Sandstrom SFML16 User manual

IB-SFML16-211129V8
UNPACKING
SAFETY
Thank you for purchasing your new product.
Please follow this quick start guide for a successful rst time set up.
Read all the safety instructions carefully before use and keep the quick start guide
for future reference.
Full Motion TV Mount
for Large TVs
Instruction Manual
SFML16
Currys Group Limited (co. no. 504877)
1 Portal Way, London, W3 6RS, UK
EU Representative
Currys Ireland Limited (259460)
3rd Floor Oce Suite
Omni Park SC, Santry, Dublin 9, Republic of Ireland
Visit Partmaster.co.uk today for the easiest way to buy
electrical spares and accessories. With over 1 million
spares and accessories available we can deliver direct to
your door the very next day. Visit www.partmaster.co.uk
or call 0344 800 3456 (UK customers only) Calls charged
at National Rate.
This Mount comes with a 3-year guarantee. If the product fails whilst in use for its
intended purpose, please return it, along with your receipt, for a full refund or
replacement. Please follow the instruction manual carefully when installing this device.
Http://sandstromstyle.com
Watch this video for
quick assembling.
Quick Start Guide
WARNING! READ THE FOLLOWING BEFORE STARTING INSTALLATION
• Assembly is required. Installation must be carried out by qualied personnel only. Incorrect assembly can result in severe personal injury and property
damage.
• The supplied TV bracket is only for use on vertical walls constructed from solid brick, solid concrete, solid wood and solid wooden columns.
• It is the installers’responsibility to verify that the wall will safely support the total load of the TV and the TV bracket. Never exceed the designated
maximum TV load.
• Parts are heavy; take care when handling. For some steps, 2 people are required for installation.
• Check the TV bracket frequently to ensure that it is safe and secure. Additional tools (not included) are required for the installation. Do not over-tighten
screws.
• Keep this instruction manual for future reference.
TV LOAD
40 kg
KG
TV SIZE
37” - 75”
DISTANCE TO WALL
55 - 680 mm
VESA COMPLIANCE
200 x 200 – 600 x 400 mm
TILT ANGLE
-12° ~ +8°
SWIVEL ANGLE
-90° ~ 90°
× 4
A1 × 4 A2 × 4 A3 × 1 A4 × 1 A5
× 2
A8
× 1
A6 × 2 A7
Ø6 × 15mm Ø6 × 35mmØ5 × 30mmØ5 × 15mm
× 4
B1 × 4 B2 × 4 B3 × 4 B4
Ø8 × 20mm
× 4
B5
Ø8 × 35mm
× 4
B6
Ø8 × 50mm
× 4
B7
× 4
B8 × 8 B9
Ø6-Ø8 × 5mm Ø6-Ø8 × 10mm
× 4
B10
Ø5 / Ø8

24 5
1
TOOLING
INSTALLATION
3
A4
ø5mm
90mm
ø10mm
95mm
Ensure mounting screws are in
the centre of the timber stud.
A7
A7
A2 A3 A1
A1
A8
Use spacers provided for mounting TVs with
curved/recessed backs, recessed mounting
holes, or to allow access to A/V inputs.
B8 B9
B10
B1 B2 B3 B4
B7B5 B6
A6
A5
2 people are required to lift
the unit during assembly.
