Samsung HM1600 User manual

HM1600

English ..............................................................................1
Français ..........................................................................23

English
1
Contents
Getting started
Your headset overview ......................................................................... 4
Button functions.................................................................................... 5
Charging the headset ........................................................................... 6
Wearing the headset ............................................................................ 8
Using your headset
Turning the headset on or off................................................................ 9
Pairing and connecting the headset ................................................... 10
Pairing via the Active pairing feature .................................................. 13
Using call functions............................................................................. 14
Appendix
Frequently asked questions................................................................ 17
Certication and Safety approvals ..................................................... 19
UL certied travel adapter .................................................................. 20
Warranty and parts replacement ........................................................ 21
Specications ..................................................................................... 22

2

English
3
Please read all Safety precautions before using your headset to ensure safe and
proper use.
Safety precautions
When using your headset while driving, follow local regulations in the region you are in.•
Never disassemble or modify your headset for any reason. Doing this may cause the•
headset to malfunction or become combustible. Bring the headset to an authorized service
center to repair it.
Keep your device and all accessories out of the reach of small children or animals. Small •
parts may cause choking or serious injury if swallowed.
Avoid exposing your device to very cold or very hot temperatures (below 0° C or above 45° C).•
Extreme temperatures can cause the deformation of the device and reduce the charging
capacity and life of your device.
Do not allow your device to get wet — liquids can cause serious damage. Do not handle•
your device with wet hands. Water damage to your device can void your manufacturer’s
warranty.
Avoid using your device’s light close to the eyes of children or animals.•
Do not use the device during a thunderstorm. Thunderstorms can cause the device to•
malfunction and increase the risk of electric shock.
Excessive exposure to sound at high volumes can cause hearing damage. Always
turn the volume down before plugging the earphones into an audio source and use
only the minimum volume setting necessary to hear your conversation or music.

4
Getting started
This section explains what to remember for the proper use of your Bluetooth
headset.
Your headset overview
Make sure you have the following items with your headset: travel adapter, ear•hook, ear rubbers and user manual.
The items supplied with your headset may vary depending on your region.•
Charger jack
Earpiece
Volume button
Indicator light
Talk button
Ear hook
Power button
Microphone

English
5
Button functions
Button Function
Power Press and hold to turn the headset on or off.
Talk
Press and hold to enter•Pairing mode.
Press to make or answer a call.•
Press to end a call.•
Volume
Press to adjust the volume.•
Press and hold to turn the microphone on or off.•
In Pairing mode, press and hold the Volume up button•
to turn the Multi-point feature on.
In Pairing mode, press and hold the Volume down•
button to turn the Multi-point feature off.

6
Charging the headset
This headset has a rechargeable internal battery which is non-removable. Ensure
that you fully charge the battery before using the headset for the rst time.
1Connect the travel adapter to the headset (see below image).
2Plug the travel adapter in to the wall outlet.
During charging, the indicator light will turn red. If charging does not begin,
unplug the travel adapter and plug it in again.
3When the headset is fully charged, the indicator light changes to blue. Unplug
the travel adapter from the power outlet and the headset.

English
7
Use only Samsung-approved chargers. Unauthorized chargers may cause an • explosion or damage to the headset.
The battery will gradually wear out while charging or discharging because•it is a consumable part.
When a call comes in while charging, disconnect your headset from the charger•and answer the call.
When the battery charge gets low
The headset beeps and the indicator light ashes red. Recharge the battery. If the
headset powers off during a call, the call will be automatically transferred to the phone.
Checking the battery level
At the same time, press and hold the Volume down and the Talk button. Depending
on the battery level, the indicator light ashes 5 times in one of the following colors:
Battery level Indicator light color
Above 80% Blue
80 ~20% Violet
Below 20% Red

8
Wearing the headset
Place the headset on your ear. Depending on which ear you are going to wear the
headset, simply adjust the ear hook accordingly.
Right
Left
Handle the headset properly to improve performance
Do not block the device’s internal antenna. The human body can interfere with a•Bluetooth signal.
If you usually use your mobile phone with your right hand, wear the headset on•your right ear.
Avoid coming in contact with the internal antenna of a headset or mobile for a•better performance.

English
9
Using your headset
This section explains how to turn the headset on, pair and connect to the phone,
and use various functions.
Activated functions and features may differ depending on the phone type.•
Some devices, especially those that are not tested or approved by Bluetooth SIG, • may be incompatible with your headset.
Turning the headset on or off
To turn the headset on, press and hold the power button. The blue indicator light•
ashes 4 times.
To turn the headset off, press and hold the power button. The indicator light•
ashes red then turns off.

10
Pairing and connecting the headset
Pairing will create a unique and encrypted wireless link between two Bluetooth
enabled devices, such as a Bluetooth phone and a Bluetooth headset.
To use the headset with other Bluetooth phones, the devices must be paired. When
trying to pair the two devices, keep the headset and the phone reasonably close together.
After pairing, the two devices will connect automatically when switched on.
Pairing and connecting the headset with a phone
1Enter pairing mode.
With the headset turned on, press and hold the Talk button until the blue•
indicator light stays lit.
If you turn on the headset for the rst time, it proceeds into Pairing mode •
immediately.
2Activate the Bluetooth feature on your phone and search for the headset
(see your phone’s user manual).
3 Select the headset (HM1600) from the list of devices found by your phone.
4Enter the Bluetooth PIN (0000, 4 zeros) to pair and connect the headset
to your phone.

English
11
Your headset supports the Simple Pairing feature which allows the headset to be
paired with a phone without requesting a PIN. This feature is available for phones
that are compliant with Bluetooth version 2.1 or higher.
The headset also can be paired via the Active pairing feature, see page 13.
Connecting with two Bluetooth phones
With the Multi-point feature activated, your headset can be connected with two
Bluetooth phones at the same time.
1 After connecting with the rst Bluetooth phone, press and hold the Talk button
until the blue indicator light stays lit.
2Press and hold the Volume up button to activate the Multi-point feature.
3Activate the Bluetooth feature on the second Bluetooth phone and search
for the headset (see your phone’s user manual).
4 Select the headset (HM1600) from the list of devices found by the second
Bluetooth phone.
5Enter the Bluetooth PIN (0000, 4 zeros) to connect the headset to the phone.
6Turn the headset off and on. When the headset turns on, it automatically
connects with the two Bluetooth phones.

12
When the headset connects to two Bluetooth phones, some phones may not connect
to the headset as the second Bluetooth phone.
Disconnecting the headset
To disconnect the headset from your phone,
Turn off the headset.•
Use the Bluetooth menu on your phone.•
Reconnecting the headset
When the headset is already paired with phones, it will attempt to automatically
reconnect each time you turn it on.
If the headset does not automatically attempt to reconnect,
Press the Talk button.•
Use the Bluetooth menu on your phone.•
If the Multi-point feature is deactivated, your headset will reconnect only to a primary
phone. To turn Multi-point feature on or off, see page 5.

English
13
Pairing via the Active pairing feature
With the Active pairing feature, your headset can automatically search for
a Bluetooth phone and try to make a connection with it.
This feature is available for mobile phones, but the phone’s Bluetooth visibility option
must be set to on.
1Turn on the headset.
2Press and hold the Talk button to enter Pairing mode.
3Press and hold the Talk button until the violet indicator light turns on.
The headset will switch to Active Pairing mode, search for a Bluetooth phone
within range, and attempt to pair with it.
Ensure the phone you wish to connect to is within range of the headset. Place•the headset and phone close to each other to avoid pairing with other devices.
The headset will attempt Active pairing for up to 20 seconds.•
This feature may not be available on some PDA’s.•
The Bluetooth phone you want to connect with must not be paired with other•devices. If the phone is already connected to another device, end the connection
and restart Active pairing feature.

14
Using call functions
Available call functions may vary by the phone.•
*This function is available only on the Hands-Free prole. For more information, • see your phone’s user manual.
Making a call
Redialing the lastest number
Press and hold the Talk button to redial the latest number of the most recently
connected phone.
Press the Talk button twice to redial the latest number of the other phone.
For some phones, pressing the Talk button opens the call log list. Press the Talk
button again to dial the selected number.
Dialing a number by voice
Press the Talk button and say a name. You can dial a number of the rst phone.
Answering a call
Press the Talk button to answer a call when you hear incoming call tones.
When two calls from the two connected phones come in, you can answer the call
of the rst phone.

English
15
Ending a call
Press the Talk button to end a call.
Rejecting a call*
Press and hold the Talk button to reject a call when a call comes in.
When two calls from the two connected phones come in, you can reject the call
of the rst phone.
Using options during a call
You can use the following functions during a call.
Adjusting the volume
Press the Volume up or down button to adjust the volume.
You can hear a beep when the volume level of the headset reaches it’s lowest or
highest leve.
Muting the microphone
Press and hold the Volume up or down button to turn the microphone off so that
the person with whom you are speaking cannot hear you. When the microphone
is turned off, the headset beeps at regular intervals. Press and hold the Volume up
or down button again to turn the microphone back on.
Transferring a call from the phone to the headset
Press the Talk button to transfer a call from the phone to the headset.

16
Placing a call on hold*
Press and hold the Talk button to place the current call on hold.
When the headset is connected with two phones, this function is not available.
Answering a second call*
Press the Talk button to end the rst call and answer a second call of the •
same phone when you hear call waiting tones.
Press and hold the Talk button to place the rst call on hold and answer a second •
call of the same phone when you hear call waiting tones.
To switch between the current call and the held call, press and hold the Talk button.•
When the headset is connected with two phones, you cannot answer a second call of
the same phone.
Answering a new call of the second phone*
Press the Talk button to end the rst call and answer a second call of the other •
phone when you hear call waiting tones.
Press and hold the Talk button to place the rst call on hold and answer a second •
call of the other phone when you hear call waiting tones.
To switch between the current call and the held call, press and hold the Talk button.•

English
17
Appendix
Frequently asked questions
Will my headset work
with laptops, PCs, and
PDAs?
Your headset will work with devices that support
your headset’s Bluetooth version and proles.
For specications, see page 22.
Why do I hear static
or interference while
on a call?
Appliances such as cordless phones and wireless
networking equipment may cause interference, which
usually sounds like static. To reduce any interference,
keep the headset away from other devices that use or
produce radio waves.
Will my headset
interfere with my
car’s electronics,
radio, or computer?
Your headset produces signicantly less power than
a typical mobile phone. It also only emits signals that
are in compliance with the international Bluetooth
standard. Therefore, you should not expect any
interference with standard consumer-grade electronics
equipment.

18
Can other Bluetooth
phone users hear
my conversation?
When you pair your headset to your Bluetooth phone,
you are creating a private link between only these two
Bluetooth devices. The wireless Bluetooth technology
used in your headset is not easily monitored by third
parties because Bluetooth wireless signals are signicantly
lower in radio frequency power than those produced
by a typical mobile phone.
Why do I hear an echo
while on a call?
Adjust the headset volume, or move to another area
and try again.
How do I clean
my headset?
Wipe it with a soft dry cloth.
The headset does
not fully charge.
The headset and the travel adapter may not have
been connected properly.
Separate the headset from the travel adapter,
reconnect, and charge the headset.
