Sandstrom SFMGL15 User manual

Quick Start Guide
Easy glide full motion
TV mount
SFMGL15
Thank you for purchasing your new Sandstrøm Bracket.
Please follow this quick start guide for a successful first time set up.
Read all the safety instructions carefully before use and keep the quick start guide
for future reference.
DSG Retail Ltd. (co. no. 504877)
1 Portal Way, London, W3 6RS, UK
IB-SFMGL15-160302V3
Visit Partmaster.co.uk today for the easiest way to buy electrical spares and
accessories. With over 1 million spares and accessories available we can deliver direct to
your door the very next day. Visit www.partmaster.co.uk or call 0344 800 3456 (UK
customers only) Calls charged at National Rate.
CUSTOMER HELPLINE (UK Customers Only)
0344 561 1234
Quick Start Guide
WARNING! READ THE FOLLOWING BEFORE STARTING INSTALLATION
• Assembly is required. Installation must be carried out by qualified personnel only. Incorrect assembly can result in severe personal injury
and property damage.
• The supplied TV bracket is only for use on vertical walls constructed from solid brick, solid concrete, solid wood and solid wooden
columns.
• It is the installers’ responsibility to verify that the wall will safely support the total load of the TV and the TV bracket. Never exceed the
designated maximum TV load.
• Parts are heavy; take care when handling. For some steps, 2 people are required for installation.
• Check the TV bracket frequently to ensure that it is safe and secure. Additional tools (not included) are required for the installation. Do
not over-tighten screws.
• Keep this instruction manual for future reference.
UNPACKING
SAFETY
SWIVEL ANGLE
-90° ~ +90°
TV LOAD
15 - 25 kg
KG
TV SIZE
47” - 65”
DISTANCE TO WALL
84 - 667 mm
TILT ANGLE
-5° ~ +10°
VESA COMPLIANCE
200 x 100 - 600 x 400 mm
This Mount comes with a 3-year guarantee. If the product fails whilst in use for its
intended purpose, please return it, along with your receipt, for a full refund or
replacement. Please follow the instruction manual carefully when installing this device.
M6 × 15
M8 × 12
M6 × 20 M6 × 35
M8 × 20 M8 × 35M8 × 15
M5 × 20 M5 × 30M5 × 15
Ø6-Ø8 × 5 Ø6-Ø8 × 10 Ø4-Ø5 Ø6-Ø8
x 4
B1 x 4 B2 x 4 B3 x 4 B4 x 4 B5 x 4 B6
x 4
B7
x 4
B10 x 6 B11 x 4 B12 x 4 B13
x 4
B8 x 4 B9
x 4
A1 x 4 A2 x 4 A3
x 2
A13 x 1 A14 x 2 A15
x 1
A4
x 1
A8 x 1
A10 x 1 A11
x 1
A9
x 3
A6
M6 × 10
x 2
A7
full motion
x 1
A12
SFMGL15
Http://sandstromstyle.com
M8 × 55
x 2
B14
x 4
A5
Soft pad

2
34
6
5
1
TOOLING
INSTALLATION
Use spacers provided for mounting TVs with curved/recessed
backs, recessed mounting holes, or to allow access to A/V inputs.
Place the soft pad as desired to act as cushion between the TV
and the bracket.
A5
2 people are required to lift the unit
during assembly.
A2
A3
A1
A12
A13
A6
A9
A4
A3
A1
A13
A7 A10
A7
B2 B3
B6
B1
B7 B8
B4 B5
B9 B14
B13B12
B11B10
A5
A15
A14
A11A8
A12
ø5mm
90mm
ø10mm
90mm
Ensure mounting screws are in
the centre of the timber stud.
