Chapter 1 Introduction
E
The DAY/NIGHT Camera operates in a co or mode in an the
i umination over the standard va ue and otherwise in B/W mode by
de eting the IR Cut function, which contributes to the improvement
of sensitivity so that it is ca ed a ow i umination camera which is
ab e to identify objects in a dark area. Meanwhi e, it has
incorporated a Sense Up function owing to a ow speed shutter and
a fie d accumu ation method to improve its ow i umination feature
prominent y.
The DAY/NIGHT Camera is most y used in dark p aces ike
basement parking ots with a comparative y ow i umination. In
daytime, it provides a co or screen of high density with a horizonta
reso ution of 480, and, at night, it uti izes the DAY/NIGHT function
as we as the Sense Up function to identify objects. In same cases,
you may use this camera in reation to the infrared ray emission
equipment additiona y.
[DAY/NIGHT]
It is a function of a co or camera to de ete the fiter with the
IR Cut function in an i umination be ow the standard va ue
so that it has a better sensitivity.
00424ASCC-B2307P-eng 4/7/059:11PM ˘`5

6
Chapter 2 Special Features
E
High Sensitivity
It has an up-to-date 1/3" Super(EXview)-HAD IT CCD for an image of high
sensitivity.
Low Illumination Function
It has both a ow i umination function and DAY/NIGHT function based on
digita signa technoogy in order to operate in the worst environment
without ight.
Digital Zoom Function
It has a digita zoom function for a 10 time en argement as a maximum. (If
you turn the PIP function to the Digita Zoom mode, the whoe screen wi
be disp ayed as a PIP screen.
Superior Back Light Adjustment Function
In case the object has a bright i umination or sun ight behind it, this camera
adjusts the image shaded by the back ight for c ear photographs.
Digital Power Supply Synchronization Method
The Fu Digita Method Line Lock is rea ized in this camera, which adjusts
the vertica camera synchronization direct y to improve contro abi ity and
re iabi ity of the camera.
Resolution
It rea izes high reso ution resu ting from fu digita image processing
supported by a state-of-art digita signa techno ogy.
Output Signal Setting
It is abe to reverse video output signa s and set both a vertica and
horizonta profi e.
00424ASCC-B2307P-eng 4/7/059:11PM ˘`6

7
Chapter 3 Part Names and Functions
E
Side View
Mount Adapter Fixing Groove
This groove is used for screwing the mount adapter, a part of the bracket
where the camera wi be insta ed.
Camera Lens(Option)
This ens is insta ed in the camera.
* A camera ens with a stained surface shou d be c eaned softy with a ens
tissue or ethano painted cotton c oth.
Auto Iris Lens Connector
This connector provides the automatic shutter ens with power supp y,
contro signa , video signa , or DC signa necessary for the contro of the
ens shutter
Automatic Shutter
Lens Contro Cab e
ALC Lens
Se ection Switch
Auto Iris Lens
Connector
Mount Adapter Fixing
Groove
Back Focus
Contro Bar
Camera Lens
00424ASCC-B2307P-eng 4/7/059:11PM ˘`7

E
8
Auto Iris Lens Control Cable
This cab e transmits the contro signa from the camera to contro the ens
shutter.
Back Focus Control Bar
It contro s the back focus.
ALC Lens Setting Switch
This switch sets the Auto Iris ens type for use.
 DC : When you attach an Auto Iris ens requiring the DC contro signa,
p ease put this switch in the DC position.
 VIDEO : When you attach an Auto Iris ens requiring the video contro
signa , p ease put this switch in the VIDEO position.
Rear View
00424ASCC-B2307P-eng 4/7/059:11PM ˘`8

E
9
① Power Display LED
When the camera is supp ied with power, LED is on.
➁Video Output Terminal
The monitor video input termina is connected with this termina through
which the camera video signa comes out.
➂Remote Input Terminal(RS-232)
This termina is used for camera contro at the production p ant.
1234
1 TXD
2 RXD
3 +5V
4 GND
00424ASCC-B2307P-eng 4/7/059:11PM ˘`9

E
10
➃ DAY/NIGHT External Signal Input & Alarm Signal Output
This is a function to receive the externa DAY/NIGHT signa from the
sensor(option) and convert the signa into BW. The MOTION DET
function generates an a arm signa when a movement is detected.
①
➁
DAY/NIGHT IN
GND
ALARM OUT
Connect an externa sensor to the DAY/NIGHT termina as shown in ①then
connect any externa device such as a buzzer or amp to the ALARM
termina as shown in ➁.
The ALARM output termina is an open co ector with the fo owing capacity:
DC 16V and 100mA.
OFF : Open contact
ON : Be ow 100mA
The DAY/NIGHT input termina has the input of DC 5V pu -up and over
0.2mA.
OFF : Open contact
ON : C osed contact
00424ASCC-B2307P-eng 4/7/059:11PM ˘`10

E
11
⑤ Camera Operation Switch(Setup Switch)
The function of the camera operation switch changes depending on
whether the camera is current y in the usua operation mode(No setup
menu is seen on the screen) or the setup menu mode.
In the usual operation mode
[LEFT/RIGHT] key : Press key for about 2 seconds and the
menu comes out to contro the DC IRIS eve . The
[LEFT] key raises the eve and the [RIGHT] key
owers the eve .
[ENTER] key : It is used to enter the Setup menu.(Press it about 2
seconds.)
In the setup menu mode
[UP/DOWN] key : These keys move up or down the cursor.
[LEFT/RIGHT] key : These keys move the cursor to the eft or right or
identify the vaues sequentia y which can be
assigned in each setup menu.
[ENTER] key : It is used to enter a sub-menu of a setup menu by
c icking the setup menu or to set the current va ue.
➅ Power Connection Port
This port is connected to the power(adapter) cabe.
[LEFT/RIGHT] key
[ENTER] key
[UP/DOWN] key
00424ASCC-B2307P-eng 4/7/059:11PM ˘`11

12
Chapter 4 Installation
E
This chapter describes what shou d be checked before insta ation, how to
set the insta ation environment, and what shou d be done during
insta ation. Then, it describes how to insta the camera and connect the
cab e in actua circumstances.
Be sure to check if the fo owing items are inc uded in the package.
Before Installation
Checking the contents of the package
Camera Camera Ho der(Mount)
C Mount Adapter Auto Iris
Lens Connector
User's Manua
00424ASCC-B2307P-eng 4/7/059:11PM ˘`12

E
13
① Do not disassemb e the camera on your own.
➁Be carefu when hand ing the camera at a times. Do not strike the
camera with your fists or shake it. The camera shoud be stored and
treated with care to avoid any damage.
➂Do not put or operate the camera in rain or wet p aces.
➃ Do not scrub the camera body with rough sandpaper when it is stained.
P ease use a dry c oth at a times.
⑤ Put the camera in a coo area free from direct ight. Otherwise, the
camera may be damaged.
What should be done during installation and use
00424ASCC-B2307P-eng 4/7/059:11PM ˘`13

E
1
Connecting Auto Iris Lens Connector
Prepare the Auto Iris ens connector, a camera auxi iary, as fo ows :
Connect each uncovered shutter contro cab e wire to the Auto Iris ens
connector as fo ows.
Pin No. DC Contro Type VIDEO Contro Type
1 Damp(-) Power (+12V)
2 Damp(+) N/A
3 Drive(+) VIDEO Signa
4 Drive(-) GROUND
00424ASCC-B2307P-eng 4/7/059:11PM ˘`14

E
15
Installation
Lens Fixing
In case of CS lenses
Turn the CS ens c ockwise unti it is fixed as shown as fo ows.
In case of C lenses
Turn the C-mount adapter c ockwise to fix it. Then turn the C ens
c ockwise unti it is fixed as fo ows.
CS lens
C lens
00424ASCC-B2307P-eng 4/7/059:12PM ˘`15

E
16
Setting Switch Control
Back Focus Adjustment
You shou d change the position of the ens setting switch on the side of the
camera according to the ens type. Depending on whether you fixed the DC
contro type Auto Iris ens or video contro type automatic shutter ens, you
shou d put the switch in "DC" or "VIDEO" position respective y.
The camera back focus is adjusted at the p ant before de ivery, but some
enses are out of focus though the number differs in types. If it's the case,
you shou d make the back focus adjustment as fo ows. First, this is the
back focus adjustment procedure for fixed focus enses.
Lenses without zoom function
① Image an object with high reso ution( etticed) at more than 10m distance
and put the ens focus ring in the infinite(∞) position.
➁Rotate the BACK FOCUS contro bar unti the object is seen best.
➂Tighten the BACK FOCUS contro bar fixing screw.
00424ASCC-B2307P-eng 4/7/059:12PM ˘`16

E
17
Lenses with zoom function
① Image an object with high reso ution( etticed) at a distance of 3 to 5 m
and zoom in the ens as c ose to TELE as possib e. Then adjust the ens
focus bar unti the object is seen best.
➁Zoom in the ens as c ose to WIDE as possib e and adjust the BACK
FOCUS adjustment bar unti the object is seen best.
➂Repeat from ①to ➁above 2 or 3 times unti the focus on the ZOOM
TELE side is in ine with that on the ZOOM WIDE side.
00424ASCC-B2307P-eng 4/7/059:12PM ˘`17

E
18
Connecting Cables and Checking Operation
1 First, connect the connector of the BNC cabe to the Video Out termina
2 Second, connect the other connector of the BNC cab e to the Video In
termina .
3 Then, connect the power adapter. Connect a part of the power adapter
composed of 2 ines to the Camera Power In termina with a fat-head
driver as fo ows.(GND : marked with a white ine)
* Power source may be AC24V or DC12V irrespective of po arity
BNC cabe
Video Out Termina
Video In Termina of
Monitor Rear Surface
00424ASCC-B2307P-eng 4/7/059:12PM ˘`18

E
19
00424ASCC-B2307P-eng 4/7/059:12PM ˘`19

20
Chapter 5 Camera Set-Up
E
This chapter describes how to set up the camera. The first part
describes the whoe set up menu and composition and the second part
describes the function of each menu.
ON...
ALC...
ELC...
BW...
EXT...
AUTO...
USER...
COLOR...
MANU...
LINE...
MOTION DET ON...
CAMERA ID
ON.../OFF
CAMERA ID AND
LOCATION SETUP
DC IRIS SETUP
LEVEL SETUP
AREA SETUP
GAIN, AGC COLOR
SETUP
BURST SETUP
BURST, LEVEL,
DURATION SETUP
3200K/5600K/USER
RED, BLUE SETUP
PHASE SETUP
AREA SETUP
SENSITIVITY SETUP
BAU DRATE D-ZOOM, PIP,
MIRROR,
POSI/NEGA,DETAIL,
MOTION DET
IRIS
ALC.../ELC...
COLOR/BW
COLOR.../BW.../
AUTO.../EXT...
SHUTTER
OFF/1/100~1/10K
OFF/AUTO X2~X128
OFF/FIX X2~X128
AGC
OFF/LOW
/HIGH
MOTION
S.SLOW~F.FAST
WHITE BAL
ATW/AWC/MANU...
SYNC
INT/LINE...
SETUP
MENU
SPECIAL
...
EXIT
QUIT/SAVE/PRESET
BLC
OFF/BOTTOM.../
TOP.../LEFT.../
RIGHT.../
CENTER.../USER..
00424ASCC-B2307P-eng 4/7/059:12PM ˘`20
