Samsung Yepp YP-700 User manual

AH68-00966E
http://www.samsungelectronics.com.hk
YP-700
YP-700
2X P3
emory Expansion Slot
P3 & W A Playback
F Remote Controller(Option)
Voice Recording Function
High Speed USB
D.I.Y. Support
Upgradeable
Service centre
Samsung Customer Service Centre
11/F Phase 2, TL Warehouse Building
Berth One, Kwai Chung, NT, Kowloon, Hong Kong
Tel: [phone]
Fax: [phone]
e-mail: [email protected]
HK-cover 12/23/02 4:54 PM Page 2

32
Using the Charger
- A charger is provided with yepp.
- Use only approved battery and charger.
Insert the rechargeable battery into the battery slot.
❈ Make sure that you put the polarity of the battery
in the right direction.
Plug the charger into a wall outlet.
❈ The charger should be used at right power source.
(refer to the label on charger
❈ Red light indicates that battery is being charged.
❈ Green light indicates that battery is fully charged
after charging about 4 hours.
❈ When light color changes to green, remove the rechargeable
battery from the charger within one hour.
WW
WWaa aarr rrnn nnii iinn nngg gg :: ::
 Never use any charger or battery that is damaged in any way.
 After charging the rechargeable battery, disconnect charger from power source.
 Do not overload the outlet or extension cords.
The battery can be charged and discharged hundreds of times, but it will gradually wear out.
When the operation time is noticeably shorter than normal, it is time to buy a new battery.
Don’t charge the rechargeable battery over 24 hours.
Overcharging or overdischarging will shorten the life of the rechargeable battery.
To use the rechargeable battery for long time, repeat full charging and full discharging.
When using the rechargeable battery for the first time or when left unused for a long time,
charge it fully before using it again.
Do not short-circuit the battery. Accidental short circuiting can occur when a metallic object
(coin, clip or pen causes a direct connection between the + and - terminals of the battery.
Short-circuiting the terminals may damage the battery.
1
2
SAFETY(Charger)
Safety symbols information
RISK OF ELECTRIC SHOCK
DO NOT OPEN
!
!
CAUTION
This symbol indicates uninsulated material within your unit
may cause an electrical shock. For the safety of everyone
in your household, please do not remove product covering.
The symbol calls attention to features for which you should
read the enclosed literature closely to prevent operating
and maintenance problems.
WW
WWAA AARR RRNN NNII IINN NNGG GG:: ::TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE
THIS EQUIPMENT TO RAIN OR MOISTURE.
CC
CCAA AAUU UUTT TTII IIOO OONN NN:: ::To prevent electic shock, match wide blade of plug to wide slot,
and fully insert.
yp-700-eng-HK 12/23/02 4:51 PM Page 2

5
4
Contents
SAFETY(Charger ................................................................................................................2
Using the Charger ................................................................................................................3
Features ................................................................................................................................6
Components ..........................................................................................................................9
Location of Controls (yepp ..................................................................................................10
Location of Controls (Remote Controller ............................................................................12
Inserting the Battery..............................................................................................................14
Using the SmartMedia Card ................................................................................................15
Preparations
Listening to Music with yepp ................................................................................................16
Setting up Volume/Hold Functions ......................................................................................17
Changing Modes ..................................................................................................................18
Recording Voice ..............................................................................................................19
Searching for Music/Voice Files ..........................................................................................20
FM Listening Function(Option ............................................................................................22
Basic Usage
Loop Repeating ....................................................................................................................24
Setting up MENU..................................................................................................................25
Repeating Tracks ................................................................................................................26
Setting up EQ ......................................................................................................................28
Managing Files ....................................................................................................................30
Customizing Options (Display ............................................................................................34
Searching Quickly For Music/Voice Files ............................................................................37
Additional Usage
How to use yepp Explorer ....................................................................................................49
Copying Files to yepp (PC ..................................................................................................50
Downsizing MP3 ..................................................................................................................52
Copying Files to yepp (Mac ................................................................................................54
Deleting Files (PC ..............................................................................................................56
Deleting Files (Mac ..............................................................................................................57
Formatting (PC ..............................................................................................................58
Formatting (Mac ..............................................................................................................59
Uploading Files (PC ............................................................................................................60
Uploading Files (Mac ..........................................................................................................61
Rearranging Files ..............................................................................................................62
Installing CD Ripper ............................................................................................................63
Software Usage
Description of Buttons (yepp player ....................................................................................64
MENU Table ........................................................................................................................66
Appendix
Precautions ..........................................................................................................................68
Troubleshooting....................................................................................................................69
Security ..............................................................................................................................70
Specifications........................................................................................................................71
Custo er Support
Connecting yepp to PC ........................................................................................................38
Manual Installation of USB Driver ........................................................................................42
Connecting yepp to Mac ......................................................................................................46
Connection to Co puter
yp-700-eng-HK 12/23/02 4:51 PM Page 4

Farewell to shortage
2X MP3
2X MP3
MP3 compression technology that allows you to downsize your
MP3 files via software.
Expectation
Upgradeable
Upgradeable
You can upgrade the built-in programs if necessary.
ex Add functions, CODEC, etc.
Please refer to the yepp home page (http://www.samsungelectronics.com.hk
when you need to upgrade your yepp.
Endless Drea for Expansion
Me ory Expansion Slot
Me ory Expansion Slot
You can expand 8MB~128MB by adding a SmartMedia card.
Polyphagous player
MP3 & WMA
MP3 & WMA Playback Playback
MP3 is an MPEG1 Layer3 audio format.
WMA is a Microsoft Windows Media audio format.
Joy of Life
FM Re ote Controller(Option)
FM Re ote Controller(Option)
Capable of storing 5 stations
My yepp
D.I.Y
D.I.Y. .
● Setting up EQ
● Decorating LOGO
● Changing LCD Font
● Adjusting Scroll speed
● Adjusting Contrast
yp-700-eng-HK 12/23/02 4:51 PM Page 6

9
Components
YR-20FS
FM
Player
Earphone
Remote Controller
Rechargeable Battery
(1.2V NI-MH (Option
User’s Guide Carrying case
● SmartMedia Card(3.3V and Disposal Battery(AAA type are not included.
● Design of accessories is subject to change for improvement without notice.
Battery Pack
USB Cable Installation
CD
Charger
(Option
Powerful yepp'
Playing T
Playing Ti e i e
This unit uses a NI-MH rechargeable battery
Operation can last 20 hours (AAA alkaline battery + rechargeable battery
The Light of the Light Wow!
Backlight High Speed USB
Backlight High Speed USB
Blue-color backlight Download speed Max. 5Mbps
Exciting
Sound
Sound
You can adjust equalizer manually.
Making Valuable Record
V
Voice Recording Function oice Recording Function
Suitable for recording lectures and meetings
Model
Built-in memory
YP-700i
192MB
YP-700H
128MB
YP-700S
64MB
yp-700-eng-HK 12/23/02 4:51 PM Page 8

10 11
Location of Controls (yepp)
Front Rear
Display
USB Cable
Connection Port
Battery Cover
Memory Expansion Slot
Auxiliary Battery Pack
Connection Port
Hold Switch Remote Controller/Earphone Jack Microphone
Play/Stop/Pause/
Forward/Backward
Button
Voice Recording
Button
Volume Buttons
MENU/Mode/Loop
Repeating Button
yp-700-eng-HK 12/23/02 4:51 PM Page 10

Location of Controls (Remote Controller)
12 13
Display
YR-20FS
FM
Re ote Controller Connection
1
Insert the remote controller plug
into the remote controller jack on the
top of the yepp player.
2
Insert the earphone plug into
the earphone jack on the remote
controller
Remote Controller
Player
Models with FM
(Option)
Model without FM
(Option)
YR-20FS
FM
Hold Switch
Earphone Jack
Stop/Power Off
Button
Volume Control
Dial
FM Mode
Button
REW/FF
Button
Power On/
Play/Pause
Button
Display
Equalizer/
Repeating
Button
Loop Repeating
Button(A-B
YR-20S
Hold Switch
Earphone Jack
Stop/Power Off
Button
Volume Control
Dial
REW/FF
Button
Power On/
Play/Pause
Button
Display
Equalizer/
Repeating
Button
Loop Repeating
Button
yp-700-eng-HK 12/23/02 4:51 PM Page 12

1514
Inserting the Battery
Using the Rechargeable Battery
Using a Disposal Battery
◗
Open the battery cover by pushing it
in the direction of the arrow. Insert the battery into the groove and make
sure that you put the polarity of the battery in
the right direction. Close the battery cover by
pushing it in the direction of the arrow.
Open the battery pack cover in the
direction of arrow.
Insert the battery correctly and close
the battery pack cover.
1
12
2
Plug the battery pack into the
extension battery connection port.
3
◗
Using the Smart edia Card
Your yepp player allows you to expand memory capacity by adding a SmartMedia card.
Insert the SmartMedia
card into the memory
expansion slot on your
yepp player in the
direction of the arrow.
Inserting the
S artMedia card Ejecting the
S artMedia card
Confirm the SmartMedia
card mark is displayed on
the display.
Push the SmartMedia card again
in the direction of the arrow to
take out the SmartMedia card
from the slot.
NN
NNoo oott ttee ee :: ::
Do not insert/eject the SmartMedia card during playback of music/voice files.
Make sure to turn off the player before inserting/ejecting the SmartMedia card.
Use 3.3V SmartMedia cards only.
SmartMedia cards of 8MB~128MB can be used.
Do not touch the metal face of the SmartMedia card.
◗ ◗
12 3
3.3V
Player
Remote Controller
yp-700-eng-HK 12/23/02 4:51 PM Page 14

17
Setting up Volume/Hold Functions
16
Listening to usic with yepp
First, insert a battery and connect the earphones and the remote controller to the player.
Playing Music
(Power On) Stopping Music (Power Off)
When you press the button(yepp player /
the button(remote controller , the yepp
logo appears and a music/voice file is played.
When you press the button
(yepp player or the button(remote controller
while playing, the music stops.
If no buttons are pressed within 5 seconds, the
yepp automatically powers off.
NN
NNoo oott ttee ee :: ::
If the button on remote controller is pressed while
playing, yepp is paused.
WMA file can be played only at a bit rate between 48Kbps
and 192Kbps.[supplied by Windows Media Player (Ver 8.0 ]
Adjusting the Volu e
HOLD Function
HOLD function on the player
Press the button on the side of the yepp
player to adjust the volume while playing.
NN
NNoo oott ttee ee :: :: Volume ranges from 00 to 30.
Press briefly to adjust step by step.
Press and hold to adjust continuously.
Under Hold mode, no buttons work.
Slide the switch on the player in
the direction of the arrow.
❈ Then no buttons on the yepp player will work.
Only the remote controller buttons will work.
❈ When a button is pressed, “Hold” message
will appear on the display.
❈ The mark will appear on the display.
HOLD function on the re ote controller
Slide the switch on the re ote
controller in the direction of the arrow.
❈ The mark will appear on the display.
No buttons on the remote controller will work.
(Volume control dial will work.
Only the yepp player buttons will work.
◗◗ ◗◗
◗
Player Player Remote Controller Remote Controller
yp-700-eng-HK 12/23/02 4:51 PM Page 16

19
Recording Voice
18
Changing odes
Press the MODE button on the yepp player or the A-B button on the remote
controller in STOP mode.
Music Mode Voice Mode FM Mode(Option)
To Record Voice
➡
FM Mode button is
available on the remote
controller only.
Press the REC button(player in STOP mode.
Use the button to select built-in
memory/SmartMedia card and start recording
using the REC or button
1
Press the button to pause while recording.
Press the button again to resume recording.
2
Press the REC button to stop recording.
A new voice file is created.
The Voice messages are recorded on the built-in memory
in order of VI001, VI002...., or they will be recorded on the
SmartMedia card in order of VS001, VS002....
3
NN
NNoo oott ttee ee :: ::
When the recording function does not work well, format the relevant memory first before starting recording again.
Voice recording function button is available on the player only.
Do not take out or insert the SmartMedia card while voice recording is under way.
When memory is full, recording stops automatically.
(The available time is displayed on the right of display(player when recording begins.
◗
◗
◗
◗
Button on the remote controller
Player Player
Player
Remote Controller
Remote Controller
Remote Controller
Œ
´
ˇ
yp-700-eng-HK 12/23/02 4:51 PM Page 18

21
Searching for usic/Voice Files
20
Searching for Specific Parts in PLAY Mode
Press and hold the button while playing to find
the part you want to listen to.
Release the button to resume playing.
Searching for Music/Voice
Files in PLAY Mode.
Press the button briefly while playing
to advance to the next track.
Press the button briefly within 5 seconds
from the start of the track to play the previous
track. Press the button briefly after 5
seconds from the start of the track to play the
beginning of the current track.
Searching for Music/Voice Files
in STOP Mode.
Press the button in STOP mode to
skip to the previous or next track.
Press the button to play.
NN
NNoo oott ttee ee :: ::
With VBR files, pressing the
button within the first 5 seconds of
the start of track may not result in
the previous track playing.
With VBR files, the actual running
time may differ from that of the
player display.
VBR(Variable Bit Rate file:
MP3 file whose compression rate
changes when played.
◗
◗
◗
yp-700-eng-HK 12/23/02 4:51 PM Page 20

23
F Listening Function(Option)
22
Turn on the power of yepp and connect the remote controller.
➡
Switching to FM Mode
To Save a Radio Station
Press the MODE button
on the remote controller.
Manual Searching for
FM Frequency
Press and hold the
button on the remote
controller.
Auto search for frequency
will start.
Press the button
briefly on the remote
controller.
Manually set the frequency
that you want.
NN
NNoo oott ttee ee :: ::
Only buttons on the remote controller will work in the FM mode.
In FM mode, you can’t connect yepp to a computer.
Backlight function of the remote controller display will not work in the FM mode.
To exit FM mode, press the MODE button.
NN
NNoo oott ttee ee :: ::
Up to five stations(a, b, c, d, and e can be saved.
You can replace one station with another at each saved location, but it is not possible to delete a saved station.
Press the A-B button to access the saved location directly.
Press the EQ/REP button on the
remote controller for the radio station
frequency that you want to store.
1
Press the A-B button to select
the location to save.
 Select one of the following locations: a, b, c, d, or e
 The radio station frequency is saved in the chosen location
2
Press the EQ/REP button to save a
Radio Station.
3
Select the location to save a Radio Station Save a Radio Station
◗
◗
▼▼
Player
Remote Controller Remote Controller
Remote Controller
Auto atic Searching for
FM Frequency
yp-700-eng-HK 12/23/02 4:51 PM Page 22

25
Setting up ENU
24
Loop Repeating
Loop Function
Starting Point
While playing music/voice files,
press the MODE button briefly
(yepp player / the A-B button
(Remote controller at the
beginning of the loop you want to
set.
flickers in the display.
NN
NNoo oott ttee ee :: ::
Press the MODE button briefly (yepp player / the A-B button (Remote controller to cancel the loop.
Ending Point
Press the MODE button briefly
(yepp player / the A-B button
(Remote controller at the end of
the loop.
appears in the display.
The loop is played repeatedly.
Play ode : To select track repeating mode.
Equalizer : To use equalizer function.
Play list : To select files to listen to.
File : To delete or format music/voice files.
Setting : To change the basic setup options of the display.
Track : To search for the file quickly.
Exit enu : To exit MENU.
Press and hold the MODE button on the yepp player to switch to MENU ode.
Use the button to select and the button to move.
Press the MODE button one more time to cancel the MENU mode.
NN
NNoo oott ttee ee :: ::
In MENU, Go up can be used to exit the current setting.
In MENU mode, no input for 10 seconds will cancel the MENU mode.
3. Play list
2. Equalizer
1. Play ode 1. Play ode
4. File
2. Equalizer 2. Equalizer 3. Play list 4. File
5. Setting 5. Setting
6. Track 6. Track 7. Exit enu
◗ ◗ ◗
◗ ◗ ◗
yp-700-eng-HK 12/23/02 4:51 PM Page 24

2726
Repeating Tracks
Track Repeating Function On the yepp Player
In MENU, select 1.Play ode.
1
In PLAY MODE, use the button to move to the mode you
want and press the button to select.
Each time the EQ/REP button is pressed and held, the mode will change in
order of REP, ALL, SHU, INT and Nor al.
2
● Nor al: To play all the tracks in order one time.
● Repeat one: To repeat one track.
● Repeat all: To repeat all tracks.
Repeats one track only.
Repeats all tracks.
Enables random playback.
Enables yepp to repeat the first 10 seconds of each track.
● Shuffle: To play tracks at random.
● Intro: To play the first 10 seconds of
each track.
One
intro
Nor.
All
2. Repeat one
Nor al Nor al
2. Repeat one 2. Repeat one
3. Repeat all
3. Repeat all
4. Shuffle 4. Shuffle 5. lntro
◗ ◗
◗ ◗
On the Re ote Controller
REP
ALL
SHU
INT
NN
NNoo oott ttee ee :: ::
Normal mode is not indicated on the display.
yp-700-eng-HK 12/23/02 4:51 PM Page 26

29
28
Setting up EQ
In MENU, select 2. Equalizer.
1
In EQ, use the button to move to the setting you
want (out of the 8 settings and press the button to select.
If you want manual equalizer, select User and Bass/Treble.
2
NN
NNoo oott ttee ee :: ::
DBB is for Dynamic Bass Booster, which enhances bass response.
NN
NNoo oott ttee ee :: ::
DBB and User cannot be accessed with the remote controller.
Normal mode is not indicated on the display.
Nor.
Nor. DBB
Clas Jazz Rock
Clas Jazz Rock
DBB DBB DBB
Normal Classic Jazz Rock
Normal-DBB Classic-DBB Jazz-DBB Rock-DBB
EQ Function On the yepp Player
On the Re ote Controller
Each time the EQ/REP button is pressed, briefly, the mode will change in
order of Classic, Jazz, Rock, and Nor al.
yp-700-eng-HK 12/23/02 4:51 PM Page 28

30 31
Listening to Files Selected in Play List
In MENU, select 3. Play list
1
In PLAY LIST, select the mode (Music or Voice to use Play list and select On.
2
PLAY LIST
MENU
2. Equalizer
3. Play list 1. Music
2. Voice
MUSIC
On
2. Off
Without you Ma
When Play list is selected, is displayed on yepp player.
Press the button to play the file saved in Play list.
3
◗ ◗
anaging Files
Editing Play List
In MENU, select 3. Play list
1
In PLAY LIST, select the mode (Music or Voice
to edit and select Edit.
Select Delete to erase play list.
2
Move to the file to add to
Play list and press the
button to add. The file is added
to Play list.
Press the button again to cancel.
3
Select Confir to save
Play list.
Select Cancel not to save Play list.
4
PLAY LIST
MENU
2. Equalizer
3. Play list 1. Music
2. Voice
PLAY LIST
2. Off
Edit
2: Without you Ma
01 : My love for hot
EDIT
01 : My love for hot
EDIT
02 : Without you Ma
5: Confir
6: Cancel
EDIT
◗ ◗
◗
➡
Continued...
yp-700-eng-HK 12/23/02 4:51 PM Page 30

3332
For atting
In MENU, select 4. File
1
In FILE, select For at and the memory to format.
Select Cancel to exit the mode.
2
NN
NNoo oott ttee ee :: ::
You can also format in yepp Explorer.
All files will be deleted when formatting the memory.
1. Flash
2. SMC
◗
◗ ◗
Deleting
In MENU, select 4. File
1
In FILE, select Delete and
the mode (Music or Voice
the target file is in.
2
Move to the file to delete and
press the button to select.
The file is deleted.
3
Select Go up ➞ Cancel to
exit the mode.
4
◗◗
yp-700-eng-HK 12/23/02 4:51 PM Page 32

3534
Display ➞ 1. Infor ation
 Play ti e: displays current play time
 Re ain ti e: displays remaining play time
 Total ti e: displays total play time
Display ➞ 2. Logo
Default: "yepp" logo
User define: displays user-defined logo
None: displays no logo.
 Co pression: displays compression rate
 Free e ory: displays remaining memory
Default Setting ex User defined setting
NN
NNoo oott ttee ee :: ::
yepp homepage (http://www.samsungelectronics.com.hk offers a program to edit
the user defined logo. You can download from SUPPORT.
You can’t use yepp logo Editor on Mac.
Customizing Options (Display)
Setting Function
In MENU, select 5. Setting
1
In SETTING, use the button to move to the function you want to
change and select the function by using the button.
2
2. Backlight
SETTING
1. Display
SETTING
2. Backlight
3. Scroll speed
SETTING
4. Contrast
5. Go up
SETTING
3. Scroll speed
4. Contrast
SETTING
1. Display
2. Backlight
◗ ◗
◗
◗
➡
Continued...
yp-700-eng-HK 12/23/02 4:52 PM Page 34

37
Searching Quickly For usic/Voice Files
36
Track function
In MENU, select 6. Track
1
In TRACK, select the memory or the track to listen to first.
When Direct flash is selected, first track in flash memory is played first.
When Direct SMC is selected, first track in SMC is played first.
2
When DIRECT TRACK is selected, select the track number by using
the button. When the button is pressed, playback starts
from the selected track number.
3
2. Direct SMC
TRACK
1. Direct flash
TRACK
1. Direct flash
2. Direct SMC
TRACK
2. Direct SMC 3. Direct Track
DIRECT TRACK
◗
◗
◗
Backlight
Press the button to set
the backlight “ON” time.
When a button is pressed, backlight
will stay on for the time you set.
Scroll speed
Press the button to set
the scroll speed.
Contrast
Press the button to set
the contrast.
◗◗
◗
yp-700-eng-HK 12/23/02 4:52 PM Page 36

39
Connecting yepp to PC
38
Before connecting yepp to PC, ake sure to install
yepp Explorer. If “Add New Hardware Wizard” appears,
press the [Cancel] button and install yepp Explorer.
Insert the Installation CD into CD-ROM drive.
The window shown below appears.
Select [yepp Explorer Install].
1
Click [Next] in the series
of windows that appear.
2
When installation is completed,
connect yepp to PC and use it
as shown on next page.
Syste Require ents.
Pentium 133MHz or greater
Windows 98/ME/2000/XP
20MB of available hard disk space
CD-ROM drive
(double speed or greater
USB port supported
VGA graphic
Installing software
➡
Continued...
yp-700-eng-HK 12/23/02 4:52 PM Page 38
