SBM XD User manual

Manufacturer : Agent :
SBM
3 cottages de la Norge
21490 CLENAY
FRANCE
http : //www.sbm-international.net
1
GAS INFRARED HEATERS
1312
XD – XD D
HEATERS
USER INSTRUCTIONS
Nr 05000375/5
1. PRODUCT SPECIFICATION
2. SAFETY RECOMMENDATIONS
3. IGNITION
4. SHUT-OFF
5. MAINTENANCE
6. CHANGING THE GAS USED
TR
IE
GB

2
1. PRODUCT SPECIFICATION :
Refer to the rating plate sticked on the side of the heater.
(see example below).
MODEL XD 8
XD 8 D
XD 10
XD 10 D
XD 12
XD 12 D
XD 16
XD 16 D
P.I.N. 1312 CQ 6090
Class NOx 4
Weight (kg) 5.25 5.75 6.50 7.75
Net calorific value Qn
(kW) Hi 3.30 3.80 5.10 6.80
Combustion air G20
(m3/h) G31
3.40
3.10
3.90
3.60
5.30
4.80
7.00
6.30
Required air renewal rate
(m3/h) 33 38 51 68
Consumption G20
(m3/h) 0.350 0.400 0.540 0.715
Consumption G31
(kg/h) 0.260 0.300 0.400 0.530

3
2. SAFETY RECOMMENDATIONS :
THESE HEATERS MUST BE INSTALLED AND MAINTAINED BY A QUALIFIED INSTALLER
IN ACCORDANCE WITH THE CURRENTLY APPLICABLE SAFETY REGULATIONS AND
WITH THE SBM INSTALLER INSTRUCTIONS Nr. 05000376.
TO AVOID ABNORMAL MECHANICAL CONSTRAINTS ON THE RADIANT, IT IS
RECOMMENDED THAT IT BE CONNECTED TO THE GAS MAINS BY A FLEXIBLE TUBE.
TO BE INSTALLED IN WELL-VENTILATED PREMISES. NOT FOR DOMESTIC USE.
THE XD-D HEATERS MUST BE INSTALLED ONLY IN A TERRACE (OUTSIDE) AND THE
TERRACE MUST BE SUFFICIENTLY OPEN.
2.1 HEATER INCLINATION
2.2 MINIMUM SAFETY CLEARANCES (INFLAMMABLE MATERIALS: max=70°C)
15°, 25° or 35°
1 m mini.
0.25 m
mini.
0.20 m
mini.
HEATED AREA
HEATED AREA
0.20m
XD 8 (D) : 0.70 m
XD 10 (D) : 0.80 m
XD 12 (D) : 1.00 m
XD 16 (D) : 1.20 m

4
3. START-UP :
Manual operation
 Open the main gas valve.
 Switch the power on.
 Start the heater ignition cycle.
 If the flame is not lit after 45 seconds, start a second ignition cycle.
 If the flame is still not lit or goes out, close the main gas valve, switch
the power off and call your SBM installer.
Automatic control
(VisioLon Ind-T control module)
 Open the main gas valve.
 Switch the power on.
 Check the settings (temperature, time).
 Change module programming if necessary.
 The module automatically controls the ignition and the extinction of the
heaters.
4. SHUT OFF :
 Close the main gas valve.
 Switch the power off.
5. MAINTENANCE :
 To be performed once a year by your SBM installer, according to the
SBM INSTALLER INSTRUCTIONS Nr. 05000376.
6. CHANGING THE GAS USED :
 For any change in the type of gas used, please contact your SBM
installer.

TO BE DISPLAYED
NEXT TO THE CONTROL UNIT

Manufacturer :
SBM
3 cottages de la Norge 21490 CLENAY - FRANCE 1312
Agent :
Installer's stamp :
GAS INFRARED HEATERS
XD – XD D HEATERS
USER GUIDE
Nr 05000375/5
( TO BE DISPLAYED NEXT TO THE CONTROL UNIT )
M A N U A L O P E R A T I O N
START-UP :
 Open the main gas valve.
 Switch the power on.
 Start the heater ignition cycle.
 If the flame is not lit after 45 seconds, start a second ignition cycle.
 If the flame is still not lit or goes out, close the main gas valve, switch
the power off and call your SBM installer.
SHUT OFF :
 Close the main gas valve.
 Switch the power off.
MAINTENANCE :
 To be performed once a year by your SBM installer, according to the
SBM INSTALLER INSTRUCTIONS Nr. 05000376.


Manufacturer :
SBM
3 cottages de la Norge 21490 CLENAY - FRANCE 1312
Agent :
Installer's stamp :
GAS INFRARED HEATERS
XD – XD D HEATERS
USER GUIDE
Nr 05000375/5
( TO BE DISPLAYED NEXT TO THE CONTROL UNIT )
A U T O M A T I C C O N T R O L
VisioLon Ind-T module
START-UP :
 Open the main gas valve.
 Switch the power on.
 Check the settings (temperature, time).
 Change module programming if necessary.
 The module automatically controls the ignition and the extinction of the
heaters.
SHUT OFF :
 Close the main gas valve.
 Switch the power off.
MAINTENANCE :
 To be performed once a year by your SBM installer, according to the
SBM INSTALLER INSTRUCTIONS Nr. 05000376.

