Service Manual

FILE NO.

REFERENCE No. SM2810024

PRODUCT CODE No.

129 726 07

Micro Component System DC-DA1450M (AU)

CONTENTS

Laser Beam Safety Precaution ........................................ 1

Tuner Adjustment ............................................................. 2

Exploded View (Cabinet & Chassis) ................................ 3

Parts List .......................................................................... 4

Wiring Connection ............................................................ 7

Schematic Diagram .......................................................... 8

Wiring Diagram ................................................................ 16

OLL

RB-DA

1450

- 1 -

• Pickup that emits a laser beam is used on this CD section.

CAUTION :

USE OF CONTROLS OR ADJUSTMENTS OR

PERFORMANCE OF PROCEDURES OTHER

THAN THOSE SPECIFIED HEREIN MAY RESULT

IN HAZARDOUS RADIATION EXPOSURE.

LASER OUTPUT................ 0.6 mW Max. (CW)

WAVE LENGTH ................. 790 nm

LASER BEAM SAFETY PRECAUTION

LOOP FM

ANT SPEAKERS

4MIN

CAUTION - INVISIBLE LASER RADIATION WHEN OPEN AND

INTERLOCKS DEFEATED. AVOID EXPOSURE TO BEAM.

ADVARSEL - USYNLIG LASER STRÅLING VED ÅBNING, NÅR

SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION, UNDGÅUDS ÆTTELSE

FOR STRÅLING.

VARNING - OSYNLIG LASER STRÅLNING NÄR DENNA DEL ÄR ÖPPNAD

OCH SPÄRR ÄR URKOPPLAD. STRÅLEN ÄR FARLIG.

VORSICHT - UNSICHTBARE LASERSTRAHLUNG TRITT AUS, WENN

DECKEL GEÖFFNET UND WENN SICHERHEITSVERRIEGELUNG

ÜBERBRÜCKT IST. NICHT, DEM STRAHL AUSSETZEN.

VARO - AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET ALTTIINA

NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE. ÄLÄKATSO SÄTEESEEN.

CLASS 1 LASER PRODUCT

LUOKAN 1 LASERLAITE

KLASS 1 LASERAPPARAT

- 2 -

TUNER ADJUSTMENTS

Use a plastic screw driver for adjustments.

Adjust the intermediate frequency of AM to the frequency of ceramic filter.

Set of unit

Supply voltage

AC 230V

speaker impedance

4 ohms

standard output

50 mW

Function select:

TUNER

a. Parts Locatio

a.AM Adjustment Band :AM

SG Position of VTVM

Input Output Frequency Tuning dial Oscilloscope

Closed the output

termial by sweep

generator,it place

to AM ANT

Connect AM SG to TP5(H) 522 KHz 522 KHz

L2202

VT: 1.0±0.05V

test loop TP6(E) 1611 KHz 1611 KHz VT: 7.5±0.5V

Connect AM SG to Connect VTVM to 603 KHz 603 KHz L2201

test loop speaker terminals. 1404 KHz 1404KHz CT221

b.FM Adjustment Band :FM FM Dummy antenna: 75 ohms unbalance

SG Position of VTVM

Input Output Frequency Tuning dial Oscilloscope

FM ANT TP5(H) 87.50 MHz 87.50 MHz L2102 VT: 1.0±0.01V

TP6(E) 108.00 MHz 108.00 MHz VT: 7.5±0.5V

FM ANT

TP7(L) 90.00 MHz 90.00 MHz

TP9(R) 106.00 MHz 106.00 MHz

Step

cover range

Adjusting

Circuit

Step Adjustment

IF T2301

Tuning

522 KHz450 KHz

Connections

Adjusting Connection

Max.

Adjustment

Circuit

Tracking

Tracking Max.

TP7(L)

TP9(R)

Tuning

cover range

L2202 XF231

CT221

L2102

T2301

L2201 XF201

D2004

D2003

D2201

CN201

C2110

D2101

D2301

X2101

D2001

D2002

Q2301

CN202

C2210

C2207

XF232

XF233

D2102

C2303

C2404

J2212

IC201

Q2101

X2401

J2211

J2202

J2203

J2204

C2304

J2103

C2118

C2117

J2001

J2209

J2210

J2213

C2408

L2101

L2301

Q2302 J2104

J2105

IC202

J2214

J2215

D2401

R2411

J2206

C2407

C2502

J2005

J2003

J2004

C2201

J2101

C2505

J2208

J2102

J2207

J2002

J2216

J2006

J2007

C2150

J2205

D2403

D2402

C4715

C4951

D4951

Q4951

Q4992

R4951

C4953

Q4994

J4011

J4108

J4229

J4010

J4236

J4233

D4964

C4911

R4952

D4953

R2203

C2109

C2002

C2206

C2205

R2204

R2307

C2104

R2101

R2106

R2104

C2102

R2102

R2308

C2202

C2208

C2209

R2303

R2304

R2302

R2103

C2108

R2105

R2306

C2402

IC202

R2305

C2401

R2402

R2403

C2403

C2406

C2405

C2409

C2103

R2108

C2305

R2107

C2105

R2111

R2201

C2106

R2409

C2412

C2413

C2414

R2301

C2116

R2110

C2107

C2101

C2112

C2111

R2406

C2203

C2301

C2306

R2309

R2311R2310

C2204

R2412

C2415

R2202

C2501

C2115

C2114

C2113

R2505

R2109

R2506

C2504

R2504

R2501

R2415

Q2102

R2001

R2002

R2312

C2503

C2506

R4757

R4758

R4718

C4952

R4953

R4958

T2301

CT221

L2201

L2202 VT

L2102

Max.

TP8(E)

- 3 -

EXPLODED VIEW(CABINET & CHASSIS)

128

10 11 12 13

Y01

Y27

Y26

Y02

Y03

Y04

Y05

Y06

Y07

Y28

Y25

Y09

Y14

Y14 Y14 Y15 Y19

Y20

Y21

Y22

Y23

Y24

Y21

Y15

Y13

Y15

Y17

Y18

- 4 -

PARTS LIST

CAUTION : Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram.

Regular type resistors are less than 1/4W carbon type and 0 ohm chip resistors.

Regular type capacitors are less than 50V and less than 1000µF of Ceramic type and Electrolytic type.

PRODUCT SAFETY NOTICE

EACH PRECAUTION IN THIS MANUAL SHOULD BE FOLLOWED DURING SERVICING. COMPONENTS IDENTIFIED WITH

THE IEC SYMBOL !

!! IN THE PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATE COMPONENTS IN WHICH SAFETY

CAN OF SPECIAL SIGNIFICANCE. WHEN REPLACING A COMPONENT IDENTIFIED , USE ONLY THE REPLACEMENT

PARTS DESIGNATED, OR PARTS WITH THE SAME RATINGS OF RESISTANCE, WATTAGE OR VOLTAGE THAT ARE

DESIGNATED IN THE PARTS LIST IN THIS MANUAL. LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS MUST

BE MADE TO DETERMINE THAT EXPOSED PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT

BEFORE RETURNING THE PRODUCT TO THE CUSTOMER.

REF.NO. PART NO. DESCRIPTION

PACKING & ACCESSORIES

REF.NO. PART NO. DESCRIPTION

58 614 335 4215 ASSY,BOX,SPEAKER

614 335 9395 CARTON CASE

614 334 4841 CUSHION,REAR

614 334 4858 CUSHION,FRONT

614 335 9401 INSTRUCTION MANUAL

645 011 9736 POLY BAG-0250X0350*NC,

INST MANUAL

645 068 7280 POLY SHEET-0340X0280*NC,SET

645 037 8102 POLY BAG-0150X0500*NC,

AC CORD

645 037 9833 POLY BAG-0180X0250*NC,

ACCESSORY

645 063 7483 ASSY,ANTENNA,LOOP

645 083 6756 REMOCON,RB-DA1450M

CABINET & CHASSIS

REF.NO. PART NO. DESCRIPTION

1 614 335 3041 LID,CASSETTE

2 614 334 4803 SPRING,DOOR DECK,CASSETTE

3 614 334 9655 BUTTON,FUNCTION,4 KEY

4 614 316 2490 KNOB,ROTARY,VOL

5 614 334 9648 ASSY,PANEL FRONT

6 614 309 7969 ASSY,GEAR,CASSETTE

7 614 335 3614 PWB,CONNECT,CASSETTE GEAR

8 614 334 4643 KNOB,DECK,MECHA,REC

9 614 334 4650 KNOB,DECK,MECHA,PLAY

10 614 334 4667 KNOB,DECK,MECHA,REW

11 614 334 4674 KNOB,DECK,MECHA,FFWD

12 614 334 4681 KNOB,DECK,MECHA,STOP/EJECT

13 614 334 4698 KNOB,DECK,MECHA,PAUSE

14 614 334 4728 MOUNTING,DECK,KNOB

15 614 327 8023 SPRING,REC

19 614 310 3899 SPACER,MECHA

20 614 335 4147 COVER,PICK-UP

21 614 334 9853 BUTTON,POWER

22 614 322 2132 ASSY,GEAR,LID,CD

23 614 335 4154 MOUNTING,CD

24 614 334 4810 SPRING,DOOR CD

25 614 303 0263 LATCH,PUSH,CD DOOR LOCKING

26 614 334 4711 LID,CD

27 614 335 0569 PWB,CONNECT,AC CORD

28 614 335 9371 ASSY,CABINET,REAR

29 614 327 7668 ASSY,MECHA,DA11B3N

30 614 334 4513 BUTTON,PLAY,4 KEY

31 614 333 3388 ASSY,MECHA,TK20FX-S898001

FIXING PARTS

REF.NO. PART NO. DESCRIPTION

Y01 411 193 8603 SCR S-TPG BRZ+FLG 3X10,

DECK GEAR

Y02 411 193 8603 SCR S-TPG BRZ+FLG 3X10,

DECK PWB+PANEL FRONT

Y03 411 021 3404 SCR S-TPG BIN 3X10,

DECK PWB+PANEL

Y04 411 187 2808 SCR S-TPG BIN 2.3X8,

PANEL+FRONT PWB

Y05 411 021 3404 SCR S-TPG BIN 3X10,

PANEL+MTG DECK KNOB

Y06 411 021 3404 SCR S-TPG BIN 3X10,

PANEL+DECK MECHA

Y07 411 204 2101 SCR S-TPG PAN 2X3,

SPRING REC+DECK

Y09 411 193 8603 SCR S-TPG BRZ+FLG 3X10,

MTG CD+AMP PWB

Y13 411 193 8603 SCR S-TPG BRZ+FLG 3X10,

MTG CD+CD PWB

Y14 411 194 8503 WASHER Z 2.6X10X0.5,

MECHA CD+MOUNTING

Y15 411 021 1608 SCR S-TPG BIN 2.6X10,

MTG CD+MECHA CD

Y17 411 021 3404 SCR S-TPG BIN 3X10,

MTG CD+ASSY GEAR

Y18 411 021 3404 SCR S-TPG BIN 3X10,

MTG+CD PWB SWITCH

Y19 411 021 3404 SCR S-TPG BIN 3X10,

REAR+PWB POWER

Y20 411 021 3404 SCR S-TPG BIN 3X10,

REAR+STOPPER

Y21 411 098 7701 SCR S-TPG FLT 3X10,

PANEL+REAR+MTG

Y22 411 021 3404 SCR S-TPG BIN 3X10,MTG+REAR

Y23 411 126 4108 SCR S-TPG BIN 3X16,PANEL+REAR

Y24 411 191 4201 SCR S-TPG BRZ+FLG 3X12,

REAR+TRANS

Y25 411 021 3404 SCR S-TPG BIN 3X10,

MTG CD+AMP PWB

Y26 411 098 4205 SCR S-TPG BIN 3X8,

MOUNTING CD+FRONT PWB

Y27 411 187 2808 SCR S-TPG BIN 2.3X8,

BUTTON POWER+PANEL FRONT

Y28 411 021 3404 SCR S-TPG BIN 3X10,

MTG CD+CD PWB

ELECTRICAL-PARTS

REF.NO. PART NO. DESCRIPTION

32 614 309 8799 ASSY,WIRE,R/P HEAD-AMP

33 614 309 8805 ASSY,WIRE,MECHA SW-AMP

51 614 274 2013 CORD,ID CONNECTOR

52 !

!! 423 032 8101 FUSE 250V 2.5A

53 614 335 1368 ASSY,WIRE,CD-MOTOR

54 !

!! 614 335 8558 FLEXIBLE FLAT CABLE,CD-LASER

56 !

!! 645 083 7630 TRANS,POWER

57 !

!! 645 068 1059 CORD,POWER-2.0MK

DECK P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

71 614 334 9471 ASSY,PWB,DECK(Only initial)

C5025 403 056 7502 POLYESTER 1000P J 50V

CN501 645 075 3855 PLUG,4P

or 614 310 2458 PLUG,4P

CN502 614 310 2755 PLUG,4P

or 645 078 2428 PLUG,4P

CN503 614 310 2519 PLUG,10P

or 645 075 4302 PLUG,10P

- 5 -

PARTS LIST

REF.NO. PART NO. DESCRIPTION REF.NO. PART NO. DESCRIPTION

IC501 409 384 3506 IC BA3314F

L5002 645 086 4773 TRANS,OSC,85KHZ

Q5001 405 141 3307 TR KTC3198-GR

or 405 141 3208 TR KTC3198-Y

or 405 019 2708 TR 2SC536-F-NP

or 405 019 3804 TR 2SC536-G-NP

Q5002 405 141 3307 TR KTC3198-GR

or 405 141 3208 TR KTC3198-Y

or 405 019 2708 TR 2SC536-F-NP

or 405 019 3804 TR 2SC536-G-NP

S5050 645 038 7586 SWITCH,PUSH,R/PSW

FRONT P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

72 614 334 9488 ASSY,PWB,FRONT(Only initial)

AH601 614 334 9716 HOLDER,LCD,HOLDER-LCD

AH602 614 334 9709 DEC,SHEET LCD,DEC-SHEET-LCD

AH603 614 334 9808 REFLECTOR,LED,

REFELECTOR-LCD

AH604 614 334 9686 COVER,LED,COVER-LED

CN602 645 075 4050 PLUG,5P

or 614 310 2465 PLUG,5P

CN604 645 075 4050 PLUG,5P

or 614 310 2465 PLUG,5P

CN605 645 075 3831 PLUG,2P

or 614 310 2434 PLUG,2P

CN608 645 070 6851 JACK,PHONE D3.6

D6001 407 012 4406 DIODE 1SS133

D6007 407 012 4406 DIODE 1SS133

D6008 407 253 0304 LED LT0334-43-UA91,LCD_LIGHT

DS660 407 232 4002 PHOTO DIODE SPS-440-1-VG

IC601 410 608 2304 IC LC877C64C-57P8-E

L6001 645 002 1459 INDUCTOR,22U K

L6007 645 002 1459 INDUCTOR,22U K

L6100 645 002 1459 INDUCTOR,22U K

L6101 645 002 1459 INDUCTOR,22U K

L6102 645 002 1459 INDUCTOR,22U K

LCD61 645 083 6749 LCD,LCD

Q6001 405 014 4509 TR 2SC2412K-R

or 405 011 1006 TR 2SC1623-L6

or 405 146 2107 TR KTC3875-Y

or 405 146 2206 TR KTC3875-GR

S6001 645 057 4689 SWITCH,ROTARY(ENCODER)

S6010 614 220 5471 SWITCH,TACT

or 614 240 1002 SWITCH,TACT

or 645 037 2759 SWITCH,PUSH
