Samsung MIM-H02 Guide

CAC WiFi Kit APP_03384A(1).indd 36 2012-10-12 오후 3:37:16

Smart A/C application
MIM-H02
Air Conditioner
user & installation manual
imagine the possibilities
EDB68-03384A(1)
CAC WiFi Kit APP_03384A(1).indd 37 2012-10-12 오후 3:37:16

2
Contents
Safetyprecautions ................................................................................................ 3
CheckbeforeinstallingWi-Fikit ................................................................................... 4
Parts.................................................................................................................... 4
Exteriordimension...................................................................................................... 4
HowtoinstallWi-Fikit ............................................................................................. 5
Wi-Fikitinstallation..................................................................................................... 5
Theprocedureofsettingoption........................................................................................ 10
Installingnetwork ............................................................................................... 12
Checkingbeforeusingawirelessrouter .......................................................................... 12
Connectingnetwork ............................................................................................ 12
ConnectingthewirelessIProuterwithanairconditioner............................................................... 12
CheckingtheWi-Fikit.................................................................................................. 13
Checkingnetwork..................................................................................................... 14
Connecting the wireless router with an air conditioner by the network (Select one of the 2 methods) . . . . . . . . . . . . . . . . . . . 15
Registeringservice .............................................................................................. 19
Registeringanairconditioner.......................................................................................... 19
OperatingSmartA/Capplication ................................................................................ 22
Homescreen.......................................................................................................... 22
AccessingIn-home .................................................................................................... 22
Controlling an air conditioner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Settingadditionalfunctionsoftheairconditioner...................................................................... 24
Settingtimerfunction................................................................................................. 24
Settingairconditionerinformation..................................................................................... 25
AccessingOut-of-home................................................................................................ 26
Troubleshooting ................................................................................................ 27
OpenSourceAnnouncement .................................................................................... 28
Reference ....................................................................................................... 35
CAC WiFi Kit APP_03384A(1).indd 2 2012-10-12 오후 3:37:08

3
Safety precautions
This installation manual explains how to installWi-Fi kit that connects to indoor unit of Samsung system air conditioner.
Read the installation manual thoroughly before installing the Wi-Fi kit.
(Refer to the appropriate manual for installing product or other optional parts.)
WARNING Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION Hazards or unsafe practices that may result in minor personal injury or property damage.
WARNING
fContact service center for installation.
- There is a risk of product malfunction, water leakage, electric shock or fire.
fInstall theWi-Fi kit firmly on the place that can withstand the weight of the product.
- If the installation location is not strong enough, remote controller may fall and get damaged.
fConnect the power with rated voltage when installing.
- If not, there is risk of fire or damage to the Wi-Fi kit.
fDo not attempt to move or re-install theWi-Fi kit that is already installed.
- There is risk of electric shock and fire.
fDo not attempt to modify or repair theWi-Fi kit on your own.
- There is potential risk of product damage, electric shock or fire. When repair is needed, consult service center.
fCheck if the installation was done properly according to the installation manual.
- If the Wi-Fi kit is installed incorrectly, there is risk of electric shock or fire.
fMake sure that all wiring work is done by qualified person complying regional standards and instructions in this manual.
- If the installation is done by unqualified person, there is risk of product malfunction, electric shock or fire caused by
incorrect installation.
fContact the service center if you need to dispose the Wi-Fi kit.
CAUTION
fDo not install the product in a place where it is or might be exposed to inflammable gas leakage.
- There is risk of fire or explosion.
fDo not install the product in a place where it will be exposed to oil or vapor etc.
- If the product is used in a place where it is exposed to oil, vapor or sulphur dioxide, parts of the product may get
damaged or product may function abnormally.
fMake sure that water does not get into the Wi-Fi kit.
- There is risk of electric shock and fire.
fMake sure there is no tension to the cable during installation.
- Cable may get cut and cause fire.
fInstall the product in a place with temperature between 0°C~39°C with no direct sunlight.
- If not, there is risk of electric shock or abnormal operation.
fDo not install the product in a place where special spray or acid/alkali solution is used.
- There is risk of electric shock or abnormal operation.
fDo not press the button with sharp object.
- There is risk of electric shock or damaging the parts.
fDo not connect the power cable to the communication cable terminal.
- There is risk of fire.
fWhen installing the product in hospitals or other places, make sure that the product does not interrupt with other
products.
- Abnormal operation may occur.
CAC WiFi Kit APP_03384A(1).indd 3 2012-10-12 오후 3:37:08

4
Check before installing Wi-Fi kit
Parts
AssyWi-Fi kit Cable tie (2) Cable clamp (3) M4×16 screw (5)
User & Installation manual U- terminal (6)
• Wi-Fi kit should be installed by a certified installer.
• Before installing a Wi-Fi kit, you should check whether the power of the kit is turned off.
• The wire of Wi-Fi kit should be installed in accordance with electric wiring regulation and should also be installed
inside the wall so that it cannot be touched by users.
Exterior dimension
120
124
27.7
(Unit : mm)
CAUTION
CAC WiFi Kit APP_03384A(1).indd 4 2012-10-12 오후 3:37:08

5
How to install Wi-Fi kit
Wi-Fi kit installation
• For smooth operation, install the Wi-Fi kit and the wireless router in open space with no obstacles between them.
Operation may not be possible if the distance between the Wi-Fi kit and the wireless router is too far or if there's any
obstacle between them.
1. After pushing the two hooks on the bottom of theWi-Fi kit at the same time, lift the front cover up and then detach if
from the rear cover.
❋ Push the two hooks at the same time.
• It might be easier to disassemble the Wi-Fi kit if you put a flat-head screw driver
into the square hole above the fixing hook.
2. Place the power wire and communication wire to fittings in the rear cover.
<When the cover is not buried> <When the cover is buried>
15cm 10cm
It can be detached if you need
more space.
CAUTION
NOTE
CAC WiFi Kit APP_03384A(1).indd 5 2012-10-12 오후 3:37:09

6
How to install Wi-Fi kit
3. After fixing the rear cover of a Wi-Fi kit firmly into the wall with two or more screws, connect the power wire(V1, V2) and
communication wire(F1, F2) to the terminal at the back side of the front cover with proper length.
• Centralized controller and the Wi-Fi kit cannot be used together.
10mm or
more
10mm or more
50mm or more
10mm or more
Screw
fixing
hole
Rear cover
❋ Before fixing the rear cover, allow
10mm or more space for upper,
left, and right sides and 50mm
space for bottom side.
❋ You should fix the screws into the
screw fixing holes.
❋ Do not tighten the PCB terminal with
too much force.
V1V2 F1 F2
Wi-Fi kit
PCB terninal
4. Reassemble theWi-Fi kit.
• Put the front cover of the kit into the upper grooves first and then fit it as shown in the picture. After
assembling theWi-Fi kit, please check if there is any gap because of the connection cable between front
cover and rear cover.
• When installing aWi-Fi kit with 10m or more wire, the communication wire and power wire of aWi-Fi kit should be
installed separately. (The Wi-Fi kit will malfunction because of electrical fault. )
• When installing aWi-Fi kit on the wall, select proper thickness of wires in the consideration of the hole size for wire
on the wall.
• Wire for Wi-Fi kit PCB connection
- When installing aWi-Fi kit in a buried way, install the kit in accordance with U-terminal wiring regulation.
- When installing aWi-Fi kit with 4-line PVC wires, peel 30cm of the sheath for the PVC wire and use only 4-line
wires. (Recommnendation: AWG21)
• Specification of compressed U-terminal for connectingWi-Fi kit PCB
W
t
G
E
F
L
Stud D
Wire range for
connection
Rated
size
Stud
size Basic size(mm)
AWG mm2mm2mm t ΦD G E F W L
22~16 0.25~
1.65 1.5 3 0.7 3.8 10.0 4.5 6.5 6.0 21.2
The maximum distance for connection between communication wire and power wire: 50m
• Tighten the fixing screws for a PCB terminal with less than 6Nm torque. When the screws are tightened with more
than 6Nm torque, the screw thread will be damaged.
NOTE
NOTE
CAUTION
CAC WiFi Kit APP_03384A(1).indd 6 2012-10-12 오후 3:37:10

7
5. Setting an indoor unit installation option
fWi-Fi kit is an optional item, therefore Wi-Fi kit usage option(SEG5) is set to 'Disable' as factory default setting.If you install
the Wi-Fi kit separately, you must set the Wi-Fi kit usage option(SEG5) as shown in the below table to use it normally.
fInput the setting option more than twice.
fFor proper operation, reset the power after inputting the option.
❋ Be aware of the fact that Wi-Fi kit will not operate properly if you only install the Wi-Fi kit but don't set the model option.
1) Set the indoor unit installation option by wired remote controller.
Main Menu Sub-menu 1 2 3 54 6
Data bit
1 2 3 4 5 6
Option CodePage number
SEG1 SEG2 SEG3 SEG4 SEG5 SEG6
0

Page number
SEG7 SEG8 SEG9 SEG10 SEG11 SEG12
1
Page number
SEG13 SEG14 SEG15 SEG16 SEG17 SEG18
2

Page number
SEG19 SEG20 SEG21 SEG22 SEG23 SEG24
3
Page number
In order to check and set the indoor unit installation option code use the wired remote controller and follow the directions
below.
1. Press the and buttons at the same time for more than 3 seconds and then a Main menu will be displayed.
2. Press the / button to select and then press button to enter a Sub-menu setting screen.
3. Press the / button to select and then press button to enter a Indoor unit installation option code setting
screen.
• The first digit represents the page number and the remaining five digits are installation option.
• The total option codes are 24 digits. You can set six digits at a time and it is distinguished by page number (0, 1,
2, 3).
NOTE
4. Press the / button to set the installation option code in order. Press button to go to the next page.
CAC WiFi Kit APP_03384A(1).indd 7 2012-10-12 오후 3:37:11

8
How to install Wi-Fi kit
Option No. : 02XXXX-1XXXXX-2XXXXX-3XXXXX
Option SEG1 SEG2 SEG3 SEG4 SEG5 SEG6
Explanation PAGE MODE
RESERVED
Use of external
temperature sensor
Use of central control or
Wi-Fi kit
RESERVED
Indication
and Details
Indication Details Indication Details Indication Details Indication Details
0 2 0 Disuse 0 Disuse
1 Use 1 Use
Option SEG7 SEG8 SEG9 SEG10 SEG11 SEG12
Explanation PAGE Use of drain pump
RESERVED RESERVED RESERVED
Master / Slave
Indication
and Details
Indication Details Indication Details Indication Details
1
0 Disuse 0 slave
1 Use 1 master
2
Use +
3minute
delay
- -
Option SEG13 SEG14 SEG15 SEG16 SEG17 SEG18
Explanation PAGE Use of external
control
Setting the output of
external control S-Plasma ion Buzzer control Number of hours using filter
Indication
and Details
Indication Details Indication Details Indication Details Indication Details Indication Details Indication Details
2
0 Disuse 0 Thermo
on 0 Disuse 0 Use of buzzer 2 1000 Hour
1ON/OFF
Control 1Operation
on
1Use 1 Non use of
buzzer 6 2000 Hour
2OFF
Control
Option SEG19 SEG20 SEG21 SEG22 SEG23 SEG24
Explanation PAGE control of a remote
controller
Heating setting
compensation
RESERVED
Motion detect sensor
RESERVED
Indication
and Details
Indication Details Indication Details Indication Details Indication Details
3
0 or 1 Indoor 1 0 Disuse 0. No Use (Factory Setting)
1. Standard Mode/Auto
Set OFF30 Min.
2. Standard Mode/Auto
Set OFF60 Min.
3. Standard Mode/Auto
Set OFF 120 Min.
4. Standard Mode/Auto
Set OFF 180 Min.
5. Premium Mode/
Auto Set OFF30 Min.
6. Premium Mode/
Auto Set OFF60 Min.
7. Premium Mode/Auto
Set OFF 120 Min.
8. Premium Mode/Auto
Set OFF 180 Min.-
2 Indoor 2 1 2°C
3 Indoor 3
2 5°C
4 Indoor 4
5. Press the button to save and complete the option setting.
6. Press the button to exit to normal mode.
• Press button anytime during setup to exit without setting.
• Option code will not be applied if you don't press button.
• Setting Installation option code is available only with a master wired remote controller.
• Setting Installation option code is available when there is one on one connection between a wired remote
controller and an indoor unit.
NOTE
CAC WiFi Kit APP_03384A(1).indd 8 2012-10-12 오후 3:37:11

9
2) In order to check and set the indoor unit installation option code use the wireless remote controller
High Temp Button High Fan Button
Mode change
Low Temp Button Low Fan Button
Entering mode for
option setting
Option setting mode
1. Remove batteries from the remote controller.
2. Insert batteries and while you press [+ Temperature] and [-Temperature] button at the same time.
3. Check if you have entered the option setting status.
4. After entering the option setting status, select the option as listed below.
Step 2. The procedure of option setting
After entering the option setting status, select the option as listed below.
Option setting is available from SEG1 to SEG 24
• SEG1,SEG7,SEG13,SEG19arenotsetaspageoption.
• SettheSEG2~SEG6,SEG8~SEG12asONstatusandSEG14~18,SEG20~24asOFFstatus.
SEG1 SEG2 SEG3 SEG4 SEG5 SEG6 SEG7 SEG8 SEG9 SEG10 SEG11 SEG12
0XXXXX1XXXXX
SEG13 SEG14 SEG15 SEG16 SEG17 SEG18 SEG19 SEG20 SEG21 SEG22 SEG23 SEG24
2XXXXX3XXXXX
On(SEG1~12) O(SEG13~24)
CAC WiFi Kit APP_03384A(1).indd 9 2012-10-12 오후 3:37:12

10
How to install Wi-Fi kit
The procedure of setting option
Operation Indication
* Step 1
1. Remove the batteries from the remote controller.
2. Insert batteries while pressing High Temp Button and Low Temp Button.
* Step 2
1. Press LowFan Button to enter SEG2 value.
2. Press High Fan Button to enter SEG3 value.
* Step 3
PressModeButtontobechangetoCoolmodeintheONstatus.
1. Press Low Fan Button to enter SEG4 value.
2. Press High Fan Button to enter SEG5 value.
* Step 4
PressModeButtontobechangedtoDRYmodeintheONstatus.
1. Press Low Fan Button to enter SEG6.
2.PressHighFanButtontoenterSEG8.
* Step 5
PressModeButtontobechangedtoFANmodeintheONstatus.
1.PressLowFanButtontoenterSEG9value.
2.PressHighFanButtontoenterSEG10value.
* Step 6
PressModeButtontobechangedtoHEATmodeintheONstatus.
1. Press Low Fan Button to enter SEG11 value.
2. Press High Fan Button to enter SEG12value
*Step7
Press Mode Button to be changed to AUTO mode in the OFF status.
1. Press Fan button to enter SEG14 value.
2. Press High Fan Button to enter SEG15 value.
*Step8
Press Mode Button to be changed to Cool mode in the OFF status.
1. Press Low Fan Button to enter SEG16 value.
2.PressHighFanButtontoenterSEG17value.
*Step9
Press Mode Button to be changed to DRY mode in the OFF status.
1.PressLowFanButtontoenterSEG18value.
2.PressHighFanButtontoenterSEG20value.
*Step10
PressModeButtontobechangedtoFANmodeinOFFstatus
1. Press Low Fan Button to enter SEG21 value.
2. Press High Fan Button to enter SEG22 value.
*Step10
Press Mode button to be changed to HEAT mode in the OFF status
1. Press Low Fan Button to enter SEG23 value.
2. Press High Fan Button to enter SEG24 value.
* Step 11
Press operation button to enter option.
CAC WiFi Kit APP_03384A(1).indd 10 2012-10-12 오후 3:37:12

11
Option SEG1 SEG2 SEG3 SEG4 SEG5 SEG6
Explanation PAGE MODE
RESERVED
Use of external
temperature sensor
Use of central
control or Wi-Fi kit
RESERVED
Indication
and
Details
Indication Details Indication Details Indication Details Indication Details
020Disuse 0Disuse
1 Use 1 Use
Option SEG7 SEG8 SEG9 SEG10 SEG11 SEG12
Explanation PAGE Use of drain
pump
RESERVED RESERVED RESERVED
Master / Slave
Indication
and
Details
Indication Details Indication Details Indication Details
1
0Disuse 0slave
1 Use 1 master
2
Use +
3minute
delay
- -
Option SEG13 SEG14 SEG15 SEG16 SEG17 SEG18
Explanation PAGE
Use of external
control
Setting the output
of external control S-Plasma ion Buzzer control
Numberofhours
using lter
Indication
and
Details
Indication Details Indication Details Indication Details Indication Details Indication Details Indication Details
2
0Disuse 0
Thermo
on
0 Disuse 0
Use of
buzzer
2 1000Hour
1
ON/OFF
Control
1
Operation
on
1 Use 1
Use of
buzzer
6 2000Hour
2
OFF
Control
Option SEG19 SEG20 SEG21 SEG22 SEG23 SEG24
Explanation PAGE
control of remote
controller
Heating setting
compensation
RESERVED
Motion detect
sensor
RESERVED
Indication
and
Details
Indication Details Indication Details Indication Details
Indication Details
3
0or1 Indoor 1
0Disuse
0. No Use (Factory
Setting)
1. Standard Mode/Auto
Set OFF30 Min.
2. Standard Mode/Auto
Set OFF60 Min.
3. Standard Mode/Auto
Set OFF 120 Min.
4. Standard Mode/Auto
Set OFF 180 Min.
5. Premium Mode/
Auto Set OFF30 Min.
6. Premium Mode/
Auto Set OFF60 Min.
7. Premium Mode/Auto
Set OFF 120 Min.
8. Premium Mode/Auto
Set OFF 180 Min.--
2 Indoor 2
1 2°C
3 Indoor 3
2 5°C
4 Indoor 4
Option No. : 02XXXX-1XXXXX-2XXXXX-3XXXXX
CAC WiFi Kit APP_03384A(1).indd 11 2012-10-12 오후 3:37:12

12
Installing network
[Connecting Network]
Connect the wireless IP router to an air conditioner.
[Registering service]
Access the http: //global.samsungsmartappliance.
com and register the service.

Checking before using a wireless router
❋ This Wi-Fi Aircon support only below three encryption.
- Open (No encryption), WPA/TKIP, WPA2/AES
fFor Wi-Fi Aircon installation, select indoor unit location near to wireless router. In caseWi-Fi signal strength is weakened,
Smart App. may be disconnected depending on the Wi-Fi signal strength.
fSmart-Phone should be in theWi-Fi signal zone to use Smart App.
fFor Mobile broadband internet access, Smart App. can be used when Mobile Broadband Dongle is activated to use Wi-Fi.
fThis product supports only DHCP(Dynamic Host Configuration Protocol ). If users use an existing wireless router, the
DHCP server option function should be activated.
fSelect a channel for the wireless router that is not currently being used.
fIf a wireless router is connected by other than the above modes, the router may not be connected with the air
conditioner or may not work.To use 802.11n, usingWPA2/AES is recommended.
fThe quality of wireless network connection can be affected by the surrounding wireless environment.
fIf an internet service provider has permanently registered the users PC or MAC address (a unique identifying number),
the air conditioner might not be connected to internet. When appliances other than a PC are to be connected to Internet,
ask your ISP (Internet service provider) about the procedures required to connect to the internet.
fIf your internet service provider requires an ID or a password to connect to the internet, your air conditioner may not be
able to connect to the internet. If this is the case, you must enter your ID or password when connecting to the internet.
fThe internet connection may fail because of a firewall problem. If this is the case, contact your internet service provider.
fIf you cannot connect to the internet even after you have followed the procedures of your internet service provider,
please contact a samsung service center.
Connecting network
Connecting the wireless IP router with an air conditioner
fFor wireless router installation, refer to the user manual of the
corresponding router.
fSamsung smart air conditioner supports the communication protocols
of IEEE802.11 b/g/n(2.4Ghz).
fFor wireless router installation, refer to the user manual of each
manufacturing company.
Samsung does not provide customers with the wireless router manual.
fUncertified router may not be able to connect with an air conditioner.
fWhen the wireless router is not connected to internet, 'Out-of-home'
control will not be available and reserve function will also not work
properly with 'In-home' control.
fCertified router has the logo of below on the package or user manual.
Wall LAN terminal
LAN cable
Wireless router
(The router that supports DHCP server.)
CAC WiFi Kit APP_03384A(1).indd 12 2012-10-12 오후 3:37:12

13
Connecting network
Checking the Wi-Fi kit
Power LED
AP Button
Wi-Fi Connect LED
WPS Button
Wi-Fi Configure LED
<Wi-Fi kit front view>
LED status information
fPower LED
- According to the power On/Off of a Wi-Fi kit, LED will be On/Off.
- When there is a communication error, the LED will blink at an interval of 500ms.
fWi-Fi Connect LED
- Off : WhenWi-Fi is not connected with a wireless router
- 500ms Blink :WhenWi-Fi is connected with a wireless router but internet has not been connected
- On : WhenWi-Fi is connected with both a wireless router and internet without a problem.
fWi-Fi Configure LED
- When a wireless router operates in AP mode: The LED will blink at intervals of 2sec, On, 1sec, Off.
- When a wireless router operates in WPS mode:The LED will blink at intervals of 4sec, On, 1sec, Off.
- When authentication function is in operation: When you press 'AP' button for 5 seconds for authentication, the LED will
blink at an interval of 250ms for 10 seconds.
CAC WiFi Kit APP_03384A(1).indd 13 2012-10-12 오후 3:37:12

14
Connecting network
Checking network
Check whether the wireless router connects with a smart phone.
When the internet is not connected with a smart phone, the network function of the air conditioner cannot be used.
1. Search for the wireless router on the smart phone.
2. Select the wireless router you are using now on the searched wireless router list.
3. Check whether the smart phone can access the website http://global.samsungsmartappliance.com
• If you need ID and Password to use the internet at commercial building, inform the network administrator of MAC
address of your air conditioner and get the approval of internet use for the air conditioner.
• If private program installation of ISP is needed for internet use, the air conditioner cannot be connected with the
internet.
NOTE
CAUTION
CAC WiFi Kit APP_03384A(1).indd 14 2012-10-12 오후 3:37:13

15
Connecting the wireless router with an air conditioner by the network (Select one of the 2 methods)
Connecting network withWPS setting
Preparation
• Please check whether a wireless router supportsWi-Fi Protected Setup TM(WPS).
• Check whether the wireless router has the 'WPS' ( ) button.
❋ Samsung smart air conditioner uses only PBC method ofWPS.
1. Press the 'WPS' button of aWi-Fi kit.
- When the kit is in normal operation, LED 2 will go off and LED 3 will blink at an interval of 4sec and 1sec.
2. Press the 'WPS' button of a wireless router.
• Since the way to operate the wireless router in WPS mode may vary according to wireless router manufacturer,
please refer to the manual of corresponding manufacturer
For certain wireless routers, if you press the 'WPS' button for a long time, the set value of the wireless router may be
initialized. Please be careful about that.
3. When setting is done successfully, LED 2 of a Wi-Fi kit will blink according to Wi-Fi connection status.
- When setting a wireless router with WPS function, one wireless router can be set with only one device at the same time.
- When setting multiple devices, each device should be set separately.
- When operatingWPS mode according to each wireless router feature, the setting information of a wireless router such
as SSID will change automatically, which can disconnect all the connection with current devices. Therefore, please refer
to the manual of a corresponding wireless router.
Connecting network with a Smart phone APP
Setting application on Samsung smart phone (Android based smart phone )
• Android based smart phone users can download the Smart A/C application by searching‘Smart Air Conditioner’at
Android market(Google Play Store) or Samsung Apps.
Use the‘Smart Air Conditioner(CAC)’from the searched applications.
3
2
1
1. Connect the power cable of the air conditioner and then press the‘AP’button on the side of theWi-Fi kit.
Check if the‘AP/WPS’lamp on the front panel blinks.
2. After operating Smart A/C application, press the [Network Setting] tab.
3. Press the [Setting Start] tab.
NOTE
NOTE
NOTE
CAC WiFi Kit APP_03384A(1).indd 15 2012-10-12 오후 3:37:13

16
Connecting network
4
56
4. Select the wireless router that you are using now.
- When using free wireless router, refer to the corresponding user manual for password.
5. After entering the password of selected wireless router, press the [OK] tab.
- When the password has not been set, press the [OK] tab without entering the password.
6. When 'Transfer complete' pop up comes on, press the [OK] tab.
- When the air conditioner is connected with wireless router correctly, the second LED of Wi-Fi kit ( ) will be On.
- After connecting the wireless router with the air conditioner and when the second LED of Wi-Fi kit ( ) blinks, check
the internet connection status.
7. After 2minutes, if the Wi-Fi LED of the air conditioner is still on, it means the configuration has succeeded. At this point,
you can use smart phone to control the system.
• When searching a network by pressing 'AP' button, third LED ( ) will be on for a maximum of 5 minutes.
• Smart A/C application is optimized with Samsung smart phones. Supported models are; Galaxy S, Galaxy S2, Galaxy
Note, Galaxy S2 HD LTE, GalaxyTab 7.0 and Galaxy tab 10.1 and other models can be added in the future.When the
Smart A/C application is used with other smart phones, some functions may not work.
NOTE
CAC WiFi Kit APP_03384A(1).indd 16 2012-10-12 오후 3:37:13

17
Setting application on iPhone
• iPhone users can download the Smart A/C application by searching‘Smart Air Conditioner’at Apple App store.
Use the‘Smart Air Conditioner(CAC)’from the searched applications.
5
4
1
1. Connect the power cable of the air conditioner and then press the‘AP’button on the side of theWi-Fi kit.
2. Check if the‘AP/WPS’lamp on the front panel blinks.
3. Select [Settings] [Wi-Fi] on your iPhone.
4. From the list ofWi-Fi, select SMARTAIRCON and enter‘1111122222’as password.
5. After operating Samsung Smart A/C application, press the [Network Setting] tab.
NOTE
CAC WiFi Kit APP_03384A(1).indd 17 2012-10-12 오후 3:37:13

18
Connecting network
6
7
8
6. Press the [Setting Start] tab.
7. Enter the information of wireless router and press the [OK] tab.
- Required information is; SSID, Security type, Encryption type and Password.
• If you do not know the information of wireless router, check its manual or contact your ISP (internet service
provider).
8. When 'Transfer complete' pop up comes on, press the [OK] tab.
9. Select [Settings] [Wi-Fi] on your iPhone.
10. Select the wireless router that you are using, and enter the password.
- When the air conditioner is connected with wireless router correctly, the second LED of Wi-Fi kit ( ) will be On.
- After connecting the wireless router with the air conditioner and when the second LED of Wi-Fi kit ( ) blinks, check
the internet connection status.
11. After 2 minutes, if theWi-Fi LED of the air conditioner is still on, it means the configuration has succeeded. At this point,
you can use smart phone to control the system.
• When searching a network by pressing 'AP' button, third LED ( ) will be on for a maximum of 5 minutes.
• Supported models are; iphone4, iphone4S. and other models can be added in the future.
NOTE
NOTE
CAC WiFi Kit APP_03384A(1).indd 18 2012-10-12 오후 3:37:14

19
Registering service
Registering an air conditioner
1. Access Samsung Smart appliance website (http://global.samsungsmartappliance.com).
2. Enter the User ID and Password to log in.
- If you don’t have an account, press [Create a Samsung account] and fill in the form to become a member.
3
3. Select [My page][My page].
4
4. Select [Add device] .
CAC WiFi Kit APP_03384A(1).indd 19 2012-10-12 오후 3:37:14
