Sangean MMR-88 User manual

Operating instruction
Mode d’emploi
Instruccions de manejo
Gebruiksaanwijzing
Bedienungsanleitung
GB
F
E
NL
D
3A81YV1000010
MMR-88

1
Important safety instructions
Please read these instructions carefully.
Please keep these instructions for future reference.
Heed all warnings
Follow all instructions
Do not use this apparatus near water
Clean only with dry cloth
Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions
Do not install near any heat sources such as radiators, heat registers,
stoves or other apparatus (including ampliers) that produce heat.
Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong are provided for your safety. If the
provided plug does not t into your outlet, consult an electrician for
replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched particularly
at plugs, convenience receptacles and the point where they exit from
the apparatus.
Only use attachments/accessories specied by the manufacturer.
Use only with the cart, stand, tripod, bracket or table specied by the
manufacturer or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury
from tip-over.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.

GB
2
Unplug this apparatus during lightning storms or when unused for a
long period of time.
Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture does not operate normally or has been
dropped.
Apparatus shall not be exposed to dripping or splashing and no
objects filled with liquids, such as vases, shall be placed on the
apparatus.
To reduce the risk of fire or electric shock, do not expose this
apparatus to rain or moisture.
Caution: Danger of explosion if battery replaced. Replace only with
the same or equivalent type.
Battery shall not be exposed to excessive heat such as direct
sunlight, re or the like.
IMPORTANT NOTE:
To comply with the FCC RF exposure compliance requirements, no
change to the antenna or the device is permitted. Any change to
the antenna or the device could result in the device exceeding the
RF exposure requirements and void user’s authority to operate the
device and all product warranties.
CAUTION:
To reduce the risk of the electric shock, do not perform any servicing
other than that contained in the operating instructions unless you are
qualied to do so.
13.
14.
15.
16.
17.
18.

3

GB
4
Controls
LED Flashlight switch
Solar charging panel
Charging indicator
Tuning LED indicator
LCD display
Tuning Up
Power button
Tuning Down
Speaker
Emergency siren button
Display/Mono button
Band selection/Time set button
Preset station
Volume Control -down
Volume Control - up
LED Flashlight
3.5 mm headphone socket
USB charging socket to mobile phones or MP3 players
Micro USB charging outlet
Carrying strap holder
Telescopic antenna
Dynamo power hand crank
Battery compartment
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23

5
Battery power level meter
FM stereo indicator
Auto shut off indicator
Memory preset
Time and radio frequency
AM/PM local time indicator
AM Frequency Band
FM Frequency Band
A
B
C
D
E
F
G
H
LCD display icon
A
E
B C D
H
G
F
The MMR-88 is powered by an 850mAh rechargeable Lithium-ion battery
(supplied). Before operating the radio for the rst time, ensure that you
fully charge the supplied battery.

GB
6
1.
2.
Note:
Please use one of the following methods to recharge your radio or when
the battery power indicator LED blinks indicating the battery power is
low.
1.
2.
NOTE:
The radio will begin charging the Lithium-ion battery. Charging time will
take approx. 2 hours to be fully charged. The battery power icon will
stop ashing when the radio is fully charged. Reduced power, distortion,
stuttering sounds or when the battery power indicator light is low are all
signs that the battery needs to be recharged.
NOTE:
The radio can play approx. 10 hours when the battery is fully charged.
Inserting the supplied rechargeable battery
Open the battery compartment on the back of the unit by pushing the
battery door following the arrow direction.
Insert the supplied rechargeable battery into the space in the
compartment. Make sure the battery is inserted with correct polarity as
shown in the compartment.
Recharging the radio
Using the supplied USB to Micro USB cable simply plug the USB end
into a USB socket on a computer, tablet or any USB power supply.
Then plug the Micro USB end into the Micro USB socket on the right
hand side of the radio.
Using an AC adapter with a Micro USB connector (not supplied) plug
the AC adapter into a standard AC outlet. Then plug the Micro USB
end into the Micro USB socket on the right hand side of the radio. The
battery power icon will illuminate showing that charging is in progress.
The CHARGE LED indicator will also be on at the same time during
the charging process.

7
1.
2.
3.
4.
5.
Important:
The radio does not need to be switched on in order for the solar panel to
operate.
1.
2.
3.
Using Dynamo power
Make sure the telescopic antenna is in the rest position before rotating
the dynamo handle.
Take the Dynamo power handle from its rest position.
Rotate the Dynamo power handle approx. 120 rotations per minute,
either clock-wise or counter-clock wise until the charging LED indicator
appears red.
Under normal listening conditions, one minute of charging from
Dynamo power will allow you to listen to the radio for approx. 5-7
minutes (AM band mode using the speaker at a moderate volume
level).
Make sure the handle is in its rest position after charging is completed.
Using solar power
In order to recharge your MMR-88 battery using solar power, position
the radio so that the solar panel receives direct sunlight. The more
direct sunlight that shines on the solar panel, the more electricity it can
generate to power the radio.
Adjust the position of the radio to achieve maximum brightness of the
CHARGE indicator LED.
It takes approx.15 hours to fully charge the battery under direct
sunlight.

GB
8
Note:
The best performance of the solar panel will be achieved when the sun
is directly overhead, and the sunlight is unobstructed by clouds, foliage,
curtains etc. In certain situations and poor light conditions, the solar
panel may not be effective and should not be relied upon as the primary
energy source for standard usage. The solar panel is designed as a
supplementary energy source which under suitable light conditions is
able to contribute up to 100% of the radio energy requirements.
The solar panel will charge the battery only under natural sunlight. It will
not deliver a charge in articial light.
DO NOT attempt to charge the battery by placing the solar panel directly
under any kind of sun-lamp, this will cause irreversible damage to the
radio and may damage the casing. (Doing so will void all warranties)
Setting the clock
You can set the clock with either the radio turned on or off.
After the radio is charged, the display will appear with (- : --) Press and
hold BAND/TIME SET button until the hour setting begins blinking.
Select the hour by pressing Tuning UP/Down button until desired hour is
displayed. Press BAND/TIME SET button again to set the minutes. The
minute indicator should now be blinking, press the Tuning button UP/
DOWN until the desired minutes are displayed. Press BAND/TIME SET
button again to complete clock setting. The time should display solidly
with the colon blinking periodically.
Radio operation
Note:
The MMR-88 features a 90 minute auto shut off feature.
Turn on the radio, press and hold the power button for approx. 1/2
second, the radio will turn on and the 90 minute auto shut off icon will
appear on the display indicating the radio will auto shut off after 90
minutes of operation. If you don't require this feature, press and hold the
power button a little bit longer until the icon disappears from the display.
Turn off the radio by pressing the Power button for approx. 1/2 second until
the display shuts OFF. The radio will appear with the clock time in the display.

9
Seek Tuning
Turn the radio on by pressing the Power button. Select the desired band
by pressing the BAND button.
Press and hold the Tuning UP/Down button for approx. 1/2 second, the
radio will seek for the next active station. Repeat as many times until the
desired station is found.
Manual tuning
Turn the radio on by pressing the Power button; select the desired band
by pressing the Band button.
Press Tuning Up/Down button repeatedly until the desired frequency is
found.
To Preset stations
1.
2.
3.
4.
5.
Tuning the radio - using Seek Tuning, Manual Tuning
and Memory preset recall.
Turn the radio on and use seek tuning or manual tuning as described
above to tune to your desired station.
Press and hold the PRESET button for approx. 2 seconds until the
display blinks M (Memory) to enter the preset mode.
When the M (Memory) display blinks with the previous preset station
frequency, press the Tuning UP/Down button to select the desired
memory position as shown on the display.
Press the PRESET button again to complete the memory setting, the
display will appear with a P (preset) and the chosen preset position.
After the P and preset position disappear from the display, you may
then press the Tuning UP/Down button again to tune to next desired
station.
This radio features a total of 19 preset memories in random selection
for AM/FM.

GB
10
Recall stations
1.
2.
3.
Telescopic Antenna
The telescopic antenna is used for the FM reception. Extend fully
and rotate for the best FM reception. There is a built-in directional bar
antenna for the AM band reception. To achieve the best AM reception, it
may be necessary to move the radio to achieve proper reception.
Stereo/Mono switch
If the FM radio station being listened to has a weak signal, some hiss
may be audible. It is possible to reduce this hiss by forcing the radio to
play the station in mono rather than stereo.
Press and hold the Display/Mono button to switch to mono. LCD display
Stereo icon will disappear.
Note:
FM stereo is only available via earphones.
Volume Control
Press the Volume Control Button (+/-) to adjust the desired level of
sound.
Display information
When the radio is on, press and release the Display button. You can
switch the on-screen information between station frequency and time.
Turn on the radio, press the PRESET button to enter the preset mode,
the display will show your last preset station position.
Press the Tuning Up/Down button to select your desired preset
station.
Press and release the PRESET button to skip preset mode, the P
(preset) and preset position will disappear. You may then press the
Tuning UP/Down button to tune to the next desired station.

11
Changing the AM/FM tuning step
In Europe and other parts of the world the AM tuning step is 9 kHz, in North
America the AM tuning step is 10 kHz. FM tuning steps also vary from
country to country. To change the AM/FM tuning step, proceed as follows.
1.
2.
3.
Note:
Re-setting the AM tuning step will erase all the preset AM stations.
Note:
Re-setting the FM tuning step will not erase preset FM stations.
Emergency Siren
The Emergency Siren will work when either the radio is switched on or
off. Simply press and hold Emergency Siren button for 1 second, this will
activate the siren until it’s switched off by pressing the Emergency Siren
button for 1 second or the Power button.
LED Flashlight
The MMR-88 features 4 selections for the LED Flashlight. Press the
LED Flashlight button once for High, again for Low, again for Blinking
once more for SOS (Morse Code Distress Signal, three short flashes,
three long ashes, three short ashes) and one more time to shut the
Flashlight off. Or in any mode you can hold the Flashlight button down
until the Flashlight shuts off.
When the radio is turned OFF, press and hold the PRESET button for
approx. 2 seconds, the display will first show software version (e.g.
P01) then blink the FM tuning step 100 (kHz). During the blinking,
press Tuning UP/DOWN to cycle through 100 and 50 (kHz) tuning
step. Press PRESET button again to choose your desired FM tuning
step.
The display will then blink the AM tuning step 10 (kHz), press Tuning
UP/DOWN button to cycle through 10 and 9 (kHz). Press the PRESET
button again to choose your desired AM tuning step.
The radio will default to clock mode (radio is off) after re-setting tuning
step.

GB
12
Plug the headphones into the headphone socket for private listening.
This will disconnect the external speaker.
The MMR-88 features a USB charging socket to charge your mobile
phone or MP3 player and related devices with the its built-in Lithium-ion
battery.
1.
2.
You may attach the supplied carrying strap into the strap holder for easy
transport.
This radio is a water resistant device NOT a waterproof device. Please
ensure the rubber cover on the USB, Micro USB and Headphone jack
section is properly secured.
Listening with Headphones
Charging mobile phones and MP3 players
In order not to interfere with radio listening, we suggest to charge
your mobile phone, MP3 player and related devices when the radio is
switched off.
The USB charging socket can provide a maximum of 500mAh of
charging current.
Strap holder
Conditional water resistant

13
Specications
Power Supply:
850mAH rechargeable Lithium-ion battery (supplied) x 1
Dynamo - charging to rechargeable Lithium battery.
Solar panel - charging to rechargeable Lithium battery
Optional Power Supply:
AC power adaptor with Micro USB connector, (not included)
Audio Output: 400 mW
(DC In (5V/0.5A) Micro USB B Type Socket for Charging the MMR-88.
USB A to Micro B Cable & Hand strap included)
Frequency Coverage
FM (VHF): 87.50 - 108 MHz
AM: 522 - 1710 kHz (9 kHz tuning step)
520 - 1710 kHz (10 kHz tuning step)
Antenna:
Telescopic antenna: FM
Built-in Ferrite rod antenna: AM
Socket
DC Socket: DC IN Micro USB 5V 500 mA
DC OUT USB Type A 5V 300 mA
Earphones Jack:
3.5, mm in diameter, Stereo, 32 ohm Impedance
Dimension: 152 x 85 x 69 mm (W x H x D)
Weight: 400g (excluding battery)
If at any time in the future you should need to dispose of this product
please note that: Waste electrical products should not be disposed of
with household waste. Please recycle where facilities exist.Check with
yourLocalAuthority or retailer for recycling advice. (Waste Electrical and
Electronic Equipment Directive)
The company reserves the right to amend the specification without
notice.

GB
14

15
IInstructions importantes sur la sécurité
Lisez ces instructions.
Conservez ces instructions.
Tenez compte de toutes les mises en garde.
Suivez toutes les instructions.
N’utilisez pas cet appareil à proximité de l’eau.
Ne nettoyez qu’à l’aide d’un linge sec.
N’obstruez aucune voie de ventilation. Installez conformément aux
instructions du fabricant.
N’installez pas à proximité de sources de chaleur telles que
radiateurs, registre de chaleur, poêle ou autres appareils (y compris
les amplicateurs) qui produisent de la chaleur.
Ne sous-estimez pas l’importance en termes de sécurité des prises
polarisées ou de type terre. Une prise polarisée a deux ches dont l’
une est plus large que l’autre. Une prise de type terre a deux ches
plus une che supplémentaire de raccord à la terre. La che large
ou le raccord à la terre sont conçues pour votre sécurité. Si la prise
fournie ne s’adapte pas à votre installation, consultez un électricien
pour le remplacement de votre installation obsolète.
Protégez le cordon d’alimentation contre les piétinements ou les
pincements, particulièrement au niveau des branchements, prises de
courant, et du point d’où il sort de l’appareil.
N’utilisez que les extensions/accessoires spéciés par le fabricant.
N’utilisez qu’avec un chariot, support, trépied, crochet ou table spécié
par le fabricant, ou vendu avec l’appareil. Lorsque vous utilisez un
chariot, soyez attentif lorsque vous déplacez la combinaison chariot/
appareil pour éviter les blessures dues au renversement.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.

F
16
Débranchez cet appareil lors des orages ou lorsqu’il est inutilisé
pendant une longue période.
Confiez les réparation à du personnel d'entretien agréé. La
réparation est nécessaire lorsque l’appareil a été endommagé de
quelque sorte, par exemple si le cordon d’alimentation ou la prise
sont endommagés, si du liquide a été répandu ou si des objets sont
tombés dans l’appareil, si ce dernier a été exposé aux moisissures
ou à la pluie, s’il ne fonctionne pas normalement, ou qu’il a chuté.
L’appareil ne doit pas être exposé aux gouttes ou aux
éclaboussements et les objets remplis de liquides, tels que des
vases, ne doivent pas être placés près de l'appareil.
Pour réduire le risque d'incendie ou de choc électrique, n'exposez
pas cet appareil à la pluie ou l'humidité.
Attention: Danger d’explosion si les piles ne sont pas correctement
remplacées. Remplacez seulement avec les mêmes ou un type équivalent.
Les batteries ne doivent pas être exposées à des chaleurs
excessives telles que la lumière du soleil, le feu ou autres.
REMARQUE IMPORTANTE:
Pour être conforme aux exigences de conformité des
radiofréquences de la FCC, aucun changement sur l’antenne ou sur l’
appareil n’est autorisée. Tout changement sur l’antenne ou l’appareil
pourrait aboutir à un dépassement des conditions d’exposition aux
radiofréquences par l’appareil et annuler le droit de l’utilisateur à faire
fonctionner l’appareil.
ATTENTION:
Pour réduire le risque de choc électrique, ne procédez à aucune
réparation autre que celles détaillées dans ces instructions
d'utilisation a moins que vous ne disposiez des qualications.
13.
14.
15.
16.
17.
18.

17

F
18
Commandes
Interrupteur lampe torche LED
Panneau de chargement solaire
Indicateur de chargement
Indicateur de réglage DEL
Écran LCD
Réglage +
Touche d’alimentation
Réglage -
Haut parleur
Touche de sirène d'urgence
Touche Afchage/Mono
Touche de sélection de bande/Réglage de l'heure
Présélection des stations
Contrôle du volume -
Contrôle du volume +
Lampe torche LED
Fente casque 3,5 mm
Fente de chargement USB sur téléphones portables ou lecteurs MP3
Sortie de chargement micro USB
Support courroie de transport
Antenne télescopique
Dynamo à manivelle manuelle
Compartiment des piles
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23

19
Alimentation de la télécommande
Indicateur stéréo FM
Indicateur d'extinction automatique
Mémoires de présélection
Heure et fréquence radio
Indicateur d'heure local AM/PM
Bande de fréquence AM
Bande de fréquence FM
A
B
C
D
E
F
G
H
Icône d'écran LCD
Le MMR-88 est alimenté par une batterie 850 mAh lithium-ion
rechargeable (fournie). Avant d’utiliser la radio pour la première fois,
assurez-vous de recharger complètement la batterie.
A
E
B C D
H
G
F
