SERVICE
Manual
YEPP
Model Name : YP-P3
Model Code : YP-P3JCB/XEE
YP-P3JCB/XEF
YEPP
Refer to the service manual in the GSPN (see the rear cover) for the more information.
CONTENTS
1. Precaution
2. Product Specification
3. Disassembly & Reassembly
4. Troubleshooting
5. Exploded View & Part List
6. PCB Diagram
7. Schematic Diagram
YP-P3

This Service Manual is a property of Samsung Electronics
Co.,Ltd. Any unauthorized use of Manual can be punished
under applicable International and/or domestic law.
GSPN (Global Service Partner Network)
Area Web Site
North America service.samsungportal.com
Latin America latin.samsungportal.com
CIS cis.samsungportal.com
Europe europe.samsungportal.com
China china.samsungportal.com
Asia asia.samsungportal.com
Mideast & Africa mea.samsungportal.com
© Samsung Electronics Co.,Ltd. Jan. 2009
Printed in Korea

Contents
1. Precaution
1-1 Safety Precautions...........................................................................................1-1
1-2 Static Electricity Precautions............................................................................1-2
2. Product Specification
2-1 Product Feature ...............................................................................................2-1
2-2 Specifications...................................................................................................2-2
2-3 Specifications Analysis.....................................................................................2-3
2-4 Accessories......................................................................................................2-5
3. Disassembly & Reassembly
3-1 Disassembly Method........................................................................................3-1
4. Troubleshooting
4-1 Checkpoints by Error Mode..............................................................................4-2
4-2 Upgrade Methods.............................................................................................4-12
5. Exploded View & Part List
5-1 Exploded View .................................................................................................5-2
5-2 Electrical Part List ............................................................................................5-4
6. PCB Diagram
6-1 MAIN PCB Top .................................................................................................6-2
6-2 MAIN PCB Bottom ...........................................................................................6-4
7. Schematic Diagram
7-1 Overall Block Diagram .....................................................................................7-2
7-2 Power Management.........................................................................................7-3
7-3 TCC7801 Power_Block....................................................................................7-4
7-4 TCC7801 I/O Setting........................................................................................7-5
7-5 Memory (SDRAM, NAND-flash).......................................................................7-6
7-6 Audio CODEC..................................................................................................7-7
7-7 24pin I/O, Interface...........................................................................................7-8
7-8 WQVGA LCD Interface ....................................................................................7-9
7-9 Blue-Tooth, FM.................................................................................................7-10

Samsung Electronics 1-1
Precaution
1. Precaution
1-1 Safety Precautions
1. Do not use liquid or an aerosol cleaner when wiping dirt from the case lid. Instead, use a dry cloth.
2. Do not use attachments which the company doesn’t recommend. This may cause danger or damage.
3. Do not use the product near a source of water, e.g., bathtub, bucket, sink, washing machine, swimming pool, or
lake.
4. Power: Use only the type of battery specified on the label.
5. Do not insert any objects or liquid into the product. This may cause failure or malfunctioning.
6. A technician must use standard parts when replacement is required. Using non-standard parts may cause
failure.

1-2 Samsung Electronics
Precaution
1-2 Static Electricity Precautions
Some semiconductor devices may easily be damaged by static electricity. In general these devices are called
Electro-static Devices (ESD). Representative examples of ESDs are IC, FET and semiconductor chips. The
following procedure must be performed to reduce damage to devices due to static electricity.
1. Ensure that all electric charges are discharged from your body by using grounded materials when dealing with
semiconductor devices or equipment with semiconductor devices. Another way is to use a commercialized
anti-static electricity bracelet. It must be removed, however, due to potential impact before applying power to
equipment under testing.
2. After removing an electronic device with an ESD, place it on a conductible surface, e.g., aluminum foil, to
prevent a build-up of electric charge, or exposure of the device.
3. Make sure to use a soldering iron with its end grounded to solder the ESD or to remove soldering.
4. Minimize movements of the body when dealing with an ESD which is not wrapped for replacement.
(Otherwise it may cause static electricity due to unconscious actions, e.g., friction between your clothing,
moving a foot on the carpet.)

Samsung Electronics 2-1
Product Specification
2. Product Specification
2-1 Product Feature
Stylish Slim Design
- 9.9mm Stylish Slim Design
- Tempered glass touch screen + beautiful metal design.
- Wide 3" screen with high portability and multi format playback.
Emoture™2.0 + Widgets + Haptic
- Offers a more convenient touch interface than Emoture™1.0
- Offers color icons and stylish GUI, and enables user to move icons freely.
- The menu screen can be neatly personalized with the widget function using Flash.
- A vibration motor maximizes the feeling of touching the product.
Supports an external speaker
- User can listen to music without earphones anywhere, as an external speaker is supported.

2-2 Samsung Electronics
Product Specification
2-2 Specifications
Basic Specification
Rating DC 5.0V / 1A
Built-in Battery Power 610mAh / DC 3.7V
File Compatibility
AUDIO: MPEG1/2/2.5 Layer3 (8kbps ~ 320kbps, 22kHz ~ 48kHz),
WMA(8kbps ~ 320kbps, 8kHz ~ 48kHz), Ogg (Q-1 ~ Q10),
FLAC (Free Lossless Audio Codec),
AAC-LC (16kbps ~ 256kbps, 8kHz ~ 48kHz),
AAC-Plus (16kbps ~ 256kbps, 16kHz ~ 44.1kHz),
Enhanced-AAC-Plus (16kbps ~ 56kbps, 32kHz ~ 44.1kHz)
VIDEO: AVI/SVI: MPEG-4 Video (480x272) Simple Profile,
MP3 Audio (44.1KHz, 128kbps), WMV: WMV9 Video (480x272)
Simple Profile, WMA Audio, Max bitrate 860kbps
MP4: H.264/AVC Video (480x272) Baseline Profile @ Level 1.3,
AAC/AAC+ Audio
IMAGE: JPEG (Baseline, Progressive), BMP (Max 32bit), PNG,
GIF (89a/87a)
Earphone Output 20mW/Ch. (based on 16Ω)
Output Frequency Range 20Hz ~ 20kHz
Signal to Noise Ratio 89dB with 20kHz LPF (based on 1kHz 0dB)
Play Time
Music: Max. 30hours
(MP3 128kbps, Volume: 15, Normal Sound Mode, LCD Off)
Video : Max. 5hours (Brightness 5, Volume: 15, Normal Sound Mode)
Temperature Range for
Operation -5 ~ 35˚C (23 ~ 95˚F)
Case Tempered glass, Plastic, Aluminum
Weight 96g
Dimensions (WxHxD) 52.7 x 102 x 9.9 mm
Speaker
Rated Output 0.8W Mono
Impedance 8Ω
Frequency
Range 400Hz ~ 20kHz
FM
FM Frequency 87.5 ~ 108.0MHz
FM Signal to
Noise Ratio 45dB
FM T.H.D 0.8%
FM Useable
Sensitivity 5dB

Samsung Electronics 2-3
Product Specification
2-3 Specifications Analysis
Model Name YP-P3 YP-P2
Basic
Storage Type Flash Memory (MLC) Flash Memory (MLC)
LCD Display
Size: 3.0" 16.7M WQVGA
Display Color: 16.7M LCD
(Dot pitch: 0.0455(H) x 0.1365(V))
Resolution: 480RGB(H) x 272(V)
Size: 3.0" 16.7M WQVGA
Display Color: 16.7M LCD
(Dot pitch: 0.0455(H) x 0.1365(V))
Resolution: 480RGB(H) x 272(V)
Platform TCC79x (Telechips) TCC78x (Telechips)
Battery Type Li-Polymer rechargeable battery Li-Polymer rechargeable battery
Battery Capacity Built-in rechargeable battery capacity 610 mAh Built-in rechargeable battery capacity 830 mAh
Playing Time
35 hrs when using the earphones
(MP3 128 kbps, Volume 20, Normal Sound
Mode), Play Movies for 5 hrs
35 hrs when using the earphones
(MP3 128 kbps, volume 20, normal sound
mode), play movies for 5 hrs
Color Black/Silver Black/White/Red Wine
Capacity 4G/8G/16G/32G 2G/4G/8G/16G
Case Tempered glass, Plastic, Aluminum Plastic, Aluminum
Widgets X
Colorful +
Moving GUI
X
HAPTIC X
Speaker Output (Mono) X
Files
Supported
MP3  
WMA  
OGG (up to Q10) (up to Q10)
WAV X X
AAC X
Audible X X
JPEG  
FLAC X
APE X X
WMV  
MPEG4 (SVI)  
SWF X
Others X X
DRM
Netsync (Korea)  
SKT Melon (Korea) X X
WMA DRM  
Janus  
: application, X: non-application

2-4 Samsung Electronics
Product Specification
Model Name YP-P3 YP-P2
Sound
Field
DNSE
DNSE 3.0
(General, Studio, Rock, Classical, Jazz, Ballad,
Club, R&B, Dance, Cafe, Concert, Cathedral)
DNSE 2.0
(General, Studio, Rock, Classical, Jazz, Ballad,
R&B, Dance, Concert)
User EQ (9 Band Control) (9 Band Control)
Street Mode  
Sound Feedback (AUI) (AUI)
High-pitched Sound
Recovery
X
Playlist DNSE X
Speed Control (MP3 file play 0.75~1.3X) (MP3 file play 0.75~1.3X)
Output Power
(Earphone) 20mW/CH 20mW/CH
Output Power
(Speaker) 800mW (Mono) X
Tuner
FM  
RDS  
ETC X X
Additional
Functions
Alarm  
Bluetooth  
Photo Viewer (Slideshow Effect) 
Text Viewer  
Game  
Dictionary  
Wallpaper  
World Clock (Support More) 
Voice Recording  
FM Recording  
Wise Volume
(Hearing Protection)
X
Address Book  
Data Cast  
Flash Player X
Calculator  
TTS (Text to Speech) X
Calendar  
MEMO X
Bookmark TEXT, VIDEO, TTS TEXT, VIDEO
Vive Woofer
(Using Haptic)
(Music, Video) X
Quick Tray (Home Key, Hold, Sound Output, Bluetooth) X
Mini Player (Music, FM) X
: application, X: non-application

Samsung Electronics 2-5
Product Specification
2-4 Accessories
2-4-1 Supplied Accessories
Accessories Item Item code Remark
Earphones AH59-01884A
Samsung Service CenterUSB Cable AH39-00899A
Program Installation CD
XEE AH46-00088C
XEF AH46-00088D

2-6 Samsung Electronics
MEMO

Samsung Electronics 3-1
Disassembly & Reassembly
3. Disassembly & Reassembly
3-1 Disassembly Method
- Be careful to follow the disassembly sequence described in the manual. Otherwise, the product
may be damaged.
- Be sure to carefully read and understand the safety instructions before performing any work as
the IC chips on the PCB are vulnerable to static electricity.
- Assemble in the reverse order of disassembly.
No. Part Name Description Description Photo
1 CABINET-
FRONT
1) Remove the COVER-SCREW on the
top of the CABINET-FRONT.
2) Remove the screw on the top of the
CABINET-FRONT.
: CH,+,M1.4,L2.0,CR PLT,SWRCH18
Make sure not to scratch the
product when using a screwdriver.
2 CABINET-
BACK
1) Remove the CABINET-BACK by
pushing it upward.
Do not apply excessive pressure
on the product, as it may cause
damage to the PCB.

3-2 Samsung Electronics
Disassembly & Reassembly
No. Part Name Description Description Photo
3 CONNECTOR 1) Remove the TSP Connector.
2) Remove the SPK-Module Connector.
4 BATTERY 1) Remove the SPK-Module.
(Remove it by pulling the
disassembly rib at the end.)
2) Remove the BATTERY.
(Remove the double-sided tape and
the battery connector.)

Samsung Electronics 3-3
Disassembly & Reassembly
No. Part Name Description Description Photo
5 MAIN PCB 1) Remove the two screws on the
MAIN PCB.
: CH,+,M1.4,L2.0,CR PLT,SWRCH18
2) Disconnect the LCD connector and
remove the MAIN PCB.
6 LCD 1) Remove the six screws on the LCD.
: CH,+,M1.4,L2.0,CR PLT,SWRCH18
2) Remove the LCD.

3-4 Samsung Electronics
Disassembly & Reassembly
No. Part Name Description Description Photo
7 KNOB-HOLD
/
KNOB-
VOLUME
1) Remove the KNOB-HOLD.
Make sure not to scratch the
product during the removal.
2) Remove the KNOB-VOLUME.
Make sure not to scratch the
product during the removal.
8 SET 1) Picture after completion of
disassembly.

Samsung Electronics 4-1
Troubleshooting
4. Troubleshooting
4-1 Checkpoints by Error Mode ................................................................4-2
4-2 Upgrade Methods.................................................................................4-12

4-2 Samsung Electronics
Troubleshooting
4-1 Checkpoints by Error Mode
Oscilloscope Setting Values
Voltage/DIV 1V/div
TIME/DIV 20us/div
4-1-1 If there is no power
If there is no power
Replace the battery.
Yes
Complete
No
After checking that the IC304 24 pin
is high by pressing the power key,
check voltage - 1.8V at L303
check voltage - 1.04V at L304
check voltage - 3.2V at L305.
If the power is not the problem,
a detailed inspection is required.
N.G.
(detailed inspection)
Yes
Yes
No
No
No
Yes
1. Check that the key
connector is inserted correctly.
2. Press the power key and then check
the IC304 24 Pin HIGH.
(Check the R903 HIGH
signal)
1. Check that the
key connector is inserted correctly.
2. Press the power key and then check
the IC304 24 Pin
HIGH.
Refer to wave pattern
image of Fig. 4-2.
Refer to wave pattern
image of Fig. 4-1.
Charge the battery
with the USB or the adaptor, and then
check that the power is on.
Restore the system
(FWDN) and then check that the
power is on.

Samsung Electronics 4-3
Troubleshooting
FRP
C911 4700nF
LCD_CHECK
CON902
70P,SMD-S
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
C909 4700nF
C927 2200nF
I2C_CLK1
C917 4700nF C919 4700nF C918 4700nF C908 4700nF
C926 2200nF
C913 4700nF
GND
C923 2200nF
FRP
LCD_RST
C920 4700nF
C925 2200nF
R906 33K
C910 4700nF
I2C_DAT1
C924 2200nF
C928 2200nF
C912 4700nF C914 4700nF C916 4700nF C915 4700nF
LED-
LED+
GND
R908
27
P3.2V
R907
150K
LCD_RED2
LCD_GRN0
LCD_RED5
LCD_RED3
LCD_BLU3
LCD_GRN3
LCD_RED4
LCD_GRN1
LCD_GRN4
LCD_BLU0
LCD_RED1
LCD_RED6
LCD_BLU7
LCD_GRN2
LCD_RED0
LCD_GRN6
LCD_GRN7
LCD_BLU6
LCD_BLU5
LCD_RED7
LCD_BLU4
LCD_BLU1
LCD_BLU2
LCD_GRN5
LCD_PCLK
LCD_VSYNC
LCD_HSYNC
LCD_CS
CASIO_SDO
R901 4.7K
C_LSPK+
R910
1K
R905
10K
R902
1K
VOLUME_UP
GND
MOT_MIN
CON901
10P,ST
1
2
3
4
5
6
7
8
9
10
R909
10K
R903 1K
V_DDCON
MOT_PLUS
R900
0
C901
100nF
PWR_IN_DDCON
C_LSPK-
P3.2V
PWR_IN_CPU
VOLUME_DOWN
GND
L900 1000
L901 1000
IC902
?IC903
?
C905
470nF
10V
CON900
2P,SMD-A
1
2
INN_BATT
GND
CON903
EXF-0023-02
C934 4700nF
IC907
?
IC905
?
IC908
?
L903
60
C907 N.C C922 N.C
C900
100nF
16V
C906 100nF
C903 100nF
VDDCON : 3.2V --> 2.42V
5.0V --> 3.79V
BOTTOM
BOTTOM
TOP side Lay-out
BOTTOM
WQVGA LCD Interface, page 7-9
A U O
R 4 0 0
R 4 0 1
R 4 0 3
R 4 0 4
R 4 0 5
R 4 0 7
R 8 0 5
R 8 0 6 R 8 0 7
R 8 1 1
R 8 1 2
R 8 1 4
C 4 0 0
C 4 0 1
C 4 0 2
C 4 0 3
C 4 0 4
C 4 0 6
C 4 0 7
C 4 0 8
C 4 0 9
C 6 0 0
C 6 0 1
C 6 0 2
C 6 0 3
C 4 1 0
C 6 0 4
CON801
C 4 1 1 C 6 0 5
C 4 1 2
CON802
CON803
C 4 1 3
C 6 0 7
C 4 1 4
C 6 0 9
C 4 1 5
C 8 0 0
C 8 0 1
C 8 0 2
C 8 0 3
C 8 0 4
C 8 0 5
C 6 1 2
C 8 0 6
C 6 1 5
C 8 1 0
X-TAL500
Q 3 0 0
Q 3 0 1
Q 3 0 2
Q 3 0 3
Q 3 0 4
Q 3 0 7
D 4 0 0
L 1 0 0
L 3 0 4
L 3 0 5
IC401
L 7 0 0
L 7 0 1
L 7 0 2
L 7 0 3
L 7 0 4
L 7 0 5
IC600
L 9 0 0
L 9 0 1
L 9 0 3
IC800
IC801
IC802
IC803
IC804
IC805
IC806
IC808
IC809
IC810
IC811
IC812
IC813
R 1 0 0
R 1 0 6 R 1 0 7
R 1 0 8
R 3 0 1
R 3 0 4
R 3 0 5
R 3 0 6
R 3 0 8 R 3 0 9
R 5 0 0
R 5 0 1
R 5 0 2
R 5 0 3
R 3 1 0
R 5 0 4
R 3 1 1
R 5 0 5
R 5 0 6
R 5 0 7
R 3 1 3
R 3 1 4
R 5 0 8
R 5 0 9
R 3 1 5
R 3 1 8
R 3 1 9
R 5 1 0
R 7 0 4
R 7 0 5
R 5 1 2
R 7 0 6
R 5 1 3
R 5 1 4
R 3 2 1
R 5 1 5
R 3 2 2
R 5 1 6
R 3 2 3
R 5 1 7
R 9 0 0
R 3 2 4
R 5 1 8
R 9 0 1
R 5 1 9
R 9 0 2
R 9 0 3
R 3 2 7
R 3 2 8
R 9 0 5
R 3 2 9
R 9 0 6
R 7 1 2
R 9 0 7
R 9 0 8
R 5 2 0
R 9 0 9
R 5 2 1
R 5 2 2
R 7 1 6
R 5 2 3
R 3 3 0
R 5 2 5
R 3 3 1
C 1 0 1
R 5 2 6
R 3 3 2
R 9 1 0
R 5 2 8
C 1 0 4
R 3 3 5
R 5 2 9
R 3 3 6
C 1 0 6
R 3 3 7
C 1 0 7
R 3 3 8
R 5 3 0
C 3 0 0
C 3 0 1
R 5 3 2
R 5 3 3
R 5 3 4
R 5 3 5
C 1 1 1
R 3 4 2
R 5 3 6
C 1 1 2
R 5 3 7
R 5 3 8
C 1 1 4
C 3 0 8
R 5 3 9
C 1 1 7
C 1 1 8
C 5 0 0
C 1 1 9
C 5 0 1
C 5 0 2
C 5 0 3
R 5 4 0
C 5 0 4
R 5 4 1
C 5 0 5
R 5 4 2
C 3 1 2
C 5 0 6
C 3 1 3
C 5 0 7 C 1 2 0
C 3 1 4
C 5 0 8
C 5 0 9
C 3 1 6
C 3 1 7
C 3 1 8
C 7 0 0
C 1 2 5
C 3 1 9
C 7 0 1 C 7 0 2
C 5 1 0
C 5 1 1
CON901
C 7 0 5
C 5 1 2
C 7 0 6
CON903
C 3 2 0
C 7 0 8
C 7 0 9
C 9 0 0
C 9 0 1
C 3 2 6
C 9 0 3
C 3 2 8
C 7 1 0
C 9 0 5
C 3 2 9
C 7 1 1
C 9 0 6
C 7 1 2
C 9 0 7
C 9 0 8
C 7 1 4
C 9 0 9
C 3 3 0
C 3 3 1
C 3 3 2
C 3 3 4
C 9 1 0
C 9 1 1
C 9 1 2 C 9 1 3
C 9 1 4
C 9 1 6
C 9 2 0
C 9 2 2
C 9 2 3 C 9 2 4 C 9 2 5 C 9 2 6 C 9 2 7 C 9 2 8
D 3 0 0
VAR800
D 3 0 1
D 3 0 3
D 7 0 1
IC302
IC501
IC502
IC503
IC504
L 8 0 1
IC506 IC507
IC508
IC509
IC700
IC701
IC703
IC510
IC704
IC705
IC511
IC706
IC708
IC902
IC903
IC907
IC908
CON903
CON803
IC302
IC401
IC802
CON801
IC700
IC701 CON802
CON901
IC600
JACK700
12
3
45
MAIN PCB Bottom, page 6-4
<Fig. 4-1>
1
1
1

4-4 Samsung Electronics
Troubleshooting
LED+
EXT_PWR
CPU_RST
CHG_STATUS
JTAG_RST
V_DDCON
INN_BATT P3.2V P5V
P1.8V
P5V
P3.2V
P1.07V
V_DDCON
P3.2V
R337
5.6K
R305
18K
R338
10K
R313
100K
R304
22K
R335
100K
R332 1K
R333
1K
R334
1K
R318 120K
GND
GND
GND
GND
GND
L304
4.7uH
L305
4.7uH
LED-
CHRG_CTL
POWER_OFF
RTC_INT
CHARGE_STOP
CPU_RST
PWR_IN_DDCON
C309
0.1nF
C308
0.1nF
C314
4700nF
C328 1000nF
C330
100nF
16V
C326
0.1nF C325 10000nF
C317 0.1nF
C310 22nF
C311
4700nF
Q307
KRC408V
D301
KDS121V
VAR300
N.C
V_DDCON
L301
4.7uH
C300
4700nF
5V_SPK_CTL
GND
SPK_5V
S/W300
12V
C312
10uF
25V
GND
C319
1000nF
10V
R310
0
R306
0
R315
0
L303
4.7uH
P3.2V
R328
220K
GND
INN_BATT
CORE_VOLT2
CORE_VOLT1
LED_DIMMING
R329
4.7K
R330
100K
GND
Q302
KRC408V
R314
330K
P3.2V
Q300
KRC408V
C301
100nF
BATT_LEV
R301 100K
GND
INN_BATT
Q304
KRA304V
L300
60
R308
47K
D300
KDS121V
C329
10uF
6.3V
C302
10uF
10V
R331 3.3K
D303
RB551V-30
C303
100nF
C306
100nF
C331
100nF
C313
100nF
C322
100nF
C324 100nF
C320
100nF
R336
10K
R312
10K
R300
10K
R309
10K
R317
10K
R324 10K
R326
10K
C332
10uF 6.3V
C327
10uF
6.3V
R311
100K
R342
150K
R322
270K
R323
1M
L306
10uH
R327
6.8K
R321
51K
R319 150K
Q301
KRC857E
1
2
34
5
6
IC302
7WH74
1CK
2
D
3
Q
4GND
5Q
6CLR
7PR
8VCC
IC304
MAX8819
1
COMP4
2
FB4
3
OVP4
4
PG4
5
LX4
6
GND
7
EN4
15
CHG
16
PG1
17
LX1
18
PV13
19
LX3
20
PG3
21
DLIM1
22
FB2
23
FB3
24
EN123
25
PV2
26
LX2
27
PG2
28
DLIM2
12 CEN
10 SYS
8
RST1
13 FB1
11 DC
9
BAT
14
CISET
Q303
KRC857E
1
2
34
5
6
C333
10uF6.3V
C334
10uF
6.3V
IC300
AAT1265IJS-5.0-T1
1 1
22
3 3
4 4 5
5
6
6
7
7
8
8
C316
10uF
16V
C318
10uF 16V
LIM1
0
0
1
1
1% OK
1% OK
ADT->1.8V
3.0V
1% OK!
1% OK!
Charge(mA)
300mA
440mA
1% OK!
1% OK!
1% OK
1% OK
1% OK
R1 R2
3.3K X
3.3K
200ms delay
1% OK
6.8K
400mA
300mA
200mA
H
clear
PR
preset
ª
x
x
L
H
H
x
G
ower off
H
/
Q
L
H
G
ower on
L
ª CnI
H
H
Q
L
H
L
H
H
CLR
x
H
D
L
x
x
L
x
CK
H
1% OK
1% OK
1% OK
1% OK
Location Near CPU
0
1000mA
DC LIM(mA)
1
suspend
LIM2
1
95mA
0
475mA
(1
ª K Default 1000mA set
~Rª M
)
1%
ª¶
Power Management, page 7-3
1
9
2008.10.06
AH41-01179A
YP-P3-REV1.1
A U O
R 4 0 2
R 4 0 6
R 8 0 0 R 8 0 1
R 8 0 2 808R308R
R 8 0 9
X-TAL100
R 8 1 7
C 4 0 5
CON800
C 6 0 6
C 6 0 8
C 6 1 0
X-TAL501
VAR300
L 1 0 1 L 1 0 2
L 1 0 3
L 1 0 4
L 1 0 5
L 3 0 0
L 3 0 1
L 3 0 3
JACK700
L 3 0 6
IC400
IC601
IC602
IC807
S/W300
R 1 0 9
R 3 0 0
R 1 1 0
R 1 1 2
R 1 1 4
R 1 1 5
R 3 1 2
R 3 1 7
R 3 2 6
R 7 1 0
R 7 1 1
C 1 0 0
R 5 2 4
C 1 0 2 C 1 0 3
R 5 2 7
R 3 3 3
R 3 3 4
C 1 0 5C 1 0 8
C 1 0 9
C 3 0 2
C 3 0 3
C 1 1 0
CON500
C 3 0 6
C 1 1 5
C 3 0 9
C 1 1 6
C 3 1 0
C 3 1 1
C 1 2 1
C 1 2 2
C 1 2 3
C 1 2 4
C 7 0 3
CON900 CON902
C 7 0 7
C 3 2 2
C 3 2 4
C 3 2 5
C 3 2 7
C 7 1 3
C 7 1 5
C 7 1 6
C 3 3 3
C 9 1 5 C 9 1 7
C 9 1 8 C 9 1 9
C 9 3 4
VAR801
VAR802
IC100
IC102
IC300
IC304
IC707
CON800
JACK700
CON902
CON900
IC304
IC602
IC400
IC807
IC707
IC100
IC102
IC300
IC601
12
3
45
MAIN PCB Top, page 6-2
A U O
R 4 0 0
R 4 0 1
R 4 0 3
R 4 0 4
R 4 0 5
R 4 0 7
R 8 0 5
R 8 0 6 R 8 0 7
R 8 1 1
R 8 1 2
R 8 1 4
C 4 0 0
C 4 0 1
C 4 0 2
C 4 0 3
C 4 0 4
C 4 0 6
C 4 0 7
C 4 0 8
C 4 0 9
C 6 0 0
C 6 0 1
C 6 0 2
C 6 0 3
C 4 1 0
C 6 0 4
CON801
C 4 1 1 C 6 0 5
C 4 1 2
CON802
CON803
C 4 1 3
C 6 0 7
C 4 1 4
C 6 0 9
C 4 1 5
C 8 0 0
C 8 0 1
C 8 0 2
C 8 0 3
C 8 0 4
C 8 0 5
C 6 1 2
C 8 0 6
C 6 1 5
C 8 1 0
X-TAL500
Q 3 0 0
Q 3 0 1
Q 3 0 2
Q 3 0 3
Q 3 0 4
Q 3 0 7
D 4 0 0
L 1 0 0
L 3 0 4
L 3 0 5
IC401
L 7 0 0
L 7 0 1
L 7 0 2
L 7 0 3
L 7 0 4
L 7 0 5
IC600
L 9 0 0
L 9 0 1
L 9 0 3
IC800
IC801
IC802
IC803
IC804
IC805
IC806
IC808
IC809
IC810
IC811
IC812
IC813
R 1 0 0
R 1 0 6 R 1 0 7
R 1 0 8
R 3 0 1
R 3 0 4
R 3 0 5
R 3 0 6
R 3 0 8 R 3 0 9
R 5 0 0
R 5 0 1
R 5 0 2
R 5 0 3
R 3 1 0
R 5 0 4
R 3 1 1
R 5 0 5
R 5 0 6
R 5 0 7
R 3 1 3
R 3 1 4
R 5 0 8
R 5 0 9
R 3 1 5
R 3 1 8
R 3 1 9
R 5 1 0
R 7 0 4
R 7 0 5
R 5 1 2
R 7 0 6
R 5 1 3
R 5 1 4
R 3 2 1
R 5 1 5
R 3 2 2
R 5 1 6
R 3 2 3
R 5 1 7
R 9 0 0
R 3 2 4
R 5 1 8
R 9 0 1
R 5 1 9
R 9 0 2
R 9 0 3
R 3 2 7
R 3 2 8
R 9 0 5
R 3 2 9
R 9 0 6
R 7 1 2
R 9 0 7
R 9 0 8
R 5 2 0
R 9 0 9
R 5 2 1
R 5 2 2
R 7 1 6
R 5 2 3
R 3 3 0
R 5 2 5
R 3 3 1
C 1 0 1
R 5 2 6
R 3 3 2
R 9 1 0
R 5 2 8
C 1 0 4
R 3 3 5
R 5 2 9
R 3 3 6
C 1 0 6
R 3 3 7
C 1 0 7
R 3 3 8
R 5 3 0
C 3 0 0
C 3 0 1
R 5 3 2
R 5 3 3
R 5 3 4
R 5 3 5
C 1 1 1
R 3 4 2
R 5 3 6
C 1 1 2
R 5 3 7
R 5 3 8
C 1 1 4
C 3 0 8
R 5 3 9
C 1 1 7
C 1 1 8
C 5 0 0
C 1 1 9
C 5 0 1
C 5 0 2
C 5 0 3
R 5 4 0
C 5 0 4
R 5 4 1
C 5 0 5
R 5 4 2
C 3 1 2
C 5 0 6
C 3 1 3
C 5 0 7 C 1 2 0
C 3 1 4
C 5 0 8
C 5 0 9
C 3 1 6
C 3 1 7
C 3 1 8
C 7 0 0
C 1 2 5
C 3 1 9
C 7 0 1 C 7 0 2
C 5 1 0
C 5 1 1
CON901
C 7 0 5
C 5 1 2
C 7 0 6
CON903
C 3 2 0
C 7 0 8
C 7 0 9
C 9 0 0
C 9 0 1
C 3 2 6
C 9 0 3
C 3 2 8
C 7 1 0
C 9 0 5
C 3 2 9
C 7 1 1
C 9 0 6
C 7 1 2
C 9 0 7
C 9 0 8
C 7 1 4
C 9 0 9
C 3 3 0
C 3 3 1
C 3 3 2
C 3 3 4
C 9 1 0
C 9 1 1
C 9 1 2 C 9 1 3
C 9 1 4
C 9 1 6
C 9 2 0
C 9 2 2
C 9 2 3 C 9 2 4 C 9 2 5 C 9 2 6 C 9 2 7 C 9 2 8
D 3 0 0
VAR800
D 3 0 1
D 3 0 3
D 7 0 1
IC302
IC501
IC502
IC503
IC504
L 8 0 1
IC506 IC507
IC508
IC509
IC700
IC701
IC703
IC510
IC704
IC705
IC511
IC706
IC708
IC902
IC903
IC907
IC908
CON903
CON803
IC302
IC401
IC802
CON801
IC700
IC701 CON802
CON901
IC600
JACK700
12
3
45
MAIN PCB Bottom, page 6-4
<Fig. 4-2>
2
2
2
2
L304: 1.04V
2
L303: 1.8V
2
L305: 3.2V
22
2

Samsung Electronics 4-5
Troubleshooting
First check that the
earphones work correctly.
No
Yes
4-1-2 If there is no sound
1. Solder the ear
jack and check the sound.
2. Connect the speaker connector
correctly and check
the sound.
Complete
Yes
No
No
No
Yes
Yes
If there is no sound
If mute is on, cancel it.
Check the
power at the audio codec.
check - 1.8V at L701
check - 3.2V at C706
check- 5V at C712
Check that the IC700 is
cold soldered or short-circuited.
Solder the IC700 or
remove short-circuit.
Yes
No
Yes
No
Refer to wave pattern
image of Fig. 4-3.
N.G.
(detailed inspection)
