Sandstrom SFMGM18 User manual

Easy-glide Full-motion TV mount
Instruction Manual
SFMGM18
Thank you for purchasing
your new product.
Please follow this quick start guide
for a successful first time set up.
Read all the safety instructions
carefully before use and keep
the quick start guide for future
reference.
Scan to watch an
assembly video
• 2 people are required to install
the Wall Mount and to lift the TV
onto the Mount.
Sandstrom Easy Glide Full Motion TV Mount SFMGM18 Manual.indd 1 17/03/2020 08:01

Safety
WARNING! READ THE FOLLOWING BEFORE STARTING INSTALLATION
• Assembly is required. Installation must be carried out by qualified personnel only. Incorrect assembly can result in severe personal
injury and property damage.
• The supplied TV bracket is only for use on vertical walls constructed from solid brick, solid concrete, solid wood and solid wooden
columns.
• It is the installers’ responsibility to verify that the wall will safely support the total load of the TV and the TV bracket. Never exceed the
designated maximum TV load.
• Parts are heavy; take care when handling. For some steps, 2 people are required for installation.
• Check the TV bracket frequently to ensure that it is safe and secure. Additional tools (not included) are required for the installation. Do
not over-tighten screws.
• Keep this instruction manual for future reference.
TV LOAD
6 - 20 kg
KG
TV SIZE
32” - 55”
DISTANCE TO WALL
73 - 565 mm
VESA COMPLIANCE
100 x 100 – 400 x 400 mm
TILT ANGLE
-5° ~ +10°
SWIVEL ANGLE
-90° ~ +90°
ROTATE ANGLE
-5° ~ +5°
Use the
Spanner
provided
Use the
Spanner
provided
Sandstrom Easy Glide Full Motion TV Mount SFMGM18 Manual.indd 2 17/03/2020 08:01

Unpacking the TV Mount
Remove all packaging from the TV Mount. Retain the packaging. If you dispose of it please do so according to local regulations.
The following items are included:
Type - M4
Size - 4 x 15mm
Type - M6 / M8 Spacer
Size - 4 x 5mm
Type - M6 / M8 Spacer
Size - 8 x 10mm M4 / M5 / M6 / M8 Washer× 4
Type - M5
Size - 4 × 15mm
Type - M4
Size - 4 x 35mm
Type - M5
Size - 4 × 30mm
Type - M6
Size - 4 × 15mm
Type - M6
Size - 4 × 35mm
Type - M8
Size - 4 × 20mm
B1 B2
B10 B11 B12
B3 B4
Vesa Mount Screws, Spacers & Washers
B5 B6 B7
Type - M8
Size - 4 × 35mm
B8
Type - M8
Size - 4 × 50mm
B9
Wall Mount
Screws x 4
Wall Plugs
x 4
Wall Mount
Washer x 4
Soft Washer
x 4
Spanner
x 1
Self adhesive
spirit level x 1
Back plate
Nuts x 2
A1 A2 A3 A4 A6A5 A7
Allen Key x 1
A9A8 A10 A11
Plastic covers Back Plate Back Plate
edges
TV Mounts
A12
Card template x 1
Only 4 of the vesa mount screws will be required, check your TVs instruction manual for the correct size (M5, M6 or M8).
Sandstrom Easy Glide Full Motion TV Mount SFMGM18 Manual.indd 3 17/03/2020 08:01

Installation
First decide where you are wanting to mount your TV, remember the TV mount is fully adjustable. Also think which type of wall the TV mount
is going to be attached to. If its a stud wall then you'll have to position the bracket on the studs, so this may also influence where the TV mount
can be positioned.
Tools Required
You will need the following tools to install your TV mount. Tools are not supplied
Stud/Multi
Detector
Tape Measure Drill Ø10mm Masonry Drill Bit
Ø 4.5mm Wood Drill Bit
Screw
Driver
Socket
Set
Pencil Hammer
Locating the Wall Mount
You will need the following tools to install your TV mount. Tools are not supplied
A4
1. For mounting on a stud wall, first use a stud/multi
detector and mark where the studs are.
2. Then stick the spirit level to the card template. Hold the card template
against the wall and mark the positions of the drill holes. Make sure
they are on the studs.
3. For a masonry walls use the stud/multi detector to check for pipes
or cables then use the card template to mark the location of the drill
holes.
Scan to watch an
assembly video
• 2 people are required to install
the Wall Mount and to lift the TV
onto the Mount.
Sandstrom Easy Glide Full Motion TV Mount SFMGM18 Manual.indd 4 17/03/2020 08:01

Fixing the Wall Mount to the wall
For mounting to a stud wall you will need a Ø 4.5mm wood drill bit, or for masonry walls you will need a Ø 10mm masonry drill bit.
• Parts are heavy; 2 people are required for installation.
ø10mm
60mm
ø4.5mm
60mm
Ensure mounting screws are in
the centre of the timber stud.
A9
&
A10
A3 A1
A2 A3 A1
Masonry wall Stud wall
1. Using a Ø10mm masonry drill bit, drill 4 holes to a depth
of 60mm. Make sure you don’t drill into the cement
between the bricks.
2. Insert a wall plug into each hole.
3. 2 people are required for the next step, one to hold the
mount against the wall and one to insert the screws.
4. Slide a washer (A3) onto a screw (A1) then use a Socket
Set (not supplied) to screw the screw into the wall. Repeat
for all 4 screws.
1. Using a Ø4.5mm wood drill bit, drill 3 holes to a depth of
60mm. Make sure the holds are in the centre of each stud.
2. 2 people are required for the next step, one to hold the
mount against the wall and one to insert the screws.
3. Slide a washer (A3) onto a screw (A1) then use a Socket
Set (not supplied) to screw the screw into the wall. Repeat
for all 3 screws.
Sandstrom Easy Glide Full Motion TV Mount SFMGM18 Manual.indd 5 17/03/2020 08:01

Fitting the Back Plate and Covers
A11
A10
A11
A9
A9
A6
A6
1. Slide the plastic covers (A9) over the wall mount and
screw the cable management clip to the front of the
mount.
2. Attach the back plate (A10) to the mount using 2 nuts
(A6) and tighten the nuts.
3. Fit the back plate edges (A11).
Fitting the TV Mounts to the Back of the TV
Consult your TVs instruction maunal to find out which vesa mount screw size you should use M4, M5, M6 or M8. You will only need to use 4 of
the supplied screws. If the back of your TV is uneven you may need to use some spacers when attaching the TV Mounts to the TV.
B6 B7 B8B5
B9
B2 B3B1 B4
B12
B11B10
A5
A12
Screw M8
Screw M5-M6
Screw M4
Use spacers provided for mounting TVs with
curved/recessed backs, recessed mounting
holes, or to allow access to A/V inputs.
Place the soft pad as desired to act as
cushion between the TV and the bracket.
A5
Sandstrom Easy Glide Full Motion TV Mount SFMGM18 Manual.indd 6 17/03/2020 08:01

1. Hook the TV mounts onto the top of the back plate
then rotate the TV to clip in at the bottom. You may
need to put on the release strings to allow it to click
into position.
Attaching the TV to the Wall Mount
You can position the TV in numerous positions along the back plate. This help you choose the position you prefer.
• 2 people are required to lift the TV onto the Mount.
Adjusting the Tension of the Wall Mount
Your TV must be attached to the wall mount before you try to adjust the tension. The tension of the spring in the wall mount will need to be
adjusted so that you can freely adjust the height of your TV without it springing up or sagging down. Only use the allen key (A8) to adjust the
tension.
20kg
6kg
20Kg
6Kg
20Kg
6Kg
Turn Clockwise to increase the tension
Turn Anti-Clockwise to decrease the tension
• If your TV is heavy and sagging down under its own
weight. Use the supplied allen key and turn the tension
adjustment screw clockwise to increase the tension of
the adjustable mount arm.
• If your TV is light and springing up on its own. Use the
supplied allen key and turn the tension adjustment
screw anti-clockwise to decrease the tension of the
adjustable mount arm.
• Once fully adjusted you should be able to easily
position the TV at your desired height and it will stay in
that position.
• Only use the supplied allen key to adjust the tension.
Sandstrom Easy Glide Full Motion TV Mount SFMGM18 Manual.indd 7 17/03/2020 08:01

Visit Partmaster.co.uk today for the easiest way to buy electrical spares and accessories. With over 1 million
spares and accessories available we can deliver direct to your door the very next day.
Visit www.partmaster.co.uk or call 0344 800 3456 (UK customers only). Calls charged at National Rate.
DSG Retail Ltd. (co. no. 504877)
1 Portal Way, London, W3 6RS, UK
EU Representative
DSG Retail Ireland Ltd (259460)
3rd Floor Office Suite
Omni Park SC, Santry, Dublin 9, Republic of Ireland
This Mount comes with a 3-year guarantee. If the product fails whilst in use for its intended purpose, please return it, along with your receipt,
for a full refund or replacement. Please follow the instruction manual carefully when installing this device.
Whether it’s a tech emergency or you need plain good advice, we’re always on hand to help,
call (UK) 0344 5611234 or (Ireland) 1 890 818 575.
All the support you need.
Currys.co.uk
Cable Management
Your TV Mount has a cable management system to keep your TV cables neat.
Slide the plastic clips out,
place the cable behind
the clips and slide them
back into place.
Remove the plastic
cover. Place the cable
in the plastic cover
then replace the cover.
IB-SFMGM18-200317V4
