Samsung YP-C1X User manual

- MP3, WMA , Audio ASF and Ogg Playback
- Removable Storage Device
- Direct MP3 Recording
- USB 2.0 Support
- Upgradable
- 42 Hours of Continuous Play
- Voice Recording Function
YP-C1
SAMSUNG ELECTRONICS CANADA, INC.
HEADQUARTERS
55 Standish Court Mississauga, Ontario L5R 4B2 Canada
TEL: [phone]
www.samsung.ca
SERVICE DIVISION
55 Standish Court Mississauga, Ontario L5R 4B2 Canada
1-800-SAMSUNG (1-800-726-7864)
AH68-01694S (Rev 0.0)

3
ContentsContents
2
Safety Instructions................................................................................................................................................4
Features ..............................................................................................................................................................6
Components ........................................................................................................................................................8
Location of Controls ............................................................................................................................................9
IPreparations
Playing Music and Turning Off the Device ........................................................................................................28
HOLD Function ..................................................................................................................................................29
Recording Voice ................................................................................................................................................29
Recording MP3s ................................................................................................................................................30
Searching for Music/Voice Files ........................................................................................................................32
Setting Bookmark ..............................................................................................................................................33
Listening to FM Radio .......................................................................................................................................34
FM Recording ....................................................................................................................................................36
IBasic Usage
Connecting the player to PC ..............................................................................................................................11
Manual Installation of USB Driver......................................................................................................................15
Using the removable storage(PC)......................................................................................................................18
●Downloading/Uploading files ........................................................................................................................18
●Disconnecting the USB cable........................................................................................................................18
●Formatting ....................................................................................................................................................19
Installing Media Studio ......................................................................................................................................20
Using Media Studio............................................................................................................................................21
IConnection to Computer
Loop Repeating..................................................................................................................................................36
MENU Options ..................................................................................................................................................37
Using Navigation................................................................................................................................................38
Setting Playlist....................................................................................................................................................41
Setting the Advanced Functions ........................................................................................................................42
Selecting the Playmode......................................................................................................................................43
Setting the EQ mode..........................................................................................................................................44
●Preset EQ......................................................................................................................................................44
●Bass Booster ................................................................................................................................................44
●WOW Set ......................................................................................................................................................45
●User EQ Set..................................................................................................................................................46
Display Settings..................................................................................................................................................47
●Scroll / Display Time......................................................................................................................................47
●Backlight / Contrast ......................................................................................................................................48
●Tag / Bitrate ..................................................................................................................................................49
Language Settings ............................................................................................................................................50
Setting the System ............................................................................................................................................51
Recording Settings ............................................................................................................................................54
Time Settings......................................................................................................................................................55
Managing Files ..................................................................................................................................................56
To Upgrade Firmware ........................................................................................................................................57
IAdditional Usage
Troubleshooting..................................................................................................................................................60
Specifications ....................................................................................................................................................62
Warranty ............................................................................................................................................................65
ICustomer Support
MENU Table ......................................................................................................................................................59
IAppendix

5
Safety InstructionsSafety Instructions
4
IEarphones
Follow Traffic Safety Instructions
● Do not use the earphones while driving an automobile or riding a bicycle.
It’s not only dangerous, but also against the law.
●It may cause an accident if you turn up the volume of the earphones while walking.
especially when crossing intersections.
Protect your ears
● Do not turn up the volume too high. Doctors warn against prolonged exposure to high volume.
● Stop using the device or turn the volume down if you have ringing in your ears.
IAmbient operating conditions
● Ambient temperature : 5°C ~ 35°C (41°F ~ 95°F)
Humidity : 10 ~ 75%
IEnvironmental Information
● Follow local guidelines for waste disposal when discarding packages, batteries,
and old electronic appliances.
● Your player is packaged with cardboard, polyethylene etc., and does not use any unnecessary materials.
Read and understand all the instructions to avoid injury to yourself and damage to the equipment.
Do not expose to extreme temper-
atures (above 95°F or below 23°F).
Do not expose to moisture.
Do not subject the unit to severe
impact, or place heavy objects
on it.
Do not let any foreign matter spill
into the device.
Be careful not to subject the play-
er to excessive pressure when
wearing it round your neck.
Do not expose to chemicals such
as benzene and thinners.
Remove batteries when the
device is left unused for a long
period of time.
Do not expose to direct sunlight
or heat sources.
Do not store in dusty areas. Do not try to disassemble and
repair the device yourself.
✽ Please be aware that we claim no responsibility for damage from data loss
due to breakdown, repair or other causes.

7
FeaturesFeatures
6
MP3, WMA , Audio ASF and Ogg Playback
●The player supports playback of MP3, WMA, Audio ASF and Ogg.
Removable Storage Device
●You can easily copy and paste files to the player using Windows Explorer.
Direct MP3 Recording
●You can convert music from CDs, cassettes, and radio into
MP3 files without a PC.
FM Reception
●Listening to an FM program is made easy with Auto Search and
Frequency Memory functions.
SRS WOW Surround Sound
●The 3D surround feature adds spaciousness to the sound.
USB 2.0 Support
●Maximum data speed transfer of 18 Mbps.
Upgradeable Firmware
●You can upgrade the built-in programs when available.
Please check the home page (www.samsung.ca) for upgrades.
42 Hours of Continuous Play
●This player uses one AA/LR6 alkaline battery. Operation can last up to 42hours.
Actual playing time may vary according to the type and capacity of the battery.
Voice Recording Function
●You can make high quality voice recordings.

9
Location of ControlsComponents
8
● The capacity of the useable built-in memory is less than indicated as the internal firmware
uses a part of the memory as well.
● Design of accessories is subject to change for the purposes of improvement, without notice.
Model
Built-in memory
YP-C1 H
128MB
YP-C1 V
256MB
YP-C1 X
512MB
YP-C1 Z
1GB
Continued...
User manual
Installation CD
Neck Strap
Recording Button Play/Pause Button
Hold Switch
Loop Repeating Button
Neck strap
Hook
Earphone Jack Battery Cover
ENC/USB Cable Connection Port
Move to Track/Speed Search
Move to Track/Speed Search
Volume Up Button
Volume Down Button
Microphone
Display MENU, Navigation button
Line In/USB
Carrying Case
Earphone
Player
One Battery
(1.5V AA/LR6 type)

11
Connecting the player to PCLocation of Controls
10
The PC system must meet the
following specifications:
● Pentium 200MHz or greater
● Windows 98 SE/ME/2000/XP
● 40MB of available hard disk space
● CD-ROM drive
(double speed or greater)
● USB port (2.0) supported
● VGA graphic
▲System Requirements.
IDisplay
IInserting a Battery
1 Slide the cover in the direction of
the arrow to open.
2 Insert a battery to the right poles
+ , – and push-close the cover in
the direction of the arrow as indicated.
NN
NNoo oott ttee ee
- Do not place heavy objects on the cover.
✍
NN
NNoo oott ttee ee
- The screen pictures are for illustration purposes only. The actual screen may differ.
✍
NN
NNoo oott ttee ee
- Install the operating system in Administrator Account
(main user) for Windows 2000 or XP.
Otherwise, installation will not be completed.
- Windows ME, 2000 and XP can recognize the driver
without installing the provided program. However,
you must install the program in order to format the
player and upgrade firmware.
- If the YP-C1 program has not been installed in
Windows 98, then it will not communicate with your
removable disc. You must install the USB driver file first.
✍
Continued...
Title (track & artist) indicator
Play/Stop/Pause indicator
Track play indicator
Indicate next track
Track Number indicator
Remaining Battery Power indicator
Play mode indicator
Equalizer, SRS indicator
Playtime indicator
➀➁
I Installing software
1Insert the Installation CD
into the CD-ROM drive.
Select [Install Player USB Driver].
Before connecting the player to PC, make sure to install USB driver. If “Add New Hardware
Wizard” appears, press the [Cancel] button and install the USB driver.

13
Connecting the player to PC
12
1 Connect the USB cable to the USB port on the computer.
2 Connect the other end of the USB cable to the USB cable connection port on
the bottom of the player.
● If you disconnect the USB cable from your PC while implementing a
command or initializing during USB driver installation, your PC may not
function correctly.
3 The USB driver is installed with a message saying that it is searching for a new
device. You may not see the display screen during installation.
Go to the device manager to check that installation has been successfully
completed.
4 Upon installation of the USB driver "Samsung YP-C1 USB Device" will appear in
the [System Properties] ➝[Device Manager].
IConnecting the player to PC with the USB cable
Continued...
Connecting the player to PC
USB Cable
2 Follow the instructions in the window to complete the installation.

15
Manual Installation of USB DriverConnecting the player to PC
14
How to check USB driver
How to check USB driver
Windows 98:
Control Panel ➝ System ➝ Device Manager ➝ Disk Drives ➝ Samsung YP-C1
Windows 2000:
Control Panel ➝ System ➝ Hardware ➝ Device Manager ➝ Disk Drives ➝
Samsung YP-C1 USB Device
Windows XP:
Control Panel ➝ System ➝ Hardware ➝ Device Manager ➝ Universal Serial Bus controllers ➝
Disk Drives ➝Samsung YP-C1 USB Device
5 When the USB driver is not installed automatically, refer to the next page.
NN
NNoo oott ttee ee
- If you are using Windows 2000 and your version of Windows does not recognize the USB driver
please download and install the latest service pack from windowsupdate.microsoft.com
- The installation method may vary depending on the type of PC or operating system.
Contact your PC dealer or service center for installation information.
- If errors occur continuously when you install the USB driver, reconnect the USB cable after
rebooting your system.
✍
IWhen an error occurs installation
of the USB driver
1Check the device manager.
Windows 98,ME:
Control Panel ➝ System ➝ Device Manager
Windows 2000 / XP:
Control Panel ➝ System ➝ Hardware ➝
Device Manager
2Check if there is a device listed with an
exclamation point or a question mark
(displayed as unknown device or USB device).
3Double click on the device listed with an exclamation point or a question
mark.
Go to “Downloading/Uploading files” if the USB driver is installed.
Follow these steps if the USB driver is not installed :

17
Manual Installation of USB DriverManual Installation of USB Driver
16
IIn Windows 98
Follow the instructions in the window to complete the installation.
USB driver location
[CD-ROM]\Win98USB\Drivers
: You must reboot your computer to complete the installation.
NN
NNoo oott ttee ee
- You cannot use it as a removable disc in Windows 98 if the YP-C1 program is not installed.
Make sure to install the USB driver file first.
✍
4After selecting the driver,
click [Update Driver]. 5Click [Next].
6Select [Search for a suitable driver
for my device] and then click [Next]. 7Click [Next] to finish.

19
Using the removable storage(PC)Using the removable storage(PC)
18
IDownloading/Uploading files
IFormatting
1Connect the player to your PC with the supplied USB cable.
2Open Windows Explorer on PC.
● Removable Disc is displayed in Windows Explorer.
3Select the file to save and drag-and-drop it into the removable disk icon.
(In numerical, alphabetical order)
● If you change the name of music files in Windows Explorer like 001* * * , 002* * *...,
music files will be played in the order of number indicated.
2When the
[Stop a Hardware device]
message appears, press
the [OK] button and
disconnect the USB cable.
1Select the removable disc icon
and click the right mouse button
to select [Format].
2Press the [Start] button.
● All saved files will be formatted.
● You can change the name of removable disc
by selecting [Volume label].
IDisconnecting the USB cable
1Double-click on the green arrow in the taskbar on the
bottom right of the window.
NN
NNoo oott ttii iicc ccee ee
- The “WRITING/READING” message will appear during
file download or upload. Disconnecting the USB cable
while “WRITING/READING” is displayed may cause
malfunction of the unit.
- The order of music files is not relative to the replay order
when you select a Removable Disc in Windows Explorer.
✍
NN
NNoo oott ttee ee
- By formatting, all previously preset menus will be initialized.
- Care must be taken as formatted files can not be recovered.
✍
Continued...
After completing the file transfer, you must disconnect the cable in the following way:

21
Using Media StudioInstalling Media Studio
20
1Insert the Installation CD into CD-ROM drive.
Select [Install Samsung Media Studio].
2Select language.
Media Studio is the program that enables you to download music files to the player, and
play back music files on your PC.
3Follow the instruction in the window to complete the installation.
● Click Media Studio icon from the Desktop.
IDownloading Music Files
1Connect the player to PC.
● A device connection window will appear on the right side of the screen.
Select [Device] → [Show device Window] at the top of the screen if device connection
window does not automatically appear.
2Select the folder with the file(s) you want to transfer from the [Library] window.
● The music files within the folder appear on the center of the screen.
Device connection
window
Library
window

23
Using Media StudioUsing Media Studio
22
3When music files appear, select the file(s) you want to transfer,
and then press the [Transfer] button.
● The selected file(s) are transferred to the player.
NN
NNoo oott ttee ee
- Refer to [Help] for more detailed information.
✍
1Connect the player to PC.
2Press the [Device] →[Format] at the top ofthe screen.
3Press the [Start] button when the Format screen appears.
● The memory of the player is formatted and all the saved files will be deleted.
IFormattimg the Player
NN
NNoo oott ttee ee
- Refer to [Help] for more detailed information
✍

25
Using Media StudioUsing Media Studio
24
1Insert your CD including tracks to rip into the CD-ROM drive of your PC.
2Press the [Search Audio CD] button on the lower part of the screen.
● The tracks on the CD are displayed.
3Select tracks to be ripped and press the [Rip a CD] button.
● The selected file is converted into an MP3 file.
● Select [Tools] → [Audio Source Format Conversion Settings] on the top of
the screen to change rip settings.
IRipping Tracks from an Audio CD
NN
NNoo oott ttee ee
- Refer to [Help] for more detailed information.
✍
Change
format
Save path NN
NNoo oott ttee ee
- Refer to [Help] for more detailed information.
✍
1Connect the player to the computer.
2Press the [Create Folder] button at the bottom of device connection window.
3Enter the name of the new folder when an input screen appears.
● A new folder is created.
● If you open a new folder and transfer a file, the file is transferred to the newly
created folder.
ICreating a Folder

27
Using Media StudioUsing Media Studio
26
1Connect the player to the computer.
2Press the [Delete] button at the bottom of the connection windows after
selecting required files or folders from the device connection windows.
3Press the [Confirm] button when an Confirm Deletion screen appears.
● A selected folder or file is deleted.
IDeleting File
NN
NNoo oott ttee ee
- Refer to [Help] for more detailed information.
✍
Press F1 after starting Media Studio.
● Help will appear.
Click on [Help] at the top of the screen.
● Click on [Help] and the Help window will appear.
NN
NNoo oott ttee ee
- Music recognition technology and related data are provided by Gracenote and
Gracenote CDDB
®
Music Recognition Service
SM
.
- CDDB is a registered trademark of Gracenote. The Gracenote logo and logotype, the
Gracenote CDDB logo and logotype, and the "Powered by Gracenote CDDB" logo are
trademarks of Gracenote. Music Recognition Service and MRS are service marks of
Gracenote.
✍

29
HOLD Function Playing Music and Turning Off the Device
28
NN
NNoo oott ttee ee
- If the file name is not displayed correctly, move to [Settings] ➔[Language] ➔[Menu] and then
change the language setting. When the language setting changes, the language in the menu
screen changes accordingly.
- WMA files can only be played as music files with a compression rate of 48Kbps-192Kbps.
- The power off time can be set in the menu.
✍
ITurning Power On and Off
Power On : Press the button to turn on the power.
Power Off : Press and hold the button to turn off the power.
IAdjusting the Volume
Press , to adjust the volume from 00 to 30.
In Hold mode, all buttons are disabled.
Slide the switch in the direction of the arrow.
❈ When the button is pressed, the “ HOLD!” message will appear on the display.
IPlaying Music (Power On)
Press the button.
● Playback starts.
1Press and hold the REC button to start voice recording.
2Press the REC button again to stop the recording and save the voice file.
✽To move to other modes from the Voice mode,
refer to “Changing Mode”.
NN
NNoo oott ttee ee
- The files are recorded in the order of V001,V002......,
and saved as WAV file in the VOICE folder after recording.
- If the Memory is full, Voice Recording is stopped automatically.
- Voice Recording does not work in FM Mode or when the Line In cable is connected.
✍
IPausing Music (Power Off)
Press the button to pause playback.
● If no buttons are pressed within 10 seconds (changes depending on settings),
the player automatically powers off.
● While in Pause mode, press the button again to resume playback.
Recording Voice

31
Recording MP3sRecording MP3s
30
✽To move to other modes from LINE_ENC mode,
refer to “Changing Mode”.
1Connect the Audio Output port on the external audio source
(or the Line Out port) to the ENC port on the device with the Line cable.
2Press and hold the REC button to start MP3 recording.
● If the button is pressed, recording is paused and if the button is pressed again,
the recording resumes.
3If the REC button is pressed during recording, the recording stops and an
MP3 file is created.
● The files are recorded in the order of L001, L002....
and saved as MP3 file in LINE_ENC folder after recording.
NN
NNoo oott ttee ee
- Bit Rates can be set within the range of 32Kbps~128Kbps.
- Volume can be adjusted while monitoring the recording.
✍
NN
NNoo oott ttii iicc ccee ee
- Do not disconnect the Line cable during recording.
- If the battery is not sufficiently charged, the player will not completely record the file.
- Adjust the volume of the external audio source to a suitable level and record it.
If the volume level is too high, the sound quality may be poor.
✍

33
Setting BookmarkSearching for Music/Voice Files
32
● Press and hold , during playback to search for the part you want to listen to.
● Release , to resume play normally.
▲To search for specific parts during play
● Press briefly during playback to play the next track.
● Press briefly within 5 seconds after playback starts, to move to and play the
previous track. Press briefly after five seconds to play the current track from
the beginning.
▲To change tracks during play
● Press , in stop mode to move to the previous/next track.
▲To change tracks when stopped
NN
NNoo oott ttee ee
- VBR(Variable Bit Rate) file: A file that constantly changes the compression rate according
to the type of sounds, such as their pitch, in the file.
- In the case of a VBR file, you cannot move to and play the previous track even if you
press within 5 seconds after playback starts.
- Files that were downloaded in MP2 or MP1 and had their file extension changed to
MP3 may not play.
✍
1Press the REC button briefly during playback.
● “lB” mark will be displayed.
● Press , within the bookmarked file to
move to the bookmarked locations.
● If the bookmark is set, “B” mark is displayed when playing
files that are not bookmarked.
2To remove the bookmark, press the REC button once again at the bookmarked.
● “lB” mark will disappear.

35
Listening to FM RadioListening to FM Radio
34
● Press and hold the A↔Bbutton while in FM Mode.
● Frequencies within the range of 87.5MHz to
108.0MHz are automatically selected and stored.
● Frequencies are automatically stored, starting from 1.
NN
NNoo oott ttee ee
- To exit from FM Mode, press the "M" button.
- Mono (MO) or Stereo (ST) is automatically selected.
✍
IManual Search for a Frequency
First, press the "M" button to display the menu screen and select FM Radio.
● Press , briefly to search manually for
the frequency you want.
IManual Storage of a Frequency
● After searching manually for the frequency you want,
press the A↔Bbutton to display the save screen.
● Press , to select the number you
want to assign to save the frequency and then
press the A↔B button.
IAutomatic Search for a Frequency
● Press and hold , to search for and stop at
frequencies with reception.
IAutomatic Storage of a Frequency
Number of channels saved.
ISearching Stored Frequencies
IDeleting Stored Frequencies
1After moving to the PRESET number you want to delete,
press and hold the A↔Bbutton.
2After selecting the “Y”, press the "M" button.
● The saved PRESET number will be deleted.
NN
NNoo oott ttee ee
- You can store up to 20 frequencies.
- Press the “M” button in the PRESET screen to exit the PRESET mode.
✍
1Press the "M" button in FM Mode.
● PRESET screen will appear.
2Use , to move to the frequency you want.
1Press the button in FM mode.
● ”MUTE” is displayed and no sound is heard.
2Press the button again.
● Mute function is released.
IMute Function

37
MENU Options
Press and hold the "M" button to switch to MENU mode.
Use , to move and press the "M" button briefly to select the menu you want.
Press and hold the "M" button to exit the MENU mode.
NN
NNoo oott ttee ee
- Menu mode will be cancelled if no buttons are pressed within 25 seconds
- Language in the menu screen can be changed in [Settings] →[Language] → [Menu].
✍
● Music : To check the file currently playing.
● FM Radio : To listen to FM radio
● Navigation : To move to Navigation Mode and browse files and folders
● Playlist : To play back only the files you want
● Settings : To set the functions
● Exit : To exit MENU
FM Recording
36
1Press and hold the REC button during FM reception.
● Recording of the currently transmitted FM broadcast begins.
2Press the REC button again.
● A file is created and the recording stops.
● Files are recording in the order F001, F002, F003...and saved as MP3 files in FM_ENC folder.
Loop Repeating
While playing music files, press the A↔Bbutton
briefly at the beginning of the loop you want to set.
A↔appears in the display.
▲Starting Point
Press the A↔Bbutton briefly again to set the
end of the loop.
A↔Bappears in the display.
The loop is played repeatedly.
▲Ending Point
NN
NNoo oott ttee ee
- Press the A↔B button briefly to cancel the loop.
- Loop Repeat is automatically released if you Speed Search with , .
✍
NN
NNoo oott ttii iicc ccee ee
- If the battery is not sufficiently charged, the player will not completely record the file.
✍

39
Using NavigationUsing Navigation
38
IChanging Mode
1Press the "M" button in the
Voice mode.
2Use to move to the upper folder.
You can change the mode in the following method.
Ex) To change from the Voice mode to the Music mode
3Use , to move to the music file you want and press the button.
●As it is changed to the Music mode, the selected file will be played.
NN
NNoo oott ttee ee
- To change to the FM mode, refer to “Menu Options”.
✍
NN
NNoo oott ttee ee
- Press and hold the "M" button in Navigation mode to exit the Navigation mode.
✍
1Press the "M" button to enter Navigation mode.
or press and hold the "M" button to move to Menu and then select
Navigation in Menu.
2Select the file or folder that you want to play.
● : When moving to a higher-level folder.
●: When moving to a lower-level folder.
●, : When moving to a file or folder in the same directory.
●"M" : Move to the next folder down. When there is not a lower folder,
the selected file will be designated as part of the playlist.
3Press the button.
●The selected file will be played.
You can easily search for files or switch modes using the Navigation function.
