Samsung YP-T10 User manual

SERVICE
Manual
YEPP
Model Name : YP-T10
Model Code : YP-T10JQB/XEO
YP-T10JQB/XEU
YP-T10JAB/XEU
YEPP
Refer to the service manual in the GSPN (see the rear cover) for the more information.
CONTENTS
1. Precaution
2. Product Specification
3. Disassembly & Reassembly
4. Troubleshooting
5. Exploded View & Part List
6. PCB Diagram
7. Schematic Diagram
YP-T10

This Service Manual is a property of Samsung Electronics
Co.,Ltd. Any unauthorized use of Manual can be punished
under applicable International and/or domestic law.
GSPN (Global Service Partner Network)
Area Web Site
North America service.samsungportal.com
Latin America latin.samsungportal.com
CIS cis.samsungportal.com
Europe europe.samsungportal.com
China china.samsungportal.com
Asia asia.samsungportal.com
Mideast & Africa mea.samsungportal.com
© Samsung Electronics Co.,Ltd. Oct. 2007
Printed in Korea

Contents
1. Precaution
1-1 Safety Precautions ............................................................................................1-1
1-2 Static Electricity Precautions .............................................................................1-2
2. Product Specification
2-1 Product Feature.................................................................................................2-1
2-2 Specifications ....................................................................................................2-2
2-3 Specifications Analysis ......................................................................................2-4
2-4 Accessories .......................................................................................................2-5
3. Disassembly & Reassembly
3-1 Disassembly Method .........................................................................................3-1
3-2 Reassembly Method..........................................................................................3-4
4. Troubleshooting
4-1 Checkpoints by Error Mode ...............................................................................4-1
4-2 Upgrade Methods ..............................................................................................4-14
5. Exploded View & Part List
5-1 Exploded View...................................................................................................5-1
5-2 Electrical Part List..............................................................................................5-3
6. PCB Diagram
6-1 PCB Top ............................................................................................................6-1
6-2 PCB Bottom.......................................................................................................6-3
7. Schematic Diagram
7-1 Overall Block Diagram.......................................................................................7-2
7-2 POWER .............................................................................................................7-3
7-3 CPU PWR & MEM INF ......................................................................................7-4
7-4 CPU ...................................................................................................................7-5
7-5 MEMORY...........................................................................................................7-6
7-6 AUDIO ...............................................................................................................7-7
7-7 24PIN I/O, Interface...........................................................................................7-8
7-8 LCD Block..........................................................................................................7-9
7-9 Bluetooth Block..................................................................................................7-10

Samsung Electronics 1-1
Precaution
1. Precaution
1-1 Safety Precautions
1. To remove dust from cabinet, use a dry cloth without using liquid and aerosol cleaner.
2. You should not use attachments not recommended by the company. Otherwise, it may cause critical damage.
3. You should not use this product near water such as bathtub, swimming pool or lake etc.
4. Power supply: A type of battery as displayed on the label should be only used.
5. You should not put any object or liquid into product. Otherwise, it may cause failure or mal-operation.
6. If replacement material is required, service engineer should use materials with the same standard.
The use of non-standardized materials may cause failure of product.

1-2 Samsung Electronics
Precaution
1-2 Static Electricity Precautions
Some semi-conductor parts may be easily damaged due to static electricity.
These elements are generally called as static electricity sense device (ESD). Typically examples of EST include
IC, some transistor and chip element for semi-conductor with electrical field effect.
The following methods should be used to reduce damage of elements occurred due to static electricity:
1. Contact and emit all the grounding objects with static electricity from your body before handling with elements
for semi-conductor or devices with elements for semi-conductor. You should purchase and use static electricity
arm rings or commercially available. You should remove it due to potential shock before supplying power to the
device under test.
2. You should place appliance on the conductive surface like aluminum film to prevent that static electricity is
accumulated or the device is disclosed outside after removing electrical appliance with the ESD device.
3. You should use only soldering iron that is ground when soldering the ESD device.
4. Minimize physical operation when handling with the ESD device for replacement without packing (Otherwise,
namely friction between cloth fibers or lifting of the foot from the carpet floor may cause static electricity enough
to damage the ESD device).

Samsung Electronics 2-1
Product Specification
2. Product Specification
2-1 Product Feature
Bluetooth, Video, Best Audio, Varity of Accessory
YP-T10
Slim & Stylish
-11mm → 7.8mm
- Back Metallic Design
Advanced Video
-1.8 → 2.0"
- QCIF+/15f → QVGA/30fps
Advanced Bluetooth
B/T support to Video/Game
Best Audio
Tone quality embodiment more
than K5
Various Accessory
Various Fashion and Technical
accessory support
YP-T9

2-2 Samsung Electronics
Product Specification
2-2 Specifications
Basic Specification
Model Name YP-T10
JQB JAB JCB JQG JAG JCG JQR JAR JCR JQU JAU JCU JQW JAW JCW
Capacity 2G 4G 8G 2G 4G 8G 2G 4G 8G 2G 4G 8G 2G 4G 8G
Color Midnight Black Lime-Yellow Maple Red Mystic Purple White Cloud
Rating DC 5.0V / 500mA
Built-in Battery Power 550 mAh / DC 3.7V
File Compatibility
AUDIO: MPEG1/2/2.5 Layer3(8kbps~320kbps, 22kHz~48kHz)
WMA(5kbps~320kbps,8kHz~48kHz)
VIDEO: SVI (Video: MPEG4, Audio: MP3(44.1kHz, 128Kbps),
WMV(Video: WMV9 Simple Profi le, Audio: WMA Spec (Max
860kbps), Resolution: 320X240, Frame Rate: 30fps)
IMAGE: JPEG(ISO/IEC 10918-1/Annex F-Sequential DCT-based mode of
operation)
Earphone Output 20mW (16Ω)
Output Frequency
Range 20Hz ~ 20KHz
Signal to Noise Ratio 90dB with 20KHz LPF(based on 1kHz 0dB)
Play Time
Maximum of 30 hours for music playback
(based on: MP3 128kbps, Volume 15, Normal sound mode), Maximum of 4 hours for
video playback
Temperature
Characteristics -5 ~ 35°C (23 ~ 95°F)
Case Plastic , Aluminum
Weight 43g
Dimensions (WxHxD) 41.5 x 96 x 7.9 mm
LCD QVGA 2" TFT-LCD (30fps)
FM
RADIO
FM
Frequency 87.5 ~ 108.0MHz
FM Signal to
Noise Ratio 50dB
FM T.H.D 1%
FM Useable
Sensitivity 30dBμ

Samsung Electronics 2-3
Product Specification
Wireless System
Emission Type F1D
RF Power CLASS II
Transmit Frequency 2402MHz ~ 2480MHz
Receive Frequency 2402MHz ~ 2480MHz
No. of channels 79 CH
Temperature -10°C ~ +50°C (14 ~ 122°F)
Modulation System GFSK
Communication Mode Semi-duplex Operation
Humidity 95%
Spec Version Supported 2.0
Module BTEM48B2SA

2-4 Samsung Electronics
Product Specification
2-3 Specifications Analysis
Model Name YP-T10 YP-T9 iPod nano SONY A-series
Dimensions
(WxDxH) 41.5 x 96 x 7.9 mm 42.6 x 83 x 11 mm 40.6 x 88.9 x 6.6 mm 44.5 x 88.0 x 9.6 mm
Weight 43g 49g 39.97g 53g
LCD 2.0" QVGA
(320x240, 30fps)
1.8" QCIF+
(220x172, 15fps)
1.46"
(176x132)
2.0" QVGA
(320x240, 30fps)
Color
Midnight Black
Mystic Purple
Maple Red
Lime-Yellow
White Cloud
Black, Purple, Pink Black, Pink, Lime, Blue,
Silver, Red
Black, White, Silver, Blue,
Pink
Capacity 2GB / 4GB / 8GB 1GB / 2GB / 4GB / 8GB 2GB / 4GB / 8GB 2GB / 4GB / 8GB
Battery Time Audio: 30Hrs
Video: 4Hrs
Audio: 30Hrs
Video: 6Hrs Audio: 24Hrs Audio: 30Hrs Video: 8Hrs
Functions
Music, Video, Photo, FM
Radio, Voice Rec., FM
Rec., Text Viewer
Music, Video, Photo, FM
Radio, Voice Rec., FM
Rec., Text, Game
Music, Photo, Text, Game Music, Photo, Video
Bluetooth
Enabled
(Audio & Video)
Bluetooth 2.0
(1:2 Support)
Enabled (Only Audio)
Bluetooth 1.2 X X

Samsung Electronics 2-5
Product Specification
2-4 Accessories
2-4-1 Supplied Accessories
Accessories Item Item code Remark
Earphones Black AH30-00087E
Samsung Service centerUSB Cable AH39-00899A
Program Installation CD AH46-00049A

2-6 Samsung Electronics
MEMO

Samsung Electronics 3-1
Disassembly & Reassembly
3. Disassembly & Reassembly
3-1 Disassembly Method
- Be careful to follow the disassembly sequence described in the manual. Otherwise, the product
may be damaged.
- Be sure to carefully read and understand the safety instructions before performing any work as
the IC chips on the PCB are vulnerable to static electricity.
- Assemble in the reverse order of disassembly.
No. Part Name Description Description Photo
1 CABINET-
BACK
1) Remove Serial Label.
The label must not be damaged.
2) Please unscrew 1EA from HOLDER-
JACK.
: CH,+,B,M1.4,L5,NI PLT
3) Hook is fastened in Front top inner,
Please hold up Front top and draw
away hook.

3-2 Samsung Electronics
Disassembly & Reassembly
No. Part Name Description Description Photo
2 CABINET-
FRONT
1) Raise CABINET-FRONT like an
arrow direction.
2) Please separate CABINET-FRONT
FPC-TOUCH from YP-T10 PCB
using pinset.
When removing the FPC-TOUCH,
be sure to use a pair of tweezers to
avoid a tear.
3 TOUCH-PAD 1) Separate TOUCH-PAD.
4 LCD 1) Separate LCD from YP-T10 PCB.
Be careful not to make any scratches
as you remove it.
5 BATTERY 1) Separate Battery from YP-T10 PCB
using pinset.

Samsung Electronics 3-3
Disassembly & Reassembly
No. Part Name Description Description Photo
6 MAIN
BOARD
1) Unscrew 1EA from MAIN BOARD.
: PH,+,B,M1.4,L3,NI PLT
2) Separate MAIN BOARD from
CABINET-BOTTOM.

3-4 Samsung Electronics
Disassembly & Reassembly
3-2 Reassembly Method
No. Part Name Description Description Photo
1 CABINET-
FRONT
1) Check KNOB HOLD of ASSY-
CABINET FRONT and HOLD
SWITCH are same position. -
2) Check HOLD SWITCH is center.
-
3) The bottom of FRONT and
“SAMSUNG” logo are in contact each
other.
4) Slide in such as picture without GAP.
If you assemble right position, ignore
HOLD SWITCH position.
Be cautious only KNOB SWITCH
position.
5) Slide in ASSY FRONT to ASSY back
and push touch pad at once without
GAP.
<Don’t push LCD because of break>
<KNOB-HOLD position reaffirmation,
SW secession prevention>

Samsung Electronics 3-5
Disassembly & Reassembly
No. Part Name Description Description Photo
1 CABINET-
FRONT
6) Slide KNOB-HOLDER to down not
for separation.
7) Slide ASSY-FRONT to ASSY-BACK
tightly.
8) Check KNOB HOLDE.
9) Check GAP. (Side, Top)
- If you see a gap, don’t push.
because inner hook will be
broken.
- But If you see a top gap, push
slightly.

3-6 Samsung Electronics
MEMO

Samsung Electronics 4-1
Troubleshooting
4. Troubleshooting
4-1 Checkpoints by Error Mode
Oscilloscope Setting Values
Voltage/DIV 1V/div
TIME/DIV 10ms/div
4-1-1 No Power
Symptom Power does not turn on.
Major Checklist
1Check the power terminal connection (battery, adapter).
2Check if the key signal is ‘HIGH’ when the POWER key is pressed. (More than 2.5V)
3Check if the ENABLE pin signal of the DDCON IC is ‘HIGH’. (More than 2.5V)
4Check power. (L300: 1.08V(CORE), L301: 3.0V(MAIN), L302: 1.8V(MEMORY))
Caution Be careful not to short anything out when checking the power line.
The power does not turn on.
After insert battery to PCB,
Please TEST
No Is battery inserted to Main PCB
normally?
Yes
Does the power turn on after
recharging the battery?
Yes
No
Completion
A

4-2 Samsung Electronics
Troubleshooting
Check power at the BATTERY
(single part).
Recheck after replacing the battery.
4
Check power.
L300: 1.08V(CORE)
L301: 3.0V(MAIN)
L302: 1.8V(MEMORY)
Yes
No
1
Check BATTERY power.
TP301, TP300
Check MAIN 12Mhz clock
No
Defective
YesYes
No
No
A
Refer to wave pattern
image of Table 4-1.
Refer to wave pattern
image of Table 4-1.
Completion
3
Check DDCON enable
pin signal as ‘HIGH’
(More than 2.5V)
2
When power Key is on,
check key signal as ‘HIGH’?
(More than 2.5V)
Refer to wave pattern
image of Table 4-1.
Yes
Yes
No
Refer to wave pattern
image of Table 4-1.

Samsung Electronics 4-3
Troubleshooting
Test Point IC302(1PIN, 19PIN), D301 2PIN, L300, L301, L302
Result Check for HIGH input - POWER ON
POWER Page, 7-3
POWER Page, 7-3
CON900 IC900
FET700
IC701
CON801
PCB Top Page, 6-1
IC400
IC600
IC303
IC101
IC601
IC500
IC602
IC100
IC302
CON300
CON800
PCB Bottom Page, 6-3
<Table 4-1>
2
3
4
L300
4
L301
4
L302
4 42 3
4
2
3
4
4
4
