Satel APD-100 User manual

®
WIRELESS PASSIVE INFRARED
DETECTOR
APD-100
apd100_e 08/05
The APD-100 wireless passive infrared detector is designed for operation as part of
the ABAX two-way wireless system.
The signal from pyroelement is
processed digitally. The sensor is
characterized by a high interference
immunity. The sensor detection
sensitivity is controlled by way of
radio.
The LED indicator is "on" in the
TEST MODE only (see the ACU-
100 controller manual) to signal
communication with the controller
and violation (of the detector or
tamper contact).
As two tamper contacts are
installed on the electronics
board, tamper information is sent
both when the housing is
opened, and when the detector is
pulled off from the mounting surface.
Placed on the electronics board is a label with 7-digit serial number, which must be
indicated when registering the detector in the system.
The detector is supplied from a CR123A 3V lithium battery, which ensures approx.
two years' operation.
1. INSTALLATION
Prior to permanent mounting of the detector, you should check the level of
signal received from the detector by the ACU-100 controller and, if necessary,
change place of the installation so as to ensure optimal positioning in terms of
communication.
The battery should be installed inside the detector just before registration of the
detector in the controller. If unregistered or missing communication with the
controller, the detector consumes more energy, which affects the battery life.
The detector is designed for indoor installation. It can be attached to the wall either
directly or mounted on a holder included in the delivery set. As the tamper contact
reacts to the pull-off, it is recommended that the device be secured directly to the wall
(one of the screws should be used to fix the housing tamper element). Before the
housing is mounted, remove the electronics board and make suitable screw holes in
the rear panel of the housing. Be particularly careful so as not to contaminate or
damage the pyroelement during installation.
Fig. 1. Detector electronics board.
LED indicato
r
pyroelement
housing
tamper contactt
positionin
g
scale
batter
y
antenna
pull-off
tamper contact

SATEL APD-1002
The scale provided on the detector board (see Fig.1) is intended for properly setting the
pyroelement against the lens installed in the housing. If the detector is to be installed at
a height of 2.1m, set the board so that the central mark coincides with the indicator
placed on the housing next to the scale. Such a setting will ensure that the manufacturer
specified lens range is obtained. Otherwise, you should adjust the pyroelement setting by
moving the board up (if the detector is installed higher than 2.1m) or down (if the detector
is installed lower than 2.1m) as against its central position.
For information on registering and installing the detector in the wireless system please
see the ACU-100 controller user manual.
2. LENSES
Installed in the detector is an extra-wide lens (EWA), however it can be replaced with
another one, having different characteristics (range, number of beams, angle of view).
Lenses are available with the following specifications:
It. Lens type Range Angle of view
1 extra wide angle 15m 141.2°
2 long range with access zone
monitoring 30m main beam – 3m wide (at the end of range)
3 vertical barrier 22.5m 2.2m wide (at the end of range)
Note: The detector operating range should be selected to match the size of space
where the detector is to be installed. The size of the space along the main
direction of detector positioning is not to be less than 1/3 the nominal range of
the detector. Improper selection of the lens may cause excessive sensitivity
and trip false alarms.
tamper element
(
to be
screwed to wall)
indicator to facilitate
positioning of
electronics board
Fig. 2. View of the detector housing rear panel.

APD-100 ABAX 3
10 m
5 m
10 m
0
5 m
19.4°
TOP VIEW:
2.1 m
1.7 m 4.6 m 7.7 m 15.3 m
SIDE VIEW:
Fig. 3. Distribution of beams and operating range of detector with extra wide angle (EWA)
lens.

SATEL APD-1004
3. TECHNICAL DATA
Operating band frequency.......................................................... 868.0MHz ÷ 868.6MHz
Supply...................................................................................lithium battery CR123A, 3V
Life of detector battery............................................................................ approx. 2 years
Operating temperature range .......................................................................0°C...+55°C
Detectable movement speed......................................................................... up to 3 m/s
Housing dimensions .................................................................................. 63x96x49mm
Recommended height of installation ....................................................................... 2.1m
CAUTION
Batteries in the battery-supplied wireless equipment should be replaced by
qualified personnel. Incorrect replacement of the battery can pose an explosion
hazard.
Always use the CR123A 3V lithium batteries.
The used batteries must not be discarded, but should be disposed of in
accordance with the existing rules for environment protection.
DECLARATION OF CONFORMITY
Product:
APD-100 - Wireless PIR Detector for ABAX System
Manufacturer: SATEL spółka z o.o.
ul. Schuberta 79
80-172 Gdańsk, POLAND
tel. [phone]
fax. [phone]
Product description:Wireless movement detector of PIR type, designed for interaction with
elements of the ABAX wireless system, operating in the 868.0MHz – 868.6MHz frequency band,
supplied from a 3V lithium cell. The device is intended to be used in burglary and panic alarm
systems.
This product conforms to the following EU Directives:
R&TTE 1999/5/EC
This product meets requirements of the harmonized standards:
R&TTE: ETSI EN 300 220-1: v.1.3.1; ETSI EN 300 220-3: v.1.1.1;
EMC: ETSI EN 301 489-1: v.1.5.1.; EN 301 489-3: v.1.4.1
Safety: EN60950-1:2001
Notified body taking part in conformity evaluation:
Identification No.: 1471
Gdańsk, Poland 2005-07-15 Head of Test Laboratory:
MichałKonarski
The latest EC declaration of conformity and product approval certificates are available for
downloading on our website www.satel.pl
