Samsung CLP-415 series User manual

ColorLaserPrinter
CLP-415series
CLP-415N/415NW
(Ver1.02)
SERVICEMANUAL
ColorLaserPrinterContents
1.Precautions
2.Productspecicationanddescription
3.DisassemblyandReassembly
4.AlignmentandTroubleshooting
5.SystemDiagram
6.ReferenceInformation
RefertotheservicemanualintheGSPN(seetherearcover)formoreinformation.

Contents
Contents
1.Precautions......................................................................................................................................1−1
1.1.Safetywarning........................................................................................................................1−1
1.2.Cautionforsafety....................................................................................................................1−2
1.2.1.Toxicmaterial.............................................................................................................1−2
1.2.2.Electricshockandresafetyprecautions.........................................................................1−2
1.2.3.Handlingprecautions...................................................................................................1−3
1.2.4.AssemblyandDisassemblyprecautions...........................................................................1−3
1.2.5.Disregardingthiswarningmaycausebodilyinjury............................................................1−4
1.3.ESDprecautions......................................................................................................................1−5
2.Productspecicationanddescription.....................................................................................................2−1
2.1.ProductSpecication................................................................................................................2−1
2.1.1.ProductOverview........................................................................................................2−1
2.1.2.Specications.............................................................................................................2−2
2.1.2.1.GeneralPrintEngine......................................................................................2−2
2.1.2.2.ControllerandSoftware..................................................................................2−2
2.1.2.3.PaperHandling.............................................................................................2−5
2.1.2.4.ReliabilityandService...................................................................................2−7
2.1.2.5.Environment................................................................................................2−7
2.1.2.6.Consumables................................................................................................2−7
2.1.2.7.MaintenanceParts.........................................................................................2−8
2.1.2.8.Option.........................................................................................................2−8
2.1.3.ModelComparisonTable..............................................................................................2−9
2.2.SystemOverview.....................................................................................................................2−10
2.2.1.FrontView.................................................................................................................2−10
2.2.2.RearView..................................................................................................................2−11
2.2.3.PaperPath..................................................................................................................2−12
2.2.4.SystemLayout............................................................................................................2−13
2.2.4.1.FeedingSection............................................................................................2−14
2.2.4.2.TransferRoller.............................................................................................2−15
2.2.4.3.DriveUnit...................................................................................................2−15
2.2.4.4.FuserUnit....................................................................................................2−16
2.2.4.5.LSU(LaserScannerUnit)...............................................................................2−17
2.2.4.6.TonerCartridge.............................................................................................2−18
2.2.5.Hardwareconguration................................................................................................2−19
2.2.5.1.Mainboard..................................................................................................2−21
2.2.5.2.OPEController.............................................................................................2−23
2.2.5.3.WirelessLANboard(CLP-415NWonly)...........................................................2−24
2.2.5.4.SMPSboard.................................................................................................2−25
iCopyright©1995-2013SAMSUNG.Allrightsreserved.

Contents
2.2.5.5.HVPSboard.................................................................................................2−27
2.2.5.6.ITBEEPROMPBA.......................................................................................2−28
2.2.5.7.ElectricalPartsLocation.................................................................................2−29
2.2.6.EngineF/WControlAlgorithm......................................................................................2−31
2.2.6.1.Feeding.......................................................................................................2−31
2.2.6.2.Transfer.......................................................................................................2−31
2.2.6.3.Fusing.........................................................................................................2−32
2.2.6.4.LSU............................................................................................................2−32
2.2.7.SoftwareDescriptions..................................................................................................2−33
2.2.7.1.Softwaresystemoverview..............................................................................2−33
2.2.7.2.Architecture.................................................................................................2−33
2.2.7.3.DataandControlFlow...................................................................................2−34
3.DisassemblyandReassembly..............................................................................................................3−1
3.1.Precautionswhenreplacingparts................................................................................................3−1
3.1.1.Precautionswhenassemblinganddisassembling...............................................................3−1
3.1.2.PrecautionswhenhandlingPBA.....................................................................................3−1
3.1.3.ReleasingPlasticLatches..............................................................................................3−2
3.2.Screwsusedintheprinter..........................................................................................................3−3
3.3.Replacingthemaintenanceparts.................................................................................................3−4
3.3.1.TonerCartridge...........................................................................................................3−4
3.3.2.WasteTonerContainer.................................................................................................3−5
3.3.3.ITBUnit....................................................................................................................3−6
3.3.4.FuserUnit..................................................................................................................3−8
3.3.5.TransferRollerAssy....................................................................................................3−9
3.3.6.Pickup_Forward_Reverseroller.....................................................................................3−9
3.4.ReplacingthemainSVCparts....................................................................................................3−10
3.4.1.Cover........................................................................................................................3−10
3.4.2.HVPSboard...............................................................................................................3−12
3.4.3.OuterTemperatureSensor.............................................................................................3−12
3.4.4.Wastetonercontainersensor..........................................................................................3−13
3.4.5.LSU..........................................................................................................................3−13
3.4.6.MainBoard................................................................................................................3−14
3.4.7.SMPSboard...............................................................................................................3−14
3.4.8.FeedDriveUnit..........................................................................................................3−15
3.4.9.FRAME-RETARD......................................................................................................3−16
3.4.10.MainDriveUnit..........................................................................................................3−17
4.AlignmentandTroubleshooting...........................................................................................................4−1
4.1.AlignmentandAdjustments.......................................................................................................4−1
4.1.1.Controlpanel..............................................................................................................4−1
4.1.2.UnderstandingthestatusLED........................................................................................4−3
Copyright©1995-2013SAMSUNG.Allrightsreserved.ii

Contents
4.1.3.Clearingpaperjams.....................................................................................................4−4
4.1.4.Usefulmenuitemforservice.........................................................................................4−8
4.1.5.PeriodicDefectiveImage..............................................................................................4−10
4.1.6.Usefulmanagementtools..............................................................................................4−11
4.1.6.1.UsingSamsungEasyPrinterManager(WindowsandMacintoshonly)....................4−11
4.1.6.2.UsingSamsungPrinterStatus(Windowsonly)...................................................4−13
4.1.6.3.UsingSyncThruWebService(SWS)................................................................4−14
4.1.7.UpdatingFirmware......................................................................................................4−16
4.1.7.1.UpdatethermwarebyusingtheUSBport........................................................4−16
4.1.7.2.Updatethermwarebyusingthenetwork..........................................................4−17
4.1.8.TechMode(DiagnosticMode).......................................................................................4−19
4.2.Troubleshooting......................................................................................................................4−23
4.2.1.Procedureofcheckingthesymptoms...............................................................................4−23
4.2.1.1.BasicCheckList...........................................................................................4−24
4.2.2.ErrorCodeandTroubleshooting.....................................................................................4−25
4.2.3.Imagequalityproblems................................................................................................4−44
5.SystemDiagram................................................................................................................................5−1
5.1.BlockDiagram........................................................................................................................5−1
5.2.ConnectionDiagram.................................................................................................................5−2
6.ReferenceInformation........................................................................................................................6−1
6.1.ToolforTroubleshooting...........................................................................................................6−1
6.2.Glossary.................................................................................................................................6−2
6.3.DocumentRevisionList............................................................................................................6−8
iiiCopyright©1995-2013SAMSUNG.Allrightsreserved.

1.Precautions
1.Precautions
Inordertopreventaccidentsanddamagestotheequipmentpleasereadtheprecautionslistedbelowcarefullybefore
servicingtheproductandfollowthemclosely.
1.1.Safetywarning
1)Onlytobeservicedbyafactorytrainedservicetechnician.
Highvoltagesandlasersinsidethisproductaredangerous.Thisproductshouldonlybeservicedbyafactorytrained
servicetechnician.
2)UseonlySamsungreplacementparts.
Therearenouserserviceablepartsinsidetheproduct.Donotmakeanyunauthorizedchangesoradditionstothe
productasthesecouldcausetheproducttomalfunctionsandcreateanelectricshocksorrehazards.
3)LaserSafetyStatement
TheprinteriscertiedintheU.S.toconformtotherequirementsofDHHS21CFR,chapter1SubchapterJfor
ClassI(1)laserproducts,andelsewhereiscertiedasaClassIlaserproductconformingtotherequirementsofIEC
60825-1.ClassIlaserproductsarenotconsideredtobehazardous.Thelasersystemandprinteraredesignedso
thereisneveranyhumanaccesstolaserradiationaboveaClassIlevelduringnormaloperation,usermaintenance
orprescribedservicecondition.
•Wavelength:788nm(-13/+12)
•Beamdivergence
-Paraller:8degrees(-2/+4)
-Perpendicular:31degrees(-6/+4)
•Maximumpowerofenergyoutput:12mW
WARNING
NeveroperateorservicetheproductwiththeprotectivecoverremovedfromLaser/Scannerassembly.Thereected
beam,althoughinvisible,candamageyoureyes.
Whenusingthisproduct,thesebasicsafetyprecautionsshouldalwaysbefollowedtoreduceriskofre,electricshock,
andpersonalinjury.
Copyright©1995-2013SAMSUNG.Allrightsreserved.1-1

1.Precautions
1.2.Cautionforsafety
1.2.1.Toxicmaterial
Thisproductcontainstoxicmaterialsthatcouldcauseillnessifingested.
1)Pleasekeepimagingunitandtonercartridgeawayfromchildren.Thetonerpowdercontainedintheimagingunitand
tonercartridgemaybeharmful,andifswallowed,youshouldcontactadoctor.
1.2.2.Electricshockandresafetyprecautions
Failuretofollowthefollowinginstructionscouldcauseelectricshockorpotentiallycauseare.
1)Useonlythecorrectvoltage,failuretodosocoulddamagetheproductandpotentiallycauseareorelectricshock.
2)Useonlythepowercablesuppliedwiththeproduct.Useofanincorrectlyspeciedcablecouldcausethecableto
overheatandpotentiallycauseare.
3)Donotoverloadthepowersocket,thiscouldleadtooverheatingofthecablesinsidethewallandcouldleadtoare.
4)Donotallowwaterorotherliquidstospillintotheproduct,thiscancauseelectricshock.Donotallowpaperclips,pins
orotherforeignobjectstofallintotheproduct,thesecouldcauseashortcircuitleadingtoanelectricshockorrehazard.
5)Nevertouchtheplugsoneitherendofthepowercablewithwethands,thiscancauseelectricshock.Whenservicing
theproduct,removethepowerplugfromthewallsocket.
6)Usecautionwheninsertingorremovingthepowercord.Whenremovingthepowercord,gripitrmlyandpull.The
powercordmustbeinsertedcompletely,otherwiseapoorcontactcouldcauseoverheatingleadingtoare.
7)Takecareofthepowercable.Donotallowittobecometwisted,bentsharplyaroundcornersorpowercablemaybe
damaged.Donotplaceobjectsontopofthepowercable.Ifthepowercableisdamageditcouldoverheatandcausea
re.Exposedcablescouldcauseanelectricshock.Replacethedamagedpowercableimmediately,donotreuseor
repairthedamagedcable.Somechemicalscanattackthecoatingonthepowercable,weakeningthecoverorexposing
cablescausingreandshockrisks.
8)Ensurethatthepowersocketsandplugsarenotcrackedorbrokeninanyway.Anysuchdefectsshouldberepaired
immediately.Takecarenottocutordamagethepowercableorplugswhenmovingthemachine.
9)Usecautionduringthunderorlightningstorms.Samsungrecommendsthatthismachinebedisconnectedfromthe
powersourcewhensuchweatherconditionsareexpected.Donottouchthemachineorthepowercordifitisstill
connectedtothewallsocketintheseweatherconditions.
10)Avoiddampordustyareas,installtheproductinacleanwellventilatedlocation.Donotpositionthemachineneara
humidierorinfrontofanairconditioner.Moistureanddustbuiltupinsidethemachinecanleadtooverheatingand
causeareorcausepartstorust.
11)Donotpositiontheproductindirectsunlight.Thiswillcausethetemperatureinsidetheproducttorisepossiblyleading
totheproductfailingtoworkproperlyandinextremeconditionscouldleadtoare.
12)Donotinsertanymetalobjectsintothemachinethroughtheventilatorfanorotherpartofthecasing,itcouldmake
contactwithahighvoltageconductorinsidethemachineandcauseanelectricshock.
13)WhenreplacingtheSMPSboard,pleasewait5minutesafterunpluggingthepowercord,thenreplaceit.You
cangetashockbytheelectricdischarge.
1-2Copyright©1995-2013SAMSUNG.Allrightsreserved.

1.Precautions
1.2.3.Handlingprecautions
Thefollowinginstructionsareforyourownpersonalsafetytoavoidinjuryandsoasnottodamagetheproduct.
1)Ensuretheproductisinstalledonalevelsurface,capableofsupportingitsweight.Failuretodosocouldcause
theproducttotiporfall.
2)Theproductcontainsmanyrollers,gearsandfans.Takegreatcaretoensurethatyoudonotcatchyourngers,hairor
clothinginanyoftheserotatingdevices.
3)Donotplaceanysmallmetalobjects,containersofwater,chemicalsorotherliquidsclosetotheproductwhichifspilled
couldgetintothemachineandcausedamageorashockorrehazard.
4)Donotinstallthemachineinareaswithhighdustormoisturelevels,besideonopenwindoworclosetoahumidieror
heater.Damagecouldbecausedtotheproductinsuchareas.
5)Donotplacecandles,burningcigarettes,etcontheproduct,Thesecouldcauseare.
6)Ensurethatthemachineisinstalledandusedinproperareatomeetthetemperatureandhumidityspecications.
•IfthemachineisstoredatbelowzeroCelsiusforalongtime,donotusethemachineinstantlyaftermovement.It
canmalfunction.Takecareofthemachinestorage.IfthemachineisstoredatbelowzeroCelsiusforalongtime,
keepthemachineatroomtemperatureandinstallit.
1.2.4.AssemblyandDisassemblyprecautions
1)ReplacepartscarefullyandalwaysuseSamsungparts.Takecaretonotetheexactlocationofpartsandalsocable
routingbeforedismantlinganypartofthemachine.Ensureallpartsandcablesarereplacedcorrectly.Pleasecarryout
thefollowingproceduresbeforedismantlingtheproductorreplacinganyparts.
2)Ensurethatpowerisdisconnectedbeforeservicingorreplacinganyelectricalparts.
3)Disconnectinterfacecablesandpowercables.
4)Onlyuseapprovedspareparts.Ensurethatpartnumber,productname,anyvoltage,currentortemperaturerating
arecorrect.
5)Whenremovingorre-ttinganypartsdonotuseexcessiveforce,especiallywhenttingscrewsintoplastic.
6)Takecarenottodropanysmallpartsintothemachine.
7)HandlingoftheOPCDrum
•TheOPCDrumcanbeirreparablydamagedifitexposedtolight.TakecarenottoexposetheOPCDrumeither
todirectsunlightortouorescentorincandescentroomlighting.Exposureforaslittleas5minutescandamage
thesurfaceofthephotoconductivepropertiesandwillresultinprintqualitydegradation.Takeextracarewhen
servicingtheproduct.RemovetheOPCDrumandstoreitinablackbagorotherlightproofcontainer.Take
carewhenworkingwiththeCovers(especiallythetopcover)openaslightisadmittedtotheOPCareaandcan
damagetheOPCDrum.
•TakecarenottoscratchthegreensurfaceofOPCDrumUnit.IfthegreensurfaceoftheDrumCartridgeis
scratchedortouchedtheprintqualitywillbecompromised.
Copyright©1995-2013SAMSUNG.Allrightsreserved.1-3

1.Precautions
1.2.5.Disregardingthiswarningmaycausebodilyinjury
1)Becarefulwiththehightemperaturepart.
Thefuserunitworksatahightemperature.Usecautionwhenworkingontheprinter.Waitforthefuserunitto
cooldownbeforedisassembly.
2)Donotputngersorhairintotherotatingparts.
Whenoperatingaprinter,donotputhandorhairintotherotatingparts(Paperfeedingentrance,motor,fan,etc.).
Ifdo,youcangetharm.
3)Whenyoumovetheprinter,usesafeliftingandhandlingtechniques.
Thisprinterisheavy.Usetheliftinghandleslocatedoneachsideofthemachine.Backinjurycouldbecausedif
youdonotliftcarefully.
4)Ensuretheprinterisinstalledsafely.
Ensuretheprinterisinstalledonalevelsurface,capableofsupportingitsweight.Failuretodosocouldcausethe
printertotiporfallpossiblycausingpersonalinjuryordamagingtheprinter.
5)Donotinstalltheprinteronaslopingorunstablesurface.Afterinstallation,doublecheckthattheprinterisstable.
1-4Copyright©1995-2013SAMSUNG.Allrightsreserved.

1.Precautions
1.3.ESDprecautions
Certainsemiconductordevicescanbeeasilydamagedbystaticelectricity.Suchcomponentsarecommonlycalled
“ElectrostaticallySensitive(ES)Devices”orESDs.ExamplesoftypicalESDsare:integratedcircuits,someeldeffect
transistors,andsemiconductor“chip”components.Thetechniquesoutlinedbelowshouldbefollowedtohelpreducethe
incidenceofcomponentdamagecausedbystaticelectricity.
CAUTION
Besurenopowerisappliedtothechassisorcircuit,andobserveallothersafetyprecautions.
1)Immediatelybeforehandlingasemiconductorcomponentorsemiconductor-equippedassembly,drainoffany
electrostaticchargeonyourbodybytouchingaknownearthground.Alternatively,employacommerciallyavailable
wriststrapdevice,whichshouldberemovedforyourpersonalsafetyreasonspriortoapplyingpowertotheunit
undertest.
2)AfterremovinganelectricalassemblyequippedwithESDs,placetheassemblyonaconductivesurface,suchas
aluminumorcopperfoil,orconductivefoam,topreventelectrostaticchargebuildupinthevicinityoftheassembly.
3)UseonlyagroundedtipsolderingirontosolderordesolderESDs.
4)Useonlyan“anti-static”solderremovaldevice.Somesolderremovaldevicesnotclassiedas“anti-static”can
generateelectricalchargessufcienttodamageESDs.
5)DonotuseFreon-propelledchemicals.Whensprayed,thesecangenerateelectricalchargessufcienttodamageESDs.
6)DonotremoveareplacementESDfromitsprotectivepackaginguntilimmediatelybeforeinstallingit.Most
replacementESDsarepackagedwithallleadsshortedtogetherbyconductivefoam,aluminumfoil,oracomparable
conductivematerial.
7)ImmediatelybeforeremovingtheprotectiveshortingmaterialfromtheleadsofareplacementESD,touchtheprotective
materialtothechassisorcircuitassemblyintowhichthedevicewillbeinstalled.
8)MaintaincontinuouselectricalcontactbetweentheESDandtheassemblyintowhichitwillbeinstalled,until
completelypluggedorsolderedintothecircuit.
9)MinimizebodilymotionswhenhandlingunpackagedreplacementESDs.Normalmotions,suchasthebrushingtogether
ofclothingfabricandliftingone’sfootfromacarpetedoor,cangeneratestaticelectricitysufcienttodamageanESD.
Copyright©1995-2013SAMSUNG.Allrightsreserved.1-5

2.Productspecicationanddescription
2.Productspecicationanddescription
2.1.ProductSpecication
2.1.1.ProductOverview
1)PrintingSpeed
•18(Color)/18(Mono)ppminA4(19/19ppminLetter)
2)Processor
•533MHz
3)PrinterLanguage
•SPLC,PCL5Ce,PCL6C,PS3,PDFV1.7
4)Memory
•256MB(Standard)/512MB(Max)
5)Interface
•HighSpeedUSB2.0
•10/100/1000BaseTXnetworkconnector
•802.11b/g/nwirelessLAN(CLX-415NWonly)
6)Tonercartridge
•Initial:1K(K)/0.7K(CMY)
•Sales:2.5K(K)/1.8K(CMY)
2-1Copyright©1995-2013SAMSUNG.Allrightsreserved.

2.Productspecicationanddescription
2.1.2.Specications
NOTE
ProductSpecicationsaresubjecttochangewithoutnotice.
2.1.2.1.GeneralPrintEngine
ItemCLP-415NCLP-415NW
Simplex(C/M)Upto18/18ppminA4(19/19ppmin
Letter)
Upto18/18ppminA4(19/19ppmin
Letter)
EngineSpeed
DuplexN/AN/A
FromReady(C/M)Asfastas12/12secAsfastas12/12sec
FPOTFromSleep(C/M)Asfastas32/32secAsfastas32/32sec
Optical600x600dpi600x600dpi
ResolutionEnhancedUpto9,600x600effectiveoutputUpto9,600x600effectiveoutput
2.1.2.2.ControllerandSoftware
ItemCLP–415NCLP-415NW
ProcessorSamsung533MHzSamsung533MHz
Std.256MB256MB
MemoryMax.512MB512MB
PrinterLanguagesSPLC,PCL5Ce,PCL6C,PS3,PDF
V1.7
SPLC,PCL5Ce,PCL6C,PS3,PDF
V1.7
Fonts
•PCL:95ScalableFonts(include
OCR-A,OCR-B),1bitmap
•PS:136ScalableFonts
•PCL:95ScalableFonts(include
OCR-A,OCR-B),1bitmap
•PS:136ScalableFonts
DefaultDriverSPLSPL
[WINDOW]
•XP(32/64bit)/2003
Server(32/64bit)/
Vista(32/64bit)/2008
Server(32/64bit)/7(32/64bit)/
2008ServerR2
[WINDOW]
•XP(32/64bit)/2003
Server(32/64bit)/
Vista(32/64bit)/2008
Server(32/64bit)/7(32/64bit)/
2008ServerR2
SupportingOS
Driver
Copyright©1995-2013SAMSUNG.Allrightsreserved.2-2

2.Productspecicationanddescription
ItemCLP–415NCLP-415NW
[Linux]
•RedHatEnterpriseLinuxWS4,
5(32/64bit)
•Fedora5,6,7,8,9,10,11,12,
13(32/64bit)
•SuSELinux10.1(32bit)
•OpenSuSE10.2,10.3,11.0,
11.1,11.2(32/64bit)
•Mandriva2007,2008,2009,
2009.1,2010(32/64bit)
•Ubuntu6.06,6.10,7.04,7.10,
8.04,8.10,9.04,9.10,10.04
(32/64bit)
•SuSELinuxEnterpriseDesktop
10,11(32/64bit)
•Debian4.0,5.0(32/64bit)
[Linux]
•RedHatEnterpriseLinuxWS4,
5(32/64bit)
•Fedora5,6,7,8,9,10,11,12,
13(32/64bit)
•SuSELinux10.1(32bit)
•OpenSuSE10.2,10.3,11.0,
11.1,11.2(32/64bit)
•Mandriva2007,2008,2009,
2009.1,2010(32/64bit)
•Ubuntu6.06,6.10,7.04,7.10,
8.04,8.10,9.04,9.10,10.04
(32/64bit)
•SuSELinuxEnterpriseDesktop
10,11(32/64bit)
•Debian4.0,5.0(32/64bit)
MacOSX10.4~10.7MacOSX10.4~10.7
[UNIX]
•SunSolaris9,10(x86,SPARC)
•HP-UX11.0,11iv1,11iv2,11i
v3(PA-RISC,Itanium)
•IBMAI5.1,5.2,5.3,5.4
[UNIX]
•SunSolaris9,10(x86,SPARC)
•HP-UX11.0,11iv1,11iv2,11i
v3(PA-RISC,Itanium)
•IBMAI5.1,5.2,5.3,5.4
WHQL
•SPL/PCL6/PSdriver:Windows
2003(32bit),Windows
2003(64bit),Windows
Vista(32bit),Windows
Vista(64bit),Windows
7(32bit),Windows7(64bit),
Window/XP(32/64bit)
•XPSdriver:Windows
Vista(32bit),Windows
Vista(64bit),Windwos7(32bit),
Windows7(64bit)
•SPL/PCL6/PSdriver:Windows
2003(32bit),Windows
2003(64bit),Windows
Vista(32bit),Windows
Vista(64bit),Windows
7(32bit),Windows7(64bit),
Window/XP(32/64bit)
•XPSdriver:Windows
Vista(32bit),Windows
Vista(64bit),Windwos7(32bit),
Windows7(64bit)
Protocol
[TCP/IP]
•TCP/IPv4/IPv6,HTTP,
SNMPv1/v2c/v3,SMTP ,IPSec,
DNS/WINS,DDNS,DHCP ,
SSL/TLS,BOOTP,AutoIP ,
StandardTCP/IPprinting,LPR,
IPP,UPnP(SSDP),Bonjour,
Telnet,WSD,SLP ,SetIP ,
AirPrint,ThinPrint
[Others]
•HTTPs,IPPs,802.1x
(EAP-MD5,EAP-MSCHAPv2,
PEAP,TLS),IPSec
[TCP/IP]
•TCP/IPv4/IPv6,HTTP,
SNMPv1/v2c/v3,SMTP ,IPSec,
DNS/WINS,DDNS,DHCP ,
SSL/TLS,BOOTP,AutoIP ,
StandardTCP/IPprinting,LPR,
IPP,UPnP(SSDP),Bonjour,
Telnet,WSD,SLP ,SetIP ,
AirPrint,ThinPrint
[Others]
•HTTPs,IPPs,802.1x
(EAP-MD5,EAP-MSCHAPv2,
PEAP,TLS),IPSec
WiredNetwork
2-3Copyright©1995-2013SAMSUNG.Allrightsreserved.

2.Productspecicationanddescription
ItemCLP–415NCLP-415NW
SupportingOS
[Windows]
•MicrosoftWindows
XP(32/64bits)/2003
Server(32/64bits)/
Vista(32/64bits)/2008
Server(32/64bit)/7/2008
ServerR2/7/2008R2
[Mac]
•MacOSX10.4~10.7
[Linux]
•RedHat8~9(32bit)/Enterprise
LinuxWS4,5(32/64bit)
•FedoraCore1~7(32/64bit)
•SuSE8.2~10.2/Enterprise
Desktop9~10(32/64bit)
•Madrake9.2~10.1(32/64bit)
•Mandriva2005~2007
•Ubuntu6.06~7.04
•Debian3.1~4.0
[Novell]
•Netware5.x,6.x(TCP/IPOnly)
[Others]
•UnixSunSolaris
8,9,10(SPARC/86)IBMAIx
5.x(6.1)IBMLinux(System
P)HP-U11i(P A-RISC/IA-64)
(11.11/11.20/11.22/11.23/
11.31)
[Windows]
•MicrosoftWindows
XP(32/64bits)/2003
Server(32/64bits)/
Vista(32/64bits)/2008
Server(32/64bit)/7/2008
ServerR2/7/2008R2
[Mac]
•MacOSX10.4~10.7
[Linux]
•RedHat8~9(32bit)/Enterprise
LinuxWS4,5(32/64bit)
•FedoraCore1~7(32/64bit)
•SuSE8.2~10.2/Enterprise
Desktop9~10(32/64bit)
•Madrake9.2~10.1(32/64bit)
•Mandriva2005~2007
•Ubuntu6.06~7.04
•Debian3.1~4.0
[Novell]
•Netware5.x,6.x(TCP/IPOnly)
[Others]
•UnixSunSolaris
8,9,10(SPARC/86)IBMAIx
5.x(6.1)IBMLinux(System
P)HP-U11i(P A-RISC/IA-64)
(11.11/11.20/11.22/11.23/
11.31)
AnywebPrintNONO
SmartPanelWindowsOnly(LiteSM)WindowsOnly(LiteSM)
InstallerYESYES
EasyPrinterManagerYESYES
EasyColorManagerYESYES
EasyDocument
CreatorNONO
NetPCFaxNONO
DirectPrinting
UtilityYESYES
EasyDeployment
ManagerYESYES
Application
Network
Management
SetIP,SWAS5.0&SWS2.0,
CounThru2.5SW ASPlug-In
-JobAccounting,DriverManagement
Plug-in,DeviceMapPlug-in
SetIP,SWAS5.0&SWS2.0,
CounThru2.5SW ASPlug-In
-JobAccounting,DriverManagement
Plug-in,DeviceMapPlug-in
Copyright©1995-2013SAMSUNG.Allrightsreserved.2-4

2.Productspecicationanddescription
■Interface
ItemCLP–415NCLP-415NW
ParallelOptionInterfaceN/AN/A
USBHighSpeedUSB2.0Device1PortDevice1Port
WiredNetwork10/100/1000BaseTX10/100/1000BaseTX
WirelessNetworkN/A802.11b/g/n
LCD16charactersx2lines16charactersx2lines
LED4(ECO,POWER,NA VI,STA TUS)5(ECO,POWER,NA VI,STA TUS,
Wireless)
UserInterface
KeyPower,ECO,NA VI,OK,Stop,DemoPower,ECO,NA VI,OK,Stop,WPS
2.1.2.3.PaperHandling
ItemCLP-415NCLP-415NW
StandardCapacity-
•250-sheetCassette
Tray@80g/m²
•1-sheetManualTray
•250-sheetCassette
Tray@80g/m²
•1-sheetManualTray
Max.Capacity-251sheets@80g/m²251sheets@80g/m²
Max.Size216x356mm(8.5"x14")216x356mm(8.5"x14")
PrintingMin.Size76x127mm(3.0"x5.0")76x127mm(3.0"x5.0")
Capacity
•PlainPaper:1sheet@80g/m²
•Transparency:1sheet
•Label:1sheet
•Envelope:1sheet
•PlainPaper:1sheet@80g/m²
•Transparency:1sheet
•Label:1sheet
•Envelope:1sheet
Mediasizes
A4,Letter,Legal,Ocio,Folio,
JISB5,ISOB5,Executive,A5,
Statement,A6,IndexCardStock,
Postcard,EnvelopeMonarch,
EnvelopeNo-10,EnvelopeDL,
EnvelopeC5,EnvelopeC6,Envelope
No9,Custom[76x127mm(3.0"x
5.0")~216x356mm(8.5"x14")]
A4,Letter,Legal,Ocio,Folio,
JISB5,ISOB5,Executive,A5,
Statement,A6,IndexCardStock,
Postcard,EnvelopeMonarch,
EnvelopeNo-10,EnvelopeDL,
EnvelopeC5,EnvelopeC6,Envelope
No9,Custom[76x127mm(3.0"x
5.0")~216x356mm(8.5"x14")]
Mediatype
PlainPaper,ThinPaper,ThickPaper,
Cardstock,ThickerPaper,Hole
Punched,Transparency,Pre-Printed,
LetterHead,Recycled,Archive,Bond,
Label,Envelope,Cotton,Colored,
Glossy
PlainPaper,ThinPaper,ThickPaper,
Cardstock,ThickerPaper,Hole
Punched,Transparency,Pre-Printed,
LetterHead,Recycled,Archive,Bond,
Label,Envelope,Cotton,Colored,
Glossy
Multi-purposetray
2-5Copyright©1995-2013SAMSUNG.Allrightsreserved.

2.Productspecicationanddescription
ItemCLP-415NCLP-415NW
Mediaweight
•SupportedWeight:60~
220gsm
•ThinPaper:60~69g/m²
•PlainPaper:70~89g/m²
•ThickPaper:90~120g/m²
•Cardstock:121~163g/m²
•ThickerPaper:164~220g/m²
•Thickpaper:90~104g/m²
•BondPaper:105~120g/m²
•SupportedWeight:60~
220gsm
•ThinPaper:60~69g/m²
•PlainPaper:70~89g/m²
•ThickPaper:90~120g/m²
•Cardstock:121~163g/m²
•ThickerPaper:164~220g/m²
•Thickpaper:90~104g/m²
•BondPaper:105~120g/m²
SensingPaperEmpty:noPaperEmpty:no
Capacity•250sheets@80g/m²
•Envelope20sheets
•250sheets@80g/m²
•Envelope20sheets
Mediasizes
A4,Letter,Legal,Ocio,Folio,JIS
B5,ISOB5,Executive,A5,Statement,
A6,Postcard,EnvelopeMonarch,
EnvelopeNo-10,EnvelopeDL,
EnvelopeC5,EnvelopeC6,Envelope
No9,Custom[98x127mm(3.86"x
5.00")~216x356mm(8.5"x14")]
A4,Letter,Legal,Ocio,Folio,JIS
B5,ISOB5,Executive,A5,Statement,
A6,Postcard,EnvelopeMonarch,
EnvelopeNo-10,EnvelopeDL,
EnvelopeC5,EnvelopeC6,Envelope
No9,Custom[98x127mm(3.86"x
5.00")~216x356mm(8.5"x14")]
Mediatypes
PlainPaper,ThinPaper,ThickPaper,
Cardstock,ThickerPaper,Hole
Punched,Transparency,Pre-Printed,
LetterHead,Recycled,Archive,Bond,
Label,Envelope,Cotton,Colored
PlainPaper,ThinPaper,ThickPaper,
Cardstock,ThickerPaper,Hole
Punched,Transparency,Pre-Printed,
LetterHead,Recycled,Archive,Bond,
Label,Envelope,Cotton,Colored
Mediaweight
•SupportedWeight:60~
220gsm
•ThinPaper:60~69g/m²
•PlainPaper:70~89g/m²
•ThickPaper:90~120g/m²
•Cardstock:121~163g/m²
•ThickerPaper:164~220g/m²
•SupportedWeight:60~
220gsm
•ThinPaper:60~69g/m²
•PlainPaper:70~89g/m²
•ThickPaper:90~120g/m²
•Cardstock:121~163g/m²
•ThickerPaper:164~220g/m²
StandardCassette
Tray
Sensing
•H/WInstallDetect:No
•PaperEmpty:Yes
•PaperTypeDetect:No
•PaperSizeDetect:No
•H/WInstallDetect:No
•PaperEmpty:Yes
•PaperTypeDetect:No
•PaperSizeDetect:No
OptionCassette(SCF)N/AN/A
Capacity
(Face-Down)100sheets@80g/m²100sheets@80g/m²
OutputStacking
OutputFullsensingPaperfullSensorPaperfullSensor
ADFN/AN/A
DuplexN/AN/A
Copyright©1995-2013SAMSUNG.Allrightsreserved.2-6

2.Productspecicationanddescription
ItemCLP-415NCLP-415NW
OtherMedia
•Top&Bottom:4.23mm(0.2")
fromedge
•Left&Right:3mm(0.11")
fromedge
•Top&Bottom:4.23mm(0.2")
fromedge
•Left&Right:3mm(0.11")
fromedge
Non-PrintableArea
Envelope
•Top&Bottom:10mm(0.4")
fromedge
•Left&Right:10mm(0.4")
fromedge
•Top&Bottom:10mm(0.4")
fromedge
•Left&Right:10mm(0.4")
fromedge
2.1.2.4.ReliabilityandService
ItemCLP-415NCLP-415NW
PrintingV olume(SETAMPV)1,600sheets/month1,600sheets/month
Max.MonthlyDuty40,000sheets40,000sheets
2.1.2.5.Environment
ItemCLP-415NCLP-415NW
Operation15to30°C(59to86°F)15to30°C(59to86°F)
TemperatureStorage(packed)-20to50°C(-4to122°F)-20to50°C(-4to122°F)
Operation20to80%RH20to80%RH
HumidityStorage(packed)10to90%RH10to90%RH
PrintingLessthan50dBA(SoundPressure)Lessthan50dBA(SoundPressure)
StandbyLessthan37.0dBA(SoundPressure)Lessthan37.0dBA(SoundPressure)
AcousticNoise
Level(Sound
Power/Pressure)SleepBackGroundLevelBackGroundLevel
ReadyLessthan50WLessthan50W
A VG.Lessthan380WLessthan380W
Max/Peak1400W1400W
PowerConsumption
PowerSaveLessthan1.0WLessthan1.5W
Dimension(WxDx
H)SET420x426x264mm(16.54x16.77x 10.39inches)
420x426x264mm(16.54x16.77x
10.39inches)
WeightSET16.66Kg(36.73lbs)16.66Kg(36.73lbs)
2.1.2.6.Consumables
ItemCLP-415NCLP-415NW
Model
•CLT-K504S:Black
•CLT-Y504S:Yellow
•CLT-M504S:Magenta
•CLT-C504S:Cyan
•CLT-K504S:Black
•CLT-Y504S:Yellow
•CLT-M504S:Magenta
•CLT-C504S:Cyan
TonerCartridge
2-7Copyright©1995-2013SAMSUNG.Allrightsreserved.

2.Productspecicationanddescription
ItemCLP-415NCLP-415NW
Yield
•Averagecontinuousblack
cartridgeyield:Apporx.2,500
standardpages(Black)
•Averagecontinuouscolor
cartridgeyield:Apporx.
1,800standardpages
(Yellow/Magenta/Cyan)
NOTE
Declaredcartridgeyieldin
accordancewithISO/IEC19798
•Averagecontinuousblack
cartridgeyield:Apporx.2,500
standardpages(Black)
•Averagecontinuouscolor
cartridgeyield:Apporx.
1,800standardpages
(Yellow/Magenta/Cyan)
NOTE
Declaredcartridgeyieldin
accordancewithISO/IEC19798
ModelCLT-W504CLT-W504
WasteToner
ContainerYield
Apporx.14,000standardpages
(Black)
Apporx.3,500standardpages
(Yellow/Magenta/Cyan)
Apporx.14,000standardpages
(Black)
Apporx.3,500standardpages
(Yellow/Magenta/Cyan)
2.1.2.7.MaintenanceParts
ItemCLP-415NCLP-415NW
PartCodeJC95–01637AJC95–01637A Transferroller
Life100,000pages100,000pages
PartCodeJC91–01130A(220V)/JC91–01131A
(110V)
JC91–01130A(220V)/JC91–01131A
(110V)
Fuserunit
Life50,000pages50,000pages
PartCodeJC93–00673AJC93–00673A Pick-Uproller
Life200,000pages200,000pages
PartCodeJC93–00675AJC93–00675A Retard(Reverse)
rollerLife100,000pages100,000pages
PartCodeJC96–06514AJC96–06514A ITBunit
Life100,000pages100,000pages
2.1.2.8.Option
Support
ItemModelNameCLP-415NCLP-415NW
Memory•ML-MEM370(512
MB)YesYes
OptionCassette(SCF)-N/AN/A
Wirelessnetwork-N/AYes(Default)
HardDisk-N/AN/A
USBtoParallelCable-N/AN/A
Copyright©1995-2013SAMSUNG.Allrightsreserved.2-8

2.Productspecicationanddescription
2.1.3.ModelComparisonTable
SamsungCLP-415NWSamsungCLP-680NDHPCP2025dn
Mono/ColorSpeed
(A4)
18/18ppm24/24ppm20/20ppm
Processor533MHz533MHz600MHz
Memory(Std/Max)256MB/512MB256MB/512MB128MB/384MB
PrintLanguageSPLC,PCL5Ce,PCL6C,PS3,
PDFV1.7
SPLC,PCL5Ce,PCL6C,PS3,
PDFV1.7
HPPCL6,HPPCL5c,HP
postscript3
PaperInput250sheetsCassette250sheetsCassette
520sheetsOptionalCassette
250sheetsCassette
250sheetsOptionalCassette
DuplexN/AStandardStandard
InterfaceHighSpeedUSB2.0
10/100/1000BaseTX
HighSpeedUSB2.0
10/100/1000BaseTX
HighSpeedUSB2.0
10/100BaseTX
Size(mm)420x426x264mm(16.54x
16.77x10.39inches)
453x420x312mm(17.83x
16.54x12.28inches)
405x484x322mm
TonerCartridge
(K/CMY)
2.5K/1.8K•2K/1.5K
•6K/3.5K
3.5K/2.8K
2-9Copyright©1995-2013SAMSUNG.Allrightsreserved.

2.Productspecicationanddescription
2.2.SystemOverview
Thischapterdescribesthefunctionsandoperatingprincipalofthemaincomponent.
2.2.1.FrontView
NOTE
•Thisillustrationmaydifferfromyourmachinedependingonyourmodel.Therearevarioustypesofmachine.
•Somefeaturesandoptionalgoodsmaynotbeavailabledependingonmodelorcountry.
0
0
v
v
w
w
xx
y
y
z
z
{
{
|
|
v
v
vv
}
}
~
~
v
v
uu
v
v
ww
1Outputsupport
2Outputtray
3Controlpanel
4Controlboardcover
5Tray1
6Frontcover
7Frontcoverhandle
8Tonercartridges
9Tonercartridgehandle
10IntermediateTransferBelt(ITB)
11Paperwidthguidesonamanualfeeder
12Manualfeeder
Copyright©1995-2013SAMSUNG.Allrightsreserved.2-10

2.Productspecicationanddescription
2.2.2.RearView
NOTE
•Thisillustrationmaydifferfromyourmachinedependingonyourmodel.Therearevarioustypesofmachine.
•Somefeaturesandoptionalgoodsmaynotbeavailabledependingonmodelorcountry.
w
w
x
x
z
z
{
{
|
|
0
v
v
yy
1Wastertonercontainer
2Rearcover
3Rearcoverhandle
4Powerreceptacle
5Power-switch
6USBport
7Networkport
2-11Copyright©1995-2013SAMSUNG.Allrightsreserved.
