHz]
Uplink/Downlink
824~849
869~894
880~915
925~960
1710~1785
1805~1880
1850~1910
1930~1990
ARFCN range 128~251 0~124 & 975~1023 512~885 512~810
Tx/Rx spacing 45MHz 45MHz 95MHz 80MHz
Mod. Bit rate/
Bit Period
270.833kbps
3.692us
270.833kbps
3.692us
270.833kbps
3.692us
270.833kbps
3.692us
Time Slot Period/
Frame Period
576.9us
4.615ms
576.9us
4.615ms
576.9us
4.615ms
576.9us
4.615ms
Modulation GSM/
EGPRS
GMSK/
8PSK
GMSK/
8PSK
GMSK/
8PSK
GMSK/
8PSK
MS Power 33dBm~5dBm 33dBm~5dBm 30dBm~0dBm 30dBm~0dBm
Power Class 4(GMSK)
E2(8PSK)
4(GMSK)
E2(8PSK)
1(GMSK)
E2(8PSK)
1(GMSK)
E2(8PSK)
Sensitivity -102dBm -102dBm -100dBm -100dBm
TDMA Mux 8 8 8 8

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
2-2. GSM Tx Power Class
TX Power
control level GSM850 TX Power control level EGSM900 TX Power control level DCS1800 TX Power control level PCS1900
5 33±2 dBm 5 33±2 dBm 0 30±3 dBm 0 30±3 dBm
6 31±2 dBm 6 31±2 dBm 1 28±3 dBm 1 28±3 dBm
7 29±2 dBm 7 29±2 dBm 2 26±3 dBm 2 26±3 dBm
8 27±2 dBm 8 27±2 dBm 3 24±3 dBm 3 24±3 dBm
9 25±2 dBm 9 25±2 dBm 4 22±3 dBm 4 22±3 dBm
10 23±2 dBm 10 23±2 dBm 5 20±3 dBm 5 20±3 dBm
11 21±2 dBm 11 21±2 dBm 6 18±3 dBm 6 18±3 dBm
12 19±2 dBm 12 19±2 dBm 7 16±3 dBm 7 16±3 dBm
13 17±2 dBm 13 17±2 dBm 8 14±3 dBm 8 14±3 dBm
14 15±2 dBm 14 15±2 dBm 9 12±4 dBm 9 12±4 dBm
15 13±2 dBm 15 13±2 dBm 10 10±4 dBm 10 10±4 dBm
16 11±3 dBm 16 11±3 dBm 11 8±4 dBm 11 8±4 dBm
17 9±3 dBm 17 9±3 dBm 12 6±4 dBm 12 6±4 dBm
18 7±3 dBm 18 7±3 dBm 13 4±4 dBm 13 4±4 dBm
19 5±3 dBm 19 5±3 dBm 14 2±5 dBm 14 2±5 dBm
- - - - 15 0±5 dBm 15 0±5 dBm

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
2-3-1. WCDMA General Specification[SM-A505F/FN/FM]
Item WCDMA2100(B1) WCDMA1900(B2) WCDMA850(B5) WCDMA900(B8)
Freq. Band[MHz]
Uplink/Downlink
1920~1980
2110~2170
1850~1910
1930~1990
824~849
869~894
880~915
925~960
ARFCN range UL：9612~9888
DL：10562~10838
UL：9262~9538
DL：9662~9938
UL：4132~4233
DL：4357~4458
UL：2712~2868
DL：2937~3088
Tx/Rx spacing 190MHz 80MHz 45MHz 45MHz
Mod. Bit rate/
Bit Period
42.2Mbps(DL)
5.42Mbps(UL) 42.2Mbps(DL) 5.42Mbps(UL) 42.2Mbps(DL) 5.42Mbps(UL) 42.2Mbps(DL) 5.42Mbps(UL)
Time Slot Period/
Frame Period
WCDMA
10ms/0.667ms
HSPA
2ms/0.667ms
WCDMA
10ms/0.667ms
HSPA
2ms/0.667ms
WCDMA
10ms/0.667ms
HSPA
2ms/0.667ms
WCDMA
10ms/0.667ms
HSPA
2ms/0.667ms
Modulation QPSK
16QAM
64QAM
QPSK
16QAM
64QAM
QPSK
16QAM
64QAM
QPSK
16QAM
64QAM
MS Power
(dBm)
25.7 ~ -49(↓) 25.7 ~ -49(↓) 25.7 ~ -49(↓) 25.7 ~ -49(↓)
Power Class 3(max+24dBm) 3(max+24dBm) 3(max+24dBm) 3(max+24dBm)
Sensitivity -106dBm -104dBm -104dBm -103dBm

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
2-3-2. WCDMA General Specification[SM-A505G/GN/GT]
Item WCDMA2100(B1) WCDMA1900(B2) WCDMA AWS(B4) WCDMA850(B5) WCDMA900(B8)
Freq. Band[MHz]
Uplink/Downlink
1920~1980
2110~2170
1850~1910
1930~1990
1710~1755
2110~2155
824~849
869~894
880~915
925~960
ARFCN range UL：9612~9888
DL：10562~10838
UL：9262~9538
DL：9662~9938
UL：1312~1513
DL：1537~1738
UL：4132~4233
DL：4357~4458
UL：2712~2868
DL：2937~3088
Tx/Rx spacing 190MHz 80MHz 400MHz 45MHz 45MHz
Mod. Bit rate/
Bit Period
42.2Mbps(DL)
5.42Mbps(UL) 42.2Mbps(DL) 5.42Mbps(UL) 42.2Mbps(DL) 5.42Mbps(UL) 42.2Mbps(DL) 5.42Mbps(UL) 42.2Mbps(DL) 5.42Mbps(UL)
Time Slot Period/
Frame Period
WCDMA
10ms/0.667ms
HSPA
2ms/0.667ms
WCDMA
10ms/0.667ms
HSPA
2ms/0.667ms
WCDMA
10ms/0.667ms
HSPA
2ms/0.667ms
WCDMA
10ms/0.667ms
HSPA
2ms/0.667ms
WCDMA
10ms/0.667ms
HSPA
2ms/0.667ms
Modulation
QPSK
16QAM
64QAM
QPSK
16QAM
64QAM
QPSK
16QAM
64QAM
QPSK
16QAM
64QAM
QPSK
16QAM
64QAM
MS Power
(dBm) 25.7 ~ -49(↓) 25.7 ~ -49(↓) 25.7 ~ -49(↓) 25.7 ~ -49(↓) 25.7 ~ -49(↓)
Power Class 3(max+24dBm) 3(max+24dBm) 3(max+24dBm) 3(max+24dBm) 3(max+24dBm)
Sensitivity -106dBm -104dBm -106dBm -104dBm -103dBm

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
2-4. LTE General Specification
Item LTE Band1 LTE Band3 LTE Band5 LTE Band7
Freq. Band[MHz]
Uplink/Downlink
1920~1980
2110~2170
1710~1785
1805~1880
824~849
869~894
2500~2570
2620~2690
ARFCN range UL:18000~18599
DL:0~599
UL:19200~19949
DL:1200~1949
UL:20400~20649
DL:2400~2649
UL:20750~21449
DL:2750~3449
Tx/Rx spacing
(MHz)
190 95 45 120
Channel Bandwidth
(MHz)
5/10/15/20 1.4/3/5/10/15/20 1.4/3/5/10 5/10/15/20
Modulation QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
MS Power (dBm) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓)
Sensitivity(QPSK, BW
10MHz) (dBm)
-96.3 -93.3 -94.3 -94.3
Item LTE Band8 LTE Band38 LTE Band40 LTE Band41
Freq. Band[MHz]
Uplink/Downlink
880~915
925~960 2570~2620 2300~2400 2496~2690
ARFCN range UL:21450-21799
DL:3450-3799 UL/DL:37750 ~ 38249 UL/DL:38650 ~ 39649 UL/DL:39650 ~ 41589
Tx/Rx spacing (MHz) 45 0 0 0
Channel Bandwidth
(MHz)
1.4/3/5/10 5/10/15/20 5/10/15/20 5/10/15/20
Modulation QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
MS Power (dBm) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓)
Sensitivity(QPSK, BW
10MHz) (dBm)
-93.3 -96.3 -96.3 -94.3

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
[SM-A505F/FN/FM]
Item LTE Band20
Freq. Band[MHz]
Uplink/Downlink
832~862
791~821
ARFCN range UL:24150~24449
DL:6150~6449
Tx/Rx spacing (MHz) -41
Channel Bandwidth
(MHz)
5/10/15/20
Modulation QPSK,16/64QAM
256QAM(DL only)
MS Power (dBm) 25.7~-39(↓)
Sensitivity(QPSK, BW 10MHz) (dBm) -93.3

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
[SM-A505G/GN]
Item LTE Band2 LTE Band4 LTE Band12 LTE Band13
Freq. Band[MHz]
Uplink/Downlink
1850~1910
1930~1990
1710~1755
2110~2155
699~716
729~746
777~787
746~756
ARFCN range UL:18600~19199
DL:600~1199
UL:19950~20399
DL:1950~2399
UL:23010~23179
DL:5010~5179
UL:23180~23279
DL:5180~5279
Tx/Rx spacing
(MHz)
80 400 30 -31
Channel Bandwidth
(MHz)
1.4/3/5/10/15/20 1.4/3/5/10/15/20 1.4/3/5/10 1.4/3/5/10
Modulation QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
MS Power (dBm) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓)
Sensitivity(QPSK, BW
10MHz)(dBm)
-94.3 -96.3 -93.3 -93.3
Item LTE Band17 LTE Band28 LTE Band66
Freq. Band[MHz]
Uplink/Downlink
704~716
734~746
703~748
758~803
1710~1780
2110~2200
ARFCN range UL:23730~23849
DL:5730~5849
UL:27210~27659
DL:9210~9659
UL:131972~132671
DL:66436~67335
Tx/Rx spacing (MHz) 30 55 400
Channel Bandwidth
(MHz) 5/10 3/5/10/15/20 1.4/3/5/10/15/20
Modulation QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
MS Power (dBm) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓)
Sensitivity (QPSK, BW 10MHz)
(dBm) -93.3 -94.8 -95.8

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
[SM-A505GT]
Item LTE Band2 LTE Band4 LTE Band12 LTE Band13
Freq. Band[MHz]
Uplink/Downlink
1850~1910
1930~1990
1710~1755
2110~2155
699~716
729~746
777~787
746~756
ARFCN range UL:18600~19199
DL:600~1199
UL:19950~20399
DL:1950~2399
UL:23010~23179
DL:5010~5179
UL:23180~23279
DL:5180~5279
Tx/Rx spacing
(MHz)
80 400 30 -31
Channel Bandwidth
(MHz)
1.4/3/5/10/15/20 1.4/3/5/10/15/20 1.4/3/5/10 1.4/3/5/10
Modulation QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
MS Power (dBm) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓)
Sensitivity(QPSK, BW
10MHz)(dBm)
-94.3 -96.3 -93.3 -93.3
Item LTE Band17 LTE Band20LTE Band28 LTE Band66
Freq. Band[MHz]
Uplink/Downlink
704~716
734~746
832~862
791~821
703~748
758~803
1710~1780
2110~2200
ARFCN range UL:23730~23849
DL:5730~5849
UL:24150~24449
DL:6150~6449
UL:27210~27659
DL:9210~9659
UL:131972~132671
DL:66436~67335
Tx/Rx spacing (MHz) 30 -41 55 400
Channel Bandwidth
(MHz) 5/10 5/10/15/20 3/5/10/15/20 1.4/3/5/10/15/20
Modulation QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
MS Power (dBm) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓)
Sensitivity (QPSK, BW
10MHz) (dBm) -93.3 -93.3 -94.8 -95.8

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
4. Exploded View and Parts List
4-1-1. Cellular phone Exploded View [SM-A505F/GT]
QRE01
QSM01
QAN01
QCR205
QBC01
QME05
QVO01
QCA02
QCR12
QMP01
QCA01
QMO01
QAR01
QFR01
QCK01
QSP01
QCB02
QCB01
QBA01
QME03
QME01
QCR12
QME06
QME02
QME04
※SVC REPAIR TAPE
QRT01

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
4. Exploded View and Parts List
4-1-2. Cellular phone Exploded View [SM-A505FN]
QRE01
QSM01
QAN01
QAN02
QCR205
QBC01
QME05
QVO01
QCA02
QCR12
QMP01
QCA01
QMO01
QAR01
QFR01
QCK01
QSP01
QCB02
QCB01
QBA01
QME03
QME01
QCR12
QME06
QME02
QME04
※SVC REPAIR TAPE
QRT01

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
4. Exploded View and Parts List
4-2-1. Cellular phone Parts list [SM-A505F]
Design LOC Description SEC CODE
QCR12 SCREW-MACHINE 6001-001530
QCR205 SCREW-MACHINE 6001-003227
QCA01 ASSY CAMERA-1/2.78"_24M_A505F GH96-12415A
QCA02 ASSY VT CAMERA-1/2.8"_25M_A505F GH96-12416A
QRE01 MEA REAR-SM-A505F GH97-22993A
QSP01 SPEAKER 3001-002856
QVO01 ASSY KEY-VOLUME GH98-43923A
QCK01 ASSY KEY-POWER GH98-43924A
QME05 ASSY SUB PBA-SIDE KEY (SM-A505F) GH96-12420A
QAN01 ANTENNA-NON NFC DUMMY GH42-06315A
QAR01 AUDIO-RECEIVER 3009-001705
QCR12 SCREW-MACHINE 6001-001530
QMO01 MOTOR DC-VIBRATION (SM-J200BT) GH31-00744A
QCB01 CBF COAXIAL CABLE-A505F,177.3MM,WHITE GH39-01991A
QCB02 CBF COAXIAL CABLE-A505F,131MM,BLUE GH39-01992A
QME03 CON TO CON FPCB-MAIN (SM-A505F) GH59-15029A
QME01 CON TO CON FPCB-OCTA (SM-A505F) GH59-15030A
QME02 ASSY SUB PBA-HB (SM-A505F) GH96-12423A
QME04 ASSY SUB PBA-SM-A505F GH96-12426A
QME06 ASSY MODULE-OPTICAL FINGER SCAN SENSOR GH96-12434A
QSM01 ASSY COVER-SIM TRAY(DS)_ZK GH98-43922A
QMP01 SVC PBA-MAIN(COMM),SM-A505F/6R6D,SVC GH82-19205A
QFR01 SVC ASSY SMT-OCTA(E/ZK),SM-A505F,INS,SVC GH82-19204A
QBA01 SVC BATTERY ASSY-EB-BA505ABN,30,INS,SVC GH82-19203A
QBC01 SVC COVER ASSY-B/G GH82-19236A
QRT01 Back Glass Rework Tape GH81-16711A

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
4. Exploded View and Parts List
4-2-2. Cellular phone Parts list [SM-A505FN]
Design LOC Description SEC CODE
QCR12 SCREW-MACHINE 6001-001530
QCR205 SCREW-MACHINE 6001-003227
QCA01 ASSY CAMERA-1/2.78"_24M_A505F GH96-12415A
QCA02 ASSY VT CAMERA-1/2.8"_25M_A505F GH96-12416A
QRE01 MEA REAR-SM-A505_NFC_ZK GH97-23109A
QSP01 SPEAKER 3001-002856
QVO01 ASSY KEY-VOLUME GH98-43923A
QCK01 ASSY KEY-POWER GH98-43924A
QME05 ASSY SUB PBA-SIDE KEY (SM-A505F) GH96-12420A
QAN01 ANTENNA COIL-NFC (SM-A505FN) GH42-06264A
QAN02 ANTENNA COIL-ONLY NFC DUMMY GH42-06316A
QAR01 AUDIO-RECEIVER 3009-001705
QCR12 SCREW-MACHINE 6001-001530
QMO01 MOTOR DC-VIBRATION (SM-J200BT) GH31-00744A
QCB01 CBF COAXIAL CABLE-A505F,177.3MM,WHITE GH39-01991A
QCB02 CBF COAXIAL CABLE-A505F,131MM,BLUE GH39-01992A
QME03 CON TO CON FPCB-MAIN (SM-A505F) GH59-15029A
QME01 CON TO CON FPCB-OCTA (SM-A505F) GH59-15030A
QME02 ASSY SUB PBA-HB (SM-A505F) GH96-12423A
QME04 ASSY SUB PBA-SM-A505F GH96-12426A
QME06 ASSY MODULE-OPTICAL FINGER SCAN SENSOR GH96-12434A
QSM01 ASSY COVER-SIM TRAY(DS)_ZK GH98-43922A
QMP01 SVC PBA-MAIN(COMM) GH82-19291A
QFR01 SVC ASSY SMT-OCTA(E/ZK) GH82-19204A
QBA01 SVC BATTERY ASSY-EB-BA505ABU,30,ZTO,SVC GH82-19269A
QBC01 SVC COVER ASSY-B/G;COMM1_ZK_VN_DS GH82-19229A
QRT01 A/S-TAPE BACK COVER GH81-16711A

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
4. Exploded View and Parts List
4-2-3. Cellular phone Parts list [SM-A505GT]
Design LOC Description SEC CODE
QCR12 SCREW-MACHINE 6001-001530
QCR205 SCREW-MACHINE 6001-003227
QCA01 ASSY CAMERA-1/2.78"_24M_A505F GH96-12415A
QCA02 ASSY VT CAMERA-1/2.8"_25M_A505F GH96-12416A
QRE01 MEA REAR-SM-A505F GH97-22993A
QSP01 SPEAKER 3001-002856
QVO01 ASSY KEY-VOLUME GH98-43923A
QCK01 ASSY KEY-POWER GH98-43924A
QME05 ASSY SUB PBA-SIDE KEY (SM-A505F) GH96-12420A
QAN01 ANTENNA-NON NFC DUMMY GH42-06315A
QAR01 AUDIO-RECEIVER 3009-001705
QCR12 SCREW-MACHINE 6001-001530
QMO01 MOTOR DC-VIBRATION (SM-J200BT) GH31-00744A
QCB01 CBF COAXIAL CABLE-A505F,177.3MM,WHITE GH39-01991A
QCB02 CBF COAXIAL CABLE-A505F,131MM,BLUE GH39-01992A
QME03 CON TO CON FPCB-MAIN (SM-A505F) GH59-15029A
QME01 CON TO CON FPCB-OCTA (SM-A505F) GH59-15030A
QME02 ASSY SUB PBA-HB (SM-A505F) GH96-12423A
QME04 ASSY SUB PBA-SM-A505GT GH96-12460A
QME06 ASSY MODULE-OPTICAL FINGER SCAN SENSOR GH96-12434A
QSM01 ASSY COVER-SIM TRAY(DS)_ZK GH98-43922A
QMP01 SVC PBA-MAIN(COMM)SM-A505GT/6DL,ZTO,SVC GH82-19292A
QFR01 SVC ASSY SMT-OCTA(E/ZK) GH82-19204A
QBA01 SVC BATTERY ASSY-EB-BA505ABU,30,ZTO,SVC GH82-19269A
QBC01 SVC COVER ASSY-B/G GH82-19308A
QRT01 A/S-TAPE BACK COVER GH81-16711A

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
Parts Code Design LOC Description
D5100 0401-001110 DIODE-SWITCHING
D5000 0404-001250 DIODE-SCHOTTKY
ZD5002,ZD5005,ZD6017 0406-001561 DIODE-TVS
ZD5000 0406-001592 DIODE-TVS
ZD3002 0406-001715 DIODE-TVS
ZD1000,ZD5001,ZD7009 0406-001728 DIODE-TVS
ZD6016,ZD6018,ZD6020 0406-001781 DIODE-TVS
D6003,D6004 0406-001787 DIODE-TVS
D6000 0406-001808 DIODE-TVS
ZD6021,ZD6022 0406-001809 DIODE-TVS
Q6000 0505-001883 FET-SILICON
LED5000 0601-003768 LED
U1009 1001-001844 IC
U1007 1001-001970 IC
U1005 1001-001974 IC
U1000,U1001 1001-002064 IC
U3004,U6003 1001-002065 IC
U3001 1001-002077 IC
U2006 1001-002078 IC
U2011 1003-002802 IC
U3005 1003-002805 IC
U3017 1009-001076 IC
UME5000 1107-002589 IC
U3003 1201-003869 IC
PAM1000 1201-004100 IC
U1008 1201-004135 IC
U6001 1201-004156 IC
U1015 1201-004219 IC
U6000 1202-001120 IC
U3010 1203-008249 IC
U5019 1203-008251 IC
U7005 1203-008326 IC
U6002 1203-008475 IC
U2001 1203-008693 IC
U5003 1203-008729 IC
U3013 1203-008771 IC
U3006 1203-008865 IC
U3000,U7006 1203-008867 IC

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
U3002 1203-008872 IC
U3011,U6020 1203-008925 IC
U7007 1203-008926 IC
U7002 1203-008989 IC
U7003 1203-009035 IC
U7000 1203-009221 IC
U3009 1204-003748 IC
U6012 1205-005750 IC
U2010 1205-005767 IC
U3016 1205-005791 IC
U3018 1209-002513 IC
U3008 1209-002628 IC
U3014 1209-002629 IC
TH1000,TH4000,TH4001 1404-001724 THERMISTOR
TH5000 1404-001724 THERMISTOR
V7000 1405-001458 VARISTOR
R3000,R3007 2007-000141 R-CHIP
R3006 2007-000148 R-CHIP
R3001,R3031 2007-000982 R-CHIP
R6887,R6888 2007-003015 R-CHIP
R6016,R6017 2007-007142 R-CHIP
C6054,C6055 2007-007190 R-CHIP
R5002 2007-007193 R-CHIP
R2002,R2003,R4005 2007-007741 R-CHIP
R4013,R5017,R5028 2007-007741 R-CHIP
R5031,R6004,R6024 2007-007741 R-CHIP
R6025 2007-007741 R-CHIP
ZD6019 2007-007798 R-CHIP
R5022 2007-007942 R-CHIP
R5053 2007-008043 R-CHIP
R6023 2007-008296 R-CHIP
R5003,R5004,R5008 2007-008486 R-CHIP
L7003,R6008,R7000 2007-008531 R-CHIP
R7001 2007-008531 R-CHIP
R4444 2007-008816 R-CHIP
R3005 2007-009111 R-CHIP
R5007 2007-009155 R-CHIP
R1009,R4017,R4034 2007-009157 R-CHIP
R5018,R5052,R6015 2007-009157 R-CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
R7004,R7007 2007-009157 R-CHIP
R5001 2007-009182 R-CHIP
R4049,R4060,R5013 2007-009212 R-CHIP
R6009 2007-009212 R-CHIP
R6001 2007-009314 R-CHIP
R5010 2007-009315 R-CHIP
R4036,R4037,R4040 2007-009352 R-CHIP
R4051,R5016,R5019 2007-009352 R-CHIP
R7002 2007-009352 R-CHIP
R3008,R4015,R4018 2007-009408 R-CHIP
R4019,R4022,R4023 2007-009408 R-CHIP
R4024,R4025,R4026 2007-009408 R-CHIP
R4029,R4030,R4031 2007-009408 R-CHIP
R4032,R4033,R4038 2007-009408 R-CHIP
R4039,R4043,R4046 2007-009408 R-CHIP
R4048,R4052,R4053 2007-009408 R-CHIP
R4054,R4055,R4056 2007-009408 R-CHIP
R4057,R4058,R4059 2007-009408 R-CHIP
R4790,R4791,R4792 2007-009408 R-CHIP
R4793 2007-009408 R-CHIP
R6013,R6036 2007-009410 R-CHIP
R6000 2007-009766 R-CHIP
R1000,R1002,R1003 2007-009805 R-CHIP
R1004,R1005,R2000 2007-009805 R-CHIP
R6222 2007-009807 R-CHIP
R6012 2007-009838 R-CHIP
R5005 2007-009866 R-CHIP
R4020,R4021,R4027 2007-009920 R-CHIP
R4028 2007-009920 R-CHIP
R6011 2007-009969 R-CHIP
R6021 2007-010031 R-CHIP
R5000,R5355 2007-010202 R-CHIP
R6022 2007-010685 R-CHIP
R4000 2007-011043 R-CHIP
R6019,R6035 2007-011648 R-CHIP
R5026,R6020 2007-012202 R-CHIP
C3027,C3099 2203-000311 C-CERAMIC
C3068 2203-000438 C-CERAMIC
C3097 2203-001153 C-CERAMIC

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
C3083,C3100 2203-002443 C-CERAMIC
C5082 2203-005344 C-CERAMIC
C5087,C5099,C5113 2203-005682 C-CERAMIC
C7003,C7013 2203-005682 C-CERAMIC
C3019,C3020,C3037 2203-005725 C-CERAMIC
C3038,C7004,C7006 2203-005725 C-CERAMIC
L1041 2203-005725 C-CERAMIC
C5064,C6000,C6005 2203-005729 C-CERAMIC
C6014,C6022,C6030 2203-005729 C-CERAMIC
C7007 2203-005729 C-CERAMIC
C1003,C2040,C3025 2203-005731 C-CERAMIC
C6020,C6059 2203-005731 C-CERAMIC
C5077,C6013,C6021 2203-005732 C-CERAMIC
C6037 2203-005732 C-CERAMIC
C1007,C1081,C3054 2203-005734 C-CERAMIC
C1010,C1022,C1023 2203-005736 C-CERAMIC
C1027,C1029,C1033 2203-005736 C-CERAMIC
C1040,C1048,C1051 2203-005736 C-CERAMIC
C1057,C1069,C1074 2203-005736 C-CERAMIC
C1901,C1902,C2000 2203-005736 C-CERAMIC
C2005,C2012,C2018 2203-005736 C-CERAMIC
C2026,C2500,C2702 2203-005736 C-CERAMIC
C3005,C3032,C3036 2203-005736 C-CERAMIC
C3041,C3049,C6026 2203-005736 C-CERAMIC
C1055,C1064,C1076 2203-005777 C-CERAMIC
C1085,C1908,C2006 2203-005777 C-CERAMIC
C2007 2203-005777 C-CERAMIC
C1047,C1049,C1065 2203-005789 C-CERAMIC
C1911,C2008,C2505 2203-005789 C-CERAMIC
C1043,C1101,C1102 2203-005792 C-CERAMIC
C1013,C1096,C2002 2203-005806 C-CERAMIC
L1008 2203-006123 C-CERAMIC
C6008 2203-006194 C-CERAMIC
C1038,C1098 2203-006305 C-CERAMIC
C1004,C1056,C1106 2203-006318 C-CERAMIC
C2506 2203-006318 C-CERAMIC
C2004,C3013,C3014 2203-006400 C-CERAMIC
C3021,C3033,C3073 2203-006400 C-CERAMIC
C3078,C4013,C4014 2203-006400 C-CERAMIC

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
C4026,C4028,C5089 2203-006400 C-CERAMIC
C5139,C5140,C6003 2203-006400 C-CERAMIC
C3023 2203-006410 C-CERAMIC
C2069,C3029,C3030 2203-006423 C-CERAMIC
C3071,C5810,C6016 2203-006423 C-CERAMIC
C6033,C6036,C6051 2203-006423 C-CERAMIC
C6089,C6091,C7040 2203-006423 C-CERAMIC
L6010 2203-006423 C-CERAMIC
C6050 2203-006462 C-CERAMIC
C1006,C1031,C1054 2203-006556 C-CERAMIC
C1122,C5105 2203-006556 C-CERAMIC
C3053 2203-006604 C-CERAMIC
C1035 2203-006611 C-CERAMIC
C4003 2203-006668 C-CERAMIC
C1920,C2046,L1057 2203-006674 C-CERAMIC
C1014,C1059,C1061 2203-006839 C-CERAMIC
C1062,C1067,C1116 2203-006839 C-CERAMIC
C1119,C2003,C3022 2203-006839 C-CERAMIC
C4007,C4012,C4041 2203-006839 C-CERAMIC
C5081,C5084,C5088 2203-006839 C-CERAMIC
C6045 2203-006839 C-CERAMIC
C1072 2203-006846 C-CERAMIC
C5006,C5013,C5026 2203-006872 C-CERAMIC
C5027,C5028,C5032 2203-006872 C-CERAMIC
C5044,C5051,C5062 2203-006872 C-CERAMIC
C5095 2203-006872 C-CERAMIC
C1046,C2010,C2053 2203-006979 C-CERAMIC
C2056,C2062,C2063 2203-006979 C-CERAMIC
C2067,C2076,C2077 2203-006979 C-CERAMIC
C2079,C2091 2203-006979 C-CERAMIC
C3050,C3058,C7012 2203-007194 C-CERAMIC
L1043 2203-007194 C-CERAMIC
C4148 2203-007210 C-CERAMIC
C5045 2203-007271 C-CERAMIC
C3069,C3076 2203-007295 C-CERAMIC
C3087,C5008,C5041 2203-007317 C-CERAMIC
C5073,C5074,C5100 2203-007317 C-CERAMIC
C7000,C7011,C7018 2203-007317 C-CERAMIC
C7027,C7028,C7031 2203-007317 C-CERAMIC

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
C7032,C7033,C7034 2203-007317 C-CERAMIC
C7035 2203-007317 C-CERAMIC
C2065 2203-007391 C-CERAMIC
C2092 2203-007392 C-CERAMIC
C1041,C1044,C2028 2203-007393 C-CERAMIC
C3080,C3081,C4033 2203-007393 C-CERAMIC
C4058,C4071,C4080 2203-007393 C-CERAMIC
C4092,C4105,C5079 2203-007393 C-CERAMIC
C5091,C5098,C5145 2203-007393 C-CERAMIC
C6025,C6032,C6039 2203-007393 C-CERAMIC
C6082,C6083,C6084 2203-007393 C-CERAMIC
C6085,C6086,C6087 2203-007393 C-CERAMIC
C6092,C7023 2203-007393 C-CERAMIC
C5068 2203-007425 C-CERAMIC
C6047 2203-007456 C-CERAMIC
C2055,C2064,C2066 2203-007474 C-CERAMIC
C2080 2203-007474 C-CERAMIC
C2027,C2054,C2061 2203-007796 C-CERAMIC
C2075,C2078,C3003 2203-007796 C-CERAMIC
C3008,C3010,C3011 2203-007796 C-CERAMIC
C3012,C3017,C3026 2203-007796 C-CERAMIC
C3031,C3034,C3074 2203-007796 C-CERAMIC
C3077,C3082,C3089 2203-007796 C-CERAMIC
C3091,C3092,C3093 2203-007796 C-CERAMIC
C3094,C4001,C4002 2203-007796 C-CERAMIC
C4004,C4005,C4006 2203-007796 C-CERAMIC
C4008,C4011,C4015 2203-007796 C-CERAMIC
C4016,C4018,C4019 2203-007796 C-CERAMIC
C4020,C4021,C4022 2203-007796 C-CERAMIC
C4023,C4024,C4025 2203-007796 C-CERAMIC
C4027,C4029,C4030 2203-007796 C-CERAMIC
C4031,C4032,C4035 2203-007796 C-CERAMIC
C4042,C4043,C4054 2203-007796 C-CERAMIC
C4055,C4056,C4057 2203-007796 C-CERAMIC
C4059,C4066,C4067 2203-007796 C-CERAMIC
C4068,C4070,C4073 2203-007796 C-CERAMIC
C4074,C4075,C4076 2203-007796 C-CERAMIC
C4078,C4079,C4084 2203-007796 C-CERAMIC
C4085,C4086,C4087 2203-007796 C-CERAMIC
