Sandstrom STM14 User manual

Flat to Wall Tilting
TV Mount for
Medium TVs
Quick Start Guide
STM14
TV Mount for
Medium TVs
Thank you for purchasing your new Sandstrøm Bracket.
Please follow this quick start guide for a successful first time set up.
Read all the safety instructions carefully before use and keep the quick start guide
for future reference.
DSG Retail Ltd. (co. no. 504877)
1 Portal Way, London, W3 6RS, UK
IB-STM14-170525V6
Visit Partmaster.co.uk today for the easiest way to buy electrical spares and
accessories. With over 1 million spares and accessories available we can deliver direct to
your door the very next day. Visit www.partmaster.co.uk or call 0844 800 3456 (UK
customers only) Calls charged at National Rate.
CUSTOMER HELPLINE (UK Customers Only)
0344 561 1234
Quick Start Guide
Http://sandstromstyle.com
MAX TV LOAD
30 kg
KG
TV SIZE
32” - 47”
DISTANCE TO WALL
24mm
TILT ANGLE
0° ~ 15°
VESA COMPLIANCE
100 x 100 - 400 x 400mm
WARNING! READ THE FOLLOWING BEFORE STARTING INSTALLATION
• Assembly is required. Installation must be carried out by qualified personnel only. Incorrect assembly can result in severe personal injury
and property damage.
• The supplied TV bracket is only for use on vertical walls constructed from solid brick, solid concrete, solid wood and solid wooden columns.
• It is the installers’ responsibility to verify that the wall will safely support the total load of the TV and the TV bracket. Never exceed the
designated maximum TV load.
• Parts are heavy; take care when handling. For some steps, 2 people are required for installation.
• Check the TV bracket frequently to ensure that it is safe and secure. Additional tools (not included) are required for the installation. Do not
over-tighten screws.
• Keep this instruction manual for future reference.
This Mount comes with a 3-year guarantee. If the product fails whilst in use for its
intended purpose, please return it, along with your receipt, for a full refund or
replacement. Please follow the instruction manual carefully when installing this device.
UNPACKING
SAFETY
Soft pad
x 4
A5
x 4
A1 x 4 A2 x 4 A3 x 1 A4
x 1
A6 x 2 A7
x 4
B13 x 4 B14 x 4 B15
M6-M8 × 5 M6-M8 × 10 M4, M5/M6, M8
M5 × 15 M5 × 20 M5 × 30
M6 × 20 M6 × 35M6 × 15
M4 × 25 M4 × 35M4 × 15
x 4
B1 x 4 B2 x 4 B3 x 4 B4 x 4 B5 x 4 B6
M8 × 20 M8 × 35 M8 × 50
x 4
B10 x 4 B11 x 4 B12
x 4
B7 x 4 B8 x 4 B9
Watch this video for
quick assembling.

2
3
4
1
2 people are required to lift the unit
during assembly.
TOOLING
INSTALLATION
A1
A3
A2
A4
A1
A3
ø4.5mm
60mm
ø10.5mm
60mm
Ensure mounting screws are in
the centre of the timber stud.
A5
Use spacers provided for mounting TVs with
curved/recessed backs, recessed mounting holes,
or to allow access to A/V inputs.
Place the soft pad as desired to act as cushion
between the TV and the bracket.
B1
B7
B2
B8
B3
B9
B4
B10
B5
B11
B6
B12
B15
B13 B14
A5
Screw M4
Screw M8
Screw M5-M6
