Operating Instructions
System Settings
Read this manual carefully before you use this product and keep it handy for future
reference.For safety, please follow the instructions in this manual.

Introduction
This manual contains detailed instructions on the operation and maintenance of this machine. To get
maximum versatility from this machine all operators should carefully read and follow the instructions in
this manual. Please keep this manual in a handy place near the machine.
Please read the Safety Information in the Copy Reference before using this machine. It contains im
portant information related to USER SAFETY and PREVENTING EQUIPMENT PROBLEMS.
Notes
Some illustrations may be slightly different from your machine.
Certain options may not be available in some countries. For details, please contact your local dealer.
Operator Safety
This machine is considered a CDRH class I laser device, safe for office/EDP use. The machine con
tains a 5 milliwatt, 760 800 nanometer wavelength, GaAIAs laser diode. Direct (or indirect reflected )
eye contact with the laser beam might cause serious eye damage. Safety precautions and interlock
mechanisms have been designed to prevent any possible laser beam exposure to the operator.
Laser Safety:
The Center for Devices and Radiological Health (CDRH) prohibits the repair of laser based optical unit
in the field. The optical housing unit can only be repaired in a factory or at a location with the requisite
equipment. The laser subsystem is replaceable in the field by a qualified Customer Engineer. The laser
chassis is not repairable in the field. Customer engineers are therefore directed to return all chassis
and laser subsystems to the factory or service depot when replacement or the optical subsystem is re
quired.
Warning:
Use of controls or adjustment or performance of procedures other than those specified in this manual
might result in hazardous radiation exposure.
Notes:
The model names of the machines do not appear in the following pages. Check the type of your ma
chine before reading this manual. (For details, see P.2 “Machine Types”.)
• Type 1: 15 copies/minute (A4K, 81/2" × 11"K)
• Type 2: 18 copies/minute (A4K, 81/2" × 11"K)
Certain types might not be available in some countries. For details, please contact your local dealer.
Two kinds of size notation are employed in this manual. With this machine refer to the inch version.
For good copy quality, the supplier recommends that you use genuine toner from the supplier.
The supplier shall not be responsible for any damage or expense that might result from the use of parts
other than genuine parts from the supplier with your office products.
Power Source
120V, 60Hz, 12A or more
Please be sure to connect the power cord to a power source as above. For details about power source,
see “Power Connection” in the Copy Reference manual.

i
ENERGY STAR Progra
• Low Power mode
This product automatically lowers its power consumption 15 minutes after
the last copy or print job has finished. Fax reception and printing is still pos
sible in Low Power mode, but if you wish to make copies press the operation
switch first.
For details about how to change the default interval that the machine waits
before entering Low Power mode, see “ 4.Energy Saver Timer” on P.16 “Sys-
tem Settings”.
• Sleep mode (Fax or printer installed)
If the fax or printer features are installed, this product automatically lowers
its power consumption even further 30 minutes after the last copy or print job
has finished. Fax reception and printing is still possible in Sleep mode, but if
you wish to make copies press the operation switch first.
For details about how to change the default interval that the machine waits
before entering Sleep mode, see “6.Auto Off Timer” on P.16 “System Settings”
• Auto Off mode (Copier only)
To conserve energy, this product automatically turns off 30 minutes after the
last copying or printing job has completed. If you wish to make copies when
the machine is in Auto Off mode, press the main power switch.
For details about how to change the default interval that the machine waits
before entering Auto Off mode, see “6.Auto Off Timer” on P.16 “System Set-
tings”.
As an ENERGY STAR Partner, we have determined
that this machine model meets the ENERGY STAR
Guidelines for energy efficiency.
The ENERGY STAR Guidelines intend to establish an international energy saving system for
developing and introducing energy efficient office equipment to deal with environmental is
sues, such as global warming.
When a product meets the ENERGY STAR Guidelines for energy efficiency, the Partner shall
place the ENERGY STAR logo onto the machine model.
This product was designed to reduce the environmental impact associated with office equip
ment by means of energy saving features, such as Low power mode.

ii
Specification
Recycled Paper
In accordance with the ENERGY STAR Program, we recommend use of recycled
paper which is environment friendly.Please contact your sales representative for
recommended paper.
Copier only Fax or printer installed
Low Power
mode
Power con
sumption
70 Wh 80 Wh
Default inter
val
15 minutes 15 minutes
Recovery time Less than 20 seconds Less than 20 seconds
Sleep mode Power con
sumption
70 Wh
Default inter
val
30 minutes
Recovery time 20 seconds
Auto Off
mode
Power con
sumption
less than 1 Wh
Default inter
val
30 minutes
Recovery time 20 seconds

iii
How to Read this Manual
Symbols
In this manual, the following symbols are used:
R
WARNING:
This symbol indicates a potentially hazardous situation that might result in
death or serious injury when you misuse the machine without following the in
structions under this symbol. Be sure to read the instructions, all of which are de
scribed in the Safety Information section.
R
CAUTION:
This symbol indicates a potentially hazardous situation that might result in mi
nor or moderate injury or property damage that does not involve personal injury
when you misuse the machine without following the instructions under this
symbol. Be sure to read the instructions, all of which are described in the Safety
Information section.
* The statements above are notes for your safety.
Important
If this instruction is not followed, paper might be misfed, originals might be
damaged, or data might be lost. Be sure to read this.
Preparation
This symbol indicates the prior knowledge or preparations required before op
erating.
Note
This symbol indicates precautions for operation, or actions to take after misop
eration.
Limitation
This symbol indicates numerical limits, functions that cannot be used together,
or conditions in which a particular function cannot be used.
Reference
This symbol indicates a reference.
{}
Keys built into the machine's operation panel.

iv
TABLE OF CONTENTS
Manuals for This Machine......................................................................... 1
Machine Types........................................................................................... 2
Additional Functions Provided y Internal Options............................... 3
Copy Mode.................................................................................................... 3
Facsimile Mode (Option) ............................................................................... 3
Printer Mode (Option).................................................................................... 3
1.Modes
Changing Modes........................................................................................ 5
Multi-access ............................................................................................... 6
Copy Mode ................................................................................................. 8
Changing to Copy Mode ............................................................................... 8
Facsimile Mode.......................................................................................... 9
Changing to Facsimile Mode......................................................................... 9
Sending a Fax ............................................................................................... 9
Printing a Received Fax................................................................................ 9
Printer Mode............................................................................................. 10
Changing to Printer Mode ........................................................................... 10
Printing ........................................................................................................ 10
2.User Tools (Syste Settings)
Keys for User Tools (System Settings) ................................................. 11
Accessing the User Tools (System Settings) ....................................... 13
Exiting from the User Tools......................................................................... 14
Printing the Counter Value .......................................................................... 14
User Tools Menu (System Settings) ...................................................... 15
Settings You Can Change with the User Tools .................................... 16
System Settings .......................................................................................... 16
INDEX........................................................................................................ 21

1
Manuals for This Machine
This is a multi functional machine combining copier, printer and fax functions.
A separate manual is provided for each function. Please consult the manual that
suits your needs.
❖
❖❖
❖System Settings
Provides an overview of the machine. This manual introduces the functions
of the machine. It also introduces the options allowing you to use additional
functions and describes how to access the system user tools to make the ma
chine easier to use.
❖
❖❖
❖Copy Reference
Describes the various copying functions from basic copying to more ad
vanced functions such as reducing/enlarging copies or combining originals
into one copy.
❖
❖❖
❖Facsimile Basic Features (Option)
Explains the most frequently used facsimile functions and operations.
❖
❖❖
❖Facsimile Advanced Features (Option)
Describes more advanced facsimile functions and also explains settings for
key operations.
❖
❖❖
❖Printer Reference (Option)
Describes the system settings, procedures and functions for using this ma
chine as a printer.
❖
❖❖
❖Printer Reference 2 (Option)
Describes the procedures and provides necessary information about using
this machine as a printer.
❖
❖❖
❖Network Interface Board Quick Configuration Guide (Option)
Describes the procedures and provides necessary information about setting
up and using the printer under the network environment.
❖
❖❖
❖PS Level 2 Emulation Type 2 Operating Instructions Supplement (Option)
Describes the menus and features you can set using the PostScript printer
driver.
❖
❖❖
❖Network Interface Board Type 2 Owner's Manual (Option)
Describes the procedures and provides necessary information about setting
up and using the printer under the network environment.
❖
❖❖
❖Unix Supplement (Option)
Provides information about setting up and using the printer in a UNIX envi
ronment.

2
Machine Types
This machine comes in two models which vary in copy speed.
Type 1 Type 2
Copy speed 15 copies/minute (A4K, 81/2"
× 11"K)
18 copies/minute (A4K, 81/2"
× 11"K)
Fax unit Option Option
Printer unit Option Option

3
Additional Functions Provided by Internal
Options
You can expand the capabilities of this machine to include fax functions and
printer functions. When you want to add a function, contact your sales or service
representative.
Copy Mode
In copy mode you can make basic copies and also copy using more sophisticated
techniques, such as reduction/enlargement or combining several originals onto
one copy. You can install an optional memory expansion for storage of docu
ment images, thereby making the best use of memory with various copy func
tions (Type 1 requires the optional 16MB copier memory unit when using Sort
or Combine features).
Options for Memory Expansion
❖
❖❖
❖6MB copier memory unit (Type only)
Increases copier features, allowing you to use Sort or Combine features.
Note
❒For North American users, a 16MB copier memory unit is installed as the
standard.
❖
❖❖
❖32MB DIMM
Increases memory capacity, allowing you to increase the data of originals to
be stored. For Type 1, it is available only when the optional 16MB copier
memory unit is installed.
Facsimile Mode (Option)
You can send and receive fax messages in facsimile mode.
Printer Mode (Option)
You can use this machine as a printer when you install the optional printer con
troller.

4

5
1. Modes
Changing Modes
Press the {Copy}, {Facsimile} or {Printer} key to switch to copy, fax or printer
mode respectively.
Limitation
❒You cannot switch modes in any of the following cases:
• When scanning in a fax message for transmission.
• During immediate transmission.
• When accessing the user tools.
• During on hook dialing for fax transmission.
• During Energy Saver mode.
• When the fax handset is lifted.

Modes
6
Multi-access
You can carry out another job using a different function while the current job is
being performed.
This allows you to handle your jobs efficiently regardless of how the machine is
being used. For example:
• While making copies, the machine can send a fax message that has been
stored in memory.
• You can make copies while receiving fax data.
• The machine can receive print data in any mode.
Performing multiple functions simultaneously like this is called Multi access.
Note
❒You can choose which mode has highest priority for print jobs. The default is
“Copier”. See “11Print Priority” in P.16 “System Settings”.
-
--
-Sa ple operations
This chart is based on the following conditions:
• “11Print Priority” is set to “Interleave” (See “11Print Priority” in P.16 “System
Settings”)
• For details on operations under other conditions, contact your service repre
sentative.

Multi-access
7
✩…means that these functions can be used together.
❍…means that you can interrupt the current job with Function keys to proceed
to a subsequent job.
→…means that another job will automatically start after the current job is fin
ished.
×…means that you must manually start another job after the current job is fin
ished (i.e. these functions cannot be used together).
*1 For type 1, available only when the optional 16MB copier memory unit is installed.
*2 Simultaneous operations are only available after all copy originals have been
scanned and copying is in progress.
*3 When receiving multiple data simultaneously, other operations are not available un
til the current reception is finished.
Mode after you select Copy Facsimile Printer
Transmission Operation/ Manual Reception Operation
Transmission Reception
Receive Data
Print
Mode before you select
Copyin Sort Scannin An Ori inal for Memory Transmission Memory Transmission Immediate Transmission Memory Reception Printin Received Data Printin Sort
Copy
Copying ❍❍❍❍✩❍✩✩✩✩✩
Sort ❍❍ *1 ❍ *2 ❍ *2 ✩❍ *2 ✩✩✩✩✩
Facsimile
Transmission Operation/
Manual Reception Operation
❍❍××✩×✩✩✩✩✩
Transmission
Scanning An Original for
Memory Transmission
××××✩×✩✩✩✩✩
Memory Transmission ✩✩✩✩×××✩✩✩✩
Immediate Transmission
×××××××✩✩✩✩
Reception
Memory Reception ✩✩✩✩××→✩✩✩✩
Printing Received Data ✩✩✩✩✩ *3 ✩ *3 ✩ *3 →✩✩✩
Printer
Receive Data ✩✩✩✩✩✩✩✩→→→
Print
Printing ✩✩✩✩✩✩✩✩→→→
Sort ✩✩✩✩✩✩✩✩→→→

Modes
8
Copy Mode
Changing to Copy Mode
You can always make a copy when
the machine is not printing or scan
ning a fax data.
APress the {
{{
{Copy}
}}
} key.
The copy display appears on the
panel display.
Reference
For details, see the Copy Refer
ence manual.

Facsimile Mode
9
Facsi ile Mode
Changing to Facsimile Mode
You can always use the machine for
faxing when you are not using a scan
ner.
APress the {
{{
{Facsimile}
}}
} key.
The fax display appears on the
panel display.
Note
❒The Memory Transmission/Re
ception function is performed
automatically even when an
other function is being used.
You need not to switch the dis
play. When data is received in
memory, the Receive File indi
cator is lit.
Reference
For details, see the Facsimile
Reference manual.
Sending a Fax
Sending a fax while copying
APress the {
{{
{Facsimile}
}}
} key to switch
to the fax display.
Note
❒When you press the {Facsimile}
key while scanning originals or
sorting in Copy mode, remove
any originals of your copy job.
BComplete the usual operations
for sendin a fax, then press the
{
{{
{Start}
}}
} key.
CAfter the transmission has fin-
ished, press the {
{{
{Copy}
}}
} key.
DReset the copy job ori inals, then
press the {
{{
{Start}
}}
} key.
The machine resumes the inter
rupted copy run.
Sending a fax while printing
APress the {
{{
{Facsimile}
}}
} key to switch
to the fax display.
BComplete the usual operations
for sendin a fax, then press the
{
{{
{Start}
}}
} key.
Printing a Received Fax
When you are not copying, a received
fax is printed automatically. You do
not need to switch to Facsimile mode.
Note
❒Machine operations are different
depending “11Print Priority” (See
P.16 “System Settings”) or “13Key
Op. Tools” (See P.16 “System Set-
tings”) settings.

Modes
10
Printer Mode
Changing to Printer Mode
Whenever you print from applica
tions, you do not have to switch to
printer mode.
Reference
For details, see the Printer Refer
ence manual.
Printing
The machine can receive a print data
while any feature go on.

11
2. User Tools (Syste Settings)
Keys for User Tools (Syste Settings)
❖
❖❖
❖When the machine has the copier feature only
❖
❖❖
❖When the machine has the printer or fax feature
1. {
{{
{Cancel}
}}
} key
Press to return to the previous menu.
2. Panel display
Shows operation status, error messages
and function menu.
3. 0
00
0 or 1
11
1 keys (Cursor keys)
Press to display the previous/next menu
or select an item on the panel display.
4. {
{{
{OK}
}}
} key
Press to set the new settings and return to
the previous menu.
5. {
{{
{User Tools/Counter}
}}
} key
See P.13 “Accessing the User Tools (System
Settings)”.
6. {
{{
{Clear/Stop}
}}
} key
Press to delete a number you have en
tered or to stop copying.
7. {
{{
{Clear Modes}
}}
} key
Press to clear the previously entered copy
job settings.
8. Function keys (Fax or printer in-
stalled machine only.)
Press to change modes.
9. Number keys
Use to enter a numeric value.
10. {
{{
{Start}
}}
} key
Press to start copying or faxing.

User Tools (System Settings)
12
2
11. Operation switch
Press this switch to turn the power on or
return from the low power mode or the
sleep mode. To turn the power off, press
this switch again.

Accessing the User Tools (System Settings)
13
2
Accessing the User Tools (Syste Settings)
This section is for the key operators in
charge of this machine. You can change
or set the machine's default settings.
Preparation
After using the user tools, be sure
to return to Copy mode.
The settings are not canceled even
if the operation switch is turned off
or the {Clear Modes} key is pressed.
Reference
For information on Copy, Fax, and
Printer User Tools, see the appro
priate reference manual.
APress the {
{{
{User Tools/Counter}
}}
} key.
The User Tools Main Menu ap
pears.
BPress the 0
00
0 or 1
11
1 key until “2.Sys-
tem Settin s” is displayed, then
press the {
{{
{OK}
}}
} key.
Note
❒To view the total number of
prints made by the machine. See
P.14 “Printing the Counter Val-
ue”.
❒To switch the display language,
select “6. Language”and then
press the {OK} key.
C Press the 0
00
0 or 1
11
1 key until your
desired menu is displayed, and
then press the {
{{
{OK}
}}
} Key.

User Tools (System Settings)
14
2
Note
❒1: Press to go to the next menu.
❒0: Press to go back to the previ
ous menu.
Reference
P.15 “User Tools Menu (System
Settings)”
DChan e the settin s by followin
the instructions on the panel dis-
play. Then press the {
{{
{OK}
}}
} key.
Reference
P.16 “Settings You Can Change
with the User Tools”
Note
❒{OK} : Press to set the new set
tings and return to the previous
menu.
❒{Cancel} : Press to return to the
previous menu without chang
ing any data.
Exiting from the User Tools
AAfter chan in the user tools set-
tin s, press the {
{{
{User Tools/Coun-
ter}
}}
} key.
Printing the Counter Value
Ty e 1 requires the o tional 16 MB co ier
memory unit.
APress the {
{{
{User Tools/Counter}
}}
} key.
BMake sure “1.Counter” is dis-
played, then press the {
{{
{OK}
}}
} key to
view the total number of prints.
CPress the {
{{
{Start}
}}
} key.
