Saxby Lighting Deluge PRS250 Manual

• Refittheproduct ontothe bracket,taking careto fit
thewashersbackinthecorrectposition.
• Adjustthecablesoitdoesnotgetsnagged.Ensure
thatthecableglandisproperlytightened.
• Ensurethatthesealisintactandfittedcorrectly.Refit
thewiringcoverandtightenthescrew.
• Setthedesiredangleforthefloodlightandtightenthe
bolts.
• Replacefuseorcircuit breaker andswitch on. Your
lightisnowreadyforuse.
• Whenchangingabulb,alwaysswitchoffatthemains
andallowthebulbtocoolbeforehandling.Disposeof
usedbulbscarefully.Useasoftclothtohandlebulbs,
avoiddirectlytouchingthebulbsasthiswillshorten
theirlife.
• Alwaysensurethatyoualwaysusethecorrect
wattagelamptomatchthecontrolgear.Useof
incorrectlampwilldamagethelampandthecontrol
gear.Thelampmustbefittedinaccordancewiththe
lampmanufacturesinstructions.Failedlampsmustbe
replacedimmediatelyotherwisedamagedmayoccur
tothegearandignitor.
• TheLampsfittedmustbesuitableforuse
withanexternalignitor.
 PRS250 : 250WE40SONTor250WE40HQIT
PRS400 : 400WE40SONTor400WE40HQIT
Commissioning
Fitting/replacing bulbs
Instructionleaflet
Deluge Floodlight
PRS250,PRS400
www.saxbylighting.com
Live Voltages may be present in this unit even when turned of or when completely disconnected.
Foryoursafety,alwaysswitchoffthesupplybeforechanginglightbulbs,orcleaning.
Wasteelectricalproductsshouldnotbedisposedofwithhouseholdwaste.Pleaserecyclewherefacilities
exist.CheckwithyourLocalAuthorityorretailerforrecyclingadvice.
Recycling advice
Safety information
SaxbyLightingLtd.BH233PE
Werecommendcleaningwithasoftdampcloth.
Donotusesolventsorabrasivecleanersasthesecould
damagethefinish.
Donotjetwashthesetoclean.
Iss.118122012
This bulb is protected by a glass shade. This part must be replaced immediately should the glass
shade become cracked or damaged. This fitting must not be used without the glass shade in place.
ReplaceCracked
Shade
E
250W E40 SONT 250W E40 HQIT
400W E40 SONT 400W E40 HQIT
THE LUMINAIRE SHALL ONLY BE USED COMPLETE WITH ITS PROTECTIVE SHIELD.

Thankyouforpurchasingthislightfitting.Pleasereadtheinstructionscarefullybeforeusetoensuresafeand
satisfactoryoperationofthisproduct.Pleaseretaintheseinstructionsforfuturereference.
Warning
This is a Class 1 product and must be earthed.
Pleasereadtheseinstructionscarefullybefore
commencinganywork.
Thisfittingmustbefittedtoasuitabletrackthathas
beenproperlyinstalled.
InstallinaccordancewithIEEWiringregulationsand
currentBuildingRegulations.
Topreventelectrocutionswitchoffatmainssupply
beforeinstallingormaintainingthisfitting.Ensure
otherpersonscannotrestoretheelectricalsupply
withoutyourknowledge.Ifyouareinanydoubt,
pleaseconsultaqualifiedelectrician.
Thislightfittingshouldbeconnectedtoafusedcircuit.
Alwaysensurethatyoualwaysusethecorrect
wattagelamptomatchthecontrolgear.Useof
incorrectlampwilldamagethelampandthecontrol
gear.Donotoperatewithafailedbulborwithouta
bulbasthismaydamagetheunit.
Whenchangingabulb,alwaysswitchoffatthemains
andallowtheoldbulbtocooldownbeforehandling.
Aswithallmetalhalidefixtures,theunitmustbe
allowedtocooldownafterswitchingoffbeforethe
lampisabletore-ignite.
Disposeofusedbulbscarefullyandresponsibly.
Thisproductisnotsuitablefordimming.
ThisproductmustnotbeconnectedtoaPIR
movmentsensor.
ThisproductisratedatIP65.
Thisproductisnotsuitableforlocationinorneara
marineenvironment.
Theentireunitgetshotwhilstonforaperiodoftime.
Specification
Voltage: 240V50Hza.c.
Lamp: PRS250 : 250WE40SONTor250WE40HQIT
 PRS400 : 400WE40SONTor400WE40HQIT
IPrating: 65
Layout
• Planthedesiredlayoutofthisfittingcarefully,
ensuringthecableswillreachthedistancebetween
thejunctionboxandthelightfitting.
• Avoidlocatinganycablesinpositionsthatwould
causeahazard.Positioncablesandoutdoorrated
junctionboxes(notsupplied)awayfromareas
wheretheymaybeatriskfrombeingcut,trappedor
damaged.
• WerecommendthatyouuseH05RN-Fspecification
cable(notsupplied)whichisanoutdoorgrade,
rubbersheathedcable.Themainssupplycablemust
haveaminimumcrosssectionalareaof1.0mm²
• Cablesmustbeprotectedusingsuitableconduitor
plastictrunking.
• Fittingmustbepositioned350mm(A)awayfrom
surfacesabovethefitting.
Existingfittingsmustbecompletelyremovedbefore
installationofanewproduct.Before removing the
existing fitting, carefully note the position of each set
of wires.
• Decideonthemostappropriatepositionbasedon
thelayoutinstructionsgivenabove.
• Werecommendthatthebracketisremovedfromthe
producttoassistthefittingoftheproduct.Makea
noteofthepostionofthewashers.
• Holdtheproductorbracketinplaceandmarkthe
positionoftheholes.Ensurethattheproductis
level.
• Ensurethewalliscapableofholdingtheweight
oftheproduct.Takecaretoavoiddamaging
anyconcealedwiringandpipes.Thecorrect
fixingsshouldbeusedforbrick,cavitywallsor
plasterboard.Fixtheproducttothewall.
• Usingfixingsappropriatetotheweightofthefitting
andthemountingsurface,securethefittingin
position.
• Undothescrewsholdingthewiringcoverinplace
andsetaside.
Installation
Wiring
Check that...
• Youhavecorrectlyidentifiedthewires
• Theconnectionsaretight
• Noloosestrandshavebeenleftoutoftheconnection
block.
NEUTRAL
EARTH(GREEN/YELLOW)
SWITCHEDLIVE
BLUE(N)
GREEN/YELLOW
BROWN(L)
SUPPLY LIGHTFITTING
Havingcorrectlyidentifiedthewiringfromyourexisting
lightfitting,connecttotheconnectionblockinsidethe
productinthefollowingway:
A
B
